Hitachi / Hikoki ECS-3351B Engine Chain Saw Spare Parts

Home Details Reviews Delivery

An exploded diagram and spare parts listing for the Hitachi / Hikoki ECS-3351B Engine Chain Saw

	Ex VAT	Inc VAT
1 - SPARK PLUG CAP ASS'Y HIT-6687479.A2 6687479	-
2 - SPARK PLUG ASS'Y CJ8 HIT-6699324.A10 6699324	-
3 - CYLINDER SET HIT-6685457.A11 6685457	£63.42	£76.10
4 - CYLINDER GASKET HIT-6685724.A11 6685724	-
5 - PISTON SET HIT-6685879.A5 6685879	£39.02	£46.82
6 - CIRCLIP HIT-6685078.A22 6685078	-
7 - PISTON RING (XR1-1856) HIT-6685331.A22 6685331	£12.57	£15.08
8 - PISTON PIN HIT-6686008.A25 6686008	£3.64	£4.37
9 - HEX. HOLE BOLT M5X16/S HIT-6684903.A48 6684903	-
10 - CRANK SHAFT COMP HIT-6697636.A11 6697636	-
11 - CORD 1 HIT-6687837.A6 6687837	-
12 - IGNITION COIL COMP. HIT-6687700.A5 6687700	£40.13	£48.16
13 - TAB HIT-6688060.A6 6688060	-
14 - HIGH TENSION SCREW 4X18WS HIT-6695407.A28 6695407	-
15 - WOODRUFF KEY 3X13X4.5 HIT-6684899.A42 6684899	-
16 - CORD INSULATOR TUBE HIT-6692900.A8 6692900	-
20A - CRANK CASE ASS'Y SINCE C110351 HIT-6686523.A7 6686523	-
21 - OIL SEAL TB 12227 HIT-6684607.A179 6684607	£4.07	£4.88
22 - NEEDLE ROLLER 2.5X9.8 HIT-6685095.A17 6685095	-
23 - BALL BEARING 6201 A2C3 HIT-6685096.A1 6685096	-
24B - CRANK CASE GASKET SINCE C110351 HIT-6686701.A6 6686701	-
25 - HEX.HOLE BOLT M5X20/S HIT-6684668.A37 6684668	-
27 - D4E RETAINING RING HIT-6685101.A128 6685101	-
28 - STARTER PAWL SPRING HIT-6685105.A3 6685105	£1.67	£2.00
29A - STARTER PAWL HIT-6685334.A11 6685334	£2.84	£3.41
30 - BOLT WASHER M7 HIT-6685103.A4 6685103	-
31 - FLYWHEEL NUT HIT-6685104.A22 6685104	-
*32 - SHIM 0.1 HIT-6686474.A15 6686474	-
*32 - SHIM S T0.2 HIT-6685098.A31 6685098	-
*32 - SHIM S T0.3 HIT-6685099.A3 6685099	-
*32 - SHIM 0.4 HIT-6686475.A2 6686475	-
33 - S.WASHER 7 HIT-6695222.A4 6695222	-
40 - ENGINE CASE ASSY 1 HIT-6691360.A1 6691360	-
41 - AIR VENT VALVE (B) HIT-6685173.A26 6685173	-
42 - AIR VENT VALVE SET HIT-6697231.A2 6697231	£6.80	£8.16
43 - HEX.HOLE BOLT 5X20/PS HIT-6684634.A28 6684634	£1.67	£2.00
44 - EARTH CORD COMP. HIT-6688446.A2 6688446	-
45A - STOP SWITCH ASS'Y HIT-6601374.A8 6601374	£16.45	£19.74
46 - SWITCH NAME PLATE HIT-6687949.A2 6687949	£1.67	£2.00
47 - GROMMET A HIT-6686329.A1 6686329	£2.98	£3.57
50 - AIRCLEANER COVER A SET 1 HIT-6686299.A0 6686299	-
51 - CLEANER COVER BOLT HIT-6689735.A13 6689735	-
52 - AIRCLEANER ELEMENT COMP. HIT-6690064.A5 6690064	£6.47	£7.76
53 - CARBURETOR INSULATOR SET 1 HIT-6689934.A5 6689934	-
53A - INSULATOR SET SINCE C110351 HIT-6689935.A5 6689935	-
54 - INLET MANIFOLD GASKET TILL C110350 HIT-6689870.A5 6689870	-
54A - INSULATOR GASKET SINCE C110351 HIT-6689871.A5 6689871	-
55 - CARBURETOR INSULATOR RUBBER HIT-6690001.A11 6690001	-
56 - REED VALVE HOLDER TILL C110350 HIT-6689805.A5 6689805	-
56A - VALVE HOLDER SINCE C110351 HIT-6689806.A5 6689806	-
57 - REED VALVE TILL C110350 HIT-6689802.A4 6689802	-
57A - REED VALVE SINCE C110351 HIT-6689803.A5 6689803	-
58 - BINDING HEAD SCREW 3X12 HIT-6694964.A5 6694964	-
59 - CARBURETOR GASKET HIT-6698108.A6 6698108	-
60 - CARBURETOR SET 1 HIT-6690664.A1 6690664	-
61 - SCREW 5X45S HIT-6695350.A1 6695350	-
62 - CHOKE SHIM 0.8 HIT-6692596.A1 6692596	-
63 - SMALL WASHER 5 HIT-6684864.A149 6684864	-
64 - CHOKE VALVE HIT-6692410.A6 6692410	-
65 - TAPPING SCREW D4.5X14 HIT-6685152.A41 6685152	-
66 - AIRCLEANER COVER B HIT-6687344.A10 6687344	-
67 - HEX.HOLE BOLT M5X20/S HIT-6684668.A36 6684668	-
68 - SMALL WASHER 5 HIT-6684864.A148 6684864	-
69 - IDLE SPONGE SINCE Z116001 HIT-6685224.A16 6685224	-
71 - AIRCLEANER SPONGE HIT-6690355.A13 6690355	£1.67	£2.00
72 - SEAL COVER HIT-6687182.A5 6687182	-
81 - HEX. HOLE BOLT 5X40 HIT-6695054.A18 6695054	£1.67	£2.00
82 - WASHER 5 HIT-6684661.A53 6684661	£1.67	£2.00
83 - MUFFLER SET 1 HIT-6692445.A1 6692445	-
83A - MUFFLER SET SINCE C158851 HIT-6692446.A0 6692446	-
84 - MUFFLER BODY B COMP. HIT-6692627.A4 6692627	-
85A - MUFFLER FITTING METAL SINCE C158851 HIT-6692677.A5 6692677	-
86 - SPARK ARRESTOR HIT-6692691.A2 6692691	-
87 - MUFFLER BODY A COMP. HIT-6692607.A5 6692607	-
88 - MUFFLER GASKET HIT-6692734.A1 6692734	-
89 - MUFFLER COUPLING GASKET HIT-6692833.A5 6692833	-
101 - OIL PIPE B HIT-6691121.A1 6691121	-
102 - CLIP 7 HIT-6692312.A22 6692312	-
103 - WASHER 5 HIT-6684661.A54 6684661	£1.67	£2.00
104 - OIL FILTER HIT-6690919.A12 6690919	-
105 - OIL FILTER BODY ASS'Y HIT-6685249.A23 6685249	£1.67	£2.00
106 - THROTTLE WIRE COMP. 1 HIT-6693873.A4 6693873	-
107 - WIRE GROMMET HIT-6694836.A5 6694836	-
110 - RUBBER PIPE HIT-6692292.A1 6692292	£12.50	£15.00
111 - PUMP FILTER BODY HIT-6685199.A4 6685199	£6.38	£7.66
114 - O-RING P-18 FKM HIT-6697780.A13 6697780	-
115 - ADJUSTER CAP HIT-6687957.A4 6687957	-
116 - GROMMET HIT-6692590.A6 6692590	£1.67	£2.00
117 - CHOKE BUTTON COMP. HIT-6692513.A7 6692513	-
118 - GROMMET HIT-6687976.A4 6687976	-
119 - O RING HIT-6697898.A5 6697898	-
120 - OIL TANK CAP ASS'Y HIT-6692159.A11 6692159	£8.38	£10.06
121 - FUEL TANK CAP ASS'Y HIT-6692118.A0 6692118	£8.45	£10.14
122 - LOCK NUT M6 HIT-6684872.A82 6684872	-
131 - RECOIL STARTER ASS'Y HIT-6692906.A3 6692906	-
132 - TAPPING SCREW D5X14 HIT-6685275.A48 6685275	-
133 - BRAKE SHAFT WASHER HIT-6689681.A45 6689681	£1.67	£2.00
134 - STARTER PULLEY HIT-6693060.A5 6693060	£5.17	£6.20
135 - STARTER ROPE 3 X 890 HIT-6693159.A5 6693159	-
136 - RECOIL SPRING CASE ASS'Y HIT-6693093.A1 6693093	£9.27	£11.12
137 - STARTER HANDLE HIT-6693228.A3 6693228	-
138 - FANCASE COMP. BLK HIT-6686947.A6 6686947	-
139 - TAPPING SCREW D4.5X20 HIT-6685191.A23 6685191	-
151 - INLET SCREEN HIT-6684700.A76 6684700	-
152 - PUMP BODY HIT-6691416.A18 6691416	£16.36	£19.63
153 - SCREW HIT-6685210.A68 6685210	-
154 - PUMP GASKET HIT-6685212.A50 6685212	£3.29	£3.95
155 - PUMP DIAPHRAGM HIT-6685213.A6 6685213	£8.44	£10.13
158 - CONTROL LEVER HIT-6685217.A62 6685217	-
159 - HINGE PIN SET SCREW HIT-6685218.A2 6685218	-
160 - VALVE SPRING HIT-6690872.A2 6690872	-
161 - HINGE PIN HIT-6685219.A86 6685219	-
162 - DIAPHRAGM COVER-METERING HIT-6685222.A163 6685222	£5.70	£6.84
163 - METERING DIAPHRAGM COMP. HIT-6690827.A77 6690827	£14.02	£16.83
164 - DIAPHRAGM PACKING-METERING HIT-6685220.A16 6685220	£2.81	£3.37
165 - NEEDLE VALVE HIT-6685215.A80 6685215	£6.79	£8.15
166 - IDLE ADJUST SPRING HIT-6685297.A30 6685297	-
167 - IDLE ADJUST SCREW HIT-6685298.A0 6685298	£1.67	£2.00
170 - SET SCREW HIT-6685223.A2 6685223	-
191 - SCREW 5X14/WS HIT-6695416.A9 6695416	-
192 - OIL PUMP COVER HIT-6686763.A6 6686763	-
193 - OIL PIPE A HIT-6691223.A5 6691223	-
194 - SCREW GEAR HIT-6686645.A10 6686645	£15.03	£18.04
195 - AIR VENT SPONGE HIT-6691400.A2 6691400	-
196 - OIL PUMP ASS'Y HIT-6687324.A2 6687324	£17.82	£21.39
197 - OIL ADJUST GROMMET HIT-6690956.A1 6690956	-
198 - OIL PUMP ADJUSTER HIT-6691070.A13 6691070	-
199 - O RING HIT-6697917.A17 6697917	-
200 - OIL PUMP CASE SET 1 HIT-6686681.A12 6686681	-
201 - O RING HIT-6697917.A16 6697917	-
202 - TAPPING SCREW D5X14 HIT-6685275.A47 6685275	-
203 - FUEL PIPE HIT-6685154.A31 6685154	-
204 - CHAIN CATCHER HIT-6685155.A2 6685155	-
205 - TAPPING SCREW D4.5X14 HIT-6685152.A40 6685152	-
221 - NUT TILL F138050 HIT-6685166.A15 6685166	£3.62	£4.35
221A - CHAIN BAR CLAMP NUT SINCE F138051 HIT-6687105.A32 6687105	£1.67	£2.00
222 - CLUTCH COMP. HIT-6685142.A0 6685142	£16.34	£19.61
223 - NEEDLE BEARING HIT-6685143.A21 6685143	£4.72	£5.66
224 - CLUTCH HOUSING COMP. HIT-6685144.A0 6685144	£11.93	£14.32
225 - CLUTCH WASHER HIT-6685145.A15 6685145	-
226 - TAPPING SCREW D4X10 HIT-6685161.A18 6685161	£1.67	£2.00
227 - PLATE TILL C110350 HIT-6690790.A1 6690790	-
227A - GUIDE PLATE A SINCE C110351 HIT-6697599.A5 6697599	-
228 - CRANK SHAFT COLLAR HIT-6685146.A1 6685146	£1.67	£2.00
229 - TAPPING SCREW D4X10 SINCE C110351 HIT-6685161.A19 6685161	£1.67	£2.00
230A - SIDE CASE ASS'Y SINCE C110351 HIT-6697628.A0 6697628	-
231 - GUIDE PLATE B SINCE C110351 HIT-6690756.A6 6690756	£2.81	£3.37
232 - SCREW 2.6X5 SINCE C110351 HIT-6695269.A13 6695269	-
233B - CHAIN PULLER INCLUD.234 SINCE C110351 HIT-6698986.A10 6698986	£18.88	£22.66
234 - GEAR (A) SINCE C110351 HIT-6685168.A6 6685168	£3.45	£4.14
235 - BRAKE HANDLE HIT-6689674.A3 6689674	-
236 - BRAKE LINK COVER 1 HIT-6689712.A4 6689712	£4.65	£5.58
237 - BRAKE SPRING HIT-6697694.A1 6697694	-
238 - BRAKE SUPPORT PLATE COMP. HIT-6685119.A15 6685119	-
239 - NEEDLE ROLLER 3X9.8 HIT-6685141.A23 6685141	-
240 - BRAKE LINK HIT-6685388.A27 6685388	£12.57	£15.08
241 - BRAKE BAND HIT-6689728.A3 6689728	-
242 - CLEANER FIXING COLLAR HIT-6690805.A25 6690805	£2.69	£3.23
243 - COLLAR HIT-6685120.A1 6685120	-
244 - SIDE COVER COMP HIT-6697614.A8 6697614	-
245 - BRAKE LEVER SPRING HIT-6685122.A0 6685122	-
246 - TAPPING SCREW D4X15 HIT-6685148.A28 6685148	-
247 - TENSION ADJUSTMENT BOLT ASS'Y TILL C110350 HIT-6687071.A1 6687071	-
261 - SCREW 5X25/S HIT-6695343.A3 6695343	-
262 - U-NUT 5 HIT-6695157.A7 6695157	£1.67	£2.00
263 - SCREW 5X40/S HIT-6695348.A4 6695348	-
264 - SMALL WASHER 5 HIT-6684864.A146 6684864	-
265 - DAMPER COLLAR A HIT-6688480.A2 6688480	-
266 - DAMPER A HIT-6688117.A2 6688117	-
267 - U-NUT 5 HIT-6695157.A6 6695157	£1.67	£2.00
268 - REAR HANDLE B COMP. HIT-6685646.A2 6685646	-
269 - PUSH PIN CAP HIT-6692680.A12 6692680	-
270 - STOPPER SPRING HIT-6686447.A17 6686447	£1.67	£2.00
271 - PUSH PIN HIT-6686433.A2 6686433	-
272 - SAFETY LEVER HIT-6688361.A4 6688361	-
273 - THROTTLE LEVER HIT-6686390.A5 6686390	-
274 - THROTTLE LEVER SPRING HIT-6697845.A3 6697845	-
275 - NUT M4 HIT-6685069.A9 6685069	-
276 - REAR HANDLE A COMP. HIT-6685616.A0 6685616	-
277 - SCREW 4X22/WS HIT-6695410.A9 6695410	-
278 - FRONT HANDLE COMP. HIT-6688077.A1 6688077	£15.73	£18.88
279 - DAMPER B HIT-6688412.A9 6688412	£1.67	£2.00
280 - DAMPER COLLAR B HIT-6688485.A7 6688485	£1.67	£2.00
281 - TAPPING SCREW 5X35 HIT-6695107.A27 6695107	£1.67	£2.00
282 - TAPPING SCREW 5X35 HIT-6695107.A28 6695107	£1.67	£2.00
501 - COMBI BOX SPANNER 10/19MM TILL F138050 HIT-6685257.A13 6685257	-
501A - COMBI. BOX SPANNER 13X19 MINUS SINCE F138051 HIT-6693809.A20 6693809	-
502A - CHAIN COVER 12 HIT-6685401.A10 6685401	-

Attribute Name	Value
Brand	Hikoki
