Hitachi / Hikoki ECS-3350D Engine Chain Saw Spare Parts

An exploded diagram and spare parts listing for the Hitachi / Hikoki ECS-3350D Engine Chain Saw

	Ex VAT	Inc VAT
1 - SPARK PLUG CAP ASS'Y HIT-6687468.A37 6687468	£3.64	£4.37
2 - SPARK PLUG ASS'Y CJ8 HIT-6699324.A5 6699324	-
3 - CYLINDER SET HIT-6685457.A6 6685457	£63.42	£76.10
4 - CYLINDER GASKET HIT-6685724.A6 6685724	-
5 - PISTON SET HIT-6685879.A1 6685879	£39.02	£46.82
6 - CIRCLIP HIT-6685078.A35 6685078	-
7 - PISTON RING (XR1-1856) HIT-6685331.A26 6685331	£12.57	£15.08
8 - PISTON PIN HIT-6686008.A19 6686008	£3.64	£4.37
9 - HEX. HOLE BOLT M5X16/S HIT-6684903.A83 6684903	-
10 - CRANK SHAFT COMP HIT-6697636.A5 6697636	-
11 - CORD 1 HIT-6687837.A9 6687837	-
12 - IGNITION COIL COMP. HIT-6687700.A2 6687700	£40.13	£48.16
13 - TAB HIT-6688060.A9 6688060	-
14 - HIGH TENSION SCREW 4X18WS HIT-6695407.A9 6695407	-
15 - WOODRUFF KEY 3X13X4.5 TILL H008233 HIT-6684899.A4 6684899	-
16 - CORD INSULATOR TUBE TILL G100140 HIT-6692900.A2 6692900	-
20A - CRANK CASE ASS'Y SINCE C143201 HIT-6686523.A11 6686523	-
21 - OIL SEAL TB 12227 HIT-6684607.A133 6684607	£4.07	£4.88
22 - NEEDLE ROLLER 2.5X9.8 HIT-6685095.A11 6685095	-
23 - BALL BEARING 6201 A2C3 HIT-6685096.A10 6685096	-
24A - CRANK CASE GASKET SINCE C143201 HIT-6686701.A9 6686701	-
25 - HEX.HOLE BOLT M5X20/S HIT-6684668.A55 6684668	-
26 - MAGNETO ROTOR ASS'Y TILL H008233 HIT-6687394.A3 6687394	-
26A - MAGNETO ROTOR ASS'Y SINCE H008234 HIT-6697953.A2 6697953	-
27 - D4E RETAINING RING HIT-6685101.A77 6685101	-
28 - STARTER PAWL SPRING HIT-6685105.A10 6685105	£1.67	£2.00
29A - STARTER PAWL HIT-6685334.A8 6685334	£2.84	£3.41
30 - BOLT WASHER M7 HIT-6685103.A14 6685103	-
31 - FLYWHEEL NUT HIT-6685104.A15 6685104	-
*32 - SHIM 0.1 HIT-6686474.A12 6686474	-
*32 - SHIM S T0.2 HIT-6685098.A22 6685098	-
*32 - SHIM S T0.3 HIT-6685099.A12 6685099	-
*32 - SHIM 0.4 HIT-6686475.A7 6686475	-
33 - S.WASHER 7 TILL G003350 HIT-6695222.A1 6695222	-
40 - ENGINE CASE 1 HIT-6691361.A1 6691361	-
41 - AIR VENT VALVE (B) HIT-6685173.A35 6685173	-
42 - AIR VENT VALVE SET HIT-6697231.A3 6697231	£6.80	£8.16
43 - HEX.HOLE BOLT 5X20/PS HIT-6684634.A11 6684634	£1.67	£2.00
44 - EARTH CORD COMP. HIT-6688446.A3 6688446	-
45A - STOP SWITCH ASS'Y HIT-6601374.A1 6601374	£16.45	£19.74
46 - SWITCH NAME PLATE HIT-6687949.A9 6687949	£1.67	£2.00
50 - AIRCLEANER COVER A SET 1 HIT-6686299.A5 6686299	-
51 - CLEANER COVER BOLT HIT-6689735.A9 6689735	-
52 - AIRCLEANER ELEMENT COMP. HIT-6690064.A9 6690064	£6.47	£7.76
53 - CARBURETOR INSULATOR SET 1 HIT-6689934.A2 6689934	-
53A - INSULATOR SET SINCE C143201 HIT-6689935.A10 6689935	-
54 - INLET MANIFOLD GASKET TILL C143200 HIT-6689870.A3 6689870	-
54A - INSULATOR GASKET SINCE C143201 HIT-6689871.A8 6689871	-
55 - CARBURETOR INSULATOR RUBBER HIT-6690001.A7 6690001	-
56 - REED VALVE HOLDER TILL C143200 HIT-6689805.A2 6689805	-
56A - VALVE HOLDER SINCE C143201 HIT-6689806.A10 6689806	-
57 - REED VALVE TILL C143200 HIT-6689802.A2 6689802	-
57A - REED VALVE SINCE C143201 HIT-6689803.A10 6689803	-
58 - BINDING HEAD SCREW 3X12 HIT-6694964.A10 6694964	-
59 - CARBURETOR GASKET HIT-6698108.A9 6698108	-
60 - CARBURETOR SET 1 HIT-6690666.A2 6690666	-
61 - SCREW 5X45S HIT-6695350.A3 6695350	-
62 - CHOKE SHIM 1.0 HIT-6692597.A11 6692597	-
63 - SMALL WASHER 5 HIT-6684864.A94 6684864	-
64 - CHOKE VALVE HIT-6692410.A9 6692410	-
65 - TAPPING SCREW D4.5X14 HIT-6685152.A34 6685152	-
66 - AIRCLEANER COVER B HIT-6687344.A6 6687344	-
67 - HEX.HOLE BOLT M5X20/S HIT-6684668.A52 6684668	-
68 - SMALL WASHER 5 HIT-6684864.A97 6684864	-
69 - IDLE SPONGE HIT-6685224.A9 6685224	-
70 - SPONGE H/L 10L HIT-6687978.A10 6687978	-
71 - AIRCLEANER SPONGE TILL F148450 HIT-6690355.A10 6690355	£1.67	£2.00
72 - SEAL COVER TILL F129338 HIT-6687182.A0 6687182	-
81 - MUFFLER SET HIT-6692443.A3 6692443	-
82 - MUFFLER GASKET HIT-6692734.A4 6692734	-
83 - MUFFLER BODY B COMP. HIT-6692625.A2 6692625	-
84 - MUFFLER FITTING METAL HIT-6692676.A0 6692676	-
86 - MUFFLER BODY A COMP. HIT-6692606.A0 6692606	-
87 - HEX.HOLE BOLT M5X35 HIT-6684934.A10 6684934	-
88 - WASHER 5 HIT-6684661.A28 6684661	£1.67	£2.00
101 - OIL PIPE B HIT-6691121.A6 6691121	-
102 - CLIP 7 HIT-6692312.A30 6692312	-
103 - WASHER 5 HIT-6684661.A29 6684661	£1.67	£2.00
104 - OIL FILTER HIT-6690919.A16 6690919	-
105 - OIL FILTER BODY ASS'Y HIT-6685249.A17 6685249	£1.67	£2.00
106 - THROTTLE WIRE COMP. 1 HIT-6693873.A3 6693873	-
107 - WIRE GROMMET HIT-6694836.A3 6694836	-
108 - PRIMING PUMP COMP. HIT-6685139.A69 6685139	£10.67	£12.80
109 - FUEL PIPE 2.5X4X42 HIT-6685138.A4 6685138	£1.67	£2.00
110 - RUBBER PIPE HIT-6692292.A4 6692292	£12.50	£15.00
111 - PUMP FILTER BODY HIT-6685199.A12 6685199	£6.38	£7.66
112 - FUEL PIPE 2.5X4X150 HIT-6692351.A9 6692351	-
113 - RETURN GROMMET HIT-6697846.A157 6697846	£1.68	£2.01
114 - O-RING P-18 FKM HIT-6697780.A12 6697780	-
115 - ADJUSTER CAP HIT-6687956.A5 6687956	-
116 - GROMMET HIT-6692590.A0 6692590	£1.67	£2.00
117 - CHOKE BUTTON COMP. HIT-6692513.A10 6692513	-
118 - GROMMET HIT-6687976.A0 6687976	-
119 - O RING TILL H106060 HIT-6697898.A6 6697898	-
119A - O-RING P21 SINCE H106061 HIT-6699285.A7 6699285	-
120 - OIL TANK CAP ASS'Y HIT-6692159.A9 6692159	£8.38	£10.06
121A - TANK CAP ASS'Y HIT-6692121.A3 6692121	-
122 - LOCK NUT M6 HIT-6684872.A84 6684872	-
131 - RECOIL STARTER ASS'Y HIT-6692906.A5 6692906	-
132 - TAPPING SCREW D5X14 HIT-6685275.A46 6685275	-
133 - BRAKE SHAFT WASHER HIT-6689681.A47 6689681	£1.67	£2.00
134 - STARTER PULLEY HIT-6693060.A3 6693060	£5.17	£6.20
135 - STARTER ROPE 3 X 890 HIT-6693159.A4 6693159	-
136 - RECOIL SPRING CASE ASS'Y HIT-6693093.A2 6693093	£9.27	£11.12
137 - STARTER HANDLE HIT-6693228.A1 6693228	-
138 - FANCASE COMP. BLK HIT-6686947.A7 6686947	-
139 - TAPPING SCREW D4.5X20 HIT-6685191.A24 6685191	-
140 - WASHER 4 HIT-6684632.A4 6684632	-
151 - INLET SCREEN HIT-6684700.A74 6684700	-
152 - PUMP BODY HIT-6685211.A0 6685211	-
153 - SCREW HIT-6685210.A69 6685210	-
154 - PUMP GASKET HIT-6685212.A51 6685212	£3.29	£3.95
155 - PUMP DIAPHRAGM HIT-6685213.A5 6685213	£8.44	£10.13
156 - LOW ADJUST SCREW HIT-6690714.A0 6690714	-
157 - HIGH/LOW ADJUST SPRING HIT-6692048.A15 6692048	-
158 - CONTROL LEVER HIT-6685217.A61 6685217	-
159 - HINGE PIN SET SCREW HIT-6685218.A3 6685218	-
160 - VALVE SPRING HIT-6690873.A19 6690873	-
161 - HINGE PIN HIT-6685219.A85 6685219	-
162 - DIAPHRAGM COVER-METERING HIT-6685222.A162 6685222	£5.70	£6.84
163 - METERING DIAPHRAGM COMP. HIT-6690827.A81 6690827	£14.02	£16.83
164 - DIAPHRAGM PACKING-METERING HIT-6685220.A17 6685220	£2.81	£3.37
165 - NEEDLE VALVE HIT-6685215.A81 6685215	£6.79	£8.15
166 - IDLE ADJUST SPRING HIT-6685297.A27 6685297	-
167 - IDLE ADJUST SCREW HIT-6685298.A3 6685298	£1.67	£2.00
168 - HIGH ADJUST SCREW HIT-6690691.A6 6690691	-
169 - HIGH ADJUSTMENT SPRING HIT-6690897.A4 6690897	-
170 - SET SCREW HIT-6685223.A3 6685223	-
191 - SCREW 5X14/WS HIT-6695416.A10 6695416	-
192 - OIL PUMP COVER HIT-6686763.A4 6686763	-
193 - OIL PIPE A HIT-6691223.A4 6691223	-
194 - SCREW GEAR HIT-6686645.A8 6686645	£15.03	£18.04
195 - AIR VENT SPONGE HIT-6691400.A1 6691400	-
196 - OIL PUMP ASS'Y HIT-6687324.A0 6687324	£17.82	£21.39
197 - OIL ADJUST GROMMET HIT-6690956.A2 6690956	-
198 - OIL PUMP ADJUSTER HIT-6691070.A11 6691070	-
199 - O RING HIT-6697917.A19 6697917	-
200 - OIL PUMP CASE SET 1 HIT-6686681.A14 6686681	-
201 - O RING HIT-6697917.A18 6697917	-
202 - TAPPING SCREW D5X14 HIT-6685275.A45 6685275	-
203 - FUEL PIPE TILL G100140 HIT-6685154.A29 6685154	-
204 - CHAIN CATCHER HIT-6685155.A3 6685155	-
205 - TAPPING SCREW D4.5X14 HIT-6685152.A42 6685152	-
*221 - NUT TILL F147250 HIT-6685166.A13 6685166	£3.62	£4.35
*221 - CHAIN BAR CLAMP NUT SINCE F147251 HIT-6687105.A35 6687105	£1.67	£2.00
222 - CLUTCH COMP. HIT-6685142.A2 6685142	£16.34	£19.61
223 - NEEDLE BEARING HIT-6685143.A19 6685143	£4.72	£5.66
224 - CLUTCH HOUSING COMP.3/8 HIT-6689013.A3 6689013	£14.08	£16.89
225 - CLUTCH WASHER HIT-6685145.A16 6685145	-
226 - TAPPING SCREW D4X10 HIT-6685161.A23 6685161	£1.67	£2.00
227 - PLATE TILL C143200 HIT-6690790.A0 6690790	-
227A - GUIDE PLATE A SINCE C143201 HIT-6697599.A4 6697599	-
228 - CRANK SHAFT COLLAR HIT-6685146.A0 6685146	£1.67	£2.00
229 - TAPPING SCREW D4X10 SINCE C143201 HIT-6685161.A22 6685161	£1.67	£2.00
232 - SCREW 2.6X5 SINCE C143201 HIT-6695269.A11 6695269	-
234B - CHAIN PULLER INCLUD.235 SINCE C143201 HIT-6698986.A8 6698986	£18.88	£22.66
235 - GEAR (A) SINCE C143201 HIT-6685168.A7 6685168	£3.45	£4.14
237 - GUIDE PLATE B SINCE C143201 HIT-6690756.A7 6690756	£2.81	£3.37
244 - SIDE CASE COMP. HIT-6698015.A1 6698015	£13.43	£16.12
247 - TENSION ADJUSTMENT BOLT ASS'Y TILL C143200 HIT-6687072.A1 6687072	£6.28	£7.53
261 - SCREW 5X25 PS HIT-6695394.A7 6695394	-
262 - U-NUT 5 HIT-6695157.A9 6695157	£1.67	£2.00
263 - SCREW 5X40/S HIT-6695348.A5 6695348	-
264 - SMALL WASHER 5 HIT-6684864.A147 6684864	-
265 - DAMPER COLLAR A HIT-6688480.A1 6688480	-
266 - DAMPER A HIT-6688117.A1 6688117	-
267 - U-NUT 5 HIT-6695157.A8 6695157	£1.67	£2.00
268 - REAR HANDLE B COMP. HIT-6685646.A1 6685646	-
269 - PUSH PIN CAP HIT-6692680.A11 6692680	-
270 - STOPPER SPRING HIT-6686447.A16 6686447	£1.67	£2.00
271 - PUSH PIN HIT-6686433.A3 6686433	-
272 - SAFETY LEVER HIT-6688361.A5 6688361	-
273 - THROTTLE LEVER HIT-6686390.A4 6686390	-
274 - THROTTLE LEVER SPRING HIT-6697845.A2 6697845	-
275 - NUT M4 HIT-6685069.A8 6685069	-
276 - REAR HANDLE A COMP. HIT-6685616.A1 6685616	-
277 - SCREW 4X22/WS HIT-6695410.A10 6695410	-
278 - FRONT HANDLE COMP. HIT-6688077.A2 6688077	£15.73	£18.88
279 - DAMPER B HIT-6688412.A8 6688412	£1.67	£2.00
280 - DAMPER COLLAR B HIT-6688485.A8 6688485	£1.67	£2.00
281 - TAPPING SCREW 5X35 HIT-6695107.A25 6695107	£1.67	£2.00
282 - TAPPING SCREW 5X35 HIT-6695107.A26 6695107	£1.67	£2.00
283 - FRONT HAND GUARD HIT-6693462.A1 6693462	-
501 - COMBI BOX SPANNER 10/19MM TILL F147250 HIT-6685257.A12 6685257	-
501A - COMBI. BOX SPANNER 13X19 MINUS SINCE F147251 HIT-6693809.A19 6693809	-
502 - CHAIN COVER 14 HIT-6685256.A4 6685256	-
503A - CHAIN COVER 16 HIT-6685440.A9 6685440	£13.86	£16.63
511 - BAR 14 INCH 3/8 SPROCKET HIT-6685160.A2 6685160	£21.92	£26.30
512 - CHAIN BAR 16 HIT-6686854.A2 6686854	-
514 - SAW CHAIN (3/8X14) 91PX-52XJ HIT-781124.A15 781124	£13.99	£16.79
515 - SAW CHAIN (3/8X16) 91PX-57XJ HIT-781126.A7 781126	£19.00	£22.80
601 - NAME PLATE ECS-3350D HIT-6697956.A0 6697956	-
602 - STARTER MARK ECS-3350D HIT-6697957.A0 6697957	-

Attribute Name	Value
Brand	Hikoki

Reviews Write your own review!

There are currently no reviews of this product.

Fill in the form below to add your review for Hitachi / Hikoki ECS-3350D Engine Chain Saw Spare Parts

Your Review
Title Required!
Rating Required!
Your Review Required!
Your Details
Your Name Required!
Your Location Required!
Email Address Required!Invalid email!

United Kingdom (Including N. Ireland)

On orders up to £40.00	Add £4.00 inc VAT (Royal Mail post)
On orders £40.00 to £130.00	Add £7.00 inc VAT (Courier)
On orders over £130.00	FREE (Courier)

Shopping Basket (0) £0.00

Hitachi / Hikoki ECS-3350D Engine Chain Saw Spare Parts

Your Review

Your Details

Carry On Shopping

Try these categories

Recently Viewed

Your Order

About Us

Other Links

Search

Customization

Shopping Basket (0) £0.00

Information

Hitachi / Hikoki ECS-3350D Engine Chain Saw Spare Parts

Notify me

Your Review

Your Details

Carry On Shopping

Try these categories

Recently Viewed

Your Order

About Us

Other Links

Search
