Hitachi / Hikoki ECS-3301D Engine Chain Saw (top Handle) Spare Parts

An exploded diagram and spare parts listing for the Hitachi / Hikoki ECS-3301D Engine Chain Saw (top Handle)

	Ex VAT	Inc VAT
1 - SPARK PLUG CAP ASS'Y HIT-6687468.A38 6687468	£3.64	£4.37
2 - SPARK PLUG ASS'Y BMR6A FOR EUROPE HIT-6699315.A8 6699315	-
3 - CYLINDER SET HIT-6685457.A5 6685457	£63.42	£76.10
4 - CYLINDER GASKET HIT-6685724.A7 6685724	-
5 - PISTON SET HIT-6685879.A0 6685879	£39.02	£46.82
6 - CIRCLIP HIT-6685078.A36 6685078	-
7 - PISTON RING (XR1-1856) HIT-6685331.A27 6685331	£12.57	£15.08
8 - PISTON PIN HIT-6686008.A20 6686008	£3.64	£4.37
9 - HEX. HOLE BOLT M5X16/S HIT-6684903.A82 6684903	-
10 - CRANK SHAFT COMP HIT-6697636.A6 6697636	-
11 - CORD 1 HIT-6687837.A10 6687837	-
12 - IGNITION COIL COMP. HIT-6687700.A1 6687700	£40.13	£48.16
13 - TAB HIT-6688060.A8 6688060	-
14 - HIGH TENSION SCREW 4X18WS HIT-6695407.A10 6695407	-
15 - WOODRUFF KEY 3X13X4.5 TILL H046690 HIT-6684899.A5 6684899	-
16 - CORD INSULATOR TUBE TILL H046690 HIT-6692900.A1 6692900	-
17 - SPARK PLUG ASS'Y CJ8 FOR SAU HIT-6699324.A4 6699324	-
20 - TILL C091000 NO LONGER AVAILABLE HIT-000000.A2435 000000	-
20A - CRANK CASE ASS'Y SINCE C091001 HIT-6686523.A10 6686523	-
21 - OIL SEAL TB 12227 HIT-6684607.A132 6684607	£4.07	£4.88
22 - NEEDLE ROLLER 2.5X9.8 HIT-6685095.A10 6685095	-
23 - BALL BEARING 6201 A2C3 HIT-6685096.A11 6685096	-
24B - CRANK CASE GASKET SINCE C091001 HIT-6686701.A10 6686701	-
25 - HEX.HOLE BOLT M5X20/S HIT-6684668.A54 6684668	-
26 - MAGNETO ROTOR ASS'Y TILL H046690 HIT-6687394.A2 6687394	-
26A - MAGNETO ROTOR ASS'Y SINCE H046691 HIT-6697953.A3 6697953	-
27 - D4E RETAINING RING HIT-6685101.A76 6685101	-
28 - STARTER PAWL SPRING HIT-6685105.A11 6685105	£1.67	£2.00
29A - STARTER PAWL HIT-6685334.A7 6685334	£2.84	£3.41
30 - BOLT WASHER M7 HIT-6685103.A15 6685103	-
31 - FLYWHEEL NUT HIT-6685104.A14 6685104	-
*32 - SHIM 0.1 HIT-6686474.A11 6686474	-
*32 - SHIM S T0.2 HIT-6685098.A21 6685098	-
*32 - SHIM S T0.3 HIT-6685099.A13 6685099	-
*32 - SHIM 0.4 HIT-6686475.A8 6686475	-
40 - ENGINE CASE ASS'Y 1 HIT-6691363.A0 6691363	-
40A - ENGINE CASE ASS'Y 1 HIT-6691365.A0 6691365	-
41 - AIR VENT VALVE (B) HIT-6685173.A36 6685173	-
42 - AIR VENT VALVE SET HIT-6697231.A4 6697231	£6.80	£8.16
43 - HEX.HOLE BOLT 5X20/PS HIT-6684634.A10 6684634	£1.67	£2.00
44 - EARTH CORD 90M HIT-6697602.A2 6697602	-
45A - STOP SWITCH ASS'Y HIT-6601374.A2 6601374	£16.45	£19.74
46 - SWITCH NAME PLATE HIT-6687949.A8 6687949	£1.67	£2.00
47 - GROMMET A TILL U239500 HIT-6686329.A3 6686329	£2.98	£3.57
50 - AIRCLEANER COVER A SET 1 HIT-6686299.A4 6686299	-
51 - CLEANER COVER BOLT HIT-6689735.A10 6689735	-
52 - AIRCLEANER ELEMENT COMP. HIT-6690064.A10 6690064	£6.47	£7.76
53 - CARBURETOR INSULATOR SET 1 HIT-6689934.A1 6689934	-
53A - INSULATOR SET SINCE C091001 HIT-6689935.A11 6689935	-
54 - INLET MANIFOLD GASKET TILL C091000 HIT-6689870.A2 6689870	-
54A - INSULATOR GASKET SINCE C091001 HIT-6689871.A9 6689871	-
55 - CARBURETOR INSULATOR RUBBER HIT-6690001.A6 6690001	-
56 - REED VALVE HOLDER TILL C091000 HIT-6689805.A1 6689805	-
56A - VALVE HOLDER SINCE C091001 HIT-6689806.A11 6689806	-
57 - REED VALVE TILL C091000 HIT-6689802.A1 6689802	-
57A - REED VALVE SINCE C091001 HIT-6689803.A11 6689803	-
58 - BINDING HEAD SCREW 3X12 HIT-6694964.A9 6694964	-
59 - CARBURETOR GASKET HIT-6698108.A10 6698108	-
60 - CARBURETOR SET WT516 TILL U239500 FOR EUROPE HIT-6690665.A1 6690665	£71.77	£86.13
60A - CARBURETOR SET 1 HIT-6690666.A0 6690666	-
60B - CARBURETOR SET 1 HIT-6690667.A6 6690667	£81.68	£98.01
61 - SCREW 5X45S HIT-6695350.A4 6695350	-
62 - CHOKE SHIM 1.0 HIT-6692597.A9 6692597	-
63 - SMALL WASHER 5 HIT-6684864.A93 6684864	-
64 - CHOKE VALVE HIT-6692410.A8 6692410	-
65 - TAPPING SCREW D4.5X14 HIT-6685152.A35 6685152	-
66 - AIRCLEANER COVER B HIT-6687344.A7 6687344	-
67 - HEX.HOLE BOLT M5X20/S HIT-6684668.A53 6684668	-
68 - SMALL WASHER 5 HIT-6684864.A92 6684864	-
69 - IDLE SPONGE SINCE Z116101 HIT-6685224.A11 6685224	-
*70 - SPONGE H/L 10L SINCE Z116101 FOR EUROPE HIT-6687978.A8 6687978	-
*70 - SPONGE H/L 10L TILL B027800 FOR EUROPE HIT-6687978.A9 6687978	-
*71 - AIRCLEANER SPONGE SINCE R032271 FOR EUROPE HIT-6690355.A8 6690355	£1.67	£2.00
*71 - AIRCLEANER SPONGE TILL F138050 FOR EUROPE HIT-6690355.A9 6690355	£1.67	£2.00
72 - SEAL COVER TILL F179300 HIT-6687182.A1 6687182	-
73 - SPONGE H/L 10L FOR SAU HIT-6687978.A7 6687978	-
74 - CARBURETOR SET 1 HIT-6690666.A1 6690666	-
81A - MUFFLER SET SINCE B027801 HIT-6692447.A1 6692447	-
82 - MUFFLER GASKET HIT-6692734.A6 6692734	-
83 - MUFFLER BODY B COMP. TILL B027800 HIT-6692626.A0 6692626	-
83A - MUFFLER BODY B COMP. SINCE B027801 HIT-6692627.A2 6692627	-
84 - MUFFLER FITTING METAL HIT-6692677.A7 6692677	-
85 - MUFFLER COUPLING GASKET HIT-6692833.A0 6692833	-
86 - MUFFLER BODY A COMP. HIT-6692607.A7 6692607	-
87 - HEX. HOLE BOLT 5X40 HIT-6695054.A28 6695054	£1.67	£2.00
88 - WASHER 5 HIT-6684661.A26 6684661	£1.67	£2.00
101 - OIL PIPE B HIT-6691121.A4 6691121	-
102 - CLIP 7 HIT-6692312.A31 6692312	-
103 - WASHER 5 HIT-6684661.A27 6684661	£1.67	£2.00
104 - OIL FILTER HIT-6690919.A18 6690919	-
105 - OIL FILTER BODY ASS'Y HIT-6685249.A15 6685249	£1.67	£2.00
106 - THROTTLE ROD HIT-6690974.A4 6690974	-
107 - THROTTLE GUIDE HIT-6690982.A4 6690982	-
108 - PRIMING PUMP COMP. SINCE U239501 HIT-6685139.A71 6685139	£10.67	£12.80
109 - FUEL PIPE 2.5X4X42 HIT-6685138.A3 6685138	£1.67	£2.00
110 - RUBBER PIPE HIT-6692292.A6 6692292	£12.50	£15.00
111 - PUMP FILTER BODY HIT-6685199.A11 6685199	£6.38	£7.66
112 - FUEL PIPE 2.5X4X150 SINCE U239501 HIT-6692351.A10 6692351	-
113 - RETURN GROMMET SINCE U239501 HIT-6697846.A159 6697846	£2.08	£2.50
114 - O-RING P-18 FKM HIT-6697780.A10 6697780	-
115 - ADJUSTER CAP TILL B027800 FOR EUROPE HIT-6687956.A6 6687956	-
115A - ADJUSTER CAP SINCE B027801 FOR EUROPE HIT-6687957.A0 6687957	-
116 - GROMMET HIT-6692590.A2 6692590	£1.67	£2.00
117 - CHOKE BUTTON COMP. HIT-6692513.A11 6692513	-
118 - GROMMET HIT-6687976.A2 6687976	-
119 - O RING TILL H122700 HIT-6697898.A1 6697898	-
119A - O-RING P21 SINCE H122701 HIT-6699285.A10 6699285	-
120 - OIL TANK CAP ASS'Y HIT-6692159.A7 6692159	£8.38	£10.06
121 - TANK CAP ASS'Y HIT-6692121.A0 6692121	-
122 - ADJUSTER CAP FOR SAU HIT-6687956.A7 6687956	-
131 - RECOIL STARTER ASS'Y HIT-6692906.A7 6692906	-
132 - TAPPING SCREW D5X14 HIT-6685275.A73 6685275	-
133 - BRAKE SHAFT WASHER HIT-6689681.A33 6689681	£1.67	£2.00
134 - STARTER PULLEY HIT-6693060.A1 6693060	£5.17	£6.20
135 - STARTER ROPE 3 X 890 HIT-6693159.A8 6693159	-
136 - RECOIL SPRING CASE ASS'Y HIT-6693093.A5 6693093	£9.27	£11.12
137 - STARTER HANDLE HIT-6693228.A4 6693228	-
138 - FANCASE COMP. BLK HIT-6686947.A2 6686947	-
139 - TAPPING SCREW D4.5X20 HIT-6685191.A30 6685191	-
140 - WASHER 4 HIT-6684632.A7 6684632	-
151 - INLET SCREEN HIT-6684700.A30 6684700	-
152 - PUMP BODY TILL B027800 HIT-6685211.A6 6685211	-
152A - PUMP BODY SINCE B027801 HIT-6691416.A21 6691416	£16.36	£19.63
153 - SCREW HIT-6685210.A42 6685210	-
154 - PUMP GASKET HIT-6685212.A30 6685212	£3.29	£3.95
155 - PUMP DIAPHRAGM HIT-6685213.A24 6685213	£8.44	£10.13
156 - LOW ADJUST SCREW TILL B027800 HIT-6690714.A5 6690714	-
157 - HIGH/LOW ADJUST SPRING TILL B027800 HIT-6692048.A21 6692048	-
158 - CONTROL LEVER HIT-6685217.A41 6685217	-
159 - HINGE PIN SET SCREW HIT-6685218.A27 6685218	-
160 - VALVE SPRING TILL S146000 HIT-6690870.A0 6690870	-
160A - VALVE SPRING TILL V080958 HIT-6690872.A4 6690872	-
160B - VALVE SPRING SINCE V080959 HIT-6690873.A13 6690873	-
161 - HINGE PIN HIT-6685219.A54 6685219	-
162 - DIAPHRAGM COVER-METERING HIT-6685222.A94 6685222	£5.70	£6.84
163 - METERING DIAPHRAGM COMP. HIT-6690827.A60 6690827	£14.02	£16.83
164 - DIAPHRAGM PACKING-METERING HIT-6685220.A84 6685220	£2.81	£3.37
165 - NEEDLE VALVE TILL S146000 HIT-6691943.A5 6691943	-
165A - NEEDLE VALVE TILL S201000 HIT-6685215.A48 6685215	£6.79	£8.15
165B - NEEDLE VALVE TILL T017500 HIT-6691943.A4 6691943	-
165C - NEEDLE VALVE SINCE T017501 HIT-6685215.A49 6685215	£6.79	£8.15
166 - IDLE ADJUST SPRING HIT-6685297.A19 6685297	-
167 - IDLE ADJUST SCREW HIT-6685298.A13 6685298	£1.67	£2.00
168 - HIGH ADJUST SCREW TILL B027800 HIT-6690691.A1 6690691	-
169 - HIGH ADJUSTMENT SPRING TILL B027800 HIT-6690897.A1 6690897	-
170 - SET SCREW HIT-6685223.A26 6685223	-
171 - PUMP BODY FOR SAU HIT-6685211.A7 6685211	-
172 - IDLE ADJUST SCREW FOR SAU HIT-6685298.A14 6685298	£1.67	£2.00
173 - IDLE ADJUST SPRING FOR SAU HIT-6685297.A18 6685297	-
174 - HIGH ADJUSTMENT SPRING FOR SAU HIT-6690897.A2 6690897	-
175 - HIGH ADJUST SCREW FOR SAU HIT-6690691.A2 6690691	-
176 - HIGH/LOW ADJUST SPRING FOR SAU HIT-6692048.A22 6692048	-
177 - LOW ADJUST SCREW FOR SAU HIT-6690714.A4 6690714	-
191 - SCREW 5X14/WS HIT-6695416.A14 6695416	-
192 - OIL PUMP COVER HIT-6686763.A0 6686763	-
193 - OIL PIPE A HIT-6691223.A2 6691223	-
194 - SCREW GEAR HIT-6686645.A14 6686645	£15.03	£18.04
195 - AIR VENT SPONGE HIT-6691400.A5 6691400	-
196 - OIL PUMP ASS'Y HIT-6687324.A7 6687324	£17.82	£21.39
197 - OIL ADJUST GROMMET HIT-6690956.A5 6690956	-
198 - OIL PUMP ADJUSTER HIT-6691070.A9 6691070	-
199 - O RING HIT-6697917.A25 6697917	-
200 - OIL PUMP CASE SET 1 HIT-6686681.A8 6686681	-
201 - O RING HIT-6697917.A24 6697917	-
202 - TAPPING SCREW D5X14 HIT-6685275.A74 6685275	-
203 - FUEL PIPE TILL H046690 HIT-6685154.A21 6685154	-
204 - CHAIN CATCHER HIT-6685155.A10 6685155	-
205 - TAPPING SCREW D4.5X14 HIT-6685152.A33 6685152	-
221 - NUT TILL F179300 HIT-6685166.A22 6685166	£3.62	£4.35
221A - CHAIN BAR CLAMP NUT SINCE F179301 HIT-6687105.A22 6687105	£1.67	£2.00
222 - CLUTCH COMP. HIT-6685142.A7 6685142	£16.34	£19.61
223 - NEEDLE BEARING HIT-6685143.A12 6685143	£4.72	£5.66
224 - CLUTCH HOUSING COMP. HIT-6685144.A5 6685144	£11.93	£14.32
225 - CLUTCH WASHER HIT-6685145.A9 6685145	-
226 - TAPPING SCREW D4X10 HIT-6685161.A0 6685161	£1.67	£2.00
227 - PLATE TILL C091000 HIT-6690790.A4 6690790	-
227A - GUIDE PLATE A SINCE C091001 HIT-6697599.A3 6697599	-
228 - CRANK SHAFT COLLAR HIT-6685146.A7 6685146	£1.67	£2.00
229 - TAPPING SCREW D4X10 SINCE C091001 HIT-6685161.A1 6685161	£1.67	£2.00
230 - SIDE CASE ASS'Y TILL C091000 HIT-6601157.A1 6601157	-
231 - GUIDE PLATE B SINCE C091001 HIT-6690756.A2 6690756	£2.81	£3.37
232 - SCREW 2.6X5 SINCE C091001 HIT-6695269.A9 6695269	-
233B - CHAIN PULLER INCLUD.234 SINCE C091001 HIT-6698986.A4 6698986	£18.88	£22.66
234 - GEAR (A) SINCE C091001 HIT-6685168.A0 6685168	£3.45	£4.14
235 - BRAKE HANDLE COMP. HIT-6697958.A1 6697958	£15.15	£18.18
236 - BRAKE LINK COVER 1 HIT-6689712.A0 6689712	£4.65	£5.58
237 - BRAKE SPRING HIT-6697694.A3 6697694	-
238 - BRAKE SUPPORT PLATE COMP. HIT-6685119.A13 6685119	-
239 - NEEDLE ROLLER 3X9.8 HIT-6685141.A13 6685141	-
240 - BRAKE LINK HIT-6685388.A18 6685388	£12.57	£15.08
241 - BRAKE BAND HIT-6689728.A1 6689728	-
242 - CLEANER FIXING COLLAR HIT-6690805.A36 6690805	£2.69	£3.23
243 - COLLAR HIT-6685120.A3 6685120	-
244 - SIDE COVER COMP HIT-6697614.A6 6697614	-
245 - BRAKE LEVER SPRING HIT-6685122.A2 6685122	-
246 - TAPPING SCREW D4X15 HIT-6685148.A16 6685148	-
247 - TENSION ADJUSTMENT BOLT ASS'Y TILL C091000 HIT-6687071.A3 6687071	-
261 - NYLON LOCK NUT 4 HIT-6695163.A4 6695163	-
262 - TAPPING SCREW 5X40 HIT-6695108.A3 6695108	-
263 - DAMPER COLLAR A HIT-6688480.A5 6688480	-
264 - DAMPER A HIT-6688117.A5 6688117	-
265 - SCREW 4X30PS HIT-6695378.A1 6695378	-
266 - REAR HANDLE B COMP. HIT-6685645.A3 6685645	-
267 - PUSH PIN CAP HIT-6692680.A8 6692680	-
268 - STOPPER SPRING HIT-6686447.A9 6686447	£1.67	£2.00
269 - PUSH PIN HIT-6686430.A0 6686430	£1.67	£2.00
270 - TRIGGER LOCKOUT VERMILION HIT-6688363.A3 6688363	-
271 - THROTTLE LEVER HIT-6686392.A0 6686392	-
272 - THROTTLE LEVER SPRING HIT-6686416.A3 6686416	£2.71	£3.25
273 - REAR HANDLE HIT-6685620.A3 6685620	-
274 - TAPPING SCREW 5X35 HIT-6695107.A39 6695107	£1.67	£2.00
275 - TAPPING SCREW D4X15 HIT-6685148.A17 6685148	-
276 - FRONT HANDLE HIT-6688083.A3 6688083	£6.59	£7.91
277 - DAMPER B HIT-6688412.A12 6688412	£1.67	£2.00
278 - DAMPER COLLAR B HIT-6688485.A14 6688485	£1.67	£2.00
279 - TAPPING SCREW 5X35 HIT-6695107.A38 6695107	£1.67	£2.00
501 - COMBI BOX SPANNER 10/19MM HIT-6685257.A3 6685257	-
502 - CHAIN COVER 14 HIT-6685256.A9 6685256	-
503A - CHAIN COVER 12 HIT-6685401.A15 6685401	-
510 - BAR 12 INCH 3/8 SPROCKET HIT-6685159.A1 6685159	£38.61	£46.33
511 - BAR 14 INCH 3/8 SPROCKET HIT-6685160.A5 6685160	£21.92	£26.30
512 - CHAIN BAR 16 HIT-6686854.A1 6686854	-
513 - SAW CHAIN (3/8X12) 91PX-45XJ HIT-781122.A16 781122	£12.41	£14.89
514 - SAW CHAIN (3/8X14) 91PX-52XJ HIT-781124.A21 781124	£13.99	£16.79
515 - SAW CHAIN (3/8X16) 91PX-57XJ HIT-781126.A14 781126	£19.00	£22.80
601 - NAME PLATE ECS-3301D HIT-6699564.A0 6699564	-
602 - STARTER MARK ECS-3301D HIT-6699565.A0 6699565	-

Attribute Name	Value
Brand	Hikoki

Reviews Write your own review!

There are currently no reviews of this product.

Fill in the form below to add your review for Hitachi / Hikoki ECS-3301D Engine Chain Saw (top Handle) Spare Parts

Your Review
Title Required!
Rating Required!
Your Review Required!
Your Details
Your Name Required!
Your Location Required!
Email Address Required!Invalid email!

United Kingdom (Including N. Ireland)

On orders up to £40.00	Add £4.00 inc VAT (Royal Mail post)
On orders £40.00 to £130.00	Add £7.00 inc VAT (Courier)
On orders over £130.00	FREE (Courier)

Shopping Basket (0) £0.00

Hitachi / Hikoki ECS-3301D Engine Chain Saw (top Handle) Spare Parts

Your Review

Your Details

Carry On Shopping

Try these categories

Recently Viewed

Your Order

About Us

Other Links

Search

Customization

Shopping Basket (0) £0.00

Information

Hitachi / Hikoki ECS-3301D Engine Chain Saw (top Handle) Spare Parts

Notify me

Your Review

Your Details

Carry On Shopping

Try these categories

Recently Viewed

Your Order

About Us

Other Links

Search
