Hitachi / Hikoki DW25EG Engine Drill Spare Parts

An exploded diagram and spare parts listing for the Hitachi / Hikoki DW25EG Engine Drill

	Ex VAT	Inc VAT
1 - PLUG CAP HIT-6684894.A19 6684894	£7.75	£9.30
2 - SPARK PLUG ASS'Y BMR6A HIT-6699315.A15 6699315	-
3 - CYLINDER SET HIT-6685495.A1 6685495	£87.22	£104.66
4 - HEX.HOLE BOLT M5X18/S HIT-6684586.A44 6684586	-
5 - CYLINDER GASKET HIT-6684896.A11 6684896	£1.67	£2.00
6 - PISTON RING HIT-6686121.A10 6686121	£6.47	£7.76
7 - PISTON SET HIT-6685902.A16 6685902	£30.58	£36.70
8 - CIR CLIP HIT-6684590.A102 6684590	£1.67	£2.00
9 - PISTON PIN HIT-6684591.A26 6684591	£3.29	£3.95
10 - CRANK SHAFT COMP. HIT-6686219.A10 6686219	£121.07	£145.28
12 - STOP CORD B 190M HIT-6687836.A8 6687836	-
13 - HEX. HOLE BOLT M4X18/WS TILL E289999 HIT-6684599.A56 6684599	-
13A - HIGH TENSION SCREW 4X18WS SINCE E290001 HIT-6695407.A23 6695407	-
14 - IGNITION COIL ASS'Y HIT-6687689.A0 6687689	£51.02	£61.23
15 - WASHER T1.6 HIT-6684600.A19 6684600	-
*21 - GEAR SHAFT SHIM 0.20 HIT-6684604.A45 6684604	-
*21 - GEAR SHAFT SHIM 0.30 HIT-6684605.A36 6684605	-
22 - MAGNETO ROTOR COMP. HIT-6687385.A3 6687385	-
23 - HEX. NUT M8 HIT-6684612.A59 6684612	-
24 - BOLT WASHER M8 HIT-6684611.A60 6684611	-
25 - CRANK CASE ASS'Y HIT-6684905.A11 6684905	£30.92	£37.11
26 - OIL SEAL TB 12227 HIT-6684607.A64 6684607	£4.07	£4.88
27 - BALL BEARING 6001 C3 HIT-6684608.A134 6684608	£5.70	£6.84
28 - CRANK CASE GASKET HIT-6684904.A15 6684904	£1.67	£2.00
29 - HEX. HOLE BOLT M5X16/S HIT-6684903.A40 6684903	-
41 - INLET MANIFOLD GASKET HIT-6689895.A4 6689895	£1.67	£2.00
42 - INSULATOR SET HIT-6689972.A3 6689972	£6.59	£7.91
43 - HEX. HOLE BOLT 5X25/WS HIT-6684617.A14 6684617	-
44 - CARBURETOR PACKING HIT-6684616.A14 6684616	£1.67	£2.00
45 - CABURETOR SET WYJ-463 HIT-6690522.A7 6690522	£84.48	£101.37
46 - CLEANER BODY COMP. HIT-6690120.A26 6690120	£12.32	£14.78
47 - CLEANER SPONGE HIT-6690365.A40 6690365	£1.67	£2.00
48 - CLEANER COVER ASS'Y HIT-6690402.A7 6690402	£12.16	£14.59
49 - COVER FIXING BOLT COMP. HIT-6698730.A37 6698730	£5.52	£6.63
50 - SCREW M5X55 HIT-6694914.A30 6694914	-
51 - SMALL WASHER 5 HIT-6684864.A23 6684864	-
52 - CHOKE PLATE 2.0 HIT-6691276.A2 6691276	£1.67	£2.00
53 - CHOKE CONTROL LEVER HIT-6691239.A29 6691239	£2.98	£3.57
54 - TANK WHT TILL TE749999 HIT-6691602.A1 6691602	£13.82	£16.59
54A - TANK SINCE TE840001 HIT-6601167.A5 6601167	-
55 - COLLAR 5.8 TILL E819999 HIT-6692244.A45 6692244	£1.67	£2.00
56 - RETURN GROMMET TILL TE749999 HIT-6697846.A7 6697846	£2.08	£2.50
56A - FUEL GROMMET SINCE TE840001 HIT-6600358.A54 6600358	£1.67	£2.00
57 - FUEL PIPE 3X5X65 HIT-6684626.A8 6684626	£1.67	£2.00
58A - PUMP FILTER BODY COMP HIT-66A3864.A0 66A3864	-
59 - CLIP D6 HIT-6685198.A14 6685198	-
60 - SHIELD TUBE 3X5X180 TILL TE749999 HIT-6684618.A12 6684618	£6.12	£7.35
60A - FUEL PIPE SINCE TE840001 HIT-6601181.A5 6601181	-
62 - TANK CAP ASS'Y HIT-6685049.A40 6685049	£9.94	£11.93
63 - TANK CAP CHAIN HIT-6684625.A67 6684625	-
64 - HEX. HOLE BOLT 5X16/PS TILL E819999 HIT-6695504.A15 6695504	£1.67	£2.00
64A - BOLT (W/FLANGE) L17.8 SINCE E910001 HIT-6696574.A1 6696574	£1.67	£2.00
65 - TAP SCREW 4X14 P HIT-6695280.A35 6695280	£1.67	£2.00
66 - BOLT WASHER M4 HIT-6685070.A6 6685070	£1.67	£2.00
67 - S.WASHER 5 HIT-6684662.A23 6684662	£1.67	£2.00
71 - CYLINDER COVER (BLK) HIT-6685693.A1 6685693	-
72 - HEX. HOLE BOLT 5X16/PS HIT-6695504.A16 6695504	£1.67	£2.00
73 - HEX. HOLE BOLT M6X65 HIT-6695067.A30 6695067	£1.67	£2.00
74 - BOLT WASHER 6 HIT-6684639.A121 6684639	£1.67	£2.00
75 - MUFFLER COMP HIT-6699602.A0 6699602	-
77 - MUFFLER PROTECTOR HIT-6692817.A1 6692817	£22.97	£27.56
78 - HEX. HOLE BOLT 4X18WS TILL E819999 HIT-6695508.A23 6695508	£1.67	£2.00
78A - SCREW 4X18/PS SINCE E910001 HIT-6695375.A8 6695375	-
79 - DEFLECTOR BLACK HIT-6687217.A1 6687217	-
80 - CLUTCH WASHER B TILL E729999 HIT-6684642.A14 6684642	£1.67	£2.00
80A - CLUTCH WASHER B SINCE E820001 HIT-6697619.A18 6697619	£1.67	£2.00
81 - CLUTCH SHOE COMP. TILL E729999 HIT-6684643.A16 6684643	£12.01	£14.41
81A - CLUTCH SHOE SINCE E820001 HIT-6697656.A4 6697656	-
82 - CLUTCH SPRING TILL E729999 HIT-6684644.A7 6684644	£3.12	£3.74
82A - CLUTCH SPRING SINCE E820001 HIT-6697657.A9 6697657	-
83 - CLUTCH PLATE A 0.5 TILL E729999 HIT-6684645.A18 6684645	£1.67	£2.00
83A - CLUTCH PLATE (A) SINCE E820001 HIT-6689528.A28 6689528	£1.67	£2.00
84 - STEP BOLT TILL E729999 HIT-6684646.A16 6684646	£3.72	£4.46
84A - STEP BOLT SINCE E820001 HIT-6689627.A19 6689627	£1.67	£2.00
85 - HEX. HOLE BOLT M5X18/WS HIT-6684647.A14 6684647	£1.67	£2.00
86 - BENT WASHER 8 HIT-6684648.A49 6684648	£1.67	£2.00
87 - CLUTCH SET SINCE E820001 HIT-6697655.A20 6697655	£9.68	£11.62
88 - HEX. HOLE BOLT 4X15/PS HIT-6684682.A45 6684682	£1.67	£2.00
89 - HEAT SHIELD HIT-6687265.A9 6687265	£5.70	£6.84
90 - TAPPING SCREW 4X14 HIT-6684751.A23 6684751	£1.67	£2.00
91 - FAN CASE COMP OR HIT-6697214.A0 6697214	-
92 - PRIMARY CORD GROMMET HIT-6688057.A10 6688057	-
93 - MUFFLER SPECIAL GASKET HIT-6692886.A9 6692886	-
94 - TAIL PIPE SET HIT-6692716.A1 6692716	-
95 - SCREW M4X8/WS HIT-6684651.A5 6684651	-
96 - SPARK ARRESTER HIT-6692702.A5 6692702	-
101B - RECOIL STARTER BODY ASS'Y INCLUD.103-109 HIT-6601570.A80 6601570	£23.15	£27.78
103 - STARTER ROPE 3.5X860 HIT-6684674.A27 6684674	£5.70	£6.84
104 - RECOIL SPRING HIT-6684675.A112 6684675	£8.82	£10.58
105A - STARTER ROPE REEL SINCE TE540001 HIT-6699997.A63 6699997	-
106 - DAMPER SPRING HIT-6684677.A34 6684677	£6.66	£7.99
107A - CAM PLATE SINCE TE540001 HIT-6699996.A26 6699996	£4.28	£5.13
108 - SET SCREW HIT-6684679.A43 6684679	£2.98	£3.57
109 - STARTER HANDLE HIT-6684680.A81 6684680	£5.87	£7.04
110 - STARTER PULLEY ASS'Y HIT-6684681.A33 6684681	£18.16	£21.79
111 - D4E RETAINING RING HIT-6685101.A1 6685101	-
112 - STARTER PAWL SPRING HIT-6684684.A84 6684684	£3.29	£3.95
113 - STARTER PAWL HIT-6684685.A33 6684685	£5.07	£6.08
114 - HEX. HOLE BOLT 4X18WS TILL E819999 HIT-6695508.A24 6695508	£1.67	£2.00
114A - SCREW 4X18/PS SINCE E910001 HIT-6695375.A5 6695375	-
115 - CAMPLATE ASS'Y TILL TE449999 HIT-6699691.A20 6699691	£7.75	£9.30
121 - PUMP BODY COMP. HIT-6684879.A53 6684879	£35.37	£42.44
122 - PRIMING PUMP COMP. HIT-6684687.A72 6684687	£9.27	£11.12
123 - DIAPHRAGM COVER HIT-6684688.A27 6684688	£5.70	£6.84
124 - PRIMING BODY HIT-6684689.A72 6684689	£5.87	£7.04
125 - METERING DIAPHRAGM HIT-6684690.A35 6684690	£24.05	£28.86
126 - DIAPHRAGM GASKET HIT-6684691.A71 6684691	£5.70	£6.84
127 - PUMP DIAPHRAGM HIT-6684693.A148 6684693	£5.70	£6.84
128 - PUMP GASKET HIT-6684692.A33 6684692	£17.28	£20.73
129 - MAIN JET #38.5 HIT-6696130.A7 6696130	-
130 - O-RING HIT-6684695.A52 6684695	£1.67	£2.00
131 - STOP RING HIT-6684696.A162 6684696	-
132 - SWIVEL HIT-6684697.A38 6684697	-
133 - THROTTLE SET SCREW HIT-6684870.A25 6684870	-
134 - CABLE ADJUSTER STAY HIT-6684873.A48 6684873	-
137 - CLEANER PACKING HIT-6684875.A51 6684875	-
138 - SET SCREW HIT-6684699.A29 6684699	-
139 - THRUST WASHER HIT-6684874.A26 6684874	-
140 - INLET SCREEN HIT-6684700.A164 6684700	-
151 - GEAR CASE A COMP. HIT-6685578.A4 6685578	£62.67	£75.20
152 - NO LONGER AVAILABLE HIT-6685593.A9 6685593	-
153 - CLUTCH HOUSING COMP. HIT-6688210.A4 6688210	-
154 - GEAR 2 HIT-6685656.A5 6685656	£31.02	£37.23
155 - GEAR 3 HIT-6685702.A5 6685702	£28.68	£34.41
156 - WOOD-RUFF KEY 3X10X3.7 HIT-6686454.A3 6686454	-
157 - BALL BEARING #6001Z 1 HIT-6695532.A13 6695532	£15.01	£18.01
158 - BALL BEARING #16001 HIT-6695534.A2 6695534	-
159 - STOP RING C 11 1 HIT-6695282.A4 6695282	-
160 - GEAR 4 HIT-6685788.A1 6685788	£20.91	£25.09
161 - BALL BEARING #7202B 1 HIT-6695587.A16 6695587	£26.15	£31.38
162 - WASHAER C 5.0 HIT-6686065.A4 6686065	-
163 - BALL BEARING #6202Z 1 HIT-6695559.A5 6695559	£12.76	£15.31
164 - WAVE WASHER B.B 35 HIT-6695206.A1 6695206	-
165 - STOP RING C-35 1 HIT-6695296.A4 6695296	-
166 - WOOD-RUFF KEY 3X13X5 HIT-6686455.A10 6686455	£1.67	£2.00
167 - DRIVE SHAFT HIT-6685824.A7 6685824	£26.42	£31.70
168 - SCREW 5X18/S HIT-6695339.A7 6695339	-
169 - STOP RING C-13 1 HIT-6695283.A6 6695283	-
170 - LOCK LEVER COMP. HIT-6689992.A5 6689992	-
171 - LOCK LEVER SPRING HIT-6689998.A5 6689998	-
172 - SPECIAL WASHER HIT-6687942.A3 6687942	-
173 - BOLT WASHER M7 HIT-6685103.A35 6685103	-
174 - STEP BOLT HIT-6693366.A7 6693366	-
175 - GREASE NIPPLE COMP. HIT-6688643.A19 6688643	£1.67	£2.00
176 - S.WASHER 6 HIT-6695219.A110 6695219	£1.67	£2.00
177 - NUT M6 HIT-6684792.A7 6684792	-
201 - THROTTLE BODY A HIT-6693795.A3 6693795	£5.58	£6.69
202 - THROTTLE BODY B HIT-6693818.A4 6693818	£5.58	£6.69
203 - THROTTLE LEVER DH HIT-6686402.A0 6686402	-
204 - THROTTLE LEVER SPRING HIT-6686421.A4 6686421	£1.67	£2.00
205 - TAP SCREW 4X14 P HIT-6695280.A33 6695280	£1.67	£2.00
206 - SCREW 4X6 HIT-6694860.A4 6694860	£1.67	£2.00
207 - PROTECTION TUBE 7X530L HIT-6687537.A0 6687537	-
208 - HANDLE ASS'Y HIT-6697263.A0 6697263	-
209 - BOLT WASHER 6 HIT-6684639.A120 6684639	£1.67	£2.00
210 - S.WASHER 6 HIT-6695219.A111 6695219	£1.67	£2.00
211 - PLUS BOLT 6X12 HIT-6695015.A7 6695015	-
212 - WASHER 10 HIT-6695198.A4 6695198	-
213 - S.WASHER 10 HIT-6695225.A4 6695225	£1.67	£2.00
214 - BOLT 10X20 HIT-6695005.A1 6695005	-
215 - THROTTLE WIRE 585+32 HIT-6693989.A0 6693989	-
216 - STOP SWITCH COMP. HIT-6687777.A0 6687777	-
217 - CORD CLAMP HIT-6688015.A5 6688015	-
218 - BUTTON STOP HIT-6688366.A1 6688366	£1.67	£2.00
219 - STOP BUTTON MARK HIT-6694588.A13 6694588	£2.98	£3.57
220 - SCREW 3X10 HIT-6684913.A12 6684913	£1.67	£2.00
501 - SPANNER 17X19 HIT-6686251.A1 6686251	-
502 - COMBI BOX SPANNER 10X19 HIT-6685999.A8 6685999	-
503 - SPECIAL WRENCH 31 HIT-6693647.A2 6693647	-
