1 - FRONT CAP
HIT-306345.A4
306345
|
£3.59
|
£4.31
|
|
|
2 - STOPPER RING
HIT-306340.A37
306340
|
£1.67
|
£2.00
|
|
|
3 - GRIP
HIT-374436.A6
374436
|
-
|
|
|
|
4 - BALL HOLDER
HIT-374437.A4
374437
|
-
|
|
|
|
5 - HOLDER PLATE
HIT-374435.A4
374435
|
-
|
|
|
|
6 - HOLDER SPRING
HIT-322812.A24
322812
|
£1.67
|
£2.00
|
|
|
7 - NAME PLATE
HIT-000000.A310
000000
|
-
|
|
|
|
8 - OIL SEAL
HIT-335259.A14
335259
|
£5.07
|
£6.08
|
|
|
9 - BALL BEARING 6805
HIT-6805BB.A6
6805BB
|
-
|
|
|
|
10 - PUSHING BUTTON
HIT-322789.A22
322789
|
£6.50
|
£7.80
|
|
|
11 - PUSHING SPRING
HIT-317223.A7
317223
|
£1.67
|
£2.00
|
|
|
12 - CHANGE LEVER
HIT-334011.A3
334011
|
£3.92
|
£4.70
|
|
|
13 - O-RING (S-18)
HIT-878885.A51
878885
|
£1.67
|
£2.00
|
|
|
14 - GEAR COVER
HIT-374624.A1
374624
|
-
|
|
|
|
15 - GEAR COVER ASS'Y INCLUD.14
HIT-375018.A0
375018
|
-
|
|
|
|
16 - SPRING (E)
HIT-335800.A11
335800
|
£1.67
|
£2.00
|
|
|
17 - BALL BEARING 608VVC2PS2L
HIT-608VVM.A140
608VVM
|
£5.70
|
£6.84
|
|
|
18 - SHAFT HOLDER (B)
HIT-374422.A1
374422
|
-
|
|
|
|
19 - STEEL BALL D7.0 (10 PCS.)
HIT-335300.A12
335300
|
£1.67
|
£2.00
|
|
|
20 - CYLINDER
HIT-374426.A1
374426
|
£28.38
|
£34.06
|
|
|
21 - SECOND GEAR
HIT-335265.A12
335265
|
£10.52
|
£12.62
|
|
|
22 - SPRING (B)
HIT-374430.A9
374430
|
-
|
|
|
|
23 - WASHER (A)
HIT-301679.A4
301679
|
£1.67
|
£2.00
|
|
|
24 - RETAINING RING FOR D30 SHAFT
HIT-948310.A24
948310
|
£1.67
|
£2.00
|
|
|
25 - OIL SEAL (A)
HIT-335262.A11
335262
|
£3.12
|
£3.74
|
|
|
26 - HAMMER HOLDER (B)
HIT-374431.A1
374431
|
-
|
|
|
|
27 - HOLDER SLEEVE
HIT-374427.A8
374427
|
-
|
|
|
|
28 - SECOND HAMMER
HIT-374432.A8
374432
|
-
|
|
|
|
29 - HAMMER HOLDER (A)
HIT-374429.A1
374429
|
-
|
|
|
|
30 - DAMPER (A)
HIT-322805.A11
322805
|
£1.67
|
£2.00
|
|
|
31 - O-RING (C)
HIT-322808.A11
322808
|
£1.67
|
£2.00
|
|
|
32 - DAMPER HOLDER
HIT-324524.A20
324524
|
£8.66
|
£10.39
|
|
|
33 - STOPPER RING
HIT-322807.A17
322807
|
£1.67
|
£2.00
|
|
|
34 - STRIKER
HIT-374443.A3
374443
|
-
|
|
|
|
35 - O-RING
HIT-372816.A9
372816
|
£5.07
|
£6.08
|
|
|
36 - PISTON
HIT-372817.A3
372817
|
-
|
|
|
|
37 - PISTON PIN
HIT-335793.A21
335793
|
£5.78
|
£6.94
|
|
|
38 - PISTON WASHER
HIT-335794.A1
335794
|
£1.67
|
£2.00
|
|
|
39 - LOCK PLATE
HIT-374434.A5
374434
|
-
|
|
|
|
40 - SECOND PINION
HIT-374440.A5
374440
|
-
|
|
|
|
41 - CLUTCH SPRING
HIT-323182.A8
323182
|
£1.67
|
£2.00
|
|
|
42 - CLUTCH
HIT-375022.A1
375022
|
-
|
|
|
|
43 - WASHER
HIT-331315.A21
331315
|
£1.67
|
£2.00
|
|
|
44 - CHANGE PLATE (C)
HIT-374439.A2
374439
|
-
|
|
|
|
45 - SECOND SHAFT
HIT-374438.A5
374438
|
-
|
|
|
|
46 - RECIPROCATING BEARING
HIT-335249.A14
335249
|
£19.98
|
£23.97
|
|
|
47 - FIRST GEAR
HIT-374441.A3
374441
|
-
|
|
|
|
48 - BEARING WASHER
HIT-374442.A7
374442
|
-
|
|
|
|
49 - O-RING D72.2
HIT-335245.A8
335245
|
£1.67
|
£2.00
|
|
|
50 - INNER COVER
HIT-374625.A0
374625
|
-
|
|
|
|
51 - WEIGHT (A)
HIT-374627.A0
374627
|
-
|
|
|
|
52 - LEAF SPRING
HIT-335282.A4
335282
|
£1.67
|
£2.00
|
|
|
53 - WEIGHT (B)
HIT-374628.A3
374628
|
-
|
|
|
|
54 - SEAL LOCK HEX. SOCKET HD. BOLT M3X8
HIT-325241.A2
325241
|
£1.67
|
£2.00
|
|
|
55 - AIR CAP
HIT-334008.A19
334008
|
-
|
|
|
|
56 - FELT PACKING (A)
HIT-324543.A25
324543
|
£1.67
|
£2.00
|
|
|
57 - SPRING HOLDER
HIT-374626.A3
374626
|
-
|
|
|
|
58 - SEAL LOCK HEX. SOCKET HD. BOLT M4X12
HIT-983162.A17
983162
|
£1.67
|
£2.00
|
|
|
59 - FELT PACKING
HIT-322816.A9
322816
|
£1.67
|
£2.00
|
|
|
60 - PACKING WASHER
HIT-322818.A10
322818
|
£4.33
|
£5.20
|
|
|
61 - O-RING (P-22)
HIT-876796.A14
876796
|
£1.67
|
£2.00
|
|
|
62 - BALL BEARING 608DD
HIT-608DDM.A30
608DDM
|
£6.35
|
£7.62
|
|
|
63 - WASHER (A)
HIT-982631.A21
982631
|
£1.67
|
£2.00
|
|
|
*64 - ARMATURE (B) 110V
HIT-361108C.A0
361108C
|
-
|
|
|
|
*64 - ARMATURE (B) 220V-230V
HIT-361108E.A3
361108E
|
-
|
|
|
|
65 - HEX. HD. TAPPING SCREW D4X45
HIT-981824.A3
981824
|
-
|
|
|
|
*66 - STATOR (A) 110V (W/CR)
HIT-341028C.A0
341028C
|
£18.45
|
£22.14
|
|
|
*66 - STATOR (A) 220V-230V
HIT-341028K.A6
341028K
|
-
|
|
|
|
67 - HOUSING (B)
HIT-374622.A3
374622
|
-
|
|
|
|
68 - BRUSH HOLDER
HIT-955203.A41
955203
|
£4.16
|
£4.99
|
|
|
69 - CARBON BRUSH (1 PAIR)
HIT-999041.A60
999041
|
£5.54
|
£6.65
|
|
|
70 - CARBON BRUSH (AUTO STOP TYPE) (1 PAIR)
HIT-999072.A16
999072
|
£14.16
|
£16.99
|
|
|
71 - CHOKE COIL (BLOWN)
HIT-374615.A4
374615
|
-
|
|
|
|
72 - CHOKE COIL (BLUE)
HIT-374614.A5
374614
|
-
|
|
|
|
73 - PUSHING BUTTON
HIT-322853.A2
322853
|
£1.67
|
£2.00
|
|
|
*74 - SWITCH 100V-127V
HIT-374611.A6
374611
|
-
|
|
|
|
*74 - SWITCH 220V-240V
HIT-374610.A3
374610
|
-
|
|
|
|
75 - TAPPING SCREW (W/FLANGE) D5X35
HIT-301654.A10
301654
|
£1.67
|
£2.00
|
|
|
*76 - CORD (CORD ARMOR D8.8)
HIT-500465Z.A20
500465Z
|
£26.20
|
£31.44
|
|
|
*76 - CORD (CORD ARMOR D8.8) FOR GBR 230V
HIT-500446Z.A37
500446Z
|
£33.79
|
£40.55
|
|
|
77 - CORD ARMOR D8.8
HIT-953327.A158
953327
|
£1.67
|
£2.00
|
|
|
78 - CORD CLIP
HIT-937631.A75
937631
|
£1.67
|
£2.00
|
|
|
79 - TAPPING SCREW (W/FLANGE) D4X16
HIT-984750.A183
984750
|
£1.67
|
£2.00
|
|
|
80 - NOISE SUPPRESSOR
HIT-930039.A11
930039
|
£3.85
|
£4.62
|
|
|
81 - HANDLE COVER (B)
HIT-374623.A0
374623
|
-
|
|
|
|
82 - TAPPING SCREW (W/FLANGE) D4X20 (BLACK)
HIT-301653.A184
301653
|
£1.67
|
£2.00
|
|
|
83 - GRIP SET INCLUD.1-6
HIT-375363.A6
375363
|
-
|
|
|
|
501 - CASE
HIT-374630.A0
374630
|
-
|
|
|
|
502 - SIDE HANDLE
HIT-374447.A1
374447
|
-
|
|
|
|
503 - DEPTH GAUGE
HIT-303709.A11
303709
|
£1.67
|
£2.00
|
|
|
601 - DUST COLLECTOR (B) ASS'Y INCLUD.602
HIT-306885.A12
306885
|
£25.14
|
£30.17
|
|
|
602 - DUST COLLECTOR ASS'Y INCLUD.603-609
HIT-986802.A12
986802
|
-
|
|
|
|
603 - DUST COVER
HIT-986803.A13
986803
|
-
|
|
|
|
604 - SEAL COVER
HIT-986804.A12
986804
|
-
|
|
|
|
605 - RETAINING RING FOR D30 SHAFT
HIT-948310.A23
948310
|
£1.67
|
£2.00
|
|
|
606 - WASHER
HIT-958063.A12
958063
|
-
|
|
|
|
607 - STEEL BALL D6.35 (10 PCS.)
HIT-959150.A4
959150
|
£1.67
|
£2.00
|
|
|
608 - OUTER RACE
HIT-986805.A13
986805
|
-
|
|
|
|
609 - SOCKET
HIT-986806.A12
986806
|
-
|
|
|
|
610 - SOCKET ADAPTER (B)
HIT-306910.A31
306910
|
-
|
|
|
|
611 - DUST CUP
HIT-971787.A7
971787
|
£4.40
|
£5.28
|
|
|
612 - STOPPER
HIT-931844.A18
931844
|
-
|
|
|
|
613 - DRILL CHUCK 13VLRB-D INCLUD.614
HIT-321814.A2
321814
|
-
|
|
|
|
614 - FLAT HD. SCREW (LEFT HAND) M6X20
HIT-331966.A7
331966
|
£11.39
|
£13.67
|
|
|
615 - DRILL CHUCK 13VLD-D
HIT-321813.A50
321813
|
-
|
|
|
|
616 - + DRIVER BIT (A) NO.2 25L
HIT-971511Z.A7
971511Z
|
-
|
|
|
|
617 - + DRIVER BIT (A) NO.3 25L
HIT-971512Z.A36
971512Z
|
-
|
|
|
|
618 - ANCHOR SETTING ADAPTER A W1/4 (MANUAL)
HIT-971794.A11
971794
|
-
|
|
|
|
619 - ANCHOR SETTING ADAPTER A W5/16 (MANUAL)
HIT-971795.A22
971795
|
-
|
|
|
|
620 - ANCHOR SETTING ADAPTER A W3/8 (MANUAL)
HIT-971796.A12
971796
|
-
|
|
|
|
621 - ANCHOR SETTING ADAPTER A W1/2 (MANUAL)
HIT-971797.A21
971797
|
-
|
|
|
|
622 - ANCHOR SETTING ADAPTER A W5/8 (MANUAL)
HIT-971798.A12
971798
|
-
|
|
|
|
623 - ANCHOR SETTING ADAPTER B W1/4 (MANUAL)
HIT-971799.A22
971799
|
-
|
|
|
|
624 - ANCHOR SETTING ADAPTER B W5/16 (MANUAL)
HIT-971800.A12
971800
|
-
|
|
|
|
625 - ANCHOR SETTING ADAPTER B W3/8 (MANUAL)
HIT-971801.A22
971801
|
-
|
|
|
|
626 - ANCHOR SETTING ADAPTER B W1/2 (MANUAL)
HIT-971802.A12
971802
|
-
|
|
|
|
627 - ANCHOR SETTING ADAPTER B W5/8 (MANUAL)
HIT-971803.A21
971803
|
-
|
|
|
|
628 - SYRINGE (BLOW-OUT BULB TYPE)
HIT-320859.A35
320859
|
£10.35
|
£12.42
|
|
|
629 - COTTER
HIT-944477.A6
944477
|
£5.17
|
£6.20
|
|
|
630 - CENTER PIN (A) 109L FOR CORE BIT D32-38
HIT-982684.A4
982684
|
-
|
|
|
|
631 - NO LONGER AVAILABLE
HIT-982685.A25
982685
|
-
|
|
|
|
632 - GREASE FOR ROTARY HAMMER (500G)
HIT-335781.A13
335781
|
£91.40
|
£109.68
|
|
|
633 - GREASE FOR ROTARY HAMMER (60G)
HIT-335782.A9
335782
|
£19.89
|
£23.87
|
|
