1 - FRONT CAP
HIT-306345.A5
306345
|
£3.59
|
£4.31
|
|
|
2 - STOPPER RING
HIT-306340.A36
306340
|
£1.67
|
£2.00
|
|
|
3 - GRIP
HIT-374436.A4
374436
|
-
|
|
|
|
4 - BALL HOLDER
HIT-374437.A6
374437
|
-
|
|
|
|
5 - HOLDER PLATE
HIT-374435.A6
374435
|
-
|
|
|
|
6 - HOLDER SPRING
HIT-322812.A21
322812
|
£1.67
|
£2.00
|
|
|
7 - NAME PLATE
HIT-000000.A301
000000
|
-
|
|
|
|
8 - OIL SEAL
HIT-335259.A15
335259
|
£5.07
|
£6.08
|
|
|
9 - BALL BEARING 6805
HIT-6805BB.A3
6805BB
|
-
|
|
|
|
10 - PUSHING BUTTON
HIT-322789.A19
322789
|
£6.50
|
£7.80
|
|
|
11 - PUSHING SPRING
HIT-317223.A4
317223
|
£1.67
|
£2.00
|
|
|
12 - CHANGE LEVER
HIT-334011.A1
334011
|
£3.92
|
£4.70
|
|
|
13 - O-RING (S-18)
HIT-878885.A49
878885
|
£1.67
|
£2.00
|
|
|
14 - GEAR COVER
HIT-374618.A1
374618
|
-
|
|
|
|
15 - GEAR COVER ASS'Y INCLUD.14
HIT-375016.A1
375016
|
-
|
|
|
|
16 - SPRING (E)
HIT-335800.A8
335800
|
£1.67
|
£2.00
|
|
|
17 - BALL BEARING 608VVC2PS2L
HIT-608VVM.A143
608VVM
|
£5.70
|
£6.84
|
|
|
18 - SHAFT HOLDER (B)
HIT-374422.A2
374422
|
-
|
|
|
|
19 - STEEL BALL D7.0 (10 PCS.)
HIT-335300.A15
335300
|
£1.67
|
£2.00
|
|
|
20 - CYLINDER
HIT-374426.A3
374426
|
£28.38
|
£34.06
|
|
|
21 - SECOND GEAR
HIT-335265.A14
335265
|
£10.52
|
£12.62
|
|
|
22 - SPRING (B)
HIT-374430.A7
374430
|
-
|
|
|
|
23 - WASHER (A)
HIT-301679.A7
301679
|
£1.67
|
£2.00
|
|
|
24 - RETAINING RING FOR D30 SHAFT
HIT-948310.A28
948310
|
£1.67
|
£2.00
|
|
|
25 - OIL SEAL (A)
HIT-335262.A9
335262
|
£3.12
|
£3.74
|
|
|
26 - HAMMER HOLDER (B)
HIT-374431.A3
374431
|
-
|
|
|
|
27 - HOLDER SLEEVE
HIT-374427.A6
374427
|
-
|
|
|
|
28 - SECOND HAMMER
HIT-374432.A6
374432
|
-
|
|
|
|
29 - HAMMER HOLDER (A)
HIT-374429.A3
374429
|
-
|
|
|
|
30 - DAMPER (A)
HIT-322805.A14
322805
|
£1.67
|
£2.00
|
|
|
31 - O-RING (C)
HIT-322808.A14
322808
|
£1.67
|
£2.00
|
|
|
32 - DAMPER HOLDER
HIT-324524.A17
324524
|
£8.66
|
£10.39
|
|
|
33 - STOPPER RING
HIT-322807.A14
322807
|
£1.67
|
£2.00
|
|
|
34 - STRIKER
HIT-374443.A6
374443
|
-
|
|
|
|
35 - O-RING
HIT-372816.A11
372816
|
£5.07
|
£6.08
|
|
|
36 - PISTON
HIT-372817.A1
372817
|
-
|
|
|
|
37 - PISTON PIN
HIT-335793.A18
335793
|
£5.78
|
£6.94
|
|
|
38 - PISTON WASHER
HIT-335794.A4
335794
|
£1.67
|
£2.00
|
|
|
39 - LOCK PLATE
HIT-374434.A2
374434
|
-
|
|
|
|
40 - SECOND PINION
HIT-374440.A2
374440
|
-
|
|
|
|
41 - CLUTCH SPRING
HIT-323182.A6
323182
|
£1.67
|
£2.00
|
|
|
42 - CLUTCH
HIT-375022.A2
375022
|
-
|
|
|
|
43 - WASHER
HIT-331315.A23
331315
|
£1.67
|
£2.00
|
|
|
44 - CHANGE PLATE (C)
HIT-374439.A5
374439
|
-
|
|
|
|
45 - SECOND SHAFT
HIT-374438.A2
374438
|
-
|
|
|
|
46 - RECIPROCATING BEARING
HIT-335249.A13
335249
|
£19.98
|
£23.97
|
|
|
47 - FIRST GEAR
HIT-374441.A6
374441
|
-
|
|
|
|
48 - BEARING WASHER
HIT-374442.A4
374442
|
-
|
|
|
|
49 - O-RING D72.2
HIT-335245.A9
335245
|
£1.67
|
£2.00
|
|
|
50 - INNER COVER
HIT-374433.A1
374433
|
-
|
|
|
|
51 - AIR CAP
HIT-334008.A21
334008
|
-
|
|
|
|
52 - FELT PACKING (A)
HIT-324543.A28
324543
|
£1.67
|
£2.00
|
|
|
53 - FELT PACKING
HIT-322816.A11
322816
|
£1.67
|
£2.00
|
|
|
54 - PACKING WASHER
HIT-322818.A8
322818
|
£4.33
|
£5.20
|
|
|
55 - O-RING (P-22)
HIT-876796.A16
876796
|
£1.67
|
£2.00
|
|
|
56 - BALL BEARING 608DD
HIT-608DDM.A27
608DDM
|
£6.35
|
£7.62
|
|
|
57 - WASHER (A)
HIT-982631.A19
982631
|
£1.67
|
£2.00
|
|
|
*58 - ARMATURE (A) 110V
HIT-361106C.A0
361106C
|
£20.57
|
£24.68
|
|
|
*58 - ARMATURE (A) 120V
HIT-361106D.A1
361106D
|
-
|
|
|
|
*58 - ARMATURE (A) 220V-230V
HIT-361106E.A0
361106E
|
-
|
|
|
|
*58 - ARMATURE (A) 240V
HIT-361106F.A1
361106F
|
-
|
|
|
|
59 - HEX. HD. TAPPING SCREW D4X45
HIT-981824.A5
981824
|
-
|
|
|
|
*60 - STATOR (A) 110V
HIT-341028H.A0
341028H
|
-
|
|
|
|
*60 - STATOR (A) 110V (W/CR) FOR TPE
HIT-341028C.A1
341028C
|
£18.45
|
£22.14
|
|
|
*60 - STATOR (A) 120V
HIT-341028D.A1
341028D
|
-
|
|
|
|
*60 - STATOR (A) 220V-230V
HIT-341028K.A4
341028K
|
-
|
|
|
|
*60 - STATOR (A) 240V
HIT-341028L.A0
341028L
|
-
|
|
|
|
*61 - HOUSING (A)
HIT-374616.A0
374616
|
-
|
|
|
|
*61 - HOUSING (A) FOR MEX
HIT-374616M.A1
374616M
|
-
|
|
|
|
62 - BRUSH HOLDER
HIT-955203.A43
955203
|
£4.16
|
£4.99
|
|
|
63 - CARBON BRUSH (1 PAIR)
HIT-999041.A62
999041
|
£5.54
|
£6.65
|
|
|
64 - CARBON BRUSH (AUTO STOP TYPE) (1 PAIR)
HIT-999072.A14
999072
|
£13.72
|
£16.46
|
|
|
65 - CHOKE COIL (BLOWN) FOR EUROPE
HIT-374615.A6
374615
|
-
|
|
|
|
66 - INTERNAL WIRE (BROWN) EXCEPT FOR EUROPE
HIT-374613.A3
374613
|
-
|
|
|
|
67 - INTERNAL WIRE (BLUE) EXCEPT FOR EUROPE
HIT-374612.A3
374612
|
-
|
|
|
|
68 - CHOKE COIL (BLUE) FOR EUROPE
HIT-374614.A3
374614
|
-
|
|
|
|
69 - PUSHING BUTTON
HIT-322853.A4
322853
|
£1.67
|
£2.00
|
|
|
*70 - SWITCH 100V-127V
HIT-374611.A4
374611
|
-
|
|
|
|
*70 - SWITCH 220V-240V
HIT-374610.A5
374610
|
-
|
|
|
|
71 - TAPPING SCREW (W/FLANGE) D5X35
HIT-301654.A7
301654
|
£1.67
|
£2.00
|
|
|
*72 - CORD (CORD ARMOR D10.1)
HIT-500239Z.A3
500239Z
|
-
|
|
|
|
*72 - CORD (CORD ARMOR D8.8) FOR EUROPE
HIT-500390Z.A2
500390Z
|
-
|
|
|
|
*72 - CORD (CORD ARMOR D8.8) FOR SIN
HIT-500424Z.A0
500424Z
|
-
|
|
|
|
*72 - CORD MAL (240V)
HIT-500424Z.A1
500424Z
|
-
|
|
|
|
*72 - CORD (CORD ARMOR D8.8) FOR AUS
HIT-500408Z.A7
500408Z
|
-
|
|
|
|
*72 - CORD (CORD ARMOR D8.8) FOR HKG (220V)
HIT-500440Z.A1
500440Z
|
£22.75
|
£27.30
|
|
|
*72 - CORD (CORD ARMOR D8.8) FOR MEX
HIT-500249Z.A3
500249Z
|
-
|
|
|
|
*72 - CORD (CORD ARMOR D8.8) FOR CHN
HIT-500496Z.A4
500496Z
|
-
|
|
|
|
*72 - CORD (CORD ARMOR D10.1) FOR TPE
HIT-323974.A8
323974
|
-
|
|
|
|
*73 - CORD ARMOR D8.8
HIT-953327.A156
953327
|
£1.67
|
£2.00
|
|
|
*73 - CORD ARMOR D10.1
HIT-938051.A45
938051
|
£1.67
|
£2.00
|
|
|
74 - CORD CLIP
HIT-937631.A73
937631
|
£1.67
|
£2.00
|
|
|
75 - TAPPING SCREW (W/FLANGE) D4X16
HIT-984750.A186
984750
|
£1.67
|
£2.00
|
|
|
76 - NOISE SUPPRESSOR FOR EUROPE
HIT-930039.A13
930039
|
£3.85
|
£4.62
|
|
|
77 - HANDLE COVER (A)
HIT-374617.A0
374617
|
-
|
|
|
|
78 - TAPPING SCREW (W/FLANGE) D4X20 (BLACK)
HIT-301653.A187
301653
|
£1.67
|
£2.00
|
|
|
79 - GRIP SET INCLUD.1-6
HIT-375363.A4
375363
|
-
|
|
|
|
501 - CASE
HIT-374619.A3
374619
|
-
|
|
|
|
502 - SIDE HANDLE
HIT-374447.A3
374447
|
-
|
|
|
|
*503 - DEPTH GAUGE
HIT-303709.A14
303709
|
£1.67
|
£2.00
|
|
|
*503 - DEPTH GAUGE FOR MEX
HIT-310331.A0
310331
|
-
|
|
|
|
504 - CASE ASS'Y (STACKABLE 1) INCLUD.505-507
HIT-337739.A9
337739
|
-
|
|
|
|
505 - LATCH
HIT-336472.A18
336472
|
£1.67
|
£2.00
|
|
|
506 - HANDLE
HIT-336473.A56
336473
|
£6.43
|
£7.72
|
|
|
507 - HINGE
HIT-336474.A18
336474
|
£1.67
|
£2.00
|
|
|
508 - INNER TRAY
HIT-337741.A2
337741
|
-
|
|
|
|
601 - DUST COLLECTOR (B) ASS'Y INCLUD.602
HIT-306885.A8
306885
|
£25.14
|
£30.17
|
|
|
602 - DUST COLLECTOR ASS'Y INCLUD.603-609
HIT-986802.A10
986802
|
-
|
|
|
|
603 - DUST COVER
HIT-986803.A15
986803
|
-
|
|
|
|
604 - SEAL COVER
HIT-986804.A10
986804
|
-
|
|
|
|
605 - RETAINING RING FOR D30 SHAFT
HIT-948310.A25
948310
|
£1.67
|
£2.00
|
|
|
606 - WASHER
HIT-958063.A11
958063
|
-
|
|
|
|
607 - STEEL BALL D6.35 (10 PCS.)
HIT-959150.A5
959150
|
£1.67
|
£2.00
|
|
|
608 - OUTER RACE
HIT-986805.A15
986805
|
-
|
|
|
|
609 - SOCKET
HIT-986806.A10
986806
|
-
|
|
|
|
610 - SOCKET ADAPTER (B)
HIT-306910.A35
306910
|
-
|
|
|
|
611 - DUST CUP
HIT-971787.A6
971787
|
£4.40
|
£5.28
|
|
|
612 - STOPPER
HIT-931844.A22
931844
|
-
|
|
|
|
613 - DRILL CHUCK 13VLRB-D INCLUD.614
HIT-321814.A5
321814
|
-
|
|
|
|
614 - FLAT HD. SCREW (LEFT HAND) M6X20
HIT-331966.A3
331966
|
£11.39
|
£13.67
|
|
|
615 - DRILL CHUCK 13VLD-D
HIT-321813.A46
321813
|
-
|
|
|
|
616 - + DRIVER BIT (A) NO.2 25L
HIT-971511Z.A6
971511Z
|
-
|
|
|
|
617 - + DRIVER BIT (A) NO.3 25L
HIT-971512Z.A37
971512Z
|
-
|
|
|
|
618 - ANCHOR SETTING ADAPTER A W1/4 (MANUAL)
HIT-971794.A12
971794
|
-
|
|
|
|
619 - ANCHOR SETTING ADAPTER A W5/16 (MANUAL)
HIT-971795.A21
971795
|
-
|
|
|
|
620 - ANCHOR SETTING ADAPTER A W3/8 (MANUAL)
HIT-971796.A13
971796
|
-
|
|
|
|
621 - ANCHOR SETTING ADAPTER A W1/2 (MANUAL)
HIT-971797.A20
971797
|
-
|
|
|
|
622 - ANCHOR SETTING ADAPTER A W5/8 (MANUAL)
HIT-971798.A13
971798
|
-
|
|
|
|
623 - ANCHOR SETTING ADAPTER B W1/4 (MANUAL)
HIT-971799.A21
971799
|
-
|
|
|
|
624 - ANCHOR SETTING ADAPTER B W5/16 (MANUAL)
HIT-971800.A13
971800
|
-
|
|
|
|
625 - ANCHOR SETTING ADAPTER B W3/8 (MANUAL)
HIT-971801.A21
971801
|
-
|
|
|
|
626 - ANCHOR SETTING ADAPTER B W1/2 (MANUAL)
HIT-971802.A13
971802
|
-
|
|
|
|
627 - ANCHOR SETTING ADAPTER B W5/8 (MANUAL)
HIT-971803.A20
971803
|
-
|
|
|
|
628 - SYRINGE (BLOW-OUT BULB TYPE)
HIT-320859.A39
320859
|
£10.35
|
£12.42
|
|
|
629 - COTTER
HIT-944477.A5
944477
|
£5.17
|
£6.20
|
|
|
630 - CENTER PIN (A) 109L FOR CORE BIT D32-38
HIT-982684.A7
982684
|
-
|
|
|
|
631 - NO LONGER AVAILABLE
HIT-982685.A22
982685
|
-
|
|
|
|
632 - GREASE FOR ROTARY HAMMER (500G)
HIT-335781.A10
335781
|
£91.40
|
£109.68
|
|
|
633 - GREASE FOR ROTARY HAMMER (60G)
HIT-335782.A12
335782
|
£19.89
|
£23.87
|
|
