1 - FLAT HD. SCREW (A) (LEFT HAND) M6X25
HIT-995344.A0
995344
|
-
|
|
|
|
*3 - DRILL CHUCK 13VLRE-N (KEYLESS TYPE)
HIT-319546.A0
319546
|
-
|
|
|
|
4 - SPINDLE (D)
HIT-339139.A0
339139
|
-
|
|
|
|
5 - RETAINING RING FOR D35 HOLE (10 PCS.)
HIT-939556.A14
939556
|
£11.82
|
£14.18
|
|
|
6 - BALL BEARING 6202DD
HIT-6202DD.A18
6202DD
|
£7.32
|
£8.78
|
|
|
7 - RETAINING RING FOR D15 SHAFT (10 PCS.)
HIT-939544.A27
939544
|
£3.64
|
£4.37
|
|
|
8 - HEX. SOCKET HD. BOLT (W/FLANGE) M5X45
HIT-338764.A2
338764
|
-
|
|
|
|
9 - GEAR COVER (A)
HIT-339137.A0
339137
|
-
|
|
|
|
10 - WASHER (B)
HIT-322852.A6
322852
|
£1.67
|
£2.00
|
|
|
11 - DISTANCE PIECE
HIT-338744.A2
338744
|
-
|
|
|
|
12 - SECOND PINION (A)
HIT-338743.A0
338743
|
£36.66
|
£43.99
|
|
|
13 - INNER COVER (A)
HIT-339276.A0
339276
|
-
|
|
|
|
14 - SHIFT LEVER ASS'Y INCLUD.15
HIT-338737.A2
338737
|
-
|
|
|
|
15 - SHIFT PIN
HIT-322848.A6
322848
|
£1.67
|
£2.00
|
|
|
16 - O-RING (S-18)
HIT-878885.A54
878885
|
£1.67
|
£2.00
|
|
|
17 - SPRING (H)
HIT-981328.A8
981328
|
£1.67
|
£2.00
|
|
|
18 - STEEL BALL D3.5 (10 PCS.)
HIT-335299.A1
335299
|
£1.67
|
£2.00
|
|
|
19 - RETAINING RING (E-TYPE) FOR D15 SHAFT
HIT-323048.A6
323048
|
£1.67
|
£2.00
|
|
|
20 - WASHER (C)
HIT-322799.A4
322799
|
£1.67
|
£2.00
|
|
|
21 - LOW SPEED GEAR
HIT-338740.A2
338740
|
-
|
|
|
|
22 - HIGH SPEED GEAR
HIT-338741.A0
338741
|
-
|
|
|
|
23 - SHIFT ARM
HIT-338742.A2
338742
|
-
|
|
|
|
24 - PIN D5
HIT-984104.A3
984104
|
-
|
|
|
|
25 - LABEL (SLIP CLUTCH)
HIT-000000.A16
000000
|
-
|
|
|
|
26 - BALL BEARING 608DD
HIT-608DDM.A23
608DDM
|
£6.35
|
£7.62
|
|
|
*27 - ARMATURE 110V
HIT-361003B.A1
361003B
|
-
|
|
|
|
*27 - ARMATURE 230V
HIT-361003E.A0
361003E
|
-
|
|
|
|
28 - FAN GUIDE (B)
HIT-338766.A0
338766
|
-
|
|
|
|
29 - RUBBER BUSH
HIT-338755.A2
338755
|
-
|
|
|
|
*30 - STATOR 110V
HIT-340906B.A1
340906B
|
-
|
|
|
|
*30 - STATOR 230V
HIT-340906E.A0
340906E
|
£18.16
|
£21.79
|
|
|
31 - DUST SEAL
HIT-338751.A2
338751
|
-
|
|
|
|
32 - STATOR HOLDER
HIT-338750.A0
338750
|
-
|
|
|
|
33 - BALL BEARING 607VV
HIT-607VVC.A2
607VVC
|
£6.31
|
£7.57
|
|
|
34 - BEARING LOCK
HIT-931701.A19
931701
|
£1.67
|
£2.00
|
|
|
35 - HOUSING (B)
HIT-338749.A2
338749
|
-
|
|
|
|
36 - CLICK PLATE
HIT-338761.A2
338761
|
£1.67
|
£2.00
|
|
|
37A - WIRE BAND
HIT-313505.A11
313505
|
-
|
|
|
|
38 - CARBON BRUSH (1 PAIR)
HIT-999088.A12
999088
|
£5.23
|
£6.28
|
|
|
39 - SPRING
HIT-339292.A0
339292
|
-
|
|
|
|
40 - BRUSH COVER
HIT-338760.A0
338760
|
£1.67
|
£2.00
|
|
|
41A - HANDLE COVER (B) ASS'Y INCLUD.56
HIT-375876.A0
375876
|
-
|
|
|
|
42 - NAME PLATE
HIT-000000.A17
000000
|
-
|
|
|
|
43 - TAPPING SCREW (W/FLANGE) D4X20 (BLACK)
HIT-301653.A192
301653
|
£1.67
|
£2.00
|
|
|
44 - BRUSH HOLDER
HIT-338759.A2
338759
|
£5.52
|
£6.63
|
|
|
45C - HANDLE COVER (A) ASS'Y INCLUD.56
HIT-375874.A2
375874
|
-
|
|
|
|
46 - INTERNAL WIRE L100
HIT-338758.A0
338758
|
-
|
|
|
|
47 - SWITCH
HIT-338756.A0
338756
|
£29.35
|
£35.22
|
|
|
48 - INTERNAL WIRE L180
HIT-338757.A2
338757
|
-
|
|
|
|
*49 - FERRITE CORE EXCEPT FOR TPE
HIT-334379.A2
334379
|
-
|
|
|
|
*50 - CORD ARMOR D8.8
HIT-953327.A170
953327
|
£1.67
|
£2.00
|
|
|
51 - CORD CLIP
HIT-937631.A60
937631
|
£1.67
|
£2.00
|
|
|
52 - TAPPING SCREW (W/FLANGE) D4X16
HIT-984750.A173
984750
|
£1.67
|
£2.00
|
|
|
*53 - NOISE SUPPRESSOR
HIT-997174.A0
997174
|
-
|
|
|
|
*53A - NOISE SUPPRESSOR FOR GBR (110V)
HIT-930039.A7
930039
|
£3.85
|
£4.62
|
|
|
*54 - CORD (CORD ARMOR D8.8) FOR GBR (230V)
HIT-500435Z.A16
500435Z
|
£14.14
|
£16.97
|
|
|
*54 - CORD (CORD ARMOR D8.8) FOR GBR (110V)
HIT-500461Z.A12
500461Z
|
£15.56
|
£18.67
|
|
|
56 - CUSHION RUBBER
HIT-339577.A2
339577
|
-
|
|
|
|
501 - SIDE HANDLE
HIT-338768.A2
338768
|
-
|
|
|
|
502 - DEPTH GAUGE
HIT-303709.A9
303709
|
£1.67
|
£2.00
|
|
