1 - FLAT HD. SCREW (A) (LEFT HAND) M6X25
HIT-995344.A1
995344
|
-
|
|
|
|
*3 - DRILL CHUCK 13VLRE-N (KEYLESS TYPE)
HIT-319546.A1
319546
|
-
|
|
|
|
4 - SPINDLE (D)
HIT-323971.A0
323971
|
-
|
|
|
|
5 - RETAINING RING FOR D35 HOLE (10 PCS.)
HIT-939556.A15
939556
|
£11.82
|
£14.18
|
|
|
6 - BALL BEARING 6202DD
HIT-6202DD.A17
6202DD
|
£7.32
|
£8.78
|
|
|
7 - RETAINING RING FOR D15 SHAFT (10 PCS.)
HIT-939544.A25
939544
|
£3.64
|
£4.37
|
|
|
8 - TAPPING SCREW (W/FLANGE) D5X50 (BLACK)
HIT-322869.A0
322869
|
-
|
|
|
|
9 - GEAR COVER (A)
HIT-323959.A0
323959
|
-
|
|
|
|
10 - WASHER (B)
HIT-322852.A5
322852
|
£1.67
|
£2.00
|
|
|
11 - SECOND PINION AND GEAR SET
HIT-322867.A0
322867
|
£43.58
|
£52.30
|
|
|
12 - INNER COVER (A)
HIT-323972.A0
323972
|
-
|
|
|
|
13 - O-RING (S-22)
HIT-306353.A6
306353
|
£1.67
|
£2.00
|
|
|
14 - SHIFT PIN
HIT-322848.A5
322848
|
£1.67
|
£2.00
|
|
|
15 - SHIFT LEVER ASS'Y INCLUD.13
HIT-322847.A0
322847
|
£4.99
|
£5.99
|
|
|
16 - SPRING (H)
HIT-981328.A7
981328
|
£1.67
|
£2.00
|
|
|
17A - STEEL BALL D3.5 (10 PCS.)
HIT-335299.A0
335299
|
£1.67
|
£2.00
|
|
|
18 - RETAINING RING (E-TYPE) FOR D15 SHAFT
HIT-323048.A5
323048
|
£1.67
|
£2.00
|
|
|
19 - SHIFT ARM
HIT-322849.A0
322849
|
£1.67
|
£2.00
|
|
|
20 - PIN D5
HIT-984104.A2
984104
|
-
|
|
|
|
21 - GEAR SET
HIT-322846.A2
322846
|
£28.41
|
£34.09
|
|
|
22 - LABEL (FOR SLIP CLUTCH)
HIT-000000.A12
000000
|
-
|
|
|
|
23 - BALL BEARING 608DD
HIT-608DDM.A24
608DDM
|
£6.35
|
£7.62
|
|
|
*24 - ARMATURE 110V
HIT-360652C.A2
360652C
|
£40.43
|
£48.52
|
|
|
*24 - ARMATURE 230V
HIT-360652E.A0
360652E
|
£40.43
|
£48.52
|
|
|
25 - FAN GUIDE
HIT-322843.A2
322843
|
£3.26
|
£3.91
|
|
|
26 - HEX. HD. TAPPING SCREW D4X50
HIT-961672.A0
961672
|
-
|
|
|
|
*27 - STATOR 110V
HIT-340587C.A1
340587C
|
£35.74
|
£42.89
|
|
|
*27 - STATOR 230V
HIT-340587E.A0
340587E
|
£27.37
|
£32.84
|
|
|
28A - BALL BEARING 698VVC2
HIT-698VVC.A3
698VVC
|
£5.05
|
£6.06
|
|
|
29 - RUBBER BUSHING
HIT-309929.A29
309929
|
£1.67
|
£2.00
|
|
|
30A - HOUSING.HANDLE COVER SET
HIT-331663.A2
331663
|
£47.79
|
£57.35
|
|
|
31 - NAME PLATE
HIT-000000.A13
000000
|
-
|
|
|
|
32 - TAPPING SCREW (W/FLANGE) D4X20 (BLACK)
HIT-301653.A193
301653
|
£1.67
|
£2.00
|
|
|
34 - PUSHING BUTTON
HIT-322853.A0
322853
|
£1.67
|
£2.00
|
|
|
35 - SWITCH (1P PILLAR TYPE)
HIT-322854.A2
322854
|
£24.27
|
£29.12
|
|
|
*36 - CHOKE COIL (BROWN) 220V-240V
HIT-322517.A4
322517
|
£11.35
|
£13.62
|
|
|
*36 - CHOKE COIL (BROWN) 110V FOR GBR (110V)
HIT-322518.A0
322518
|
£11.35
|
£13.62
|
|
|
37 - CARBON BRUSH (1 PAIR)
HIT-999041.A65
999041
|
£5.54
|
£6.65
|
|
|
38 - BRUSH HOLDER
HIT-955203.A47
955203
|
£4.16
|
£4.99
|
|
|
39 - BRAND LABEL
HIT-000000.A14
000000
|
-
|
|
|
|
40 - NOISE SUPPRESSOR
HIT-994273.A23
994273
|
£7.30
|
£8.76
|
|
|
41 - EARTH TERMINAL
HIT-992635.A2
992635
|
£1.67
|
£2.00
|
|
|
*42 - CHOKE COIL (BLUE) 110V-240V
HIT-321634.A1
321634
|
£9.43
|
£11.32
|
|
|
*42 - CHOKE COIL (BLUE) 110V FOR GBR (110V)
HIT-322519.A4
322519
|
£8.74
|
£10.49
|
|
|
43 - TAPPING SCREW (W/FLANGE) D4X16
HIT-984750.A170
984750
|
£1.67
|
£2.00
|
|
|
44 - CORD CLIP
HIT-937631.A57
937631
|
£1.67
|
£2.00
|
|
|
45 - CORD ARMOR D8.8
HIT-953327.A174
953327
|
£1.67
|
£2.00
|
|
|
*46 - CORD (CORD ARMOR D8.8) FOR GBR (110V)
HIT-500461Z.A10
500461Z
|
£15.56
|
£18.67
|
|
|
*46 - CORD (CORD ARMOR D8.8) FOR GBR (230V)
HIT-500435Z.A15
500435Z
|
£14.14
|
£16.97
|
|
|
501 - SIDE HANDLE
HIT-323050.A0
323050
|
£28.41
|
£34.09
|
|
|
502 - DEPTH GAUGE
HIT-303709.A8
303709
|
£1.67
|
£2.00
|
|
