1 - SPECIAL SCREW (LEFT HAND) M6X23
HIT-311959.A10
311959
|
£1.67
|
£2.00
|
|
|
*4 - DRILL CHUCK 10VLRD-N (W/O CHUCK WRENCH)
HIT-319343.A0
319343
|
-
|
|
|
|
5 - SPINDLE (A)
HIT-319346.A0
319346
|
£18.63
|
£22.36
|
|
|
6 - RETAINING RING FOR D32 HOLE
HIT-948001.A4
948001
|
£1.67
|
£2.00
|
|
|
7 - BALL BEARING 6002VVCMPS2L
HIT-6002VV.A18
6002VV
|
£9.32
|
£11.19
|
|
|
8 - RETAINING RING FOR D15 SHAFT (10 PCS.)
HIT-939544.A14
939544
|
£3.64
|
£4.37
|
|
|
9 - TAPPING SCREW (W/FLANGE) D5X60
HIT-305701.A0
305701
|
£1.67
|
£2.00
|
|
|
10 - GEAR COVER (A)
HIT-319345.A1
319345
|
£30.87
|
£37.04
|
|
|
11 - BALL BEARING 627VVC2PS2L
HIT-627VVM.A2
627VVM
|
£7.30
|
£8.76
|
|
|
12 - FINAL GEAR (A)
HIT-319347.A0
319347
|
-
|
|
|
|
13 - SECOND PINION (A)
HIT-319545.A0
319545
|
-
|
|
|
|
14 - FIRST GEAR
HIT-319544.A0
319544
|
£7.99
|
£9.59
|
|
|
15 - BALL BEARING 606VV
HIT-606ZZM.A26
606ZZM
|
£14.07
|
£16.88
|
|
|
16 - TAPPING SCREW D5X40 (BLACK)
HIT-316458.A1
316458
|
-
|
|
|
|
17 - INNER COVER
HIT-319344.A0
319344
|
-
|
|
|
|
18 - BALL BEARING 608DD
HIT-608DDM.A44
608DDM
|
£6.35
|
£7.62
|
|
|
*19 - ARMATURE ASS'Y 110V-120V INCLUD.18
HIT-360543U.A1
360543U
|
£66.83
|
£80.20
|
|
|
*19 - ARMATURE 220V-230V
HIT-360543E.A0
360543E
|
£66.83
|
£80.20
|
|
|
20 - FAN GUIDE
HIT-319329.A1
319329
|
-
|
|
|
|
21 - HEX. HD. TAPPING SCREW D4X55
HIT-981421.A1
981421
|
-
|
|
|
|
*22 - STATOR 110V
HIT-340486D.A1
340486D
|
£38.90
|
£46.68
|
|
|
*22 - STATOR 230V-240V
HIT-340504E.A1
340504E
|
£38.90
|
£46.68
|
|
|
23 - WASHER (A)
HIT-982631.A2
982631
|
£1.67
|
£2.00
|
|
|
24 - BALL BEARING 608VVC2PS2L
HIT-608VVM.A217
608VVM
|
£5.70
|
£6.84
|
|
|
25 - HOUSING
HIT-319328.A1
319328
|
£16.38
|
£19.65
|
|
|
26 - NAME PLATE
HIT-000000.A1666
000000
|
-
|
|
|
|
27 - HANDLE (B)
HIT-319331.A0
319331
|
-
|
|
|
|
28 - TAPPING SCREW (W/FLANGE) D4X35 (BLACK)
HIT-303694.A9
303694
|
£1.67
|
£2.00
|
|
|
29 - TAPPING SCREW (W/FLANGE) D4X20 (BLACK)
HIT-301653.A223
301653
|
£1.67
|
£2.00
|
|
|
30 - GRIP COVER
HIT-319332.A2
319332
|
£16.02
|
£19.22
|
|
|
31 - SCREW (PLASTIC TIE) D4X25
HIT-319337.A1
319337
|
£1.67
|
£2.00
|
|
|
32 - BRAND LABEL
HIT-000000.A1667
000000
|
-
|
|
|
|
33 - HANDLE (A)
HIT-319330.A2
319330
|
-
|
|
|
|
34 - BRUSH HOLDER
HIT-955203.A37
955203
|
£4.16
|
£4.99
|
|
|
*35 - CHOKE COIL (BLUE) 220V-240V FOR EUROPE
HIT-320197.A2
320197
|
-
|
|
|
|
*35 - CHOKE COIL (BLUE) 110V FOR GBR (110V)
HIT-320204.A0
320204
|
-
|
|
|
|
36 - CARBON BRUSH (1 PAIR)
HIT-999041.A43
999041
|
£5.54
|
£6.65
|
|
|
*37 - CHOKE COIL (BROWN) 220V-240V FOR EUROPE
HIT-320196.A0
320196
|
-
|
|
|
|
*37 - CHOKE COIL (BROWN) 110V FOR GBR (110V)
HIT-320203.A2
320203
|
-
|
|
|
|
38 - PUSHING BUTTON
HIT-316166.A1
316166
|
£1.67
|
£2.00
|
|
|
*39 - SWITCH (1P SCREW TYPE) W/LOCK FOR EUROPE
HIT-320195.A2
320195
|
£28.14
|
£33.77
|
|
|
*39 - SWITCH (1P SCREW TYPE) W/LOCK FOR USA
HIT-319339.A1
319339
|
£28.14
|
£33.77
|
|
|
40 - TAPPING SCREW (W/FLANGE) D4X16
HIT-984750.A214
984750
|
£1.67
|
£2.00
|
|
|
41 - CORD CLIP
HIT-937631.A49
937631
|
£1.67
|
£2.00
|
|
|
42 - TUBE (D)
HIT-981373.A49
981373
|
£1.67
|
£2.00
|
|
|
43 - CORD ARMOR D8.8
HIT-953327.A91
953327
|
£1.67
|
£2.00
|
|
|
*44 - CORD (CORD ARMOR D8.8) FOR GBR (110V)
HIT-500461Z.A31
500461Z
|
£15.56
|
£18.67
|
|
|
*44 - CORD (CORD ARMOR D8.8) FOR GBR (230V)
HIT-500435Z.A32
500435Z
|
£14.14
|
£16.97
|
|
|
*45 - NOISE SUPPRESSOR EXCEPT FOR USA
HIT-320198.A0
320198
|
-
|
|
|
|
501 - SIDE HANDLE FOR M10
HIT-981205.A2
981205
|
£6.72
|
£8.06
|
|
|
502A - CASE
HIT-319543.A1
319543
|
-
|
|
|
|
601 - HOOK (A)
HIT-317676.A1
317676
|
-
|
|
|
