1 - START LABEL (C51) (EX)
HIT-6698919.A2
6698919
|
-
|
|
|
|
2 - CLEANER COVER (C51)
HIT-6698568.A1
6698568
|
-
|
|
|
|
3 - SHUTTER PLATE
HIT-6698569.A2
6698569
|
-
|
|
|
|
4A - COVER SET BOLT (B)
HIT-6699189.A2
6699189
|
-
|
|
|
|
5 - CYLINDER COVER (C51)
HIT-6698708.A2
6698708
|
-
|
|
|
|
6 - CLEANER KNOB (VERMILLION)
HIT-6698595.A2
6698595
|
-
|
|
|
|
7 - KNOB PACKING
HIT-6698570.A1
6698570
|
£2.49
|
£2.99
|
|
|
8 - CLEANER ELEMENT (B)
HIT-6698563.A2
6698563
|
-
|
|
|
|
9 - CLEANER ELEMENT (A)
HIT-6698562.A1
6698562
|
£7.03
|
£8.44
|
|
|
10 - NUT M6
HIT-6698449.A2
6698449
|
£1.67
|
£2.00
|
|
|
11 - WASHER SINCE 2.2016
HIT-6696885.A2
6696885
|
-
|
|
|
|
12 - SPRING HOLDER
HIT-6698429.A2
6698429
|
-
|
|
|
|
13 - HEX. SOCKET HD. BOLT (W/FLANGE) M6X20
HIT-881722.A4
881722
|
£1.67
|
£2.00
|
|
|
14 - ANTIVIBRATION SPRING
HIT-6698428.A3
6698428
|
-
|
|
|
|
15 - DAMPER SET BOLT
HIT-6685413.A5
6685413
|
-
|
|
|
|
16 - SEAL LOCK SCREW M4X10
HIT-6696835.A12
6696835
|
-
|
|
|
|
16A - SEAL LOCK SCREW M4X10
HIT-324082.A2
324082
|
£1.67
|
£2.00
|
|
|
17 - SCAVENGING COVER (B)
HIT-6698539.A1
6698539
|
-
|
|
|
|
18 - COVER PACKING (C51)
HIT-6698540.A2
6698540
|
-
|
|
|
|
19 - EXHAUST PIPE (C51)
HIT-6698903.A1
6698903
|
-
|
|
|
|
20 - MUFFLER GAUZE (C51)
HIT-6698575.A0
6698575
|
-
|
|
|
|
21 - TAPPING SCREW (W/FLANGE) D5X25 (BLACK)
HIT-305558.A21
305558
|
£1.67
|
£2.00
|
|
|
22A - FRONT HANDLE (B) (C51)
HIT-6699026.A1
6699026
|
-
|
|
|
|
23 - TAPPING SCREW (W/FLANGE) D5X20 (BLACK)
HIT-302089.A37
302089
|
£1.67
|
£2.00
|
|
|
24 - HEX. SOCKET HD. BOLT M4X10 (10 PCS.)
HIT-949812.A25
949812
|
£2.98
|
£3.57
|
|
|
25 - BOLT WASHER M4 (BLACK)
HIT-323210.A37
323210
|
-
|
|
|
|
26 - MUFFLER PROTECTOR
HIT-6698904.A2
6698904
|
£3.56
|
£4.27
|
|
|
27 - MUFFLER PROTECTOR GAUZE
HIT-6698905.A1
6698905
|
£1.67
|
£2.00
|
|
|
28 - MACHINE SCREW M4X16 (10 PCS.)
HIT-949219.A15
949219
|
-
|
|
|
|
29 - OIL PIPE (CS40)
HIT-6698900.A2
6698900
|
-
|
|
|
|
30 - OIL PUMP
HIT-6698554.A1
6698554
|
-
|
|
|
|
31 - CLIP
HIT-6685311.A5
6685311
|
£1.67
|
£2.00
|
|
|
32 - SEAL LOCK HEX. SOCKET HD. BOLT M5
HIT-6685412.A3
6685412
|
-
|
|
|
|
33 - SEAL LOCK SCREW M5X12
HIT-6698901.A1
6698901
|
-
|
|
|
|
34 - SPIKE
HIT-6685400.A1
6685400
|
-
|
|
|
|
35 - SEAL LOCK HEX. SOCKET HD. BOLT M5X45
HIT-6698902.A2
6698902
|
-
|
|
|
|
36 - MUFFLER CAP
HIT-6698706.A0
6698706
|
-
|
|
|
|
37 - SEAL LOCK HEX. SOCKET HD. BOLT M6X20
HIT-6698899.A5
6698899
|
£1.67
|
£2.00
|
|
|
38 - HEX. SOCKET HD. BOLT M5X12 (PRECOAT)
HIT-6696836.A0
6696836
|
-
|
|
|
|
39 - MUFFLER (C51)
HIT-6698574.A1
6698574
|
-
|
|
|
|
40 - MUFFLER PACKING (C51)
HIT-6698576.A3
6698576
|
-
|
|
|
|
41A - GROMMET
HIT-6699944.A3
6699944
|
-
|
|
|
|
42 - WORM SET INCLUD.11
HIT-6600928.A2
6600928
|
-
|
|
|
|
43 - FUEL PIPE 2.5X4X90
HIT-6685267.A17
6685267
|
£1.67
|
£2.00
|
|
|
44 - PRIMING PUMP COMP.
HIT-6685139.A115
6685139
|
£10.67
|
£12.80
|
|
|
45 - DECOMP.
HIT-6698541.A2
6698541
|
£32.28
|
£38.73
|
|
|
46A - SPARK PLUG ASS'Y BPMR7A
HIT-6699320.A6
6699320
|
-
|
|
|
|
47 - INTAKE PACKING (C51)
HIT-6698549.A1
6698549
|
-
|
|
|
|
48 - INTAKE (CS51)
HIT-6698906.A2
6698906
|
-
|
|
|
|
49 - CAB. INSULATOR RUBBER
HIT-6698551.A2
6698551
|
-
|
|
|
|
50 - CARBURETOR INSULATOR (C51)
HIT-6698552.A1
6698552
|
-
|
|
|
|
51 - FUEL PIPE (FKM) 3X6X80
HIT-6698907.A1
6698907
|
-
|
|
|
|
52 - CARBURETOR ASS'Y INCLUD.53-67
HIT-6698705.A3
6698705
|
-
|
|
|
|
53 - SCREW
HIT-6685210.A70
6685210
|
-
|
|
|
|
54 - PUMP GASKET
HIT-6685212.A52
6685212
|
£3.29
|
£3.95
|
|
|
55 - PUMP DIAPHRAGM
HIT-6685213.A4
6685213
|
£8.44
|
£10.13
|
|
|
56 - INLET SCREEN
HIT-6684700.A73
6684700
|
-
|
|
|
|
57 - NEEDLE VALVE
HIT-6685215.A82
6685215
|
£6.79
|
£8.15
|
|
|
58 - VALVE SPRING
HIT-6690873.A20
6690873
|
-
|
|
|
|
59 - DIAPHRAGM PACKING-METERING
HIT-6685220.A18
6685220
|
£2.81
|
£3.37
|
|
|
60 - METERING DIAPHRAGM
HIT-6684690.A91
6684690
|
£24.05
|
£28.86
|
|
|
61 - DIAPHRAGM COVER-METERING
HIT-6685222.A161
6685222
|
£5.70
|
£6.84
|
|
|
62 - IDLE ADJUST SPRING
HIT-6690766.A26
6690766
|
-
|
|
|
|
63 - IDLE ADJUST SCREW
HIT-6685298.A4
6685298
|
£1.67
|
£2.00
|
|
|
64 - HINGE PIN SET SCREW
HIT-6685218.A4
6685218
|
-
|
|
|
|
65 - CONTROL LEVER
HIT-6685217.A60
6685217
|
-
|
|
|
|
66 - HINGE PIN
HIT-6685219.A84
6685219
|
-
|
|
|
|
67 - SET SCREW
HIT-6685223.A4
6685223
|
-
|
|
|
|
68 - FUEL PIPE 3X5X290
HIT-6698908.A4
6698908
|
£7.75
|
£9.30
|
|
|
69 - WASHER 5
HIT-6685408.A6
6685408
|
£3.49
|
£4.19
|
|
|
70 - HEX. SOCKET HD. BOLT M5X45
HIT-6696317.A4
6696317
|
-
|
|
|
|
71A - CLEANER SUPPORT (C51)
HIT-6698553.A1
6698553
|
-
|
|
|
|
72 - FUEL PIPE 2X4X100
HIT-6698721.A2
6698721
|
-
|
|
|
|
73 - CYLINDER
HIT-6698537.A2
6698537
|
-
|
|
|
|
74 - SCAVENGING COVER (A)
HIT-6698538.A1
6698538
|
-
|
|
|
|
75 - CYLINDER PACKING (C51)
HIT-6698542.A2
6698542
|
-
|
|
|
|
76 - PISTON RING
HIT-6698534.A1
6698534
|
£14.28
|
£17.13
|
|
|
77 - PISTON (44) (M)
HIT-6698909.A1
6698909
|
£35.00
|
£42.00
|
|
|
78 - CIR CLIP
HIT-6696854.A2
6696854
|
£1.67
|
£2.00
|
|
|
79 - PISTON PIN COLLAR (C51)
HIT-6698910.A2
6698910
|
-
|
|
|
|
80A - ENGINE CASE (B) ASS'Y INCLUD.41A
HIT-6699945.A0
6699945
|
-
|
|
|
|
81 - OIL SEAL
HIT-6698914.A5
6698914
|
£5.25
|
£6.30
|
|
|
82 - BALL BEARING 6202C3
HIT-6202C3.A2
6202C3
|
£7.83
|
£9.40
|
|
|
83 - CRANK SHAFT
HIT-6698532.A2
6698532
|
-
|
|
|
|
84 - CRANK CASE PACKING (C51)
HIT-6698535.A2
6698535
|
-
|
|
|
|
85 - PISTON PIN
HIT-6696855.A3
6696855
|
£3.02
|
£3.63
|
|
|
86 - NEEDLE BEARING (A)
HIT-6698911.A1
6698911
|
-
|
|
|
|
87 - ENGINE CASE (A) ASS'Y INCLUD.81
HIT-6698530.A1
6698530
|
-
|
|
|
|
88 - REAR DAMPER (C51)
HIT-6698709.A0
6698709
|
-
|
|
|
|
89 - BRAKE HANDLE
HIT-6698572.A1
6698572
|
-
|
|
|
|
90 - CAUTION LABEL (B) (RUS) FOR RUS
HIT-6698973.A0
6698973
|
-
|
|
|
|
*90 - CAUTION LABEL (E)
HIT-6696336.A0
6696336
|
-
|
|
|
|
*90 - CAUTION LABEL (D) FOR AUS
HIT-6696335.A2
6696335
|
-
|
|
|
|
91 - BRAKE LEVER SPRING (B)
HIT-6698912.A2
6698912
|
-
|
|
|
|
92 - CHOKE ROD RUBBER
HIT-6685369.A6
6685369
|
£1.67
|
£2.00
|
|
|
93 - CHOKE BUTTON (VERMILION)
HIT-6698593.A1
6698593
|
-
|
|
|
|
94 - OPERATION PLATE
HIT-6698565.A2
6698565
|
-
|
|
|
|
95A - STOP SWITCH
HIT-6601275.A8
6601275
|
£1.67
|
£2.00
|
|
|
96 - HEX. SOCKET HD. BOLT (W/BUTTON) M5X20
HIT-6698988.A15
6698988
|
£1.67
|
£2.00
|
|
|
98A - CHAIN BAR BOLT
HIT-6699029.A1
6699029
|
-
|
|
|
|
111 - NAME PLATE
HIT-000000.A911
000000
|
-
|
|
|
|
112 - FLANGE NUT M8
HIT-6698581.A11
6698581
|
£1.67
|
£2.00
|
|
|
112A - FLANGE NUT (B) M8
HIT-6699028.A2
6699028
|
-
|
|
|
|
113A - SIDE CASE SUB
HIT-6698585.A3
6698585
|
-
|
|
|
|
114 - CHAIN PULLER BOLT
HIT-6698591.A1
6698591
|
£10.77
|
£12.92
|
|
|
*115 - SAW CHAIN 13 INCH
HIT-6687270.A5
6687270
|
-
|
|
|
|
*115 - SAW CHAIN 15 INCH
HIT-6687335.A7
6687335
|
£30.92
|
£37.11
|
|
|
*115 - SAW CHAIN 16 INCH
HIT-6687296.A3
6687296
|
-
|
|
|
|
*115 - SAW CHAIN 18 INCH
HIT-6687284.A1
6687284
|
£35.37
|
£42.44
|
|
|
*115 - SAW CHAIN 20 INCH 0.325
HIT-6698710.A3
6698710
|
£47.04
|
£56.45
|
|
|
116 - GUIDE PLATE (B)
HIT-6698592.A2
6698592
|
-
|
|
|
|
*117 - CHAIN BAR 13 INCH
HIT-6696911.A0
6696911
|
£46.08
|
£55.29
|
|
|
*117 - CHAIN BAR 15 INCH
HIT-6696912.A2
6696912
|
£50.30
|
£60.36
|
|
|
*117 - CHAIN BAR 16 INCH
HIT-6696983.A1
6696983
|
£50.30
|
£60.36
|
|
|
*117 - CHAIN BAR 18 INCH
HIT-6696982.A1
6696982
|
£59.38
|
£71.26
|
|
|
*117 - CHAIN BAR 20 INCH
HIT-6698641.A1
6698641
|
-
|
|
|
|
118 - OIL GROMMET (A)
HIT-6696868.A2
6696868
|
-
|
|
|
|
119 - FUEL PIPE
HIT-6698719.A4
6698719
|
-
|
|
|
|
120 - BOLT WASHER D5
HIT-6685407.A44
6685407
|
-
|
|
|
|
121 - OIL FILTER
HIT-6698455.A2
6698455
|
-
|
|
|
|
122 - OIL FILTER BODY
HIT-6698536.A2
6698536
|
-
|
|
|
|
123 - GUIDE PLATE (A)
HIT-6698561.A2
6698561
|
-
|
|
|
|
124 - DAMPER (C51)
HIT-6698913.A1
6698913
|
-
|
|
|
|
125A - CHAIN CATCHER
HIT-6699027.A1
6699027
|
£1.67
|
£2.00
|
|
|
126 - BRAKE LINK
HIT-6698587.A3
6698587
|
-
|
|
|
|
127 - BRAKE SPRING
HIT-6698588.A2
6698588
|
-
|
|
|
|
128 - BRAKE BAND
HIT-6698589.A1
6698589
|
£9.52
|
£11.42
|
|
|
129 - NEEDLE ROLLER D3
HIT-6685391.A3
6685391
|
£3.49
|
£4.19
|
|
|
130 - BRAKE LINK COVER
HIT-6698590.A2
6698590
|
-
|
|
|
|
131 - CLUTCH
HIT-6698560.A1
6698560
|
£18.52
|
£22.23
|
|
|
132 - CLUTCH WASHER (B)
HIT-6696882.A2
6696882
|
-
|
|
|
|
133 - CLUTCH HOUSING
HIT-6698558.A2
6698558
|
-
|
|
|
|
134 - NEEDLE BEARING
HIT-6696884.A2
6696884
|
£7.12
|
£8.54
|
|
|
135 - RIM SPROCKET
HIT-6698557.A1
6698557
|
-
|
|
|
|
136 - CLUTCH WASHER
HIT-6698556.A2
6698556
|
-
|
|
|
|
137 - OIL PUMP COVER (C51)
HIT-6698555.A1
6698555
|
-
|
|
|
|
138A - WORM SINCE. 2.2016
HIT-6600927.A1
6600927
|
-
|
|
|
|
139 - AIR VENT SPONGE
HIT-6685371.A6
6685371
|
£3.49
|
£4.19
|
|
|
140 - AIR VENT VALVE (B)
HIT-6685370.A9
6685370
|
£6.75
|
£8.10
|
|
|
141 - TAPPING SCREW (W/FLANGE) D4X16 (BLACK)
HIT-305812.A56
305812
|
£1.67
|
£2.00
|
|
|
142 - REAR HANDLE GRIP
HIT-6698805.A4
6698805
|
£1.67
|
£2.00
|
|
|
143 - TRIGGER LOCKOUT (VERMILION)
HIT-6685350.A6
6685350
|
£1.67
|
£2.00
|
|
|
144A - THROTTLE LEVER SPRING
HIT-6600341.A7
6600341
|
£1.67
|
£2.00
|
|
|
145 - NUMBER PLATE
HIT-000000.A912
000000
|
-
|
|
|
|
146 - REAR HANDLE
HIT-6698579.A3
6698579
|
-
|
|
|
|
147 - SPRING PIN 5X25
HIT-6685282.A20
6685282
|
£1.67
|
£2.00
|
|
|
148 - THROTTLE ROD
HIT-6698564.A1
6698564
|
-
|
|
|
|
149 - THROTTLE LEVER (VERMILION)
HIT-6698916.A1
6698916
|
-
|
|
|
|
150 - AIR VALVE CAP
HIT-6698580.A0
6698580
|
-
|
|
|
|
151 - INNER CAP
HIT-6685351.A9
6685351
|
-
|
|
|
|
152 - FUEL GROMMET
HIT-6696167.A11
6696167
|
-
|
|
|
|
153 - PUMP FILTER BODY
HIT-6692285.A17
6692285
|
£10.40
|
£12.48
|
|
|
154 - FRONT DAMPER
HIT-6696873.A3
6696873
|
£1.67
|
£2.00
|
|
|
155 - SPRING HOLDER
HIT-6698409.A7
6698409
|
-
|
|
|
|
156 - FLANGED TAPPING SCREW D6
HIT-6696872.A4
6696872
|
£1.67
|
£2.00
|
|
|
157 - ANTIVIBRATION SPRING
HIT-6698408.A4
6698408
|
-
|
|
|
|
*158 - TANK MARK LABEL (50:1)
HIT-6698921.A24
6698921
|
-
|
|
|
|
*158 - TANK MARK LABEL (25:1) FOR ASIA
HIT-6698922.A20
6698922
|
-
|
|
|
|
159 - TANK CAP PACKING
HIT-6685179.A33
6685179
|
£1.67
|
£2.00
|
|
|
160 - FUEL TANK CAP ASS'Y (VERMILION) INCLUD.159
HIT-6698854.A6
6698854
|
£7.03
|
£8.44
|
|
|
161 - CABLE TIE
HIT-988054.A5
988054
|
-
|
|
|
|
162 - PLUG CAP
HIT-6698548.A5
6698548
|
-
|
|
|
|
163 - CORD (A)
HIT-6698545.A1
6698545
|
-
|
|
|
|
164 - CORD (B)
HIT-6698546.A2
6698546
|
-
|
|
|
|
165A - METAL OF PLUG CAP (60) (B)
HIT-6699180.A15
6699180
|
-
|
|
|
|
166 - IGNITION COIL
HIT-6698544.A2
6698544
|
£59.46
|
£71.35
|
|
|
167 - HEX. SOCKET HD. BOLT (W/FLANGE) M4X18
HIT-6696326.A29
6696326
|
-
|
|
|
|
168 - MAGNETO ASS'Y INCLUD.169-174
HIT-6698918.A2
6698918
|
-
|
|
|
|
169 - MAGNETO ROTOR
HIT-6698543.A1
6698543
|
-
|
|
|
|
170A - STARTER PAWL SPRING (B)
HIT-6699405.A3
6699405
|
-
|
|
|
|
171 - WASHER 0.8
HIT-6696857.A8
6696857
|
£1.67
|
£2.00
|
|
|
172 - STARTER PAWL
HIT-6696877.A4
6696877
|
-
|
|
|
|
173 - SHIM
HIT-6696434.A4
6696434
|
-
|
|
|
|
174 - STEP BOLT
HIT-6696878.A1
6696878
|
£1.67
|
£2.00
|
|
|
175 - AIR DEFLECTOR
HIT-6698571.A2
6698571
|
-
|
|
|
|
176A - RECOIL STARTER INCLUD.180-183
HIT-6699421.A2
6699421
|
-
|
|
|
|
177 - BRAND LABEL
HIT-000000.A913
000000
|
-
|
|
|
|
179 - FUEL TANK CAP ASS'Y (BLACK) INCLUD.159
HIT-6698358.A7
6698358
|
£3.56
|
£4.27
|
|
|
180 - SET SCREW
HIT-6699477.A2
6699477
|
-
|
|
|
|
181 - WASHER
HIT-6699474.A2
6699474
|
-
|
|
|
|
182 - REEL
HIT-6699482.A1
6699482
|
-
|
|
|
|
183 - SPIRAL SPRING CASE
HIT-6699480.A5
6699480
|
£9.34
|
£11.21
|
|
|
184 - STARTER ROPE
HIT-6699470.A3
6699470
|
-
|
|
|
|
185 - STARTER KNOB
HIT-6699466.A2
6699466
|
-
|
|
|
|
186 - STARTER HANDLE ASS'Y INCLUD.184
HIT-6699472.A1
6699472
|
-
|
|
|
|
187 - FAN CASE
HIT-6699488.A1
6699488
|
-
|
|
|
|
188 - FLANGE NUT M6
HIT-329934.A3
329934
|
-
|
|
|
|
*501 - CHAIN COVER 14 FOR 13
HIT-6685439.A8
6685439
|
-
|
|
|
|
*501 - CHAIN COVER 16
HIT-6696909.A2
6696909
|
£6.50
|
£7.80
|
|
|
*501 - CHAIN COVER 18
HIT-6696910.A3
6696910
|
£6.50
|
£7.80
|
|
|
*501 - CHAIN COVER 20
HIT-6698577.A0
6698577
|
-
|
|
|
|
502 - COMBI BOX SPANNER 13X19
HIT-6698582.A0
6698582
|
£6.50
|
£7.80
|
|
