Hitachi / Hikoki CS45EM Engine Chain Saw Spare Parts

An exploded diagram and spare parts listing for the Hitachi / Hikoki CS45EM Engine Chain Saw

	Ex VAT	Inc VAT
1 - CYLINDER SET # HIT-6685469.A2 6685469	-
2 - CYLINDER GASKET # HIT-6685735.A0 6685735	£5.97	£7.16
3 - SPECIAL SCREW M5X20 HIT-6692328.A0 6692328	-
4 - DECOMPRESSION COMP. # HIT-6685590.A2 6685590	-
5 - DECOMP COVER HIT-6685801.A0 6685801	-
6 - PISTON PIN CIRCLIP HIT-6686031.A0 6686031	-
7 - PISTONRING # HIT-6686127.A2 6686127	-
8 - PISTON SET # HIT-6685886.A2 6685886	£50.82	£60.99
9 - PISTON PIN # HIT-6686013.A0 6686013	-
10 - PISTON PIN COLLAR # HIT-6685994.A2 6685994	-
11 - NEEDLE BEARING # HIT-6695607.A2 6695607	-
12 - CRANK SHAFT COMP. # HIT-6686187.A0 6686187	-
13 - WOOD -RUFF KEY # HIT-6686458.A3 6686458	-
21 - BAR TIGHTENING BOLT # HIT-6686806.A0 6686806	-
22 - OIL SEAL ISD15284.5 # HIT-6695640.A0 6695640	-
23 - FLY WHEEL WASHER HIT-6686439.A0 6686439	-
24 - FLY WHEEL NUT HIT-6686444.A0 6686444	-
25 - SPECIAL SCREW M5X25 HIT-6692329.A2 6692329	-
26 - OIL SEAL ISCD 15354.5 # HIT-6695642.A0 6695642	-
27 - STOPPER A # HIT-6688547.A0 6688547	-
28 - STOPPER B # HIT-6688557.A0 6688557	-
29 - DAMPER CAP A HIT-6688183.A2 6688183	-
30 - SPECIAL SCREW M5X16 HIT-6692334.A1 6692334	-
31 - FRONT DAMPER COMP. # HIT-6688114.A2 6688114	-
32 - OIL TANK CAP ASS'Y # HIT-6692156.A0 6692156	-
33 - CRANK CASE ASS'Y # HIT-6686545.A0 6686545	-
34 - PIN HIT-6686630.A2 6686630	-
35 - OIL TANK CAP PACKING HIT-6691244.A2 6691244	-
36 - STOP RING C 1 HIT-6685866.A0 6685866	-
37 - BEARING # HIT-6686682.A0 6686682	-
38 - H.L GROMMET # HIT-6687981.A0 6687981	-
39 - CRANK CASE GASKET # HIT-6686711.A2 6686711	-
40 - PLATE # HIT-6690788.A2 6690788	-
41 - MAGNETO ROTOR ASS'Y # HIT-6687356.A2 6687356	-
42 - STOP RING E HIT-6693660.A1 6693660	-
43 - PAWL SPRING # HIT-6693349.A2 6693349	-
44 - STARTER PAWL HIT-6693306.A0 6693306	-
45 - MACHINE SCREW (W/WASHERS) M4X10 HIT-6696989.A2 6696989	-
61 - IGNITION COIL ASS'Y # HIT-6687348.A0 6687348	-
62 - CORD # HIT-6687844.A0 6687844	-
63 - PLUG CAP ASS'Y # HIT-6687471.A2 6687471	-
64 - SPARK PLUG ASS'Y RCJ6Y HIT-6699326.A10 6699326	£5.70	£6.84
65 - SPARK PLUG COVER # HIT-6688335.A2 6688335	-
67 - STOP CORD # HIT-6687930.A0 6687930	-
68 - STOP SWITCH COMP. # HIT-6687742.A0 6687742	-
69 - STOP BUTTON COVER HIT-6688406.A2 6688406	-
70 - STOP BUTTON STAY # HIT-6692131.A0 6692131	-
71 - SPECIAL SCREW M5X10 HIT-6692337.A6 6692337	-
72 - INSULATOR TUBE # HIT-6688318.A2 6688318	-
73 - STOP SWITCH ASS'Y # HIT-6687507.A2 6687507	-
74 - AIR DEFLECTOR # HIT-6687330.A2 6687330	-
75 - DAMPER SEAT # HIT-6688258.A0 6688258	-
76 - SPECIAL SCREW M5X20 HIT-6692336.A0 6692336	-
91 - AIR VENT VALVE B HIT-6691378.A2 6691378	-
92 - AIR VENT SPONGE HIT-6691402.A0 6691402	-
93 - CLIP HIT-6692322.A0 6692322	-
94 - OIL PIPE # HIT-6690882.A2 6690882	-
95 - OIL FILTER BODY COMP. # HIT-6690915.A2 6690915	-
96 - OIL PIPE A # HIT-6691222.A0 6691222	-
97 - SPECIAL BOLT M4X14 HIT-6692335.A2 6692335	-
98 - OIL PUMP ASSY HIT-6687323.A2 6687323	-
99 - OIL SPONGE HIT-6686744.A2 6686744	-
100 - CLUTCH ASS'Y # HIT-6688483.A0 6688483	-
101 - CLUTCH HOUSING # HIT-6689115.A0 6689115	-
102 - NEEDLE BEARING # HIT-6689536.A2 6689536	-
103 - OIL PUMP COVER # HIT-6686760.A0 6686760	-
104 - CHAIN BAR CLAMP NUT HIT-6687106.A0 6687106	-
105 - RIM SPROCKET # HIT-6689176.A2 6689176	£35.37	£42.44
106 - GUIDE PLATE A # HIT-6690732.A0 6690732	-
107 - SPECIAL SCREW M4X10 HIT-6692330.A0 6692330	-
108 - OIL PIPE ASS'Y # HIT-6690883.A0 6690883	-
109 - CLUCH SPRING HIT-6689427.A0 6689427	-
110 - CLUTCH WASHER B # HIT-6689644.A2 6689644	-
111 - GUIDE HIT-6690797.A4 6690797	-
112 - CHAIN CATCHER # HIT-6687166.A2 6687166	-
113 - SPECIAL SCREW M5X14 HIT-6692327.A9 6692327	-
114 - SPECIAL SCREW M5X14 HIT-6692327.A10 6692327	-
115 - SPIKE # HIT-6690706.A2 6690706	-
116 - DAMPER A # HIT-6688248.A2 6688248	-
117 - DAMPER COLLAR A HIT-6688479.A2 6688479	-
118 - SPECIAL SCREW M5X16 HIT-6692334.A0 6692334	-
131 - HEAT SHIELD # HIT-6687239.A2 6687239	-
132 - CARB.INSULATOR COMP. # HIT-6689942.A2 6689942	-
133 - SPECIAL SCREW M5X14 HIT-6692327.A11 6692327	-
134 - ELBOW JOINT # HIT-6691006.A2 6691006	-
135 - CLIP A HIT-6690171.A2 6690171	-
136 - RUBBER PIPE # HIT-6692302.A0 6692302	-
137 - CARBURETOR GASKET HIT-6689830.A2 6689830	-
138 - SPACER # HIT-6688308.A0 6688308	-
139 - SPRING # HIT-6686451.A2 6686451	-
140 - INLET MANIFOLD # HIT-6689798.A0 6689798	-
141 - MUFFLER SPCIAL BOLT # HIT-6692880.A2 6692880	-
142 - INLET MANIFOLD RING # HIT-6689821.A2 6689821	-
143 - MUFFLER GASKET HIT-6692740.A0 6692740	-
144 - MUFFLER SET # HIT-6692461.A2 6692461	-
145 - MUFFLER COVER # HIT-6692720.A0 6692720	-
146 - SPECIAL SCREW M5X10 HIT-6692337.A5 6692337	-
147 - MUFFLER NUT HIT-6692684.A3 6692684	-
171 - RECOIL STARTER ASS'Y # HIT-6692920.A0 6692920	-
172 - FANCASE COMP. # HIT-6686967.A0 6686967	-
173 - ROPE GUIDE HIT-6693134.A2 6693134	-
174 - STARTER ROPE # HIT-6693163.A0 6693163	-
175 - STARTER HANDLE # HIT-6693231.A0 6693231	-
176 - ROPE STOPPER HIT-6693382.A2 6693382	-
177 - RECOIL SPRING CASE ASS'Y # HIT-6693097.A0 6693097	-
178 - H.L GUIDE # HIT-6687982.A2 6687982	-
179 - STARTER ROPE REEL # HIT-6693064.A0 6693064	-
180 - STARTER BOSS # HIT-6693278.A2 6693278	-
181 - STARTER WASHER HIT-6693251.A0 6693251	-
182 - SPECIAL SCREW M5X20 HIT-6692336.A1 6692336	-
183 - SPECIAL SCREW M5X14 HIT-6692327.A12 6692327	-
201 - CARBURETOR ASS'Y WT755A HIT-6690653.A2 6690653	-
202 - INLET SCREEN HIT-6684700.A75 6684700	-
203 - PUMP BODY # HIT-6691439.A0 6691439	-
204 - SCREW HIT-6685210.A71 6685210	-
205 - PUMP GASKET HIT-6685212.A53 6685212	£3.29	£3.95
206 - PUMP DIAPHRAGM # HIT-6691448.A0 6691448	-
207 - NEEDLE VALVE HIT-6685215.A83 6685215	£6.79	£8.15
208 - DIAPHRAGM PACKING-METERING HIT-6685220.A19 6685220	£2.81	£3.37
209 - METERING DIAPHRAGM COMP. HIT-6690827.A80 6690827	£14.02	£16.83
210 - DIAPHRAGM COVER-METERING HIT-6685222.A160 6685222	£5.70	£6.84
211 - VALVE SPRING HIT-6690872.A3 6690872	-
212 - HINGE PIN SET SCREW HIT-6685218.A5 6685218	-
213 - HINGE PIN HIT-6685219.A83 6685219	-
214 - CHOKE SPRING HIT-6691012.A2 6691012	-
215 - STEEL BALL HIT-6691405.A2 6691405	-
216 - CONTROL LEVER HIT-6685217.A59 6685217	-
217 - IDLE ADJUST SPRING HIT-6685297.A26 6685297	-
218 - IDLE ADUST SCREW # HIT-6690742.A0 6690742	-
219 - SET SCREW HIT-6685223.A5 6685223	-
241 - CLEANER COVER ASS'Y # HIT-6690405.A2 6690405	-
242 - CLEANER KNOB # HIT-6687797.A0 6687797	-
243 - CLEANER PACKING HIT-6690057.A2 6690057	-
244 - FILTER SCREEN # HIT-6690175.A0 6690175	-
245 - CLEANER ELEMENT A HIT-6690326.A0 6690326	-
246 - TAPPING SCREW 4X10 HIT-6695245.A4 6695245	-
247 - RUBBER CAP HIT-6690902.A2 6690902	-
248 - CYLINDER COVER ASS'Y # HIT-6685685.A0 6685685	-
249 - SPECIAL SCREW M5X14 HIT-6692327.A13 6692327	-
250 - HANDLE DAMPER COMP. # HIT-6688102.A0 6688102	£10.32	£12.38
251 - SPECIAL NUT # HIT-6689752.A1 6689752	-
252 - GROMMET HIT-6687975.A1 6687975	-
253 - CLEANER ELEMENT COMP. # HIT-6690069.A0 6690069	-
271 - SIDE CASE ASSY HIT-6686078.A0 6686078	-
272 - HAND GUARD SHAFT # HIT-6693444.A1 6693444	-
273 - SIDE CASE COMP. # HIT-6686041.A1 6686041	-
274 - STOPPER C # HIT-6688566.A0 6688566	-
275 - CHAIN TENSION BOLT # HIT-6687070.A1 6687070	-
276 - TENSION ADJUSTING BOSS # HIT-6687058.A1 6687058	-
277 - GUIDE PLATE B # HIT-6690753.A0 6690753	-
278 - GEAR # HIT-6688657.A0 6688657	£29.14	£34.97
279 - GUIDE HIT-6690797.A3 6690797	-
280 - CHAIN PROTECTOR # HIT-6689162.A1 6689162	-
281 - FRONT HAND GUARD ASSY HIT-6693458.A1 6693458	-
282 - SPRING PIN HIT-6691022.A2 6691022	-
283 - STOP RING E HIT-6693662.A2 6693662	-
284 - WEIGHT SPRING HIT-6693489.A2 6693489	-
285 - HAND GUARD WE/GHT # HIT-6693482.A1 6693482	-
286 - HAND GUARD SPRING # HIT-6693448.A0 6693448	-
287 - WASHER HIT-6691213.A1 6691213	-
288 - STOP RING E HIT-6693660.A0 6693660	-
289 - SPACER HIT-6693432.A1 6693432	-
290 - PIN # HIT-6693508.A0 6693508	-
291 - BRAKE ARM # HIT-6689693.A1 6689693	-
292 - BRAKE SPRING # HIT-6689703.A1 6689703	-
293 - BRAKE SPRING # HIT-6689704.A1 6689704	-
294 - BRAKE LINK SUPPORT # HIT-6689778.A1 6689778	-
295 - COLLAR HIT-6689773.A1 6689773	-
296 - BRAKE LINK COMP. # HIT-6689731.A1 6689731	-
297 - BRAKE LINK COVER # HIT-6689710.A0 6689710	-
298 - BRAKE BAND HOLDER HIT-6689716.A1 6689716	-
299 - BRAKE BAND # HIT-6689726.A0 6689726	-
300 - SPECIAL SCREW M4X12 HIT-6692341.A2 6692341	-
311 - SPECIAL SCREW M5X19 HIT-6692331.A2 6692331	-
312 - REAR HANDLE GRIP # HIT-6688216.A0 6688216	-
313 - SAFTY LEVER HIT-6688356.A0 6688356	-
314 - GROMMET HIT-6690997.A1 6690997	-
315 - THROTTLE ROD # HIT-6690970.A0 6690970	-
316 - FRONT HANDLE COMP. # HIT-6688074.A0 6688074	-
317 - SPECIAL BOLT HIT-6692339.A2 6692339	-
318 - SPECIAL SCREW M5X19 HIT-6692331.A3 6692331	-
319 - AIR CLEANER BASE COMP. # HIT-6690199.A2 6690199	-
320 - REAR DAMPER COMP. # HIT-6688180.A0 6688180	-
321 - DAMPER SET BOLT A # HIT-6688631.A1 6688631	-
322 - DAMPER CAP B HIT-6688403.A1 6688403	-
323 - CLIP 1 HIT-6684619.A13 6684619	£1.67	£2.00
324 - AIR VENT PIPE HIT-6691392.A1 6691392	-
325 - FUEL PIPE ASS'Y # HIT-6692342.A0 6692342	-
326 - SHIELD TUBE 3X5X180 HIT-6684618.A24 6684618	£6.12	£7.35
327 - COLLAR # HIT-6690878.A1 6690878	-
328 - PUMP FILTER BODY ASS'Y HIT-6692273.A9 6692273	£9.60	£11.52
329 - CUSHION RUBBER # HIT-6691826.A1 6691826	-
330 - SPECIAL SCREW M5X52 HIT-6692338.A0 6692338	-
332 - TANK CAP PACKING HIT-6692099.A0 6692099	-
333 - GUIDE HIT-6692601.A0 6692601	-
334 - CHOKE ROD COMP. HIT-6692585.A0 6692585	-
335 - CHOKE ROD RUBBER HIT-6692589.A0 6692589	-
336 - AIR VENT VALVE ASS'Y # HIT-6692173.A0 6692173	-
337 - REAR HANDLE ASS'Y HIT-6685661.A0 6685661	-
341 - FRONT DAMPER HIT-6688242.A0 6688242	-
342 - SPECIAL SCREW M4X16 HIT-6692340.A0 6692340	-
343 - PACKING HIT-6690137.A2 6690137	-
344 - THROTTLE LEVER HIT-6686385.A0 6686385	-
345 - THROTTLE LEVER SPRING HIT-6686415.A1 6686415	-
346 - SPRING PIN HIT-6691021.A0 6691021	-
347 - GROMMET A HIT-6686326.A1 6686326	-
501 - CHAIN BAR 18 HIT-6686835.A0 6686835	£61.82	£74.18
502 - BAR CHAIN 0.325 HIT-6687283.A1 6687283	-
503 - CHAIN COVER 450MM # HIT-6694798.A0 6694798	-
504 - DRIVER # HIT-6693802.A1 6693802	-
505 - COMBI.SPANNER # HIT-6693810.A2 6693810	-
601 - NAME PLATE CS45EM FOR EUROPE HIT-6694405.A0 6694405	-
602 - STARTER MARK CS45EM FOR EUROPE HIT-6694508.A0 6694508	-
603 - STARTER MARK CS45EM FOR RUS HIT-6694510.A0 6694510	-
