Hitachi / Hikoki CS40EL Engine Chain Saw Spare Parts

An exploded diagram and spare parts listing for the Hitachi / Hikoki CS40EL Engine Chain Saw

	Ex VAT	Inc VAT
1 - SPARK PLUG CAP ASS'Y HIT-6687468.A80 6687468	£3.64	£4.37
2 - SPARK PLUG ASS'Y BPMR7A HIT-6699320.A30 6699320	-
3 - CYLINDER SET HIT-6685465.A5 6685465	£87.92	£105.51
4 - CYLINDER PACKING HIT-6685732.A4 6685732	£1.67	£2.00
5 - HEX. HOLE BOLT 5X20S HIT-6695491.A10 6695491	£1.67	£2.00
6 - DECOMP. VALVE GASKET HIT-6685860.A5 6685860	£1.67	£2.00
7 - DECOMPRESSION COMP. HIT-6685589.A11 6685589	£37.61	£45.13
8 - DECOMP. COVER HIT-6685800.A5 6685800	£1.67	£2.00
9 - DUST COVER HIT-6690808.A11 6690808	-
10 - PISTON PIN CIRCLIP HIT-6686026.A7 6686026	£1.67	£2.00
11 - PISTON RING 2 HIT-6686125.A3 6686125	£8.45	£10.14
12 - PISTON SET 1 HIT-6685884.A4 6685884	£29.28	£35.14
13 - PISTON PIN 10X30 HIT-6686007.A31 6686007	£3.52	£4.23
14 - PISTON PIN COLLAR HIT-6685993.A4 6685993	£5.70	£6.84
15 - NEEDLE BEARING 1 HIT-6695602.A6 6695602	-
16 - CRANK SHAFT COMP. HIT-6686183.A4 6686183	-
17 - WOODRUFF KEY 3X13X4.5 HIT-6684899.A67 6684899	-
31 - SIDE DUMPER HIT-6688164.A2 6688164	-
32 - HEX HOLE SCREW 5X35 HIT-6695076.A9 6695076	-
33 - OIL PIPE A HIT-6691219.A4 6691219	-
34 - CLIP 7 HIT-6692312.A0 6692312	-
35 - OIL FILTER BODY COMP. HIT-6697651.A9 6697651	-
*36 - SHIM S T0.2 HIT-6685098.A11 6685098	-
*36 - SHIM S T0.3 HIT-6685099.A23 6685099	-
*36 - SHIM 0.4 HIT-6686475.A27 6686475	-
37 - CRANK CASE ASS'Y HIT-6686542.A0 6686542	-
38 - KNOCK PIN 4X12 HIT-6695521.A26 6695521	-
39 - OIL SEAL ISMX12325.5 HIT-6695633.A0 6695633	£6.18	£7.41
40 - STOP RING C-32 1 HIT-6695295.A49 6695295	£1.67	£2.00
41 - BALL BEARING 6201 A2C3 HIT-6685096.A25 6685096	-
42 - BALL BEARING 6201 A2C3 HIT-6685096.A26 6685096	-
43 - STOP RING C-32 1 HIT-6695295.A50 6695295	£1.67	£2.00
44 - OIL SEAL ISMX12325.5 HIT-6695633.A1 6695633	£6.18	£7.41
45 - CRANKCASE GASKET HIT-6686710.A6 6686710	£1.67	£2.00
46 - AIR VENT VALVE (B) HIT-6685173.A2 6685173	-
47 - AIR VENT COVER HIT-6691399.A3 6691399	£4.72	£5.66
48 - HEX.HOLE BOLT M5X18/S HIT-6684586.A81 6684586	-
49 - HEX. SOCKET HD. BOLT M5X30 S HIT-6684786.A81 6684786	£1.67	£2.00
50 - AIR DEFLECTOR HIT-6687207.A3 6687207	-
51 - BOLT WASHER M8 HIT-6684611.A92 6684611	-
52 - HEX. NUT M8 HIT-6684612.A20 6684612	-
53 - MAGNETO ROTOR ASS'Y HIT-6687395.A5 6687395	£52.30	£62.76
54 - SPECIAL WASHER HIT-6687942.A12 6687942	-
55 - PAWL SPRING HIT-6693348.A8 6693348	-
56 - STARTER PAWL HIT-6693304.A0 6693304	£3.89	£4.67
57 - STEP BOLT HIT-6693366.A14 6693366	-
58 - HANDLE DAMPER HIT-6688107.A3 6688107	-
72 - CLUTCH ASS'Y 1 HIT-6688489.A3 6688489	-
73 - CLUTCH HOUSING COMP.7T HIT-6689009.A11 6689009	£35.35	£42.42
74 - NEEDLE BEARING KT111410G HIT-6695606.A8 6695606	£14.19	£17.03
75 - OIL PUMP COVER HIT-6686755.A9 6686755	-
76 - SCREW GEAR COMP. HIT-6686640.A7 6686640	£38.15	£45.78
77 - OIL PUMP COMP. HIT-6687331.A3 6687331	£46.36	£55.63
78 - PINION WASHER 1T HIT-6686452.A5 6686452	£3.38	£4.06
79 - SMALL SCREW 4X12WS HIT-6695403.A5 6695403	-
80 - HIGH TENSION SCREW 4X18WS HIT-6695407.A51 6695407	-
81 - RELEASE VALVE HIT-6686661.A0 6686661	£1.67	£2.00
82 - O-RING S-3 HIT-6695659.A11 6695659	£1.67	£2.00
83 - O-RING P-5 HIT-6695661.A1 6695661	£1.67	£2.00
84 - CLUTCH SPRING HIT-6689426.A8 6689426	£2.98	£3.57
85 - CLUTCH SHOE HIT-6689493.A4 6689493	-
86 - CLUTCH BOSS HIT-6689497.A7 6689497	-
87 - CLUTCH WASHER B HIT-6689642.A6 6689642	-
101 - AIRCLEANER ELEMENT B COMP. HIT-6690335.A3 6690335	£9.60	£11.52
102 - AIRCLEANER ELEMENT A COMP. HIT-6690325.A6 6690325	£5.97	£7.16
103 - AIRCLEANER BASE COMP. HIT-6690198.A3 6690198	£7.75	£9.30
104 - HEX. HOLE BOLT 5X45 HIT-6695055.A12 6695055	£1.67	£2.00
105 - S.WASHER 5 HIT-6684662.A11 6684662	£1.67	£2.00
106 - SMALL WASHER 5 HIT-6684864.A50 6684864	-
107 - HEX. HOLE BOLT 5X15 WS HIT-6695512.A3 6695512	-
109 - IDLE ADJUSTMENT SCREW TILL E919999 HIT-6687993.A11 6687993	-
109A - IDLE ADJUST SCREW SINCE EO10001 HIT-6685298.A25 6685298	£1.67	£2.00
110 - SPECIAL WASHER HIT-6687943.A3 6687943	£1.67	£2.00
111 - CARB. INSULATOR 1 HIT-6690004.A9 6690004	-
112 - INSULATOR COMP. HIT-6689941.A5 6689941	-
113 - INLET MANIFOLD COMP. HIT-6689789.A3 6689789	-
114 - INLET MANIFOLD GASKET HIT-6689876.A9 6689876	-
115 - HEX. SOCKET HD. BOLT (W/SP.WASHER) M4X12 HIT-6684595.A10 6684595	£1.67	£2.00
116 - IDLE ADJUST SPRING HIT-6690766.A7 6690766	-
117 - INLET MANIFOLD SPACER HIT-6685202.A9 6685202	-
118 - MUFFLER GASKET HIT-6692737.A3 6692737	-
119 - MUFFLER SET HIT-6692459.A8 6692459	-
120 - MUFFLER STAY HIT-6692942.A12 6692942	-
121 - HEX. HOLE BOLT M5X16/S HIT-6684903.A5 6684903	-
122 - HEX. HOLE BOLT 4X10 HIT-6695036.A14 6695036	-
141 - RECOIL STARTER ASS'Y HIT-6692916.A8 6692916	£30.63	£36.76
142 - SET SCREW HIT-6693633.A37 6693633	£1.67	£2.00
143 - STARTER ROPE REEL HIT-6693059.A0 6693059	£13.29	£15.95
144 - RECOIL SPRING CASE HIT-6693096.A12 6693096	£11.90	£14.28
145 - FAN CASE COMP. HIT-6686963.A10 6686963	-
146 - PLATE HIT-6685189.A47 6685189	-
147 - STARTER HANDLE HIT-6693230.A6 6693230	-
148 - STARTER ROPE HIT-6693158.A6 6693158	£4.26	£5.11
150 - HEX. HOLE BOLT 5X15 WS HIT-6695512.A4 6695512	-
201 - CARBURETOR ASS'Y WT-497A FOR EUROPE HIT-6690606.A0 6690606	£93.28	£111.94
202 - INLET SCREEN HIT-6684700.A203 6684700	-
203 - PUMP BODY HIT-6691416.A13 6691416	£16.36	£19.63
204 - SCREW HIT-6685210.A20 6685210	-
205 - PUMP GASKET HIT-6685212.A17 6685212	£3.29	£3.95
206 - PUMP DIAPHRAGM HIT-6685213.A38 6685213	£8.44	£10.13
207 - NEEDLE VALVE HIT-6685215.A28 6685215	£6.79	£8.15
208 - DIAPHRAGM PACKING-METERING HIT-6685220.A120 6685220	£2.81	£3.37
209 - METERING DIAPHRAGM COMP. HIT-6690827.A10 6690827	£14.02	£16.83
210 - DIAPHRAGM COVER-METERING HIT-6685222.A56 6685222	£5.70	£6.84
211 - VALVE SPRING HIT-6690872.A10 6690872	-
212 - HINGE PIN SET SCREW HIT-6685218.A51 6685218	-
213 - HINGE PIN HIT-6685219.A22 6685219	-
214 - CONTROL LEVER HIT-6685217.A17 6685217	-
215 - SET SCREW HIT-6685223.A50 6685223	-
216 - CARBURETOR ASS'Y WT484 FOR RUS HIT-6690605.A2 6690605	-
217 - HIGH/LOW ADJUST SPRING FOR RUS HIT-6692048.A2 6692048	-
218 - LOW ADJUSTMENT SCREW FOR RUS HIT-6690719.A0 6690719	-
219 - HIGH ADJUSTMENT SPRING FOR RUS HIT-6690897.A18 6690897	-
220 - HIGH ADJUST SCREW FOR RUS HIT-6690696.A2 6690696	-
231 - AIRCLEANER KNOB COMP. HIT-6687793.A6 6687793	£5.92	£7.11
232 - CLEANER COVER SET 1 HIT-6690404.A11 6690404	£8.88	£10.66
233 - IDLE GROMMET HIT-6687974.A2 6687974	-
234 - ADJUSTER CAP HIT-6687954.A1 6687954	-
235 - CYLINDER COVER HIT-6685681.A8 6685681	-
236 - CYLINDR SUPPORT RUBBER HIT-6691825.A12 6691825	-
237 - CLEANER PACKING HIT-6690056.A0 6690056	-
238 - HEX. HOLE BOLT 5X15 WS HIT-6695512.A5 6695512	-
239 - INSULATOR TUBE 1 HIT-6688315.A1 6688315	-
240 - CHOKE BUTTON COMP. HIT-6692507.A7 6692507	-
241 - CHOKE ROD HOLDING RUBBER HIT-6692587.A13 6692587	-
242 - STOP SWITCH COMP. HIT-6687506.A2 6687506	£7.12	£8.54
243 - CONTROL PLATE HIT-6691192.A4 6691192	-
244 - SHUTTER PLATE HIT-6687952.A6 6687952	-
245 - STOP CORD 1 HIT-6687929.A6 6687929	-
246 - HEX.HOLE BOLT M5X12/S HIT-6684667.A66 6684667	£1.67	£2.00
247 - BUMPER SPIKE HIT-6690705.A8 6690705	£5.59	£6.71
248 - CHAIN CATCHER HIT-6687163.A6 6687163	-
249 - SPECIAL BOLT HIT-6689734.A7 6689734	-
250 - FUEL PIPE HIT-6685154.A13 6685154	-
251 - DAMPER COMP. HIT-6688113.A5 6688113	£5.70	£6.84
252 - TAPPING SCREW 5X35 HIT-6695107.A13 6695107	£1.67	£2.00
253 - COLLAR 15 HIT-6692248.A11 6692248	£1.67	£2.00
254 - OIL TANK CAP ASS'Y HIT-6697756.A14 6697756	£5.87	£7.04
255 - OIL TANK CAP PACKING HIT-6697888.A14 6697888	£1.67	£2.00
256 - IGNITION COIL COMP. HIT-6687695.A10 6687695	£73.85	£88.62
257 - HEX. HOLE BOLT M4X18/WS HIT-6684599.A5 6684599	-
271 - NUT M4 HIT-6685069.A16 6685069	-
272 - CHAIN BAR CLAMP NUT HIT-6687105.A11 6687105	£1.67	£2.00
273 - TAP SCREW 4X14 P HIT-6695280.A46 6695280	£1.67	£2.00
274 - FRONT HAND GUARD HIT-6693454.A7 6693454	£7.57	£9.08
275 - MACHINE SCREW (W/SP. WASHER) M4X12 HIT-6685068.A28 6685068	-
276 - HAND GUARD WEIGHT HIT-6693481.A3 6693481	-
277 - SIDE CASE ASS'Y HIT-6686095.A3 6686095	£92.02	£110.42
278 - TAPPING SCREW D4X10 HIT-6685161.A47 6685161	£1.67	£2.00
279 - BRAKE BAND HOLDER HIT-6689715.A3 6689715	-
280 - SIDE COVER COMP. HIT-6686043.A6 6686043	-
281 - CLEANER FIXING COLLAR HIT-6690805.A7 6690805	£2.69	£3.23
282 - BRAKE SUPPORT FITTING COMP. HIT-6689777.A3 6689777	-
283 - BRAKE LEVER SPRING HIT-6689781.A4 6689781	-
284 - BRAKE LINK COMP. HIT-6685121.A2 6685121	£18.38	£22.05
285 - BRAKE SPRING HIT-6689700.A2 6689700	£3.56	£4.27
286 - BRAKE BAND HIT-6689724.A3 6689724	£15.38	£18.45
287 - NEEDLE ROLLER 3X9.8 HIT-6685141.A4 6685141	-
288 - BRAKE LINK COVER HIT-6689709.A6 6689709	-
289 - TAPPING SCREW D4X10 HIT-6685161.A48 6685161	£1.67	£2.00
290 - GUIDE PLATE B HIT-6697598.A6 6697598	£3.56	£4.27
291 - SCREW 4X8 HIT-6694861.A19 6694861	-
292 - GUIDE PLATE A HIT-6697597.A6 6697597	£3.56	£4.27
293 - CHAIN BAR STUD BOLT HIT-6686804.A2 6686804	-
294 - CHAIN TENSION BOLT ASSY HIT-6687067.A4 6687067	£5.70	£6.84
311 - TAPPING SCREW 5X18 HIT-6695106.A16 6695106	-
312 - REAR HANDLE GRIP HIT-6688212.A8 6688212	-
313 - TRIGGER LOCKOUT BLACK HIT-6688352.A8 6688352	-
314 - THROTTLE ROD COMP. HIT-6690967.A7 6690967	-
315 - THROTTLE LEVER HIT-6686381.A10 6686381	-
316 - THROTTLE LEVER SPRING HIT-6686412.A5 6686412	-
317 - REAR HANDLE ASS'Y HIT-6685663.A8 6685663	£50.06	£60.07
318 - SPRING PIN 5X25 HIT-6685282.A10 6685282	£1.67	£2.00
319 - NO LONGER AVAILABLE HIT-6688079.A4 6688079	-
320 - TAPPING SCREW 5X18 HIT-6695106.A17 6695106	-
321 - AIR VENT VALVE ASS'Y HIT-6692172.A7 6692172	-
322 - AIRVENT PIPE HIT-6691391.A7 6691391	-
323 - FRONT DAMPER HIT-6688241.A4 6688241	-
324 - DAMPER COMP. HIT-6688261.A9 6688261	-
325 - DAPMPER COLLAR HIT-6688478.A8 6688478	-
326 - HEX. HOLE BOLT 4X20 HIT-6695039.A4 6695039	-
327 - CLIP 5.2 HIT-6692311.A13 6692311	-
328 - FUEL PIPE ASS'Y L=195 HIT-6688173.A8 6688173	-
329 - CLIP 1 HIT-6684619.A55 6684619	£1.67	£2.00
330 - PUMP FILTER BODY HIT-6692285.A1 6692285	£10.40	£12.48
331 - TANK CAP ASS'Y HIT-6692111.A7 6692111	£5.87	£7.04
332 - TANK CAP PACKING HIT-6685179.A5 6685179	£1.67	£2.00
*501 - CHAIN BAR 16 FOR EUROPE HIT-6686859.A0 6686859	-
*501 - CHAIN BAR 16 325 FOR RUS HIT-6695895.A0 6695895	-
502 - SAW CHAIN 16 INCH HIT-6687296.A9 6687296	-
503A - CHAIN COVER 16 HIT-6685440.A3 6685440	£13.86	£16.63
504 - COMBI. BOX SPANNER 13X19 MINUS HIT-6693809.A3 6693809	-
601 - NAME PLATE FOR EUROPE HIT-6699643.A0 6699643	-
602 - STARTER MARK CS40EL FOR EUROPE HIT-6699642.A0 6699642	-
603 - STARTER MARK CS40EL FOR RUS HIT-6696525.A0 6696525	-

Attribute Name	Value
Brand	Hikoki

Reviews Write your own review!

There are currently no reviews of this product.

Fill in the form below to add your review for Hitachi / Hikoki CS40EL Engine Chain Saw Spare Parts

Your Review
Title Required!
Rating Required!
Your Review Required!
Your Details
Your Name Required!
Your Location Required!
Email Address Required!Invalid email!

United Kingdom (Including N. Ireland)

On orders up to £40.00	Add £4.00 inc VAT (Royal Mail post)
On orders £40.00 to £130.00	Add £7.00 inc VAT (Courier)
On orders over £130.00	FREE (Courier)

Shopping Basket (0) £0.00

Hitachi / Hikoki CS40EL Engine Chain Saw Spare Parts

Your Review

Your Details

Carry On Shopping

Try these categories

Recently Viewed

Your Order

About Us

Other Links

Search

Customization

Shopping Basket (0) £0.00

Information

Hitachi / Hikoki CS40EL Engine Chain Saw Spare Parts

Notify me

Your Review

Your Details

Carry On Shopping

Try these categories

Recently Viewed

Your Order

About Us

Other Links

Search
