Hitachi / Hikoki CS40EK Engine Chain Saw Spare Parts

An exploded diagram and spare parts listing for the Hitachi / Hikoki CS40EK Engine Chain Saw

	Ex VAT	Inc VAT
1 - SPARK PLUG CAP ASS'Y HIT-6687468.A33 6687468	£3.64	£4.37
2 - SPARK PLUG ASS'Y BPMR7A HIT-6699320.A10 6699320	-
3 - CYLINDER SET 1 HIT-6685464.A5 6685464	£62.56	£75.07
4 - CYLINDER GASKET HIT-6685731.A1 6685731	£1.67	£2.00
5 - HEX. HOLE BOLT 5X20S HIT-6695491.A18 6695491	£1.67	£2.00
6 - DECOMP. VALVE GASKET HIT-6685860.A11 6685860	£1.67	£2.00
7 - DECOMPRESSION COMP. HIT-6685589.A1 6685589	£37.61	£45.13
8 - DECOMP. COVER HIT-6685800.A11 6685800	£1.67	£2.00
9 - DUST COVER HIT-6690808.A0 6690808	-
10 - PISTON PIN CIRCLIP HIT-6686026.A16 6686026	£1.67	£2.00
11 - PISTON RING 2 HIT-6686124.A4 6686124	£8.45	£10.14
12 - PISTON SET 1 HIT-6685883.A1 6685883	£20.98	£25.18
13 - PISTON PIN 10X30 HIT-6686007.A3 6686007	£3.52	£4.23
14 - PISTON PIN COLLAR HIT-6685993.A19 6685993	£5.70	£6.84
15 - NEEDLE BEARING 1 HIT-6695602.A15 6695602	-
16 - CRANKSHAFT COMP. HIT-6686182.A4 6686182	-
17 - WOODRUFF KEY 3X13X4.5 HIT-6684899.A11 6684899	-
31 - SIDE DUMPER HIT-6688164.A1 6688164	-
32 - HEX HOLE SCREW 5X35 HIT-6695076.A12 6695076	-
33 - OIL PIPE A HIT-6691219.A11 6691219	-
34 - CLIP 7 HIT-6692312.A33 6692312	-
35 - OIL FILTER BODY COMP. HIT-6697651.A12 6697651	-
*36 - SHIM S T0.2 HIT-6685098.A25 6685098	-
*36 - SHIM S T0.3 HIT-6685099.A9 6685099	-
*36 - SHIM 0.4 HIT-6686475.A10 6686475	-
37 - CRANK CASE ASS'Y HIT-6697589.A0 6697589	-
38 - KNOCK PIN 4X12 HIT-6695521.A16 6695521	-
39 - OIL SEAL ISMX12325.5 HIT-6695633.A23 6695633	£6.18	£7.41
40 - STOP RING C-32 1 HIT-6695295.A8 6695295	£1.67	£2.00
41 - BALL BEARING 6201 A2C3 HIT-6685096.A6 6685096	-
42 - BALL BEARING 6201 A2C3 HIT-6685096.A7 6685096	-
43 - STOP RING C-32 1 HIT-6695295.A9 6695295	£1.67	£2.00
44 - OIL SEAL ISMX12325.5 HIT-6695633.A24 6695633	£6.18	£7.41
45 - CRANKCASE GASKET HIT-6686710.A2 6686710	£1.67	£2.00
46 - AIR VENT VALVE (B) HIT-6685173.A32 6685173	-
47 - AIR VENT COVER HIT-6691399.A10 6691399	£4.72	£5.66
48 - HEX.HOLE BOLT M5X18/S HIT-6684586.A11 6684586	-
49 - HEX. SOCKET HD. BOLT M5X30 S HIT-6684786.A17 6684786	£1.67	£2.00
50 - AIR DEFLECTOR HIT-6687207.A0 6687207	-
51 - BOLT WASHER M8 HIT-6684611.A1 6684611	-
52 - HEX. NUT M8 HIT-6684612.A117 6684612	-
53 - MAGNETO ROTOR ASS'Y HIT-6687395.A11 6687395	£52.30	£62.76
54 - SPECIAL WASHER HIT-6687942.A17 6687942	-
55 - PAWL SPRING HIT-6693348.A11 6693348	-
56 - STARTER PAWL HIT-6693304.A11 6693304	£3.89	£4.67
57 - STEP BOLT HIT-6693366.A3 6693366	-
58 - HANDLE DAMPER HIT-6688107.A1 6688107	-
72 - CLUTCH ASS'Y 1 HIT-6688489.A1 6688489	-
73 - CLUTCH HOUSING COMP.7T HIT-6689009.A2 6689009	£35.35	£42.42
74 - NEEDLE BEARING KT111410G HIT-6695606.A1 6695606	£14.19	£17.03
75 - OIL PUMP COVER HIT-6686755.A10 6686755	-
76 - SCREW GEAR COMP. HIT-6686640.A9 6686640	£38.15	£45.78
77 - OIL PUMP COMP. HIT-6687331.A1 6687331	£46.36	£55.63
78 - PINION WASHER 1T HIT-6686452.A1 6686452	£3.38	£4.06
79 - SMALL SCREW 4X12WS HIT-6695403.A14 6695403	-
80 - HIGH TENSION SCREW 4X18WS HIT-6695407.A6 6695407	-
81 - RELEASE VALVE HIT-6686661.A11 6686661	£1.67	£2.00
82 - O-RING S-3 HIT-6695659.A1 6695659	£1.67	£2.00
83 - O-RING P-5 HIT-6695661.A16 6695661	£1.67	£2.00
84 - CLUTCH SPRING HIT-6689426.A0 6689426	£2.98	£3.57
85 - CLUTCH SHOE HIT-6689493.A1 6689493	-
86 - CLUTCH BOSS HIT-6689497.A10 6689497	-
87 - CLUTCH WASHER B HIT-6689642.A11 6689642	-
101 - AIRCLEANER ELEMENT B COMP. HIT-6690335.A1 6690335	£9.60	£11.52
102 - AIRCLEANER ELEMENT A COMP. HIT-6690325.A11 6690325	£5.97	£7.16
103 - AIRCLEANER BASE COMP. HIT-6690198.A11 6690198	£7.75	£9.30
104 - HEX. HOLE BOLT 5X45 HIT-6695055.A3 6695055	£1.67	£2.00
105 - S.WASHER 5 HIT-6684662.A74 6684662	£1.67	£2.00
106 - SMALL WASHER 5 HIT-6684864.A85 6684864	-
107 - HEX. HOLE BOLT 5X15 WS HIT-6695512.A43 6695512	-
109 - IDLE ADJUSTMENT SCREW TILL E919999 HIT-6687993.A0 6687993	-
109A - IDLE ADJUST SCREW SINCE EO10001 HIT-6685298.A19 6685298	£1.67	£2.00
110 - SPECIAL WASHER HIT-6687943.A2 6687943	£1.67	£2.00
111 - CARB. INSULATOR 1 HIT-6690004.A2 6690004	-
112 - INSULATOR COMP. HIT-6689941.A12 6689941	-
113 - INLET MANIFOLD COMP. HIT-6689789.A2 6689789	-
114 - INLET MANIFOLD GASKET HIT-6689876.A1 6689876	-
115 - HEX. SOCKET HD. BOLT (W/SP.WASHER) M4X12 HIT-6684595.A52 6684595	£1.67	£2.00
116 - IDLE ADJUST SPRING HIT-6690766.A36 6690766	-
117 - INLET MANIFOLD SPACER HIT-6685202.A18 6685202	-
118 - MUFFLER GASKET HIT-6692737.A11 6692737	-
119 - MUFFLER SET HIT-6692459.A2 6692459	-
120 - MUFFLER STAY HIT-6692942.A1 6692942	-
121 - HEX. HOLE BOLT M5X16/S HIT-6684903.A78 6684903	-
122 - HEX. HOLE BOLT 4X10 HIT-6695036.A1 6695036	-
141 - RECOIL STARTER ASS'Y HIT-6692916.A2 6692916	£30.63	£36.76
142 - SET SCREW HIT-6693633.A19 6693633	£1.67	£2.00
143 - STARTER ROPE REEL HIT-6693059.A11 6693059	£13.29	£15.95
144 - RECOIL SPRING CASE HIT-6693096.A0 6693096	£11.90	£14.28
145 - FAN CASE COMP. HIT-6686963.A2 6686963	-
146 - PLATE HIT-6685189.A3 6685189	-
147 - STARTER HANDLE HIT-6693230.A15 6693230	-
148 - STARTER ROPE HIT-6693158.A0 6693158	£4.26	£5.11
150 - HEX. HOLE BOLT 5X15 WS HIT-6695512.A44 6695512	-
201 - CARBURETOR ASS'Y WT-497A HIT-6690606.A7 6690606	£93.28	£111.94
202 - INLET SCREEN HIT-6684700.A38 6684700	-
203 - PUMP BODY HIT-6691416.A22 6691416	£16.36	£19.63
204 - SCREW HIT-6685210.A46 6685210	-
205 - PUMP GASKET HIT-6685212.A41 6685212	£3.29	£3.95
206 - PUMP DIAPHRAGM HIT-6685213.A15 6685213	£8.44	£10.13
207 - NEEDLE VALVE HIT-6685215.A60 6685215	£6.79	£8.15
208 - DIAPHRAGM PACKING-METERING HIT-6685220.A81 6685220	£2.81	£3.37
209 - METERING DIAPHRAGM COMP. HIT-6690827.A56 6690827	£14.02	£16.83
210 - DIAPHRAGM COVER-METERING HIT-6685222.A97 6685222	£5.70	£6.84
211 - VALVE SPRING HIT-6690872.A7 6690872	-
212 - HINGE PIN SET SCREW HIT-6685218.A25 6685218	-
213 - HINGE PIN HIT-6685219.A56 6685219	-
214 - CONTROL LEVER HIT-6685217.A43 6685217	-
215 - SET SCREW HIT-6685223.A24 6685223	-
231 - AIRCLEANER KNOB COMP. HIT-6687793.A10 6687793	£5.92	£7.11
232 - CLEANER COVER SET 1 HIT-6690404.A2 6690404	£8.88	£10.66
233 - IDLE GROMMET HIT-6687974.A10 6687974	-
234 - ADJUSTER CAP HIT-6687954.A11 6687954	-
235 - CYLINDER COVER HIT-6685681.A9 6685681	-
236 - CYLINDR SUPPORT RUBBER HIT-6691825.A2 6691825	-
237 - CLEANER PACKING HIT-6690056.A10 6690056	-
238 - HEX. HOLE BOLT 5X15 WS HIT-6695512.A45 6695512	-
239 - INSULATOR TUBE 1 HIT-6688315.A10 6688315	-
240 - CHOKE BUTTON COMP. HIT-6692507.A10 6692507	-
241 - CHOKE ROD HOLDING RUBBER HIT-6692587.A3 6692587	-
242 - STOP SWITCH COMP. HIT-6687506.A12 6687506	£7.12	£8.54
243 - CONTROL PLATE HIT-6691192.A1 6691192	-
244 - SHUTTER PLATE HIT-6687952.A1 6687952	-
245 - STOP CORD 1 HIT-6687929.A10 6687929	-
246 - HEX.HOLE BOLT M5X12/S HIT-6684667.A19 6684667	£1.67	£2.00
247 - BUMPER SPIKE HIT-6690705.A12 6690705	£5.59	£6.71
248 - CHAIN CATCHER HIT-6687163.A1 6687163	-
249 - SPECIAL BOLT HIT-6689734.A2 6689734	-
250 - FUEL PIPE HIT-6685154.A28 6685154	-
251 - DAMPER COMP. HIT-6688113.A13 6688113	£5.70	£6.84
252 - TAPPING SCREW 5X35 HIT-6695107.A40 6695107	£1.67	£2.00
253 - COLLAR 15 HIT-6692248.A0 6692248	£1.67	£2.00
254 - OIL TANK CAP ASS'Y HIT-6697756.A5 6697756	£5.87	£7.04
255 - OIL TANK CAP PACKING HIT-6697888.A3 6697888	£1.67	£2.00
256 - IGNITION COIL COMP. HIT-6687695.A0 6687695	£73.85	£88.62
257 - HEX. HOLE BOLT M4X18/WS HIT-6684599.A68 6684599	-
271 - NUT M4 HIT-6685069.A0 6685069	-
272 - CHAIN BAR CLAMP NUT HIT-6687105.A19 6687105	£1.67	£2.00
273 - TAP SCREW 4X14 P HIT-6695280.A6 6695280	£1.67	£2.00
274 - FRONT HAND GUARD HIT-6693454.A1 6693454	£7.57	£9.08
275 - MACHINE SCREW (W/SP. WASHER) M4X12 HIT-6685068.A74 6685068	-
276 - HAND GUARD WEIGHT HIT-6693481.A8 6693481	-
277 - SIDE CASE ASS'Y HIT-6686095.A7 6686095	£92.02	£110.42
278 - TAPPING SCREW D4X10 HIT-6685161.A12 6685161	£1.67	£2.00
279 - BRAKE BAND HOLDER HIT-6689715.A7 6689715	-
280 - SIDE COVER COMP. HIT-6686043.A1 6686043	-
281 - CLEANER FIXING COLLAR HIT-6690805.A27 6690805	£2.69	£3.23
282 - BRAKE SUPPORT FITTING COMP. HIT-6689777.A7 6689777	-
283 - BRAKE LEVER SPRING HIT-6689781.A11 6689781	-
284 - BRAKE LINK COMP. HIT-6685121.A6 6685121	£18.38	£22.05
285 - BRAKE SPRING HIT-6689700.A7 6689700	£3.56	£4.27
286 - BRAKE BAND HIT-6689724.A7 6689724	£15.38	£18.45
287 - NEEDLE ROLLER 3X9.8 HIT-6685141.A17 6685141	-
288 - BRAKE LINK COVER HIT-6689709.A1 6689709	-
289 - TAPPING SCREW D4X10 HIT-6685161.A11 6685161	£1.67	£2.00
290 - GUIDE PLATE B HIT-6697598.A11 6697598	£3.56	£4.27
291 - SCREW 4X8 HIT-6694861.A5 6694861	-
292 - GUIDE PLATE A HIT-6697597.A1 6697597	£3.56	£4.27
293 - CHAIN BAR STUD BOLT HIT-6686804.A12 6686804	-
294 - CHAIN TENSION BOLT ASSY HIT-6687067.A7 6687067	£5.70	£6.84
311 - TAPPING SCREW 5X18 HIT-6695106.A2 6695106	-
312 - REAR HANDLE GRIP HIT-6688212.A10 6688212	-
313 - TRIGGER LOCKOUT BLACK HIT-6688352.A0 6688352	-
314 - THROTTLE ROD COMP. HIT-6690967.A9 6690967	-
315 - THROTTLE LEVER HIT-6686381.A1 6686381	-
316 - THROTTLE LEVER SPRING HIT-6686412.A12 6686412	-
317 - REAR HANDLE ASS'Y HIT-6685663.A1 6685663	£50.06	£60.07
318 - SPRING PIN 5X25 HIT-6685282.A19 6685282	£1.67	£2.00
319 - NO LONGER AVAILABLE HIT-6688079.A11 6688079	-
320 - TAPPING SCREW 5X18 HIT-6695106.A3 6695106	-
321 - AIR VENT VALVE ASS'Y HIT-6692172.A3 6692172	-
322 - AIRVENT PIPE HIT-6691391.A1 6691391	-
323 - FRONT DAMPER HIT-6688241.A2 6688241	-
324 - DAMPER COMP. HIT-6688261.A1 6688261	-
325 - DAPMPER COLLAR HIT-6688478.A2 6688478	-
326 - HEX. HOLE BOLT 4X20 HIT-6695039.A10 6695039	-
327 - CLIP 5.2 HIT-6692311.A2 6692311	-
328 - FUEL PIPE ASS'Y L=195 HIT-6688173.A2 6688173	-
329 - CLIP 1 HIT-6684619.A3 6684619	£1.67	£2.00
330 - PUMP FILTER BODY HIT-6692285.A14 6692285	£10.40	£12.48
331 - TANK CAP ASS'Y HIT-6692111.A11 6692111	£5.87	£7.04
332 - TANK CAP PACKING HIT-6685179.A28 6685179	£1.67	£2.00
501 - CHAIN BAR 16 HIT-6686859.A1 6686859	-
502 - SAW CHAIN 16 INCH HIT-6687296.A2 6687296	-
503A - CHAIN COVER 16 HIT-6685440.A19 6685440	£13.86	£16.63
504 - COMBI. BOX SPANNER 13X19 MINUS HIT-6693809.A29 6693809	-
601 - NAME PLATE CS40EK HIT-6694400.A0 6694400	-
602 - STARTER MARK CS40EK HIT-6694503.A0 6694503	-
