Hitachi / Hikoki CS38EK Engine Chain Saw Spare Parts

An exploded diagram and spare parts listing for the Hitachi / Hikoki CS38EK Engine Chain Saw

	Ex VAT	Inc VAT
1 - SPARK PLUG CAP ASS'Y HIT-6687468.A52 6687468	£3.64	£4.37
2 - SPARK PLUG ASS'Y BPMR7A HIT-6699320.A18 6699320	-
3 - CYLINDER SET 1 HIT-6685464.A1 6685464	£62.56	£75.07
4 - CYLINDER GASKET HIT-6685731.A4 6685731	£1.67	£2.00
5 - HEX. HOLE BOLT 5X20S HIT-6695491.A4 6695491	£1.67	£2.00
6 - DECOMP. VALVE GASKET HIT-6685860.A2 6685860	£1.67	£2.00
7 - DECOMPRESSION COMP. HIT-6685589.A4 6685589	£37.61	£45.13
8 - DECOMP. COVER HIT-6685800.A10 6685800	£1.67	£2.00
9 - DUST COVER HIT-6690808.A2 6690808	-
10 - PISTON PIN CIRCLIP HIT-6686026.A11 6686026	£1.67	£2.00
11 - PISTON RING 2 HIT-6686124.A0 6686124	£8.45	£10.14
12 - PISTON SET 1 HIT-6685883.A3 6685883	£20.98	£25.18
13 - PISTON PIN 10X30 HIT-6686007.A16 6686007	£3.52	£4.23
14 - PISTON PIN COLLAR HIT-6685993.A10 6685993	£5.70	£6.84
15 - NEEDLE BEARING 1 HIT-6695602.A1 6695602	-
16 - CRANKSHAFT COMP. HIT-6686182.A1 6686182	-
17 - WOODRUFF KEY 3X13X4.5 HIT-6684899.A86 6684899	-
31 - SIDE DUMPER HIT-6688164.A10 6688164	-
32 - HEX HOLE SCREW 5X35 HIT-6695076.A4 6695076	-
33 - OIL PIPE A HIT-6691219.A10 6691219	-
34 - CLIP 7 HIT-6692312.A20 6692312	-
35 - OIL FILTER BODY COMP. HIT-6697651.A0 6697651	-
*36 - SHIM 0.1 FOR RUS HIT-6686474.A7 6686474	-
*36 - SHIM S T0.2 HIT-6685098.A5 6685098	-
*36 - SHIM S T0.3 HIT-6685099.A29 6685099	-
*36 - SHIM 0.4 HIT-6686475.A16 6686475	-
37 - CRANK CASE ASS'Y HIT-6697589.A4 6697589	-
38 - KNOCK PIN 4X12 HIT-6695521.A37 6695521	-
39 - OIL SEAL ISMX12325.5 HIT-6695633.A13 6695633	£6.18	£7.41
40 - STOP RING C-32 1 HIT-6695295.A59 6695295	£1.67	£2.00
41 - BALL BEARING 6201 A2C3 HIT-6685096.A35 6685096	-
42 - BALL BEARING 6201 A2C3 HIT-6685096.A36 6685096	-
43 - STOP RING C-32 1 HIT-6695295.A60 6695295	£1.67	£2.00
44 - OIL SEAL ISMX12325.5 HIT-6695633.A14 6695633	£6.18	£7.41
45 - CRANKCASE GASKET HIT-6686710.A4 6686710	£1.67	£2.00
46 - AIR VENT VALVE (B) HIT-6685173.A16 6685173	-
47 - AIR VENT COVER HIT-6691399.A2 6691399	£4.72	£5.66
48 - HEX.HOLE BOLT M5X18/S HIT-6684586.A63 6684586	-
49 - HEX. SOCKET HD. BOLT M5X30 S HIT-6684786.A53 6684786	£1.67	£2.00
50 - AIR DEFLECTOR HIT-6687207.A11 6687207	-
51 - BOLT WASHER M8 HIT-6684611.A77 6684611	-
52 - HEX. NUT M8 HIT-6684612.A44 6684612	-
53 - MAGNETO ROTOR ASS'Y HIT-6687395.A8 6687395	£52.30	£62.76
54 - SPECIAL WASHER HIT-6687942.A6 6687942	-
55 - PAWL SPRING HIT-6693348.A1 6693348	-
56 - STARTER PAWL HIT-6693304.A8 6693304	£3.89	£4.67
57 - STEP BOLT HIT-6693366.A10 6693366	-
58 - HANDLE DAMPER HIT-6688107.A11 6688107	-
72 - CLUTCH ASS'Y 1 HIT-6688489.A10 6688489	-
73 - CLUTCH HOUSING COMP.7T HIT-6689009.A3 6689009	£35.35	£42.42
74 - NEEDLE BEARING KT111410G HIT-6695606.A11 6695606	£14.19	£17.03
75 - OIL PUMP COVER HIT-6686755.A1 6686755	-
76 - SCREW GEAR COMP. HIT-6686640.A0 6686640	£38.15	£45.78
77 - OIL PUMP COMP. HIT-6687331.A11 6687331	£46.36	£55.63
78 - PINION WASHER 1T HIT-6686452.A3 6686452	£3.38	£4.06
79 - SMALL SCREW 4X12WS HIT-6695403.A11 6695403	-
80 - HIGH TENSION SCREW 4X18WS HIT-6695407.A38 6695407	-
81 - RELEASE VALVE HIT-6686661.A7 6686661	£1.67	£2.00
82 - O-RING S-3 HIT-6695659.A4 6695659	£1.67	£2.00
83 - O-RING P-5 HIT-6695661.A11 6695661	£1.67	£2.00
84 - CLUTCH SPRING HIT-6689426.A11 6689426	£2.98	£3.57
85 - CLUTCH SHOE HIT-6689493.A12 6689493	-
86 - CLUTCH BOSS HIT-6689497.A0 6689497	-
87 - CLUTCH WASHER B HIT-6689642.A8 6689642	-
101 - AIRCLEANER ELEMENT B COMP. HIT-6690335.A12 6690335	£9.60	£11.52
102 - AIRCLEANER ELEMENT A COMP. HIT-6690325.A8 6690325	£5.97	£7.16
103 - AIRCLEANER BASE COMP. HIT-6690198.A2 6690198	£7.75	£9.30
104 - HEX. HOLE BOLT 5X45 HIT-6695055.A7 6695055	£1.67	£2.00
105 - S.WASHER 5 HIT-6684662.A17 6684662	£1.67	£2.00
106 - SMALL WASHER 5 HIT-6684864.A12 6684864	-
107 - HEX. HOLE BOLT 5X15 WS HIT-6695512.A33 6695512	-
109 - IDLE ADJUSTMENT SCREW TILL E919999 HIT-6687993.A3 6687993	-
109A - IDLE ADJUST SCREW SINCE EO10001 HIT-6685298.A43 6685298	£1.67	£2.00
110 - SPECIAL WASHER HIT-6687943.A10 6687943	£1.67	£2.00
111 - CARB. INSULATOR 1 HIT-6690004.A10 6690004	-
112 - INSULATOR COMP. HIT-6689941.A7 6689941	-
113 - INLET MANIFOLD COMP. HIT-6689789.A11 6689789	-
114 - INLET MANIFOLD GASKET HIT-6689876.A11 6689876	-
115 - HEX. SOCKET HD. BOLT (W/SP.WASHER) M4X12 HIT-6684595.A25 6684595	£1.67	£2.00
116 - IDLE ADJUST SPRING HIT-6690766.A17 6690766	-
117 - INLET MANIFOLD SPACER HIT-6685202.A1 6685202	-
118 - MUFFLER GASKET HIT-6692737.A1 6692737	-
119 - MUFFLER SET HIT-6692459.A11 6692459	-
120 - MUFFLER STAY HIT-6692942.A4 6692942	-
121 - HEX. HOLE BOLT M5X16/S HIT-6684903.A37 6684903	-
122 - HEX. HOLE BOLT 4X10 HIT-6695036.A5 6695036	-
141 - RECOIL STARTER ASS'Y HIT-6692916.A10 6692916	£30.63	£36.76
142 - SET SCREW HIT-6693633.A26 6693633	£1.67	£2.00
143 - STARTER ROPE REEL HIT-6693059.A8 6693059	£13.29	£15.95
144 - RECOIL SPRING CASE HIT-6693096.A3 6693096	£11.90	£14.28
145 - FAN CASE COMP. HIT-6686963.A3 6686963	-
146 - PLATE HIT-6685189.A32 6685189	-
147 - STARTER HANDLE HIT-6693230.A9 6693230	-
148 - STARTER ROPE HIT-6693158.A4 6693158	£4.26	£5.11
150 - HEX. HOLE BOLT 5X15 WS HIT-6695512.A34 6695512	-
201 - CARBURETOR ASS'Y WT-497A FOR EUROPE HIT-6690606.A5 6690606	£93.28	£111.94
202 - INLET SCREEN HIT-6684700.A179 6684700	-
203 - PUMP BODY HIT-6691416.A4 6691416	£16.36	£19.63
204 - SCREW HIT-6685210.A2 6685210	-
205 - PUMP GASKET HIT-6685212.A3 6685212	£3.29	£3.95
206 - PUMP DIAPHRAGM HIT-6685213.A53 6685213	£8.44	£10.13
207 - NEEDLE VALVE HIT-6685215.A3 6685215	£6.79	£8.15
208 - DIAPHRAGM PACKING-METERING HIT-6685220.A156 6685220	£2.81	£3.37
209 - METERING DIAPHRAGM COMP. HIT-6690827.A33 6690827	£14.02	£16.83
210 - DIAPHRAGM COVER-METERING HIT-6685222.A18 6685222	£5.70	£6.84
211 - VALVE SPRING HIT-6690872.A19 6690872	-
212 - HINGE PIN SET SCREW HIT-6685218.A66 6685218	-
213 - HINGE PIN HIT-6685219.A4 6685219	-
214 - CONTROL LEVER HIT-6685217.A2 6685217	-
215 - SET SCREW HIT-6685223.A67 6685223	-
216 - CARBURETOR ASS'Y 1 HIT-6690604.A0 6690604	-
217 - HIGH/LOW ADJUST SPRING FOR RUS HIT-6692048.A10 6692048	-
218 - LOW ADJUSTMENT SCREW FOR RUS HIT-6690719.A6 6690719	-
219 - HIGH ADJUSTMENT SPRING FOR RUS HIT-6690897.A12 6690897	-
220 - HIGH ADJUSTMENT SCREW FOR RUS HIT-6690697.A2 6690697	-
231 - AIRCLEANER KNOB COMP. HIT-6687793.A8 6687793	£5.92	£7.11
232 - CLEANER COVER SET 1 HIT-6690404.A4 6690404	£8.88	£10.66
233 - IDLE GROMMET HIT-6687974.A0 6687974	-
234 - ADJUSTER CAP HIT-6687954.A8 6687954	-
235 - CYLINDER COVER HIT-6685681.A0 6685681	-
236 - CYLINDR SUPPORT RUBBER HIT-6691825.A5 6691825	-
237 - CLEANER PACKING HIT-6690056.A8 6690056	-
238 - HEX. HOLE BOLT 5X15 WS HIT-6695512.A30 6695512	-
239 - INSULATOR TUBE 1 HIT-6688315.A8 6688315	-
240 - CHOKE BUTTON COMP. HIT-6692507.A2 6692507	-
241 - CHOKE ROD HOLDING RUBBER HIT-6692587.A8 6692587	-
242 - STOP SWITCH COMP. HIT-6687506.A7 6687506	£7.12	£8.54
243 - CONTROL PLATE HIT-6691192.A10 6691192	-
244 - SHUTTER PLATE HIT-6687952.A3 6687952	-
245 - STOP CORD 1 HIT-6687929.A1 6687929	-
246 - HEX.HOLE BOLT M5X12/S HIT-6684667.A89 6684667	£1.67	£2.00
247 - BUMPER SPIKE HIT-6690705.A0 6690705	£5.59	£6.71
248 - CHAIN CATCHER HIT-6687163.A10 6687163	-
249 - SPECIAL BOLT HIT-6689734.A10 6689734	-
250 - FUEL PIPE HIT-6685154.A6 6685154	-
251 - DAMPER COMP. HIT-6688113.A3 6688113	£5.70	£6.84
252 - TAPPING SCREW 5X35 HIT-6695107.A1 6695107	£1.67	£2.00
253 - COLLAR 15 HIT-6692248.A4 6692248	£1.67	£2.00
254 - OIL TANK CAP ASS'Y HIT-6697756.A18 6697756	£5.87	£7.04
255 - OIL TANK CAP PACKING HIT-6697888.A9 6697888	£1.67	£2.00
256 - IGNITION COIL COMP. HIT-6687695.A4 6687695	£73.85	£88.62
257 - HEX. HOLE BOLT M4X18/WS HIT-6684599.A33 6684599	-
271 - NUT M4 HIT-6685069.A24 6685069	-
272 - CHAIN BAR CLAMP NUT HIT-6687105.A2 6687105	£1.67	£2.00
273 - TAP SCREW 4X14 P HIT-6695280.A37 6695280	£1.67	£2.00
274 - FRONT HAND GUARD HIT-6693454.A5 6693454	£7.57	£9.08
275 - MACHINE SCREW (W/SP. WASHER) M4X12 HIT-6685068.A7 6685068	-
276 - HAND GUARD WEIGHT HIT-6693481.A0 6693481	-
277 - SIDE CASE ASS'Y HIT-6686095.A0 6686095	£92.02	£110.42
278 - TAPPING SCREW D4X10 HIT-6685161.A64 6685161	£1.67	£2.00
279 - BRAKE BAND HOLDER HIT-6689715.A0 6689715	-
280 - SIDE COVER COMP. HIT-6686043.A8 6686043	-
281 - CLEANER FIXING COLLAR HIT-6690805.A15 6690805	£2.69	£3.23
282 - BRAKE SUPPORT FITTING COMP. HIT-6689777.A0 6689777	-
283 - BRAKE LEVER SPRING HIT-6689781.A0 6689781	-
284 - BRAKE LINK COMP. HIT-6685121.A4 6685121	£18.38	£22.05
285 - BRAKE SPRING HIT-6689700.A0 6689700	£3.56	£4.27
286 - BRAKE BAND HIT-6689724.A0 6689724	£15.38	£18.45
287 - NEEDLE ROLLER 3X9.8 HIT-6685141.A11 6685141	-
288 - BRAKE LINK COVER HIT-6689709.A10 6689709	-
289 - TAPPING SCREW D4X10 HIT-6685161.A65 6685161	£1.67	£2.00
290 - GUIDE PLATE B HIT-6697598.A1 6697598	£3.56	£4.27
291 - SCREW 4X8 HIT-6694861.A12 6694861	-
292 - GUIDE PLATE A HIT-6697597.A11 6697597	£3.56	£4.27
293 - CHAIN BAR STUD BOLT HIT-6686804.A7 6686804	-
294 - CHAIN TENSION BOLT ASSY HIT-6687067.A0 6687067	£5.70	£6.84
311 - TAPPING SCREW 5X18 HIT-6695106.A24 6695106	-
312 - REAR HANDLE GRIP HIT-6688212.A2 6688212	-
313 - TRIGGER LOCKOUT BLACK HIT-6688352.A10 6688352	-
314 - THROTTLE ROD COMP. HIT-6690967.A0 6690967	-
315 - THROTTLE LEVER HIT-6686381.A6 6686381	-
316 - THROTTLE LEVER SPRING HIT-6686412.A1 6686412	-
317 - REAR HANDLE ASS'Y HIT-6685663.A4 6685663	£50.06	£60.07
318 - SPRING PIN 5X25 HIT-6685282.A2 6685282	£1.67	£2.00
319 - NO LONGER AVAILABLE HIT-6688079.A1 6688079	-
320 - TAPPING SCREW 5X18 HIT-6695106.A23 6695106	-
321 - AIR VENT VALVE ASS'Y HIT-6692172.A15 6692172	-
322 - AIRVENT PIPE HIT-6691391.A10 6691391	-
323 - FRONT DAMPER HIT-6688241.A11 6688241	-
324 - DAMPER COMP. HIT-6688261.A11 6688261	-
325 - DAPMPER COLLAR HIT-6688478.A6 6688478	-
326 - HEX. HOLE BOLT 4X20 HIT-6695039.A7 6695039	-
327 - CLIP 5.2 HIT-6692311.A8 6692311	-
328 - FUEL PIPE ASS'Y L=195 HIT-6688173.A7 6688173	-
329 - CLIP 1 HIT-6684619.A37 6684619	£1.67	£2.00
330 - PUMP FILTER BODY HIT-6692285.A8 6692285	£10.40	£12.48
331 - TANK CAP ASS'Y HIT-6692111.A1 6692111	£5.87	£7.04
332 - TANK CAP PACKING HIT-6685179.A15 6685179	£1.67	£2.00
*501 - CHAIN BAR 15 FOR EUROPE HIT-6687334.A1 6687334	£43.64	£52.37
*501 - CHAIN BAR 15 0.325 SP FOR RUS HIT-6695924.A0 6695924	-
502 - SAW CHAIN 15 INCH HIT-6687335.A0 6687335	£30.92	£37.11
503A - CHAIN COVER 16 HIT-6685440.A8 6685440	£13.86	£16.63
504 - COMBI. BOX SPANNER 13X19 MINUS HIT-6693809.A12 6693809	-
601 - NANE PLATE CS38EK FOR EUROPE HIT-6694399.A0 6694399	-
602 - STARTER MARK CS38EK FOR EUROPE HIT-6694502.A0 6694502	-
603 - STARTER MARK CS38EK FOR RUS HIT-6699644.A0 6699644	-

Attribute Name	Value
Brand	Hikoki

Reviews Write your own review!

There are currently no reviews of this product.

Fill in the form below to add your review for Hitachi / Hikoki CS38EK Engine Chain Saw Spare Parts

Your Review
Title Required!
Rating Required!
Your Review Required!
Your Details
Your Name Required!
Your Location Required!
Email Address Required!Invalid email!

United Kingdom (Including N. Ireland)

On orders up to £40.00	Add £4.00 inc VAT (Royal Mail post)
On orders £40.00 to £130.00	Add £7.00 inc VAT (Courier)
On orders over £130.00	FREE (Courier)

Shopping Basket (0) £0.00

Hitachi / Hikoki CS38EK Engine Chain Saw Spare Parts

Your Review

Your Details

Carry On Shopping

Try these categories

Recently Viewed

Your Order

About Us

Other Links

Search

Customization

Shopping Basket (0) £0.00

Information

Hitachi / Hikoki CS38EK Engine Chain Saw Spare Parts

Notify me

Your Review

Your Details

Carry On Shopping

Try these categories

Recently Viewed

Your Order

About Us

Other Links

Search
