1 - SPARK PLUG CAP ASS'Y
HIT-6687468.A54
6687468
|
£3.64
|
£4.37
|
|
|
*2 - SPARK PLUG ASS'Y BMR6A FOR EUROPE
HIT-6699315.A2
6699315
|
-
|
|
|
|
*2 - SPARK PLUG ASS'Y RCJ8 FOR BRA
HIT-6699327.A0
6699327
|
-
|
|
|
|
3 - CYLINDER SET
HIT-6685457.A3
6685457
|
£63.42
|
£76.10
|
|
|
4 - CYLINDER GASKET
HIT-6685724.A1
6685724
|
-
|
|
|
|
5 - PISTON SET
HIT-6685879.A10
6685879
|
£39.02
|
£46.82
|
|
|
6 - CIRCLIP
HIT-6685078.A2
6685078
|
-
|
|
|
|
7 - PISTON RING (XR1-1856)
HIT-6685331.A3
6685331
|
£12.57
|
£15.08
|
|
|
8 - PISTON PIN
HIT-6686008.A9
6686008
|
£3.64
|
£4.37
|
|
|
9 - HEX. HOLE BOLT M5X16/S
HIT-6684903.A36
6684903
|
-
|
|
|
|
10 - CRANK SHAFT COMP
HIT-6697636.A3
6697636
|
-
|
|
|
|
11 - CORD 1
HIT-6687837.A1
6687837
|
-
|
|
|
|
12 - IGNITION COIL COMP.
HIT-6687700.A11
6687700
|
£40.13
|
£48.16
|
|
|
13 - TAB
HIT-6688060.A3
6688060
|
-
|
|
|
|
14 - HIGH TENSION SCREW 4X18WS
HIT-6695407.A40
6695407
|
-
|
|
|
|
15 - WOODRUFF KEY 3X13X4.5 TILL ED09999
HIT-6684899.A87
6684899
|
-
|
|
|
|
16 - CORD INSULATOR TUBE TILL E609999
HIT-6692900.A19
6692900
|
-
|
|
|
|
20 - CRANK CASE ASS'Y
HIT-6686523.A3
6686523
|
-
|
|
|
|
21 - OIL SEAL TB 12227
HIT-6684607.A71
6684607
|
£4.07
|
£4.88
|
|
|
22 - NEEDLE ROLLER 2.5X9.8
HIT-6685095.A2
6685095
|
-
|
|
|
|
23 - BALL BEARING 6201 A2C3
HIT-6685096.A37
6685096
|
-
|
|
|
|
24 - CRANK CASE GASKET
HIT-6686701.A3
6686701
|
-
|
|
|
|
25 - HEX.HOLE BOLT M5X20/S
HIT-6684668.A15
6684668
|
-
|
|
|
|
26A - MAGNETO ROTOR ASS'Y SINCE E110001
HIT-6697953.A8
6697953
|
-
|
|
|
|
27 - D4E RETAINING RING
HIT-6685101.A6
6685101
|
-
|
|
|
|
28 - STARTER PAWL SPRING
HIT-6685105.A18
6685105
|
£1.67
|
£2.00
|
|
|
29A - STARTER PAWL
HIT-6685334.A29
6685334
|
£2.84
|
£3.41
|
|
|
30 - BOLT WASHER M7
HIT-6685103.A31
6685103
|
-
|
|
|
|
31 - FLYWHEEL NUT
HIT-6685104.A4
6685104
|
-
|
|
|
|
*32 - SHIM S T0.2
HIT-6685098.A4
6685098
|
-
|
|
|
|
*32 - SHIM S T0.3
HIT-6685099.A30
6685099
|
-
|
|
|
|
*32 - SHIM 0.4
HIT-6686475.A18
6686475
|
-
|
|
|
|
33 - S.WASHER 7 TILL E500020
HIT-6695222.A6
6695222
|
-
|
|
|
|
40 - ENGINE CASE ASS'Y 1
HIT-6691365.A4
6691365
|
-
|
|
|
|
41 - AIR VENT VALVE (B)
HIT-6685173.A17
6685173
|
-
|
|
|
|
42 - AIR VENT VALVE SET
HIT-6697231.A9
6697231
|
£6.80
|
£8.16
|
|
|
43 - HEX.HOLE BOLT 5X20/PS
HIT-6684634.A47
6684634
|
£1.67
|
£2.00
|
|
|
44 - EARTH CORD 90M
HIT-6697602.A0
6697602
|
-
|
|
|
|
45A - STOP SWITCH ASS'Y
HIT-6601374.A13
6601374
|
£16.45
|
£19.74
|
|
|
46 - SWITCH NAME PLATE
HIT-6687949.A15
6687949
|
£1.67
|
£2.00
|
|
|
50 - CLEANER COVER TILL E809999
HIT-6686302.A1
6686302
|
-
|
|
|
|
50A - AIRCLEANER COVER A SET 1
HIT-6686299.A10
6686299
|
-
|
|
|
|
51 - CLEANER COVER BOLT
HIT-6689735.A2
6689735
|
-
|
|
|
|
52 - AIRCLEANER ELEMENT COMP.
HIT-6690064.A3
6690064
|
£6.47
|
£7.76
|
|
|
53 - INSULATOR SET
HIT-6689935.A3
6689935
|
-
|
|
|
|
54 - INSULATOR GASKET
HIT-6689871.A3
6689871
|
-
|
|
|
|
55 - CARBURETOR INSULATOR RUBBER
HIT-6690001.A1
6690001
|
-
|
|
|
|
56 - VALVE HOLDER
HIT-6689806.A3
6689806
|
-
|
|
|
|
57 - REED VALVE
HIT-6689803.A3
6689803
|
-
|
|
|
|
58 - BINDING HEAD SCREW 3X12
HIT-6694964.A1
6694964
|
-
|
|
|
|
59 - CARBURETOR GASKET
HIT-6698108.A3
6698108
|
-
|
|
|
|
60 - CARBURETOR SET 1
HIT-6690667.A1
6690667
|
£81.68
|
£98.01
|
|
|
61 - SCREW 5X45S
HIT-6695350.A13
6695350
|
-
|
|
|
|
62 - CHOKE SHIM 1.0
HIT-6692597.A3
6692597
|
-
|
|
|
|
63 - SMALL WASHER 5
HIT-6684864.A16
6684864
|
-
|
|
|
|
64 - CHOKE VALVE
HIT-6692410.A1
6692410
|
-
|
|
|
|
65 - TAPPING SCREW D4.5X14
HIT-6685152.A6
6685152
|
-
|
|
|
|
66 - AIRCLEANER COVER B
HIT-6687344.A1
6687344
|
-
|
|
|
|
67 - HEX.HOLE BOLT M5X20/S
HIT-6684668.A16
6684668
|
-
|
|
|
|
68 - SMALL WASHER 5
HIT-6684864.A15
6684864
|
-
|
|
|
|
69 - IDLE SPONGE
HIT-6685224.A1
6685224
|
-
|
|
|
|
71 - AIRCLEANER SPONGE TILL E890040
HIT-6690355.A1
6690355
|
£1.67
|
£2.00
|
|
|
72 - SEAL COVER TILL E890040
HIT-6687182.A8
6687182
|
-
|
|
|
|
81 - MUFFLER SET
HIT-6692447.A4
6692447
|
-
|
|
|
|
82 - MUFFLER GASKET
HIT-6692734.A13
6692734
|
-
|
|
|
|
83 - MUFFLER BODY B COMP.
HIT-6692627.A7
6692627
|
-
|
|
|
|
84 - MUFFLER FITTING METAL
HIT-6692677.A2
6692677
|
-
|
|
|
|
85 - MUFFLER COUPLING GASKET
HIT-6692833.A7
6692833
|
-
|
|
|
|
86 - MUFFLER BODY A COMP.
HIT-6692607.A2
6692607
|
-
|
|
|
|
87 - HEX. HOLE BOLT 5X40
HIT-6695054.A8
6695054
|
£1.67
|
£2.00
|
|
|
88 - WASHER 5
HIT-6684661.A87
6684661
|
£1.67
|
£2.00
|
|
|
101 - OIL PIPE B
HIT-6691121.A11
6691121
|
-
|
|
|
|
102 - CLIP 7
HIT-6692312.A18
6692312
|
-
|
|
|
|
103 - WASHER 5
HIT-6684661.A88
6684661
|
£1.67
|
£2.00
|
|
|
104 - OIL FILTER
HIT-6690919.A7
6690919
|
-
|
|
|
|
105 - OIL FILTER BODY ASS'Y
HIT-6685249.A1
6685249
|
£1.67
|
£2.00
|
|
|
106 - THROTTLE ROD
HIT-6690974.A0
6690974
|
-
|
|
|
|
107 - THROTTLE GUIDE
HIT-6690982.A1
6690982
|
-
|
|
|
|
108 - PRIMING PUMP COMP.
HIT-6685139.A32
6685139
|
£10.67
|
£12.80
|
|
|
109 - FUEL PIPE 2.5X4X42
HIT-6685138.A7
6685138
|
£1.67
|
£2.00
|
|
|
110 - RUBBER PIPE
HIT-6692292.A8
6692292
|
£12.50
|
£15.00
|
|
|
111 - PUMP FILTER BODY
HIT-6685199.A18
6685199
|
£6.38
|
£7.66
|
|
|
112 - FUEL PIPE 2.5X4X150
HIT-6692351.A3
6692351
|
-
|
|
|
|
113 - RETURN GROMMET
HIT-6697846.A3
6697846
|
£1.68
|
£2.01
|
|
|
114 - O-RING P-18 FKM
HIT-6697780.A2
6697780
|
-
|
|
|
|
115 - ADJUSTER CAP
HIT-6687957.A6
6687957
|
-
|
|
|
|
116 - GROMMET
HIT-6692590.A11
6692590
|
£1.67
|
£2.00
|
|
|
117 - CHOKE BUTTON COMP.
HIT-6692513.A1
6692513
|
-
|
|
|
|
118 - GROMMET
HIT-6687976.A13
6687976
|
-
|
|
|
|
119 - O RING TILL E619999
HIT-6697898.A14
6697898
|
-
|
|
|
|
119A - O-RING P21 SINCE E710001
HIT-6699285.A5
6699285
|
-
|
|
|
|
120 - OIL TANK CAP ASS'Y
HIT-6692159.A2
6692159
|
£8.38
|
£10.06
|
|
|
121A - TANK CAP ASS'Y
HIT-6692121.A6
6692121
|
-
|
|
|
|
131 - RECOIL STARTER ASS'Y OR TILL E809999
HIT-6692909.A3
6692909
|
-
|
|
|
|
131A - RECOIL STARTER ASS'Y OR SINCE E900001
HIT-6697606.A1
6697606
|
-
|
|
|
|
132 - FAN CASE COMP. OR TILL E809999
HIT-6686950.A1
6686950
|
-
|
|
|
|
133 - STARTER HANDLE TILL E809999
HIT-6693240.A10
6693240
|
£16.35
|
£19.62
|
|
|
134 - ROPE TILL E809999
HIT-6693168.A23
6693168
|
£2.82
|
£3.39
|
|
|
135 - RECOIL SPRING TILL E809999
HIT-6693138.A0
6693138
|
£12.10
|
£14.52
|
|
|
136 - SPRING CASE ASS'Y TILL E809999
HIT-6693094.A2
6693094
|
£29.16
|
£34.99
|
|
|
137 - STARTER PULLEY TILL E809999
HIT-6693061.A2
6693061
|
-
|
|
|
|
138 - SPECIAL WASHER 5.2X15 TILL E809999
HIT-6687947.A1
6687947
|
-
|
|
|
|
139 - TAPPING SCREW D5X14 TILL E809999
HIT-6685275.A6
6685275
|
-
|
|
|
|
140 - TAPPING SCREW D4.5X20
HIT-6685191.A4
6685191
|
-
|
|
|
|
141 - AIR DEFLECTOR TILL E809999
HIT-6687326.A1
6687326
|
-
|
|
|
|
142 - FAN CASE COMP OR SINCE E900001
HIT-6697608.A1
6697608
|
-
|
|
|
|
143 - STARTER HANDLE SINCE E900001
HIT-6693230.A10
6693230
|
-
|
|
|
|
144 - ROPE SINCE E900001
HIT-6685186.A7
6685186
|
-
|
|
|
|
145 - DAMPER SPRING SINCE E900001
HIT-6685183.A22
6685183
|
£5.70
|
£6.84
|
|
|
146 - SPRING CASE SET SINCE E900001
HIT-6685185.A6
6685185
|
£11.12
|
£13.35
|
|
|
147 - STARTER PULLEY SINCE E900001
HIT-6685184.A7
6685184
|
£6.18
|
£7.41
|
|
|
148 - SET SCREW SINCE E900001
HIT-6684679.A47
6684679
|
£2.98
|
£3.57
|
|
|
149 - CAM PLATE SINCE E900001
HIT-6685182.A5
6685182
|
£3.56
|
£4.27
|
|
|
150 - PLATE SINCE E900001
HIT-6685189.A31
6685189
|
-
|
|
|
|
161 - INLET SCREEN
HIT-6684700.A177
6684700
|
-
|
|
|
|
162 - PUMP BODY
HIT-6691416.A2
6691416
|
£16.36
|
£19.63
|
|
|
163 - SCREW
HIT-6685210.A1
6685210
|
-
|
|
|
|
164 - PUMP GASKET
HIT-6685212.A1
6685212
|
£3.29
|
£3.95
|
|
|
165 - PUMP DIAPHRAGM
HIT-6685213.A55
6685213
|
£8.44
|
£10.13
|
|
|
168 - CONTROL LEVER
HIT-6685217.A1
6685217
|
-
|
|
|
|
169 - HINGE PIN SET SCREW
HIT-6685218.A67
6685218
|
-
|
|
|
|
170 - VALVE SPRING
HIT-6690873.A1
6690873
|
-
|
|
|
|
171 - HINGE PIN
HIT-6685219.A3
6685219
|
-
|
|
|
|
172 - DIAPHRAGM COVER-METERING
HIT-6685222.A17
6685222
|
£5.70
|
£6.84
|
|
|
173 - METERING DIAPHRAGM COMP.
HIT-6690827.A35
6690827
|
£14.02
|
£16.83
|
|
|
174 - DIAPHRAGM PACKING-METERING
HIT-6685220.A157
6685220
|
£2.81
|
£3.37
|
|
|
175 - NEEDLE VALVE
HIT-6685215.A1
6685215
|
£6.79
|
£8.15
|
|
|
176 - IDLE ADJUST SPRING
HIT-6685297.A0
6685297
|
-
|
|
|
|
177 - IDLE ADJUST SCREW
HIT-6685298.A45
6685298
|
£1.67
|
£2.00
|
|
|
180 - SET SCREW
HIT-6685223.A68
6685223
|
-
|
|
|
|
191 - SCREW 5X14/WS
HIT-6695416.A5
6695416
|
-
|
|
|
|
192 - OIL PUMP COVER
HIT-6686763.A9
6686763
|
-
|
|
|
|
193 - OIL PIPE A
HIT-6691223.A10
6691223
|
-
|
|
|
|
194 - SCREW GEAR
HIT-6686645.A2
6686645
|
£15.03
|
£18.04
|
|
|
195 - AIR VENT SPONGE
HIT-6691400.A10
6691400
|
-
|
|
|
|
196 - OIL PUMP ASS'Y
HIT-6687324.A9
6687324
|
£17.82
|
£21.39
|
|
|
197 - OIL ADJUST GROMMET
HIT-6690956.A10
6690956
|
-
|
|
|
|
198 - OIL PUMP ADJUSTER
HIT-6691070.A1
6691070
|
-
|
|
|
|
199 - O RING
HIT-6697917.A2
6697917
|
-
|
|
|
|
200 - OIL PUMP CASE SET 1
HIT-6686681.A2
6686681
|
-
|
|
|
|
201 - O RING
HIT-6697917.A3
6697917
|
-
|
|
|
|
202 - TAPPING SCREW D5X14
HIT-6685275.A5
6685275
|
-
|
|
|
|
203 - FUEL PIPE TILL E200030
HIT-6685154.A3
6685154
|
-
|
|
|
|
204 - CHAIN CATCHER
HIT-6685155.A19
6685155
|
-
|
|
|
|
205 - TAPPING SCREW D4.5X14
HIT-6685152.A5
6685152
|
-
|
|
|
|
221 - NUT TILL E890040
HIT-6685166.A7
6685166
|
£3.62
|
£4.35
|
|
|
221A - CHAIN BAR CLAMP NUT SINCE E990001
HIT-6687105.A4
6687105
|
£1.67
|
£2.00
|
|
|
222 - CLUTCH COMP.
HIT-6685142.A9
6685142
|
£16.34
|
£19.61
|
|
|
223 - NEEDLE BEARING
HIT-6685143.A7
6685143
|
£4.72
|
£5.66
|
|
|
224 - CLUTCH HOUSING COMP.
HIT-6685144.A8
6685144
|
£11.93
|
£14.32
|
|
|
225 - CLUTCH WASHER
HIT-6685145.A5
6685145
|
-
|
|
|
|
226 - TAPPING SCREW D4X10
HIT-6685161.A59
6685161
|
£1.67
|
£2.00
|
|
|
227 - GUIDE PLATE A
HIT-6697599.A12
6697599
|
-
|
|
|
|
228 - CRANK SHAFT COLLAR
HIT-6685146.A9
6685146
|
£1.67
|
£2.00
|
|
|
229 - TAPPING SCREW D4X10
HIT-6685161.A58
6685161
|
£1.67
|
£2.00
|
|
|
231 - GUIDE PLATE B
HIT-6690756.A10
6690756
|
£2.81
|
£3.37
|
|
|
232 - SCREW 2.6X5
HIT-6695269.A4
6695269
|
-
|
|
|
|
233B - CHAIN PULLER INCLUD.234
HIT-6698986.A22
6698986
|
£18.88
|
£22.66
|
|
|
234 - GEAR (A)
HIT-6685168.A11
6685168
|
£3.45
|
£4.14
|
|
|
235 - BRAKE HANDLE COMP.
HIT-6697958.A4
6697958
|
£15.15
|
£18.18
|
|
|
236 - BRAKE LINK COVER 1
HIT-6689712.A7
6689712
|
£4.65
|
£5.58
|
|
|
237 - BRAKE SPRING
HIT-6697694.A6
6697694
|
-
|
|
|
|
238 - BRAKE SUPPORT PLATE COMP.
HIT-6685119.A7
6685119
|
-
|
|
|
|
239 - NEEDLE ROLLER 3X9.8
HIT-6685141.A10
6685141
|
-
|
|
|
|
240 - BRAKE LINK
HIT-6685388.A5
6685388
|
£12.57
|
£15.08
|
|
|
241 - BRAKE BAND
HIT-6689728.A9
6689728
|
-
|
|
|
|
242 - CLEANER FIXING COLLAR
HIT-6690805.A19
6690805
|
£2.69
|
£3.23
|
|
|
243 - COLLAR
HIT-6685120.A9
6685120
|
-
|
|
|
|
244 - SIDE COVER COMP
HIT-6697614.A0
6697614
|
-
|
|
|
|
245 - BRAKE LEVER SPRING
HIT-6685122.A10
6685122
|
-
|
|
|
|
246 - TAPPING SCREW D4X15
HIT-6685148.A5
6685148
|
-
|
|
|
|
261 - NYLON LOCK NUT 4
HIT-6695163.A10
6695163
|
-
|
|
|
|
262 - TAPPING SCREW 5X40
HIT-6695108.A11
6695108
|
-
|
|
|
|
263 - DAMPER COLLAR A
HIT-6688480.A15
6688480
|
-
|
|
|
|
264 - DAMPER A
HIT-6688117.A15
6688117
|
-
|
|
|
|
265 - SCREW 4X30PS
HIT-6695378.A3
6695378
|
-
|
|
|
|
266 - REAR HANDLE B COMP.
HIT-6685645.A0
6685645
|
-
|
|
|
|
267 - PUSH PIN CAP
HIT-6692680.A4
6692680
|
-
|
|
|
|
268 - STOPPER SPRING
HIT-6686447.A7
6686447
|
£1.67
|
£2.00
|
|
|
269 - PUSH PIN
HIT-6686430.A9
6686430
|
£1.67
|
£2.00
|
|
|
270 - TRIGGER LOCKOUT VERMILION
HIT-6688363.A11
6688363
|
-
|
|
|
|
271 - THROTTLE LEVER
HIT-6686392.A5
6686392
|
-
|
|
|
|
272 - THROTTLE LEVER SPRING
HIT-6686416.A8
6686416
|
£2.71
|
£3.25
|
|
|
273 - REAR HANDLE
HIT-6685620.A1
6685620
|
-
|
|
|
|
274 - TAPPING SCREW 5X35
HIT-6695107.A7
6695107
|
£1.67
|
£2.00
|
|
|
275 - TAPPING SCREW D4X15
HIT-6685148.A6
6685148
|
-
|
|
|
|
276 - FRONT HANDLE
HIT-6688083.A4
6688083
|
£6.59
|
£7.91
|
|
|
277 - DAMPER B
HIT-6688412.A0
6688412
|
£1.67
|
£2.00
|
|
|
278 - DAMPER COLLAR B
HIT-6688485.A2
6688485
|
£1.67
|
£2.00
|
|
|
279 - TAPPING SCREW 5X35
HIT-6695107.A6
6695107
|
£1.67
|
£2.00
|
|
|
501 - CHAIN BAR 14 INCH 3/8 SPROCKET
HIT-6685295.A4
6685295
|
£30.92
|
£37.11
|
|
|
502 - SAW CHAIN (3/8X14) 91PX-52XJ
HIT-781124.A8
781124
|
£13.99
|
£16.79
|
|
|
503 - CHAIN COVER 14
HIT-6685256.A0
6685256
|
-
|
|
|
|
505 - COMBI BOX SPANNER 10/19MM TILL E890040
HIT-6685257.A23
6685257
|
-
|
|
|
|
505A - COMBI. BOX SPANNER 13X19 MINUS SINCE E990001
HIT-6693809.A14
6693809
|
-
|
|
|
|
601 - NAME PLATE CS35EG(S)
HIT-6694409.A0
6694409
|
-
|
|
|
