Hitachi / Hikoki CS30EH Engine Chain Saw Spare Parts

An exploded diagram and spare parts listing for the Hitachi / Hikoki CS30EH Engine Chain Saw

	Ex VAT	Inc VAT
1 - SPARK PLUG CAP ASS'Y HIT-6687468.A47 6687468	£3.64	£4.37
2 - SPARK PLUG ASS'Y RCJ8Y HIT-6699328.A1 6699328	£5.70	£6.84
3 - CYLINDER SET HIT-6685460.A0 6685460	-
4 - HEX.HOLE BOLT M5X18/S HIT-6684586.A61 6684586	-
5 - CYLINDER GASKET HIT-6685725.A1 6685725	-
6 - PISTON RING HIT-6686122.A0 6686122	-
7 - PISTON SET 1 HIT-6685880.A0 6685880	-
8 - PISTON PIN HIT-6686008.A7 6686008	£3.64	£4.37
9 - CIRCLIP HIT-6685078.A0 6685078	-
10 - CRANK SHAFT COMP. HIT-6686172.A1 6686172	-
11 - WOODRUFF KEY 3X13X4.5 HIT-6684899.A89 6684899	-
12 - HIGH TENSION SCREW 4X18WS HIT-6695407.A43 6695407	-
13 - IGNITION COIL COMP. HIT-6685089.A1 6685089	£39.71	£47.65
14 - HIGHTENSION SION CORD 110L HIT-6687890.A1 6687890	-
15 - RUBBER CAP HIT-6684602.A16 6684602	-
16 - IGNITION COIL ASS'Y HIT-6687667.A1 6687667	-
17 - CORD INSULATOR TUBE HIT-6692900.A16 6692900	-
*21 - SHIM 0.1 HIT-6686474.A6 6686474	-
*21 - SHIM S T0.2 HIT-6685098.A9 6685098	-
*21 - SHIM S T0.3 HIT-6685099.A25 6685099	-
22 - FLYWHEEL NUT HIT-6685104.A7 6685104	-
23 - S.WASHER 7 HIT-6695222.A10 6695222	-
24 - BOLT WASHER M7 HIT-6685103.A27 6685103	-
25A - MAGNETO SUB ASS'Y INCLUD.26A-28 HIT-6600090.A10 6600090	-
26A - STARTER PAWL HIT-6685334.A34 6685334	£2.84	£3.41
27 - STARTER PAWL SPRING HIT-6685105.A16 6685105	£1.67	£2.00
28 - D4E RETAINING RING HIT-6685101.A8 6685101	-
29 - HEX.HOLE BOLT M5X20/S HIT-6684668.A12 6684668	-
30 - CRANK CASE ASS'Y HIT-6686524.A0 6686524	-
31 - OIL SEAL TB 12227 HIT-6684607.A72 6684607	£4.07	£4.88
32 - CRANK CASE GASKET HIT-6686702.A0 6686702	-
33 - BALL BEARING 6201 A2C3 HIT-6685096.A29 6685096	-
34 - NEEDLE ROLLER 2.5X9.8 HIT-6685095.A4 6685095	-
51 - CLEANER BODY COMP. HIT-6687421.A0 6687421	-
52 - INLET MANIFOLD GASKET HIT-6689876.A13 6689876	-
53 - INLET MANIFOLD SPACER HIT-6685202.A3 6685202	-
54 - INLET MANIFOLD COMP. HIT-6689787.A0 6689787	-
55 - ENGINE CASE ASS'Y HIT-6691367.A0 6691367	-
56 - AIR VENT VALVE (B) HIT-6685173.A18 6685173	-
57 - PULSE GUIDE HIT-6685203.A4 6685203	-
58 - INNER CAP HIT-6685175.A2 6685175	-
59 - HEX.HOLE BOLT 5X20/PS HIT-6684634.A48 6684634	£1.67	£2.00
60 - BLOW OVER CHECK BOARD HIT-6690843.A23 6690843	£1.67	£2.00
61 - CHOKE VALVE HIT-6692411.A1 6692411	-
62 - CHOKE SHIM 0.8 HIT-6692596.A4 6692596	-
63 - CHOKE ROD RUBBER HIT-6692591.A0 6692591	-
64 - CHOKE BUTTON COMP. HIT-6692514.A1 6692514	-
*65 - ADJUSTER CAP FOR EUROPE HIT-6687959.A0 6687959	-
*65 - ADJUSTER CAP FOR RUS HIT-6687958.A0 6687958	-
66 - IDLE SPONGE HIT-6685224.A5 6685224	-
67 - CLEANER COVER SET HIT-6686304.A0 6686304	-
68 - CLEANER COVER BOLT HIT-6689735.A0 6689735	-
69 - CLEANER ELEMENT HIT-6690074.A1 6690074	£5.61	£6.73
70 - HEX. SOCKET HD. BOLT (W/SP.WASHER) M4X12 HIT-6684595.A27 6684595	£1.67	£2.00
71 - TAPPING SCREW D4.5X14 HIT-6685153.A18 6685153	-
72 - SCREW 5X42/WS HIT-6695428.A0 6695428	-
73 - HEX. HOLE BOLT 5X18PS HIT-6695505.A27 6695505	-
74 - COLLAR HIT-6685853.A1 6685853	-
75 - SMALL WASHER 5 HIT-6684864.A20 6684864	-
81 - HEX. HOLE BOLT 5X40 HIT-6695054.A6 6695054	£1.67	£2.00
82 - S.WASHER 5 HIT-6684662.A19 6684662	£1.67	£2.00
83 - MUFFLER SET HIT-6692448.A0 6692448	-
84 - MUFFLER BODY B COMP. HIT-6692628.A0 6692628	-
85 - MUFFLER PIPE HIT-6692679.A0 6692679	-
86 - MUFFLER JOINT GASKET HIT-6692834.A0 6692834	-
87 - MUFFLER BODY A COMP. HIT-6692608.A0 6692608	-
88 - MUFFLER GASKET HIT-6692735.A1 6692735	-
101 - OIL PIPE B HIT-6691121.A7 6691121	-
102 - CLIP 7 HIT-6692312.A15 6692312	-
103 - WASHER 5 HIT-6684661.A82 6684661	£1.67	£2.00
104 - OIL FILTER HIT-6690919.A10 6690919	-
105 - OIL FILTER BODY ASS'Y HIT-6685249.A7 6685249	£1.67	£2.00
106 - PIPE JOINT HIT-6685196.A3 6685196	-
107 - PRIMING PUMP COMP. HIT-6685139.A38 6685139	£10.67	£12.80
108 - FUEL PIPE 2.5X4X90 HIT-6685267.A1 6685267	£1.67	£2.00
109 - FUEL PIPE 2.5X4X210 HIT-6692353.A0 6692353	-
110 - RUBBER PIPE TILL EN99999 HIT-6697174.A1 6697174	-
110A - RUBBER PIPE SINCE ED90001 HIT-6697632.A0 6697632	£7.03	£8.44
111 - SHIELD TUBE HIT-6688155.A0 6688155	-
112 - PUMP FILTER BODY HIT-6685199.A20 6685199	£6.38	£7.66
113 - TANK CAP ASS'Y HIT-6685180.A3 6685180	£6.69	£8.03
114 - TANK CAP PACKING HIT-6685179.A14 6685179	£1.67	£2.00
115 - OIL TANK CAP ASS'Y HIT-6697756.A19 6697756	£5.87	£7.04
116 - OIL TANK CAP PACKING HIT-6697888.A8 6697888	£1.67	£2.00
121 - S-STARTER ASS'Y HIT-6692911.A0 6692911	-
122 - SET SCREW HIT-6684679.A48 6684679	£2.98	£3.57
124 - STARTER PULLEY HIT-6685184.A8 6685184	£6.18	£7.41
125 - ROPE HIT-6685186.A8 6685186	-
126 - SPRING CASE SET HIT-6685185.A5 6685185	£11.12	£13.35
127 - DAMPER SPRING HIT-6685183.A21 6685183	£5.70	£6.84
128 - STARTER HANDLE HIT-6685188.A5 6685188	-
129 - FAN CASE (S-START) HIT-6686952.A1 6686952	-
130 - TAPPING SCREW D4.5X20 HIT-6685191.A5 6685191	-
131 - CAM PLATE HIT-6685182.A6 6685182	£3.56	£4.27
132 - PLATE HIT-6685189.A26 6685189	-
133 - TAPPING SCREW D4.5X14 HIT-6685153.A17 6685153	-
134 - INTAKE CHANGE LEVER HIT-6687481.A0 6687481	-
135 - SEAL COVER HIT-6687183.A1 6687183	-
136 - AIR DEFLECTOR HIT-6687327.A1 6687327	-
141 - CARBURETOR ASS'Y WT553 FOR EUROPE HIT-6690650.A0 6690650	-
142 - INLET SCREEN HIT-6684700.A182 6684700	-
143 - PUMP BODY FOR EUROPE HIT-6691416.A6 6691416	£16.36	£19.63
144 - SCREW HIT-6685210.A8 6685210	-
145 - PUMP GASKET HIT-6685212.A8 6685212	£3.29	£3.95
146 - PUMP DIAPHRAGM HIT-6685213.A48 6685213	£8.44	£10.13
147 - CONTROL LEVER HIT-6685217.A8 6685217	-
148 - HINGE PIN SET SCREW HIT-6685218.A60 6685218	-
149 - VALVE SPRING HIT-6690872.A18 6690872	-
150 - HINGE PIN HIT-6685219.A10 6685219	-
151 - DIAPHRAGM COVER-METERING HIT-6685222.A24 6685222	£5.70	£6.84
152 - METERING DIAPHRAGM COMP. HIT-6690827.A32 6690827	£14.02	£16.83
153 - DIAPHRAGM PACKING-METERING HIT-6685220.A150 6685220	£2.81	£3.37
154 - NEEDLE VALVE HIT-6685215.A8 6685215	£6.79	£8.15
155 - IDLE ADJUST SPRING HIT-6685297.A7 6685297	-
156 - IDLE ADJUST SCREW HIT-6685298.A36 6685298	£1.67	£2.00
157 - SET SCREW HIT-6685223.A61 6685223	-
158 - CARBURETOR ASS'Y WT551 FOR RUS HIT-6690647.A0 6690647	-
159 - PUMP BODY FOR RUS HIT-6685211.A12 6685211	-
160 - LOW ADJUST SCREW FOR RUS HIT-6690721.A0 6690721	-
*161 - HIGH/LOW ADJUST SPRING FOR RUS HIT-6692048.A9 6692048	-
*161 - SCREW 5X14/WS HIT-6695416.A6 6695416	-
*162 - HIGH ADJUST SCREW FOR RUS HIT-6690701.A0 6690701	-
*162 - OIL PUMP COVER HIT-6686764.A1 6686764	-
*163 - HIGH ADJUSTMENT SPRING FOR RUS HIT-6690897.A11 6690897	-
*163 - OIL PIPE A HIT-6691223.A8 6691223	-
164 - SCREW GEAR HIT-6686645.A0 6686645	£15.03	£18.04
165 - AIR VENT SPONGE HIT-6685156.A1 6685156	-
166 - OIL PUMP ASS'Y HIT-6687325.A1 6687325	£19.89	£23.87
167 - OIL ADJUST GROMMET HIT-6690957.A1 6690957	-
168 - OIL PUMP ADJUSTER HIT-6691070.A0 6691070	-
169 - O RING HIT-6697917.A0 6697917	-
170 - OIL PUMP CASE SET 1 HIT-6686681.A0 6686681	-
171 - O RING HIT-6697917.A1 6697917	-
172 - TAPPING SCREW D5X14 HIT-6685275.A10 6685275	-
173 - FUEL PIPE HIT-6685154.A5 6685154	-
174 - CHAIN CATCHER HIT-6685155.A17 6685155	-
175 - TAPPING SCREW D4.5X14 HIT-6685152.A10 6685152	-
191 - NUT HIT-6685166.A10 6685166	£3.62	£4.35
192 - CLUTCH COMP. HIT-6685142.A8 6685142	£16.34	£19.61
193 - NEEDLE BEARING HIT-6685143.A8 6685143	£4.72	£5.66
194 - CLUTCH HOUSING COMP. HIT-6685144.A7 6685144	£11.93	£14.32
195 - CLUTCH WASHER HIT-6685145.A6 6685145	-
196 - TAPPING SCREW D4X10 HIT-6685161.A62 6685161	£1.67	£2.00
197 - GUIDE PLATE A HIT-6697599.A10 6697599	-
199 - CRANK SHAFT COLLAR HIT-6685146.A8 6685146	£1.67	£2.00
200 - TAPPING SCREW D4X10 HIT-6685161.A63 6685161	£1.67	£2.00
201 - SIDE CASE ASS'Y HIT-6686110.A1 6686110	£66.12	£79.34
202 - GUIDE PLATE B HIT-6690756.A8 6690756	£2.81	£3.37
203 - SCREW 2.6X5 HIT-6695269.A0 6695269	-
204 - BRAKE HANDLE COMP. HIT-6697958.A6 6697958	£15.15	£18.18
205B - CHAIN PULLER HIT-6698986.A16 6698986	£18.88	£22.66
206 - BRAKE LINK COVER 1 HIT-6689712.A5 6689712	£4.65	£5.58
207 - BRAKE SPRING HIT-6689705.A1 6689705	-
208 - BRAKE SUPPORT PLATE COMP. HIT-6685119.A9 6685119	-
209 - NEEDLE ROLLER 3X9.8 HIT-6685141.A12 6685141	-
210 - BRAKE LINK HIT-6685388.A6 6685388	£12.57	£15.08
211 - BRAKE BAND HIT-6689728.A6 6689728	-
212 - CLEANER FIXING COLLAR HIT-6690805.A16 6690805	£2.69	£3.23
213 - COLLAR HIT-6685120.A7 6685120	-
214 - SIDE CASE COVER HIT-6686046.A0 6686046	£14.93	£17.92
215 - BRAKE LEVER SPRING HIT-6685122.A7 6685122	-
216 - TAPPING SCREW D4X15 HIT-6685148.A7 6685148	-
221 - TAPPING SCREW 5X35 HIT-6695107.A2 6695107	£1.67	£2.00
222 - CLEANER FIXING COLLAR HIT-6690805.A17 6690805	£2.69	£3.23
223 - DAMPER COMP. HIT-6688263.A1 6688263	-
224 - TAPPING SCREW 5X40 HIT-6695108.A12 6695108	-
225 - DAMPER COLLAR A HIT-6688481.A0 6688481	-
226 - TAPPING SCREW D5X16 HIT-6685074.A9 6685074	-
227 - REAR HANDLE B HIT-6685651.A1 6685651	-
228 - PUSH PIN CAP HIT-6692680.A2 6692680	-
229 - STOPPER SPRING HIT-6686447.A3 6686447	£1.67	£2.00
230 - PUSH PIN HIT-6686430.A7 6686430	£1.67	£2.00
231 - TRIGGER LOCKOUT VERMILION HIT-6688363.A12 6688363	-
232 - THROTTLE LEVER HIT-6686395.A0 6686395	-
233 - THROTTLE LEVER SPRING HIT-6686416.A7 6686416	£2.71	£3.25
234 - REAR HANDLE HIT-6685623.A0 6685623	-
235 - TAPPING SCREW D4X15 HIT-6685148.A8 6685148	-
236 - FRONT HANDLE HIT-6688085.A0 6688085	-
237 - CORD 180MM HIT-6685252.A2 6685252	-
238 - CORD 325L HIT-6687838.A1 6687838	-
239 - STOP SWITCH HIT-6685239.A2 6685239	£6.88	£8.25
240 - THROTTLE WIRE COMP. HIT-6693874.A0 6693874	-
241 - CORD CLAMP COMP. HIT-6688011.A6 6688011	-
242 - ENGINE CASE COVER HIT-6691379.A0 6691379	-
243 - TAPPING SCREW D4.5X14 HIT-6685153.A16 6685153	-
501 - COMBI BOX SPANNER 10/19MM HIT-6685257.A26 6685257	-
503 - SPIKE HIT-6685270.A1 6685270	-
504 - TAPPING SCREW D5X14 HIT-6685275.A9 6685275	-
505 - SAW CHAIN (3/8X12) 91PX-45XJ HIT-781122.A10 781122	£12.41	£14.89
506 - CHAIN BAR 12 INCH 3/8 SPROCKET HIT-6685294.A3 6685294	£27.59	£33.11
507A - CHAIN COVER 12 HIT-6685401.A2 6685401	-
601 - NAME PLATE CS30EH(S) HIT-6694396.A0 6694396	-
602 - STARTER MARK CH30EH(S) FOR EUROPE HIT-6694499.A0 6694499	-
603 - STARTER MARK CS30EH(S) FOR RUS HIT-6694501.A0 6694501	-
