Hitachi / Hikoki CS30EG Engine Chain Saw Spare Parts

An exploded diagram and spare parts listing for the Hitachi / Hikoki CS30EG Engine Chain Saw

	Ex VAT	Inc VAT
1 - SPARK PLUG CAP ASS'Y HIT-6687468.A34 6687468	£3.64	£4.37
2 - SPARK PLUG ASS'Y BMR6A HIT-6699315.A7 6699315	-
3 - CYLINDER SET HIT-6685457.A8 6685457	£63.42	£76.10
4 - CYLINDER GASKET HIT-6685724.A8 6685724	-
5 - PISTON SET HIT-6685879.A3 6685879	£39.02	£46.82
6 - CIRCLIP HIT-6685078.A32 6685078	-
7 - PISTON RING (XR1-1856) HIT-6685331.A29 6685331	£12.57	£15.08
8 - PISTON PIN HIT-6686008.A17 6686008	£3.64	£4.37
9 - HEX. HOLE BOLT M5X16/S HIT-6684903.A79 6684903	-
10 - CRANK SHAFT COMP HIT-6697636.A8 6697636	-
11 - CORD 1 HIT-6687837.A11 6687837	-
12 - IGNITION COIL COMP. HIT-6687700.A3 6687700	£40.13	£48.16
13 - TAB HIT-6688060.A12 6688060	-
14 - HIGH TENSION SCREW 4X18WS HIT-6695407.A8 6695407	-
15 - WOODRUFF KEY 3X13X4.5 TILL ED09999 HIT-6684899.A10 6684899	-
16 - CORD INSULATOR TUBE TILL E609999 HIT-6692900.A5 6692900	-
20 - CRANK CASE ASS'Y HIT-6686523.A8 6686523	-
21 - OIL SEAL TB 12227 HIT-6684607.A127 6684607	£4.07	£4.88
22 - NEEDLE ROLLER 2.5X9.8 HIT-6685095.A13 6685095	-
23 - BALL BEARING 6201 A2C3 HIT-6685096.A5 6685096	-
24 - CRANK CASE GASKET HIT-6686701.A11 6686701	-
25 - HEX.HOLE BOLT M5X20/S HIT-6684668.A47 6684668	-
26A - MAGNETO ROTOR ASS'Y SINCE E110001 HIT-6697953.A5 6697953	-
27 - D4E RETAINING RING HIT-6685101.A87 6685101	-
28 - STARTER PAWL SPRING HIT-6685105.A7 6685105	£1.67	£2.00
29A - STARTER PAWL HIT-6685334.A5 6685334	£2.84	£3.41
30 - BOLT WASHER M7 HIT-6685103.A10 6685103	-
31 - FLYWHEEL NUT HIT-6685104.A18 6685104	-
*32 - SHIM S T0.2 HIT-6685098.A26 6685098	-
*32 - SHIM S T0.3 HIT-6685099.A8 6685099	-
*32 - SHIM 0.4 HIT-6686475.A11 6686475	-
33 - S.WASHER 7 TILL E500020 HIT-6695222.A3 6695222	-
40 - ENGINE CASE ASS'Y 1 HIT-6691365.A2 6691365	-
41 - AIR VENT VALVE (B) HIT-6685173.A30 6685173	-
42 - AIR VENT VALVE SET HIT-6697231.A6 6697231	£6.80	£8.16
43 - HEX.HOLE BOLT 5X20/PS HIT-6684634.A18 6684634	£1.67	£2.00
44 - EARTH CORD 90M HIT-6697602.A5 6697602	-
45A - STOP SWITCH ASS'Y HIT-6601374.A3 6601374	£16.45	£19.74
46 - SWITCH NAME PLATE HIT-6687949.A7 6687949	£1.67	£2.00
50 - CLEANER COVER TILL E809999 HIT-6686302.A2 6686302	-
50A - AIRCLEANER COVER A SET 1 HIT-6686299.A8 6686299	-
51 - CLEANER COVER BOLT HIT-6689735.A7 6689735	-
52 - AIRCLEANER ELEMENT COMP. HIT-6690064.A11 6690064	£6.47	£7.76
53 - INSULATOR SET HIT-6689935.A9 6689935	-
54 - INSULATOR GASKET HIT-6689871.A12 6689871	-
55 - CARBURETOR INSULATOR RUBBER HIT-6690001.A8 6690001	-
56 - VALVE HOLDER HIT-6689806.A9 6689806	-
57 - REED VALVE HIT-6689803.A9 6689803	-
58 - BINDING HEAD SCREW 3X12 HIT-6694964.A11 6694964	-
59 - CARBURETOR GASKET HIT-6698108.A11 6698108	-
60 - CARBURETOR SET 1 HIT-6690667.A5 6690667	£81.68	£98.01
61 - SCREW 5X45S HIT-6695350.A7 6695350	-
62 - CHOKE SHIM 1.0 HIT-6692597.A8 6692597	-
63 - SMALL WASHER 5 HIT-6684864.A86 6684864	-
64 - CHOKE VALVE HIT-6692410.A12 6692410	-
65 - TAPPING SCREW D4.5X14 HIT-6685152.A27 6685152	-
66 - AIRCLEANER COVER B HIT-6687344.A2 6687344	-
67 - HEX.HOLE BOLT M5X20/S HIT-6684668.A18 6684668	-
68 - SMALL WASHER 5 HIT-6684864.A7 6684864	-
69 - IDLE SPONGE HIT-6685224.A3 6685224	-
71 - AIRCLEANER SPONGE TILL E890040 HIT-6690355.A3 6690355	£1.67	£2.00
72 - SEAL COVER TILL E890040 HIT-6687182.A6 6687182	-
81 - MUFFLER SET HIT-6692447.A6 6692447	-
82 - MUFFLER GASKET HIT-6692734.A12 6692734	-
83 - MUFFLER BODY B COMP. HIT-6692627.A8 6692627	-
84 - MUFFLER FITTING METAL HIT-6692677.A1 6692677	-
85 - MUFFLER COUPLING GASKET HIT-6692833.A8 6692833	-
86 - MUFFLER BODY A COMP. HIT-6692607.A1 6692607	-
87 - HEX. HOLE BOLT 5X40 HIT-6695054.A10 6695054	£1.67	£2.00
88 - WASHER 5 HIT-6684661.A93 6684661	£1.67	£2.00
101 - OIL PIPE B HIT-6691121.A8 6691121	-
102 - CLIP 7 HIT-6692312.A17 6692312	-
103 - WASHER 5 HIT-6684661.A94 6684661	£1.67	£2.00
104 - OIL FILTER HIT-6690919.A9 6690919	-
105 - OIL FILTER BODY ASS'Y HIT-6685249.A5 6685249	£1.67	£2.00
106 - THROTTLE ROD HIT-6690974.A1 6690974	-
107 - THROTTLE GUIDE HIT-6690982.A0 6690982	-
108 - PRIMING PUMP COMP. HIT-6685139.A34 6685139	£10.67	£12.80
109 - FUEL PIPE 2.5X4X42 HIT-6685138.A6 6685138	£1.67	£2.00
110 - RUBBER PIPE HIT-6692292.A9 6692292	£12.50	£15.00
111 - PUMP FILTER BODY HIT-6685199.A17 6685199	£6.38	£7.66
112 - FUEL PIPE 2.5X4X150 HIT-6692351.A4 6692351	-
113 - RETURN GROMMET HIT-6697846.A0 6697846	£2.08	£2.50
114 - O-RING P-18 FKM HIT-6697780.A1 6697780	-
115 - ADJUSTER CAP HIT-6687957.A8 6687957	-
116 - GROMMET HIT-6692590.A10 6692590	£1.67	£2.00
117 - CHOKE BUTTON COMP. HIT-6692513.A2 6692513	-
118 - GROMMET HIT-6687976.A11 6687976	-
119 - O RING TILL E619999 HIT-6697898.A12 6697898	-
119A - O-RING P21 SINCE E710001 HIT-6699285.A2 6699285	-
120 - OIL TANK CAP ASS'Y HIT-6692159.A1 6692159	£8.38	£10.06
121A - TANK CAP ASS'Y HIT-6692121.A7 6692121	-
131 - RECOIL STARTER ASS'Y OR TILL E809999 HIT-6692909.A2 6692909	-
131A - RECOIL STARTER ASS'Y OR SINCE E900001 HIT-6697606.A2 6697606	-
132 - FAN CASE COMP. OR TILL E809999 HIT-6686950.A2 6686950	-
133 - STARTER HANDLE TILL E809999 HIT-6693240.A11 6693240	£16.35	£19.62
134 - ROPE TILL E809999 HIT-6693168.A22 6693168	£2.82	£3.39
135 - RECOIL SPRING TILL E809999 HIT-6693138.A1 6693138	£12.10	£14.52
136 - SPRING CASE ASS'Y TILL E809999 HIT-6693094.A1 6693094	£29.16	£34.99
137 - STARTER PULLEY TILL E809999 HIT-6693061.A1 6693061	-
138 - SPECIAL WASHER 5.2X15 TILL E809999 HIT-6687947.A2 6687947	-
139 - TAPPING SCREW D5X14 TILL E809999 HIT-6685275.A4 6685275	-
140 - TAPPING SCREW D4.5X20 HIT-6685191.A1 6685191	-
141 - AIR DEFLECTOR TILL E809999 HIT-6687326.A0 6687326	-
142 - FAN CASE COMP OR SINCE E900001 HIT-6697608.A0 6697608	-
143 - STARTER HANDLE SINCE E900001 HIT-6693230.A8 6693230	-
144 - ROPE SINCE E900001 HIT-6685186.A6 6685186	-
145 - DAMPER SPRING SINCE E900001 HIT-6685183.A23 6685183	£5.70	£6.84
146 - SPRING CASE SET SINCE E900001 HIT-6685185.A7 6685185	£11.12	£13.35
147 - STARTER PULLEY SINCE E900001 HIT-6685184.A6 6685184	£6.18	£7.41
148 - SET SCREW SINCE E900001 HIT-6684679.A45 6684679	£2.98	£3.57
149 - CAM PLATE SINCE E900001 HIT-6685182.A4 6685182	£3.56	£4.27
150 - PLATE SINCE E900001 HIT-6685189.A30 6685189	-
161 - INLET SCREEN HIT-6684700.A175 6684700	-
162 - PUMP BODY HIT-6691416.A1 6691416	£16.36	£19.63
163 - SCREW HIT-6685210.A5 6685210	-
164 - PUMP GASKET HIT-6685212.A6 6685212	£3.29	£3.95
165 - PUMP DIAPHRAGM HIT-6685213.A50 6685213	£8.44	£10.13
168 - CONTROL LEVER HIT-6685217.A5 6685217	-
169 - HINGE PIN SET SCREW HIT-6685218.A63 6685218	-
170 - VALVE SPRING HIT-6690873.A2 6690873	-
171 - HINGE PIN HIT-6685219.A8 6685219	-
172 - DIAPHRAGM COVER-METERING HIT-6685222.A22 6685222	£5.70	£6.84
173 - METERING DIAPHRAGM COMP. HIT-6690827.A36 6690827	£14.02	£16.83
174 - DIAPHRAGM PACKING-METERING HIT-6685220.A152 6685220	£2.81	£3.37
175 - NEEDLE VALVE HIT-6685215.A6 6685215	£6.79	£8.15
176 - IDLE ADJUST SPRING HIT-6685297.A5 6685297	-
177 - IDLE ADJUST SCREW HIT-6685298.A39 6685298	£1.67	£2.00
180 - SET SCREW HIT-6685223.A63 6685223	-
191 - SCREW 5X14/WS HIT-6695416.A2 6695416	-
192 - OIL PUMP COVER HIT-6686763.A10 6686763	-
193 - OIL PIPE A HIT-6691223.A11 6691223	-
194 - SCREW GEAR HIT-6686645.A3 6686645	£15.03	£18.04
195 - AIR VENT SPONGE HIT-6691400.A11 6691400	-
196 - OIL PUMP ASS'Y HIT-6687324.A10 6687324	£17.82	£21.39
197 - OIL ADJUST GROMMET HIT-6690956.A8 6690956	-
198 - OIL PUMP ADJUSTER HIT-6691070.A3 6691070	-
199 - O RING HIT-6697917.A7 6697917	-
200 - OIL PUMP CASE SET 1 HIT-6686681.A4 6686681	-
201 - O RING HIT-6697917.A6 6697917	-
202 - TAPPING SCREW D5X14 HIT-6685275.A3 6685275	-
203 - FUEL PIPE TILL E200030 HIT-6685154.A2 6685154	-
204 - CHAIN CATCHER HIT-6685155.A20 6685155	-
205 - TAPPING SCREW D4.5X14 HIT-6685152.A4 6685152	-
221 - NUT TILL E890040 HIT-6685166.A5 6685166	£3.62	£4.35
221A - CHAIN BAR CLAMP NUT SINCE E990001 HIT-6687105.A5 6687105	£1.67	£2.00
222 - CLUTCH COMP. HIT-6685142.A11 6685142	£16.34	£19.61
223 - NEEDLE BEARING HIT-6685143.A5 6685143	£4.72	£5.66
224 - CLUTCH HOUSING COMP. HIT-6685144.A10 6685144	£11.93	£14.32
225 - CLUTCH WASHER HIT-6685145.A3 6685145	-
226 - TAPPING SCREW D4X10 HIT-6685161.A56 6685161	£1.67	£2.00
227 - GUIDE PLATE A HIT-6697599.A13 6697599	-
228 - CRANK SHAFT COLLAR HIT-6685146.A11 6685146	£1.67	£2.00
229 - TAPPING SCREW D4X10 HIT-6685161.A57 6685161	£1.67	£2.00
231 - GUIDE PLATE B HIT-6690756.A11 6690756	£2.81	£3.37
232 - SCREW 2.6X5 HIT-6695269.A1 6695269	-
233B - INCLUD 234 HIT-6698986.A21 6698986	£18.88	£22.66
234 - GEAR (A) HIT-6685168.A13 6685168	£3.45	£4.14
235 - BRAKE HANDLE COMP. HIT-6697958.A5 6697958	£15.15	£18.18
236 - BRAKE LINK COVER 1 HIT-6689712.A8 6689712	£4.65	£5.58
237 - BRAKE SPRING HIT-6697694.A7 6697694	-
238 - BRAKE SUPPORT PLATE COMP. HIT-6685119.A6 6685119	-
239 - NEEDLE ROLLER 3X9.8 HIT-6685141.A8 6685141	-
240 - BRAKE LINK HIT-6685388.A3 6685388	£12.57	£15.08
241 - BRAKE BAND HIT-6689728.A8 6689728	-
242 - CLEANER FIXING COLLAR HIT-6690805.A21 6690805	£2.69	£3.23
243 - COLLAR HIT-6685120.A10 6685120	-
244 - SIDE COVER COMP HIT-6697614.A2 6697614	-
245 - BRAKE LEVER SPRING HIT-6685122.A9 6685122	-
246 - TAPPING SCREW D4X15 HIT-6685148.A2 6685148	-
261 - NYLON LOCK NUT 4 HIT-6695163.A9 6695163	-
262 - TAPPING SCREW 5X40 HIT-6695108.A10 6695108	-
263 - DAMPER COLLAR A HIT-6688480.A16 6688480	-
264 - DAMPER A HIT-6688117.A16 6688117	-
265 - SCREW 4X30PS HIT-6695378.A4 6695378	-
266 - REAR HANDLE B COMP. HIT-6685645.A1 6685645	-
267 - PUSH PIN CAP HIT-6692680.A5 6692680	-
268 - STOPPER SPRING HIT-6686447.A5 6686447	£1.67	£2.00
269 - PUSH PIN HIT-6686430.A8 6686430	£1.67	£2.00
270 - TRIGGER LOCKOUT VERMILION HIT-6688363.A10 6688363	-
271 - THROTTLE LEVER HIT-6686392.A4 6686392	-
272 - THROTTLE LEVER SPRING HIT-6686416.A9 6686416	£2.71	£3.25
273 - REAR HANDLE HIT-6685620.A0 6685620	-
274 - TAPPING SCREW 5X35 HIT-6695107.A8 6695107	£1.67	£2.00
275 - TAPPING SCREW D4X15 HIT-6685148.A3 6685148	-
276 - FRONT HANDLE HIT-6688083.A5 6688083	£6.59	£7.91
277 - DAMPER B HIT-6688412.A2 6688412	£1.67	£2.00
278 - DAMPER COLLAR B HIT-6688485.A1 6688485	£1.67	£2.00
279 - TAPPING SCREW 5X35 HIT-6695107.A9 6695107	£1.67	£2.00
501 - CHAIN BAR 12 INCH 3/8 SPROCKET HIT-6685294.A2 6685294	£27.59	£33.11
502 - SAW CHAIN (3/8X12) 91PX-45XJ HIT-781122.A6 781122	£12.41	£14.89
503A - CHAIN COVER 12 HIT-6685401.A5 6685401	-
505 - COMBI BOX SPANNER 10/19MM TILL E890040 HIT-6685257.A25 6685257	-
505A - COMBI. BOX SPANNER 13X19 MINUS SINCE E990001 HIT-6693809.A15 6693809	-
601 - NAME PLATE CS30EG(S) HIT-6694408.A0 6694408	-

Attribute Name	Value
Brand	Hikoki

Reviews Write your own review!

There are currently no reviews of this product.

Fill in the form below to add your review for Hitachi / Hikoki CS30EG Engine Chain Saw Spare Parts

Your Review
Title Required!
Rating Required!
Your Review Required!
Your Details
Your Name Required!
Your Location Required!
Email Address Required!Invalid email!

United Kingdom (Including N. Ireland)

On orders up to £40.00	Add £4.00 inc VAT (Royal Mail post)
On orders £40.00 to £130.00	Add £7.00 inc VAT (Courier)
On orders over £130.00	FREE (Courier)

Shopping Basket (0) £0.00

Hitachi / Hikoki CS30EG Engine Chain Saw Spare Parts

Your Review

Your Details

Carry On Shopping

Try these categories

Recently Viewed

Your Order

About Us

Other Links

Search

Customization

Shopping Basket (0) £0.00

Information

Hitachi / Hikoki CS30EG Engine Chain Saw Spare Parts

Notify me

Your Review

Your Details

Carry On Shopping

Try these categories

Recently Viewed

Your Order

About Us

Other Links

Search
