Hitachi / Hikoki CS25EPB Engine Pole Saw Spare Parts

An exploded diagram and spare parts listing for the Hitachi / Hikoki CS25EPB Engine Pole Saw

	Ex VAT	Inc VAT
1 - PLUG CAP HIT-6684894.A21 6684894	£7.75	£9.30
*2 - SPARK PLUG ASS'Y BPMR6A FOR (S) HIT-6699319.A32 6699319	-
*2 - SPARK PLUG ASS'Y BMR6A FOR (SP) HIT-6699315.A14 6699315	-
*3 - CYLINDER SET FOR (S) HIT-6685493.A8 6685493	£72.13	£86.56
*3 - CYLINDER SET FOR (SP) HIT-6685495.A2 6685495	£87.22	£104.66
4 - HEX.HOLE BOLT M5X18/S HIT-6684586.A48 6684586	-
*5 - CYLINDER GASKET T=1.0 FOR (S) HIT-6685750.A0 6685750	£2.81	£3.37
*5 - CYLINDER GASKET FOR (SP) HIT-6684896.A9 6684896	£1.67	£2.00
6 - PISTON RING HIT-6686121.A8 6686121	£6.47	£7.76
7 - PISTON SET HIT-6685902.A13 6685902	£30.58	£36.70
8 - CIR CLIP HIT-6684590.A95 6684590	£1.67	£2.00
9 - PISTON PIN HIT-6684591.A27 6684591	£3.29	£3.95
10 - CRANK SHAFT COMP. HIT-6686219.A12 6686219	£121.07	£145.28
11 - LEAD WIRE ASS'Y HIT-6687965.A3 6687965	£4.26	£5.11
12 - HEX. HOLE BOLT M4X18/WS TILL E819999 HIT-6684599.A50 6684599	-
12A - HIGH TENSION SCREW 4X18WS SINCE E910001 HIT-6695407.A20 6695407	-
*13 - IGNITION COIL ASS'Y MB-55 FOR (S) HIT-6687684.A7 6687684	£35.79	£42.95
*13 - IGNITION COIL ASS'Y MB-65 FOR (SP) HIT-6687688.A1 6687688	£48.01	£57.61
14 - WASHER T1.6 FOR (SP) HIT-6684600.A24 6684600	-
*21 - GEAR SHAFT SHIM 0.20 HIT-6684604.A40 6684604	-
*21 - GEAR SHAFT SHIM 0.30 HIT-6684605.A41 6684605	-
*22 - MAGNETO ROTOR COMP. FOR (S) HIT-6687384.A7 6687384	-
*22 - MAGNETO ROTOR COMP. FOR (SP) HIT-6687385.A4 6687385	-
23 - HEX. NUT M8 HIT-6684612.A66 6684612	-
24 - BOLT WASHER M8 HIT-6684611.A55 6684611	-
25 - CRANK CASE ASS'Y HIT-6684905.A9 6684905	£30.92	£37.11
26 - OIL SEAL TB 12227 HIT-6684607.A193 6684607	£4.07	£4.88
27 - BALL BEARING 6001 C3 HIT-6684608.A14 6684608	£5.70	£6.84
28 - CRANK CASE GASKET HIT-6684904.A11 6684904	£1.67	£2.00
29 - HEX. HOLE BOLT M5X16/S HIT-6684903.A44 6684903	-
41 - INLET MANIFOLD GASKET HIT-6689895.A22 6689895	£1.67	£2.00
42 - INSULATOR SET HIT-6689972.A22 6689972	£6.59	£7.91
*43 - HEX. HOLE BOLT M5X25WS FOR (S) HIT-6695515.A43 6695515	£1.67	£2.00
*43 - HEX. HOLE BOLT 5X25/WS FOR (SP) HIT-6684617.A9 6684617	-
44 - CARBURETOR PACKING FOR (SP) HIT-6684616.A23 6684616	£1.67	£2.00
*45 - CHOKE LEVER 1.5 FOR (S) HIT-6691281.A4 6691281	£1.67	£2.00
*45 - CHOKE PLATE 2.0 FOR (SP) HIT-6691276.A10 6691276	£1.67	£2.00
46 - CLEANER BODY COMP. HIT-6690120.A1 6690120	£12.32	£14.78
47 - CLEANER SPONGE HIT-6690365.A7 6690365	£1.67	£2.00
*48 - CLEANER COVER ASS'Y FOR (S) HIT-6690421.A9 6690421	£14.48	£17.38
*48 - CLEANER COVER ASS'Y FOR (SP) HIT-6690402.A16 6690402	£12.16	£14.59
49 - COVER FIXING BOLT COMP. HIT-6698730.A17 6698730	£5.52	£6.63
*50 - SCREW 5X57/S FOR (S) HIT-6695353.A6 6695353	£1.67	£2.00
*50 - SCREW M5X55 FOR (SP) HIT-6694914.A7 6694914	-
51 - S.WASHER 5 FOR (SP) HIT-6684662.A53 6684662	£1.67	£2.00
52 - SMALL WASHER 5 HIT-6684864.A124 6684864	-
53 - CABURETOR SET WYJ-463 FOR (SP) HIT-6690522.A2 6690522	£84.48	£101.37
54 - CHOKE CONTROL LEVER HIT-6691239.A17 6691239	£2.98	£3.57
55 - TANK WHT HIT-6691602.A13 6691602	£13.82	£16.59
56 - COLLAR C HIT-6684623.A12 6684623	£1.67	£2.00
57 - RETURN GROMMET HIT-6684627.A105 6684627	£1.67	£2.00
58 - FUEL PIPE 3X5X65 HIT-6684626.A14 6684626	£1.67	£2.00
59A - PUMP FILTER BODY COMP HIT-66A3864.A93 66A3864	-
60 - CLIP D6 HIT-6685198.A77 6685198	-
61 - SHIELD TUBE 3X5X180 HIT-6684618.A18 6684618	£6.12	£7.35
62 - HEX.HOLE BOLT 5X20/PS HIT-6684634.A41 6684634	£1.67	£2.00
63 - TANK CAP ASS'Y HIT-6685049.A5 6685049	£9.94	£11.93
64 - TAP SCREW 4X14 P HIT-6695280.A22 6695280	£1.67	£2.00
65 - BOLT WASHER M4 HIT-6685070.A30 6685070	£1.67	£2.00
66 - STAND HIT-6694787.A44 6694787	£3.56	£4.27
67 - TANK CAP CHAIN HIT-6684625.A45 6684625	-
68 - CARBURETOR GASKET FOR (S) HIT-6684615.A18 6684615	£1.67	£2.00
69 - CABURETOR SET WYJ-431 FOR (S) HIT-6690519.A1 6690519	£113.54	£136.25
*81 - CYLINDER COVER FOR (S) HIT-6685690.A1 6685690	£5.70	£6.84
*81 - CYLINDER COVER (BLK) FOR (SP) HIT-6685693.A8 6685693	-
82 - HEX. HOLE BOLT 5X16/PS HIT-6695504.A35 6695504	£1.67	£2.00
*83 - HEX. HOLE BOLT M6X55 FOR (S) HIT-6684638.A25 6684638	£1.67	£2.00
*83 - HEX. HOLE BOLT M6X65 FOR (SP) HIT-6695067.A17 6695067	£1.67	£2.00
84 - BOLT WASHER 6 HIT-6684639.A64 6684639	£1.67	£2.00
85 - MUFFLER COMP FOR (SP) HIT-6699282.A2 6699282	-
86 - TAIL PIPE GASKET FOR (SP) HIT-6692888.A6 6692888	-
87 - TAIL PIPE SET FOR (SP) HIT-6692715.A4 6692715	-
88 - SCREW M4X8/WS FOR (SP) HIT-6684651.A11 6684651	-
89 - SPARK ARRESTER FOR (SP) HIT-6692701.A4 6692701	-
*90 - MUFFLER PROTECTOR FOR (S) HIT-6692813.A3 6692813	£8.89	£10.67
*90 - MUFFLER PROTECTOR BLK FOR (SP) HIT-6692818.A0 6692818	£16.09	£19.31
91 - HEX. HOLE BOLT 4X18WS TILL E819999 HIT-6695508.A48 6695508	£1.67	£2.00
91A - SCREW 4X18/PS SINCE E910001 HIT-6695375.A16 6695375	-
*92 - PLUG CAP FOR (S) HIT-6688345.A4 6688345	£4.99	£5.99
*92 - PLUG COVER FOR (SP) HIT-6688344.A2 6688344	-
93 - CLUTCH WASHER B HIT-6684642.A28 6684642	£1.67	£2.00
94 - CLUTCH SHOE COMP. HIT-6684643.A8 6684643	£12.01	£14.41
95 - CLUTCH SPRING HIT-6684644.A16 6684644	£3.12	£3.74
96 - CLUTCH PLATE A 0.5 HIT-6684645.A9 6684645	£1.67	£2.00
97 - STEP BOLT HIT-6684646.A26 6684646	£3.72	£4.46
98 - HEX.HOLE BOLT 5X20/PS HIT-6684634.A42 6684634	£1.67	£2.00
99 - CLUTCH SET ASS'Y HIT-6699640.A0 6699640	£15.92	£19.10
100 - BENT WASHER 8 HIT-6684648.A59 6684648	£1.67	£2.00
101 - TAPPING SCREW D4.5X16 HIT-6684636.A17 6684636	£1.67	£2.00
102 - HEAT SHIELD FOR (SP) HIT-6687265.A0 6687265	£5.70	£6.84
103 - MUFFLER SET FOR EUROPE(S) HIT-6692498.A1 6692498	£25.72	£30.86
104 - MUFFLER GASKET FOR (S) HIT-6692732.A18 6692732	£1.67	£2.00
105 - HEAT SHIELD FOR (S) HIT-6687264.A8 6687264	-
106 - MUFFLER SET FOR AUS(S) HIT-6692500.A3 6692500	-
107 - TAIL PIPE SET FOR AUS(S) HIT-6692670.A0 6692670	-
108 - MUFFLER SPECIAL GASKET FOR AUS(S) HIT-6692887.A4 6692887	-
109 - SPARK ARRESTOR FOR AUS(S) HIT-6692699.A4 6692699	-
110 - MACHINE SCREW (W/SP. WASHER) M4X8 FOR AUS(S) HIT-6685109.A33 6685109	-
121B - RECOIL STARTER BODY ASS'Y INCLUD.123-129 HIT-6601570.A2 6601570	£23.15	£27.78
123 - STARTER ROPE 3.5X860 HIT-6684674.A51 6684674	£5.70	£6.84
124 - RECOIL SPRING HIT-6684675.A68 6684675	£8.82	£10.58
125A - STARTER ROPE REEL SINCE TE540001 HIT-6699997.A24 6699997	-
126 - DAMPER SPRING HIT-6684677.A66 6684677	£5.70	£6.84
127A - CAM PLATE SINCE TE540001 HIT-6699996.A65 6699996	£4.28	£5.13
128 - SET SCREW HIT-6684679.A90 6684679	£2.98	£3.57
129 - STARTER HANDLE HIT-6684680.A52 6684680	£5.87	£7.04
130 - HEX. HOLE BOLT 4X18WS TILL E819999 HIT-6695508.A49 6695508	£1.67	£2.00
130A - SCREW 4X18/PS SINCE E910001 HIT-6695375.A19 6695375	-
131 - STARTER PULLEY ASS'Y HIT-6684681.A63 6684681	£18.16	£21.79
132 - D4E RETAINING RING HIT-6685101.A148 6685101	-
133 - STARTER PAWL SPRING HIT-6684684.A50 6684684	£3.29	£3.95
134 - STARTER PAWL HIT-6684685.A61 6684685	£5.07	£6.08
135 - CAMPLATE ASS'Y TILL TE449999 HIT-6699691.A46 6699691	£7.75	£9.30
151 - PUMP BODY COMP. HIT-6684879.A2 6684879	£35.37	£42.44
152 - PRIMING PUMP COMP. HIT-6684687.A38 6684687	£9.27	£11.12
153 - DIAPHRAGM COVER HIT-6684688.A62 6684688	£5.70	£6.84
154 - PRIMING BODY HIT-6684689.A37 6684689	£5.87	£7.04
*155 - METERING DIAPHRAGM COMP. FOR (S) HIT-6690830.A9 6690830	£14.58	£17.50
*155 - METERING DIAPHRAGM FOR (SP) HIT-6684690.A67 6684690	£24.05	£28.86
156 - DIAPHRAGM GASKET HIT-6684691.A35 6684691	£5.70	£6.84
157 - PUMP DIAPHRAGM HIT-6684693.A87 6684693	£5.70	£6.84
158 - PUMP GASKET HIT-6684692.A67 6684692	£17.28	£20.73
*159 - MAIN JET #43 FOR (S) HIT-6691848.A14 6691848	£8.77	£10.52
*159 - MAIN JET #38.5 FOR (SP) HIT-6696130.A10 6696130	-
160 - O-RING HIT-6684695.A111 6684695	£1.67	£2.00
161 - STOP RING HIT-6684696.A94 6684696	-
162 - SWIVEL HIT-6684697.A90 6684697	-
163 - THROTTLE SET SCREW HIT-6684870.A76 6684870	-
164 - CABLE ADJUSTER STAY HIT-6684873.A2 6684873	-
165 - CLEANER PACKING HIT-6684875.A3 6684875	-
166 - SET SCREW HIT-6684699.A59 6684699	-
167 - THRUST WASHER HIT-6684874.A77 6684874	-
168 - INLET SCREEN HIT-6684700.A113 6684700	-
169 - LOCK NUT M6 FOR(S) HIT-6684872.A88 6684872	-
170 - CABLE ADJUSTER FOR(S) HIT-6684871.A2 6684871	-
171 - CLUTCH DRUM COMP. HIT-6688580.A4 6688580	£16.79	£20.15
172 - STOP RING C-12 OUTER HIT-6684664.A34 6684664	£1.67	£2.00
173 - CUSHION RUBBER HIT-6691823.A7 6691823	£3.56	£4.27
174 - HEX. HOLE BOLT 5X16 HIT-6695046.A15 6695046	£1.67	£2.00
175 - HEX. HOLE BOLT M5X25/S HIT-6684709.A144 6684709	£1.67	£2.00
176 - FAN CASE COMP. HIT-6686959.A4 6686959	£25.96	£31.15
177 - PIPE HOLDER 1 HIT-6689651.A20 6689651	£8.88	£10.66
178 - WASHER M5 (BLACK) HIT-6684918.A91 6684918	£1.67	£2.00
179 - GEAR CASE WASHER HIT-6689159.A52 6689159	-
180 - METAL FITTING HIT-6689664.A9 6689664	£6.12	£7.35
181 - DRIVE SHAFT 1829L HIT-6689443.A3 6689443	-
182 - MAIN PIPE COMP HIT-6699653.A0 6699653	£41.18	£49.42
183 - BUSH ASS'Y HIT-6697839.A4 6697839	-
184 - HEX.NUT 6 HIT-6684835.A15 6684835	£1.67	£2.00
185 - LOOP HANDLE BLACK HIT-6691046.A7 6691046	£16.30	£19.56
186 - HANDLE BRACKET A HIT-6691134.A6 6691134	£3.10	£3.72
187 - HANDLE GRIP HIT-6691098.A16 6691098	£10.90	£13.08
188 - BOLT 6X43/P (BLACK) HIT-6684838.A26 6684838	£1.67	£2.00
189 - TAPPING SCREW 5X20 HIT-6695255.A0 6695255	-
190 - BRAKE SHAFT WASHER HIT-6689681.A37 6689681	£1.67	£2.00
191 - HANGER D24 HIT-6689277.A4 6689277	-
192 - THROTTLE LEVER ASS'Y 24 FOR (SP) HIT-6693773.A1 6693773	-
193 - THROTTLE WIRE COMP FOR (SP) HIT-6693984.A1 6693984	£30.57	£36.68
194 - THROTTLE WIRE 4T FOR (SP) HIT-6694026.A1 6694026	£16.77	£20.12
195 - STOP SWITCH COMP FOR (SP) HIT-6687463.A2 6687463	-
196 - PROTECTION TUBE 7X175 FOR (SP) HIT-6687526.A7 6687526	-
197 - TRIGGER LOCK OUT FOR (SP) HIT-6684721.A25 6684721	£5.17	£6.20
198 - RETURN SPRING FOR (SP) HIT-6684722.A24 6684722	£1.67	£2.00
199 - SCREW M5X20 FOR (SP) HIT-6684803.A23 6684803	-
200 - CONTAL NUT 5 FOR (SP) HIT-6684727.A25 6684727	£1.67	£2.00
201 - SCREW M4X20 (BLACK) FOR (SP) HIT-6684725.A15 6684725	-
202 - THROTTLE LEVER FOR (SP) HIT-6684804.A6 6684804	£6.86	£8.23
203 - THROTTLE LEVER ASS'Y 24 DIA. FOR (S) HIT-6693767.A2 6693767	-
204 - THROTTLE WIRE COMP. FOR (S) HIT-6693978.A1 6693978	£22.29	£26.75
205 - THROTTLE WIRE FOR (S) HIT-6694022.A7 6694022	-
206 - STOP SWITCH COMP. FOR (S) HIT-6687459.A8 6687459	£17.33	£20.80
207 - PROTECTION TUBE 7X175 FOR (S) HIT-6687526.A8 6687526	-
208 - TRIGGER LOCK OUT FOR (S) HIT-6684721.A26 6684721	£5.17	£6.20
209 - RETURN SPRING FOR (S) HIT-6684722.A23 6684722	£1.67	£2.00
210 - BLIND PLUG FOR (S) HIT-6684724.A25 6684724	-
211 - SCREW M5X20 FOR (S) HIT-6684803.A24 6684803	-
212 - CONTAL NUT 5 FOR (S) HIT-6684727.A24 6684727	£1.67	£2.00
213 - SCREW M4X20 (BLACK) FOR (S) HIT-6684725.A16 6684725	-
214 - THROTTLE LEVER FOR (S) HIT-6684804.A7 6684804	£6.86	£8.23
221 - OIL TANK COVER HIT-6686138.A5 6686138	£2.81	£3.37
222 - COLLAR 3 TILL EN29999 HIT-6685961.A6 6685961	£1.67	£2.00
222A - COLLAR 3 SINCE ED20001 HIT-6699273.A0 6699273	-
223 - OIL TANK PACKING SINCE ED20001 HIT-6699567.A3 6699567	£2.77	£3.32
224 - O-RING P-5 HIT-6695661.A33 6695661	£1.67	£2.00
225 - STEP BOLT A HIT-6689757.A6 6689757	-
226 - OIL PUMP COMP. HIT-6686487.A8 6686487	£39.35	£47.22
227 - O-RING P-5 HIT-6695661.A32 6695661	£1.67	£2.00
228 - OIL PUMP SPRING HIT-6690381.A8 6690381	-
229 - OIL PUMP PISTON COMP. HIT-6686608.A8 6686608	-
230 - TANK PACKING ASS'Y HIT-6699566.A4 6699566	£3.48	£4.17
231 - FUEL PIPE 3X5X60 HIT-6692414.A8 6692414	-
232 - SMALL SCREW 4X12WS HIT-6695403.A21 6695403	-
233 - WASHER 5 HIT-6684661.A45 6684661	£1.67	£2.00
234 - OIL FILTER HIT-6690917.A5 6690917	£1.67	£2.00
235 - FILTER ASS'Y HIT-6690913.A3 6690913	-
236 - FUEL PIPE 3X5X75 HIT-6692415.A3 6692415	-
237 - OIL PUMP ADJUSTER HIT-6691066.A6 6691066	£8.79	£10.55
238 - O-RING P-5 HIT-6695661.A31 6695661	£1.67	£2.00
239 - STOP RING E-6 HIT-6695311.A15 6695311	£1.67	£2.00
240 - OIL TANK CAP ASS'Y HIT-6692050.A3 6692050	£15.87	£19.04
241 - BANJO 1 HIT-6686637.A0 6686637	-
242 - O-RING P-15 HIT-6698966.A29 6698966	£1.67	£2.00
243 - 8 PUSH NUT HIT-6695239.A3 6695239	-
244 - WASHER 2 HIT-6695187.A6 6695187	-
245 - O-RING 1.4 HIT-6695656.A3 6695656	-
261 - HEX. HOLE BOLT 5X22/S HIT-6695492.A9 6695492	-
262 - HEX. HOLE BOLT 5X10 HIT-6695042.A35 6695042	£1.67	£2.00
263 - SCREW 6X8 HIT-6695458.A5 6695458	-
264 - CASE HIT-6685793.A0 6685793	£12.52	£15.03
265 - GEAR PINION SET SPARE HIT-6688836.A3 6688836	-
266 - BALL BEARING 609 HIT-6684734.A48 6684734	-
267 - BALL BEARING 609Z ST HIT-6684735.A0 6684735	£15.48	£18.57
268 - STOP RING C-9 1 HIT-6695281.A10 6695281	-
269 - STOP RING C-24 1 HIT-6684732.A22 6684732	£1.67	£2.00
271 - BALL BEARING 627 C3 HIT-6695568.A3 6695568	£8.95	£10.74
272 - BALL BEARING 638Z HIT-6697603.A8 6697603	-
273 - STOP RING C-28 1 HIT-6684741.A8 6684741	-
274 - SPROCKET COMP. 1 HIT-6689117.A3 6689117	£47.37	£56.84
275 - FLANGE NUT 6 HIT-6695170.A15 6695170	£1.67	£2.00
276 - SIDE COVER COMP. HIT-6686038.A6 6686038	£9.67	£11.60
277 - CHAIN BAR CLAMP NUT HIT-6687105.A31 6687105	£1.67	£2.00
278 - CHAIN BAR KNOCK PIN HIT-6687130.A6 6687130	-
279 - GUIDE PLATE HIT-6697596.A3 6697596	£4.38	£5.26
280 - CHAIN BAR TIGHTENING BOLT HIT-6686803.A0 6686803	£8.53	£10.24
281 - CHAIN TENSIONER HIT-6687063.A5 6687063	£5.70	£6.84
282 - CAM HIT-6690428.A3 6690428	-
283 - COLLAR HIT-6685962.A0 6685962	-
501 - COMBI. BOX SPANNER 13X19 MINUS HIT-6693809.A22 6693809	-
502 - WRENCH 8X10 HIT-6684766.A14 6684766	-
503 - GUIDE BAR COVER 1 HIT-6694796.A12 6694796	£11.79	£14.15
504 - HEX. BAR WRENCH 4MM HIT-6684813.A36 6684813	-
505 - SHOULDER BELT HIT-6692867.A5 6692867	£8.37	£10.04
506 - SAW CHAIN HIT-6699679.A8 6699679	£20.67	£24.80
507 - CHAIN BAR 10 HIT-6686882.A5 6686882	£28.68	£34.41
601 - SYMBOL MARK CS25EPB(S) HIT-6694667.A0 6694667	-
602 - SYMBOL MARK CS25EPB(SP) HIT-6699681.A0 6699681	-

Attribute Name	Value
Brand	Hikoki

There are currently no reviews of this product.

United Kingdom (Including N. Ireland)

On orders up to £40.00	Add £4.00 inc VAT (Royal Mail post)
On orders £40.00 to £130.00	Add £7.00 inc VAT (Courier)
On orders over £130.00	FREE (Courier)

Shopping Basket (0) £0.00

Hitachi / Hikoki CS25EPB Engine Pole Saw Spare Parts

Your Review

Your Details

Carry On Shopping

Try these categories

Recently Viewed

Your Order

About Us

Other Links

Search

Customization

Shopping Basket (0) £0.00

Information

Hitachi / Hikoki CS25EPB Engine Pole Saw Spare Parts

Notify me

Your Review

Your Details

Carry On Shopping

Try these categories

Recently Viewed

Your Order

About Us

Other Links

Search
