Hitachi / Hikoki CH78ED Engine Hedge Trimmer Spare Parts

An exploded diagram and spare parts listing for the Hitachi / Hikoki CH78ED Engine Hedge Trimmer

	Ex VAT	Inc VAT
1 - PLUG CAP HIT-6684894.A17 6684894	£7.75	£9.30
2 - SPARK PLUG ASS'Y RCJ8Y HIT-6699328.A25 6699328	£5.70	£6.84
3 - SPARK PLUG RUBBER COVER HIT-6688334.A4 6688334	-
4 - CYLINDER SET HIT-6685462.A1 6685462	£93.84	£112.61
5 - HEX.HOLE BOLT M5X18/S HIT-6684586.A19 6684586	-
6 - CYLINDER GASKET HIT-6685728.A2 6685728	-
7 - PISTON RING HIT-6684588.A3 6684588	£6.38	£7.66
8 - PISTON SET HIT-6685877.A3 6685877	-
9 - CIRCLIP HIT-6685078.A38 6685078	-
10 - PISTON PIN HIT-6686016.A2 6686016	-
11 - CRANK SHAFT COMP. HIT-6686176.A2 6686176	-
12 - WOODRUFF KEY 3X13X4.5 HIT-6684899.A21 6684899	-
13 - CORD 1 HIT-6687840.A3 6687840	-
14 - HEX. HOLE BOLT M4X18/WS HIT-6684599.A63 6684599	-
15 - WASHER T1.6 HIT-6684600.A14 6684600	-
*16 - IGNITION COIL ASS'Y HIT-6687704.A4 6687704	-
*16 - IGNITION COIL ASS'Y HIT-6687704.A5 6687704	-
17 - INSULATOR TUBE HIT-6688316.A2 6688316	-
*31 - GEAR SHAFT SHIM 0.20 HIT-6684604.A18 6684604	-
*31 - GEAR SHAFT SHIM 0.30 HIT-6684605.A63 6684605	-
32 - GROMMET HIT-6688047.A2 6688047	-
33 - CRANK CASE ASS'Y HIT-6601158.A0 6601158	-
34 - OIL SEAL TB 12227 HIT-6684607.A103 6684607	£4.07	£4.88
35 - BALL BEARING 6001 C3 HIT-6684608.A97 6684608	£5.70	£6.84
36 - CRANK CASE GASKET HIT-6686705.A2 6686705	-
37 - STUD BOLT 6X22 HIT-6686771.A5 6686771	-
38 - HEX. SOCKET HD. BOLT M5X30 S HIT-6684786.A18 6684786	£1.67	£2.00
39 - HEX. HOLE BOLT 5X45 HIT-6695055.A0 6695055	£1.67	£2.00
40 - SPRING WASHER 5 HIT-6684834.A49 6684834	£1.67	£2.00
41 - MAGNETO ROTOR COMP. HIT-6687418.A4 6687418	-
42 - S.WASHER 8 HIT-6684971.A1 6684971	-
43 - BOLT WASHER M8 HIT-6684611.A30 6684611	-
44 - HEX. NUT M8 HIT-6684612.A95 6684612	-
51 - INTAKE MANIFOLD GASKET HIT-6689874.A4 6689874	-
52 - INSULATOR SET 1 HIT-6689937.A1 6689937	-
53 - HEX. HOLE BOLT M5X25WS HIT-6695515.A48 6695515	£1.67	£2.00
54 - CARBURETOR GASKET HIT-6689828.A4 6689828	-
55 - O-RING P-15 HIT-6698966.A23 6698966	£1.67	£2.00
56 - CLEANER BODY COMP. HIT-6690119.A18 6690119	£8.95	£10.74
57 - COLLAR 7.5 HIT-6690804.A9 6690804	£1.67	£2.00
58 - CHOKE VALVE HIT-6691261.A4 6691261	-
59 - WAVE WASHER 8 HIT-6684658.A44 6684658	£1.67	£2.00
60 - BLOW OVER CHECK BOARD HIT-6690843.A11 6690843	£1.67	£2.00
61 - S.WASHER 5 HIT-6684662.A92 6684662	£1.67	£2.00
62 - SCREW M5X60 HIT-6684660.A30 6684660	-
63 - CLEANER SPONGE HIT-6690364.A11 6690364	£1.67	£2.00
64 - CLEANER COVER ASS'Y HIT-6690415.A6 6690415	£5.70	£6.84
65 - SPECIAL SCREW HIT-6689737.A22 6689737	-
66 - CARBURETOR SET WYL139A HIT-6690461.A2 6690461	-
67 - SHIELD TUBE HIT-6688174.A15 6688174	-
68 - CLIP D6 HIT-6685198.A53 6685198	-
69A - PUMP FILTER BODY COMP HIT-66A3864.A76 66A3864	-
70A - TANK HIT-6699738.A1 6699738	-
71 - TANK CAP ASS'Y HIT-6685049.A8 6685049	£9.94	£11.93
73 - COLLAR 5.8 HIT-6692244.A34 6692244	£1.67	£2.00
74 - TANK CAP CHAIN HIT-6684625.A31 6684625	-
75 - HEX. HOLE BOLT 5X18PS HIT-6695505.A1 6695505	-
76 - SWIVEL CAP HIT-6691337.A21 6691337	£1.67	£2.00
77 - PRIMING PUMP COMP. HIT-6685139.A92 6685139	£10.67	£12.80
78 - FUEL PIPE 2.5X4X80 HIT-6692347.A25 6692347	£1.67	£2.00
79 - FUEL PIPE 2.5X4X70 HIT-6692346.A2 6692346	£1.67	£2.00
80 - RETURN GROMMET HIT-6697846.A130 6697846	£2.08	£2.50
91 - MUFFLER PROTECTOR HIT-6692772.A3 6692772	-
92 - MUFFLER SET HIT-6692455.A0 6692455	-
94 - BOLT WASHER 6 HIT-6684639.A50 6684639	£1.67	£2.00
95 - HEX. HOLE SCREW 6X55 HIT-6695086.A1 6695086	-
96 - TAIL PIPE HIT-6692646.A0 6692646	-
97 - FAN CASE COMP. HIT-6686957.A2 6686957	£38.90	£46.68
98 - RECOIL SPRING HIT-6684675.A7 6684675	£8.82	£10.58
99 - STARTER ROPE REEL HIT-6693066.A3 6693066	£5.17	£6.20
100 - SET SCREW HIT-6693633.A13 6693633	£1.67	£2.00
101 - STARTER PULLEY ASS'Y HIT-6693405.A6 6693405	£7.75	£9.30
102 - PRIMARY CORD GROMMET HIT-6688049.A6 6688049	-
103 - ROPE HIT-6693168.A45 6693168	£2.82	£3.39
104 - STARTER HANDLE HIT-6693237.A21 6693237	£4.55	£5.46
105 - HEX. HOLE BOLT 4X15/PS HIT-6684682.A2 6684682	£1.67	£2.00
106 - MUFFLER COVER A COMP. HIT-6692718.A1 6692718	-
107 - MUFFLER ARRESTOR HIT-6692696.A4 6692696	-
108 - WASHER 5 HIT-6684661.A1 6684661	£1.67	£2.00
109 - SCREW 4X8PS HIT-6695471.A1 6695471	-
110 - SCREW 5X8/S HIT-6695332.A4 6695332	-
111 - CLUTCH HIT-6688494.A23 6688494	£14.82	£17.78
112 - TAPPING SCREW 4.5X10 HIT-6695104.A4 6695104	-
113 - BOLT 4X12PS HIT-6695441.A27 6695441	-
114 - STARTER PAWL SPRING HIT-6684684.A3 6684684	£3.29	£3.95
115 - STARTER PAWL HIT-6693319.A6 6693319	£3.29	£3.95
121 - THROTTLE SET SCREW HIT-6684698.A5 6684698	-
122 - SWIVEL HIT-6684697.A152 6684697	-
123 - STOP RING HIT-6684696.A9 6684696	-
124 - O-RING HIT-6684695.A185 6684695	£1.67	£2.00
125 - MAIN JET #35 HIT-6691873.A4 6691873	-
126 - PUMP GASKET HIT-6691457.A29 6691457	£8.48	£10.18
127 - PUMP DIAPHRAGM HIT-6684693.A9 6684693	£5.70	£6.84
128 - INLET SCREEN HIT-6684700.A18 6684700	-
129 - PUMP BODY COMP. HIT-6691435.A4 6691435	-
130 - DIAPHRAGM PACKING-METERING HIT-6685220.A49 6685220	£2.81	£3.37
131 - METERING DIAPHRAGM COMP. HIT-6690830.A29 6690830	£14.58	£17.50
132 - DIAPHRAGM COVER-METERING HIT-6685222.A130 6685222	£5.70	£6.84
133 - SET SCREW HIT-6691312.A70 6691312	-
141 - NO LONGER AVAILABLE HIT-6688672.A3 6688672	-
142 - RETAINING RING C-TYPE D26 FOR (CP) HIT-6695294.A48 6695294	-
143 - BALL BEARING #6000 1 HIT-6695524.A35 6695524	-
144 - BALL BEARING #6000Z 1 HIT-6695526.A10 6695526	-
145 - CLUTCH HOUSING COMP. FOR (CP) HIT-6688571.A2 6688571	-
146 - GEAR 1 FOR (CP) HIT-6688968.A5 6688968	-
147 - GEAR 2 FOR (CP) HIT-6688978.A2 6688978	£29.02	£34.82
148 - CAM-ROD COMP. FOR (CP) HIT-6686810.A4 6686810	£31.02	£37.23
149 - CAM SHAFT FOR (CP) HIT-6686791.A2 6686791	-
150 - GEAR CASE GASKET FOR (CP) HIT-6688910.A2 6688910	-
151 - BALL BEARING #608 2 HIT-6684738.A3 6684738	-
152 - GREASE SEAL A FOR (CP) HIT-6686655.A0 6686655	-
153 - COLLAR FOR (CP) HIT-6688293.A1 6688293	-
154 - HEX. HOLE BOLT M5X25/S FOR (CP) HIT-6684709.A204 6684709	£1.67	£2.00
155 - GREASE NIPPLE COMP. FOR (CP) HIT-6688643.A74 6688643	£1.67	£2.00
156 - HEX. HOLE BOLT 6X18/S FOR (CP) HIT-6695495.A20 6695495	-
157 - HEX HOLE BUTTON SCREW 6X15 FOR (CP) HIT-6695079.A22 6695079	£1.67	£2.00
158 - SMALL WASHER 6 FOR (CP) HIT-6695183.A6 6695183	-
159 - FIXING PLATE FOR (CP) HIT-6686467.A3 6686467	-
160 - SUPPORT PLATE FOR (CP) HIT-6690758.A3 6690758	-
161 - HEX. SOCKET HD. BOLT M4X10 FOR (CP) HIT-6685093.A1 6685093	£1.67	£2.00
162 - SPRING NUT 6 FOR (CP) HIT-6695475.A0 6695475	-
164 - SPRING NUT 6 FOR (CP) HIT-6695475.A1 6695475	-
181 - CUTTER GUIDE 830L M6 FOR (CP) HIT-6687151.A1 6687151	-
183 - HEX. HOLE SCREW 6X25 FOR (CP) HIT-6695074.A3 6695074	-
184 - SPECIAL WASHER B FOR (CP) HIT-6684822.A46 6684822	£1.67	£2.00
186 - CUTTER B 852L FOR (CP) HIT-6687113.A0 6687113	-
187 - CUTTER A FOR (CP) HIT-6687091.A0 6687091	-
188 - WASHER 7 BLACK FOR (CP) HIT-6687187.A46 6687187	£1.67	£2.00
189 - FIXING BOLT A M6 FOR (CP) HIT-6687158.A28 6687158	£1.67	£2.00
190 - BLADE HOLDER FOR (CP) HIT-6687180.A0 6687180	-
192 - FIXING BOLT B M6 FOR (CP) HIT-6687168.A7 6687168	£1.67	£2.00
193 - HANDLE B COMP. FOR (CP) HIT-6686311.A1 6686311	£24.92	£29.91
194 - HANDLE GRIP FOR (CP) HIT-6684708.A1 6684708	£3.56	£4.27
195 - FLANGE NUT 6 FOR (CP) HIT-6695170.A43 6695170	£1.67	£2.00
196 - BOLT WASHER 6 FOR (CP) HIT-6684639.A51 6684639	£1.67	£2.00
197 - S.WASHER 6 FOR (CP) HIT-6695219.A29 6695219	£1.67	£2.00
198 - CUTTER COVER 1 HIT-6687308.A0 6687308	-
199 - GATHERING PLATE 1 HIT-6689539.A3 6689539	£32.99	£39.59
221 - GEAR CASE COMP. FOR (TP) HIT-6688684.A1 6688684	£64.00	£76.80
222 - STOP RING C-15 1 HIT-6695285.A11 6695285	£1.67	£2.00
223 - BALL BEARING 6002 C3 FOR (TP) HIT-6697745.A5 6697745	-
224 - BALL BEARING #6002Z 1 HIT-6695538.A10 6695538	£12.57	£15.08
225 - CLUTCH DRUM COMP. FOR (TP) HIT-6688570.A3 6688570	£22.90	£27.48
226 - GUIDE PLATE FOR (TP) HIT-6686612.A10 6686612	£1.67	£2.00
227 - CAM ROD FOR (TP) HIT-6686811.A1 6686811	£15.71	£18.85
228 - GEAR 2 COMP. FOR (TP) HIT-6688625.A2 6688625	£38.48	£46.17
229 - GEAR CASE GASKET FOR (TP) HIT-6688909.A14 6688909	£1.67	£2.00
230 - GEAR CASE COVER FOR (TP) HIT-6692101.A7 6692101	-
231 - CUTTER GUIDE 845L M6 FOR (TP) HIT-6687144.A3 6687144	£28.68	£34.41
232 - PROTECTION PLATE FOR (TP) HIT-6687289.A2 6687289	-
233 - HEX. HOLE FLUSH BOLT 6X25 FOR (TP) HIT-6695075.A0 6695075	£1.67	£2.00
234 - CUTTER A (812L) FOR (TP) HIT-6687092.A4 6687092	£60.99	£73.19
235 - GREASE SEAL A FOR (TP) HIT-6686654.A11 6686654	£1.67	£2.00
236 - WASHER 7 BLACK FOR (TP) HIT-6687187.A45 6687187	£1.67	£2.00
237 - FIXING BOLT A M6 FOR (TP) HIT-6687158.A30 6687158	£1.67	£2.00
238 - FLANGE NUT 6 FOR (TP) HIT-6695170.A41 6695170	£1.67	£2.00
239 - HEX. SOCKET HD. BOLT (W/SP.WASHER) M4X12 FOR (TP) HIT-6684595.A48 6684595	£1.67	£2.00
240 - GREASE NIPPLE COMP. FOR (TP) HIT-6688643.A71 6688643	£1.67	£2.00
241 - HEX. HOLE BOLT 6X18/S FOR (TP) HIT-6695495.A21 6695495	-
242 - SUPPORT PLATE FOR (TP) HIT-6690762.A1 6690762	£8.27	£9.92
243 - LOCK NUT 6 UPS-P FOR (TP) HIT-6695175.A9 6695175	£1.67	£2.00
244 - BOLT WASHER 6 FOR (TP) HIT-6684639.A53 6684639	£1.67	£2.00
245 - GEAR CASE B FOR (TP) HIT-6688846.A2 6688846	£9.00	£10.80
247 - SPRING NUT 6 FOR (TP) HIT-6695475.A5 6695475	-
248 - GUARD PLATE FOR (TP) HIT-6687275.A5 6687275	£4.47	£5.36
249 - HEX. HOLE BOLT 4X10S FOR (TP) HIT-6695484.A21 6695484	£1.67	£2.00
250 - BALL BEARING 608 ZZ C3 FOR (TP) HIT-6695547.A15 6695547	£10.17	£12.20
261 - HANDLE GRIP A FOR (CP) HIT-6686338.A0 6686338	-
262 - HANDLE GRIP B FOR (CP) HIT-6686349.A3 6686349	-
263 - THROTTLE LEVER FOR (CP) HIT-6688229.A4 6688229	£4.12	£4.94
264 - SAFETY LEVER FOR (CP) HIT-6688238.A0 6688238	-
265 - THROTTLE LEVER SPRING FOR (CP) HIT-6686414.A3 6686414	-
266 - STOP SWITCH COMP. FOR (CP) HIT-6687766.A1 6687766	-
267 - STOP BUTTON MARK FOR (CP) HIT-6694585.A9 6694585	-
268 - CAP FOR (CP) HIT-6693002.A7 6693002	£1.67	£2.00
269 - SCREW 4X30/WS FOR (CP) HIT-6695412.A6 6695412	-
270 - SCREW 4X25/WS FOR (CP) HIT-6695411.A3 6695411	-
271 - HANDLE GRIP ASS'Y FOR (CP) HIT-6686356.A0 6686356	-
272 - HANDLE A COMP. FOR (CP) HIT-6686275.A3 6686275	-
273 - THROTTLE WIRE 270+49 FOR (CP) HIT-6693877.A3 6693877	£6.61	£7.93
274 - PROTECTION TUBE 10X150L FOR (CP) HIT-6687558.A2 6687558	-
275 - SCREW 4X16WS FOR (CP) HIT-6695404.A3 6695404	-
276 - NYLON LOCK NUT 4 FOR (CP) HIT-6695163.A6 6695163	-
277 - SCREW 3X10 FOR (CP) HIT-6684913.A38 6684913	£1.67	£2.00
278 - BUTTON STOP FOR (CP) HIT-6688366.A34 6688366	£1.67	£2.00
279 - CORD CLAMP FOR (CP) HIT-6688015.A19 6688015	-
280 - HEX.HOLE BOLT M5X12/S FOR (CP) HIT-6684667.A4 6684667	£1.67	£2.00
281 - HANDLE BRACKET FOR (CP) HIT-6686370.A3 6686370	-
282 - HANDLE DUMPER RUBBER FOR (CP) HIT-6686396.A1 6686396	-
301 - FLAME FOR (TP) HIT-6688377.A0 6688377	£11.15	£13.38
302 - HANDLE FOR (TP) HIT-6688097.A3 6688097	-
303 - DAMPER COLLAR B FOR (TP) HIT-6688485.A16 6688485	£1.67	£2.00
304 - DAMPER B FOR (TP) HIT-6688412.A16 6688412	£1.67	£2.00
305 - BRAKE SHAFT WASHER FOR (TP) HIT-6689680.A8 6689680	£1.67	£2.00
306 - HEX. SOCKET HD. BOLT M5X30 S FOR (TP) HIT-6684786.A21 6684786	£1.67	£2.00
308 - HANDLE SUPPORT COMP. FOR (TP) HIT-6686111.A4 6686111	£4.81	£5.77
309 - HEX. HOLE BOLT 5X40 FOR (TP) HIT-6695054.A33 6695054	£1.67	£2.00
310 - SPRING WASHER 5 FOR (TP) HIT-6684834.A48 6684834	£1.67	£2.00
311 - WASHER M5 (BLACK) FOR (TP) HIT-6684918.A81 6684918	£1.67	£2.00
321 - HANDLE B FOR (TP) HIT-6686314.A1 6686314	£9.67	£11.60
322 - HANDLE A FOR (TP) HIT-6686279.A0 6686279	£9.67	£11.60
323 - THROTTLE LEVER FOR (TP) HIT-6688230.A0 6688230	-
324 - SAFETY LEVER OR FOR (TP) HIT-6688240.A1 6688240	£1.67	£2.00
325 - THROTTLE LEVER SPRING FOR (TP) HIT-6688244.A1 6688244	£3.51	£4.21
326 - STOP BUTTON COMP. FOR (TP) HIT-6687767.A0 6687767	-
327 - LOCK LEVER FOR (TP) HIT-6688246.A0 6688246	-
328 - SPRING FOR (TP) HIT-6688279.A0 6688279	-
329 - BOLT WASHER M4 FOR (TP) HIT-6685070.A48 6685070	£1.67	£2.00
330 - TAPPING SCREW D4X10 FOR (TP) HIT-6685161.A17 6685161	£1.67	£2.00
331 - TAPPING SCREW D4.5X16 FOR (TP) HIT-6684636.A41 6684636	£1.67	£2.00
332 - THROTTLE WIRE COMP. FOR (TP) HIT-6693940.A0 6693940	-
333 - BUTTON STOP FOR (TP) HIT-6688366.A35 6688366	£1.67	£2.00
334 - SCREW 3X10 FOR (TP) HIT-6684913.A39 6684913	£1.67	£2.00
335 - PROTECTION TUBE 150L FOR (TP) HIT-6687524.A2 6687524	-
336 - STOP BUTTON MARK FOR (TP) HIT-6694588.A6 6694588	£2.98	£3.57
501 - COMBI. BOX SPANNER 10X19 1 HIT-6685997.A31 6685997	-
502 - HEX. BAR WRENCH 4MM FOR (CP) HIT-6684813.A23 6684813	-
503 - COMBI BOX SPANNER 10/19MM FOR (CP) HIT-6685257.A6 6685257	-
601 - CYMBOL MARK CH78ED(CP) FOR (CP) HIT-6694749.A0 6694749	-
602 - SYMBOL CH78ED(TP) FOR (TP) HIT-6694748.A0 6694748	-

Attribute Name	Value
Brand	Hikoki

Reviews Write your own review!

There are currently no reviews of this product.

Fill in the form below to add your review for Hitachi / Hikoki CH78ED Engine Hedge Trimmer Spare Parts

Your Review
Title Required!
Rating Required!
Your Review Required!
Your Details
Your Name Required!
Your Location Required!
Email Address Required!Invalid email!

United Kingdom (Including N. Ireland)

On orders up to £40.00	Add £4.00 inc VAT (Royal Mail post)
On orders £40.00 to £130.00	Add £7.00 inc VAT (Courier)
On orders over £130.00	FREE (Courier)
