Hitachi / Hikoki CH55EPA Engine Pole Hedge Trimmer Spare Parts

An exploded diagram and spare parts listing for the Hitachi / Hikoki CH55EPA Engine Pole Hedge Trimmer

	Ex VAT	Inc VAT
1 - SPARK PLUG CAP ASS'Y TILL E909999 HIT-6687468.A89 6687468	£3.64	£4.37
2 - SPARK PLUG ASS'Y RCJ8Y HIT-6699328.A13 6699328	£5.70	£6.84
3 - CYLINDER SET HIT-6685489.A2 6685489	£62.25	£74.70
4 - HEX.HOLE BOLT M5X18/S HIT-6684586.A101 6684586	-
5 - CYLINDER GASKET HIT-6685709.A16 6685709	£1.67	£2.00
6 - PISTON RING HIT-6686118.A20 6686118	£6.94	£8.33
7 - PISTON ASS'Y HIT-6685869.A22 6685869	£28.00	£33.60
8 - CIR CLIP HIT-6684590.A3 6684590	£1.67	£2.00
9 - PISTON PIN HIT-6696944.A36 6696944	£5.61	£6.73
10 - CRANK SHAFT COMP. HIT-6686217.A7 6686217	£42.70	£51.24
11 - HIGH TENSION CORD 140L TILL E909999 HIT-6687888.A3 6687888	£3.89	£4.67
13 - HEX. HOLE BOLT 4X15/PS HIT-6684682.A53 6684682	£1.67	£2.00
14 - IGNITION COIL ASS'Y TILL E909999 HIT-6699772.A17 6699772	-
14A - IGNITION COIL ASS'Y SINCE EO00001 HIT-6697638.A4 6697638	-
15 - RUBBER CAP TILL E909999 HIT-6684602.A13 6684602	-
16 - LEAD WIRE ASS'Y HIT-6697836.A8 6697836	-
*31 - GEAR SHAFT SHIM 0.20 HIT-6684604.A72 6684604	-
*31 - GEAR SHAFT SHIM 0.30 HIT-6684605.A9 6684605	-
32 - CRANK CASE ASS'Y HIT-6686585.A8 6686585	£78.55	£94.26
33 - OIL SEAL TB 12227 HIT-6684607.A32 6684607	£4.07	£4.88
34 - BALL BEARING 6001 C3 HIT-6684608.A165 6684608	£5.70	£6.84
35 - CRANK CASE GASKET HIT-6686719.A7 6686719	£1.67	£2.00
36 - HEX.HOLE BOLT M5X18/S HIT-6684586.A100 6684586	-
37 - MAGNETO ASS'Y TILL E909999 HIT-6601171.A7 6601171	-
37A - MAGNETO ROTOR COMP. SINCE EO00001 HIT-6696928.A0 6696928	£50.30	£60.36
38 - BOLT WASHER M8 HIT-6684611.A107 6684611	-
39 - HEX. NUT M8 HIT-6684612.A8 6684612	-
51 - INLET MANIFOLD GASKET HIT-6689890.A13 6689890	£1.67	£2.00
52 - CARB INSULATOR SET HIT-6689914.A7 6689914	£8.34	£10.01
53 - CARBURETOR GASKET HIT-6684615.A41 6684615	£1.67	£2.00
54 - HEX.HOLE BOLT 5X22/WS HIT-6695514.A24 6695514	-
55 - SCREW 5X60/S HIT-6695354.A5 6695354	£1.67	£2.00
56 - WASHER 5 HIT-6684661.A101 6684661	£1.67	£2.00
57 - SHIELD TUBE HIT-6688174.A2 6688174	-
58 - CLIP D6 HIT-6685198.A12 6685198	-
59A - PUMP FILTER BODY COMP HIT-66A3864.A41 66A3864	-
60 - TANK 1 HIT-6691592.A7 6691592	£11.38	£13.66
61 - TANK CAP ASS'Y HIT-6685049.A35 6685049	£9.94	£11.93
62 - COLLAR 5.8 TILL E809999 HIT-6692244.A75 6692244	£1.67	£2.00
63 - CARBURETOR SET WYL182 HIT-6690512.A4 6690512	£69.17	£83.00
64 - SWIVEL CAP HIT-6691337.A83 6691337	£1.67	£2.00
65 - HEX. HOLE BOLT 5X16/PS TILL E809999 HIT-6695504.A9 6695504	£1.67	£2.00
65A - BOLT (W/FLANGE) L17.8 SINCE E900001 HIT-6696574.A31 6696574	£1.67	£2.00
66 - SCREW 5X20WS TILL E809999 HIT-6695516.A13 6695516	-
67 - TANK CAP CHAIN HIT-6684625.A99 6684625	-
68 - FUEL PIPE 3X5X85 HIT-6684880.A0 6684880	-
69 - RETURN GROMMET HIT-6697846.A74 6697846	£2.08	£2.50
91 - MUFFLER PROTECTOR BLACK HIT-6692809.A3 6692809	£8.45	£10.14
92 - SCREW 4X15PS HIT-6695373.A11 6695373	-
94 - TAPPING SCREW D4.5X12 HIT-6684637.A18 6684637	£1.67	£2.00
95 - HEX. SOCKET HD. BOLT M5X50 HIT-6685114.A23 6685114	£1.67	£2.00
96 - WASHER M5 (BLACK) HIT-6684918.A24 6684918	£1.67	£2.00
98 - MUFFLER SET HIT-6692487.A10 6692487	£29.28	£35.14
100 - MUFFLER GASKET HIT-6692745.A12 6692745	-
101 - HEAT SHIELD HIT-6687253.A10 6687253	£2.81	£3.37
103 - CLUTCH WASHER B HIT-6697619.A5 6697619	£1.67	£2.00
104 - CLUTCH SHOE COMP. 2 HIT-6688616.A14 6688616	£12.82	£15.38
104A - CLUTCH ARM COMP 54 SINCE E790001 HIT-6697161.A14 6697161	-
105 - CLUTCH SPRING TILL E699999 HIT-6689430.A19 6689430	£3.89	£4.67
105A - CLUTCH SPRING SINCE E790001 HIT-6697618.A8 6697618	-
106 - CLUTCH PLATE (A) HIT-6689528.A22 6689528	£1.67	£2.00
107 - STEP BOLT TILL E699999 HIT-6689627.A42 6689627	£1.67	£2.00
107A - STEP BOLT SINCE E790001 HIT-6684646.A9 6684646	£3.72	£4.46
108 - BENT WASHER 8 HIT-6684648.A22 6684648	£1.67	£2.00
109 - CLUTCH SET ASSY TILL E699999 HIT-6688484.A3 6688484	-
109A - CLUTCH ASS'Y SINCE E790001 HIT-6696932.A14 6696932	-
110 - HEX. HOLE BOLT M5X18/WS HIT-6684647.A22 6684647	£1.67	£2.00
112 - HEX.HOLE BOLT M5X30/WS HIT-6684973.A0 6684973	-
113 - CORD CLAMP COMP. HIT-6688011.A11 6688011	-
151 - RECOIL STARTER BODY ASS'Y TILL EN79999 HIT-6692988.A3 6692988	£53.19	£63.83
152 - STARTER HANDLE TILL EN79999 HIT-6693240.A16 6693240	£16.35	£19.62
153 - RECOIL STARTER BODY COMP. TILL EN79999 HIT-6693039.A6 6693039	-
154 - ROPE 2.6X830 TILL EN79999 HIT-6693175.A3 6693175	-
155 - RECOIL SPRING TILL EN79999 HIT-6693139.A5 6693139	-
156 - SPRING CASE ASS'Y TILL EN79999 HIT-6693102.A8 6693102	-
157 - STARTER ROPE REEL TILL EN79999 HIT-6693080.A5 6693080	-
158 - SPECIAL WASHER 5.2X15 TILL EN79999 HIT-6687947.A14 6687947	-
159 - TAPPING SCREW D5X14 TILL EN79999 HIT-6685275.A37 6685275	-
160 - HEX. HOLE BOLT 4X18WS TILL EN79999 HIT-6695508.A2 6695508	£1.67	£2.00
161 - FLUNGE NUT 5 TILL EN79999 HIT-6695169.A4 6695169	£1.67	£2.00
162 - STARTER PULLEY ASS'Y TILL EN79999 HIT-6693408.A5 6693408	£35.37	£42.44
171B - RECOIL STARTER BODY ASS'Y INCLUD.173-179 SINCE ED70001 HIT-6601570.A45 6601570	£23.15	£27.78
173 - STARTER ROPE 3.5X860 SINCE ED70001 HIT-6684674.A1 6684674	£5.70	£6.84
174 - RECOIL SPRING SINCE ED70001 HIT-6684675.A140 6684675	£8.82	£10.58
175A - STARTER ROPE REEL SINCE TE540001 HIT-6699997.A69 6699997	-
176 - DAMPER SPRING SINCE ED70001 HIT-6684677.A6 6684677	£6.66	£7.99
177A - CAM PLATE SINCE TE540001 HIT-6699996.A20 6699996	£4.28	£5.13
178 - SET SCREW SINCE ED70001 HIT-6684679.A2 6684679	£2.98	£3.57
179 - STARTER HANDLE SINCE ED70001 HIT-6684680.A113 6684680	£5.87	£7.04
180 - STARTER PULLEY ASS'Y SINCE ED70001 HIT-6684681.A2 6684681	£18.16	£21.79
181 - HEX. HOLE BOLT 4X18WS SINCE ED70001 HIT-6695508.A3 6695508	£1.67	£2.00
182 - D4E RETAINING RING SINCE ED70001 HIT-6685101.A70 6685101	-
183 - STARTER PAWL SPRING SINCE ED70001 HIT-6684684.A118 6684684	£3.29	£3.95
184 - STARTER PAWL SINCE ED70001 HIT-6684685.A1 6684685	£5.07	£6.08
*185 - CAMPLATE ASS'Y SINCE ED70001 HIT-6699691.A2 6699691	£7.75	£9.30
*185 - CAMPLATE ASS'Y TILL TE449999 HIT-6699691.A3 6699691	£7.75	£9.30
201 - CLEANER ASSY HIT-6690048.A14 6690048	£11.61	£13.93
202 - CLEANER COVER SET HIT-6690391.A4 6690391	£7.48	£8.97
203 - AIR CLEANER ELEMENT HIT-6684654.A4 6684654	£1.67	£2.00
204 - SPECIAL SCREW HIT-6689737.A31 6689737	-
205 - CLEANER BODY COMP. HIT-6684656.A4 6684656	£7.64	£9.17
206 - CHOKE VALVE HIT-6684657.A10 6684657	£2.81	£3.37
207 - WAVE WASHER 8 HIT-6684658.A9 6684658	£1.67	£2.00
208 - COLLAR 8 HIT-6684659.A10 6684659	-
221 - PUMP BODY COMP. HIT-6684879.A72 6684879	£35.37	£42.44
222 - PRIMING PUMP COMP. HIT-6684687.A98 6684687	£9.27	£11.12
223 - DIAPHRAGM COVER HIT-6684688.A1 6684688	£5.70	£6.84
224 - PRIMING BODY HIT-6684689.A100 6684689	£5.87	£7.04
225 - METERING DIAPHRAGM COMP. HIT-6690830.A62 6690830	£14.58	£17.50
226 - DIAPHRAGM GASKET HIT-6684691.A98 6684691	£5.70	£6.84
227 - PUMP DIAPHRAGM HIT-6684693.A202 6684693	£5.70	£6.84
228 - PUMP GASKET HIT-6691457.A90 6691457	£8.48	£10.18
229 - MAIN JET #38 HIT-6691844.A7 6691844	-
230 - O-RING HIT-6684695.A2 6684695	£1.67	£2.00
231 - STOP RING HIT-6684696.A217 6684696	-
232 - SWIVEL HIT-6684697.A2 6684697	-
233 - THROTTLE SET SCREW HIT-6684698.A71 6684698	-
234 - SET SCREW HIT-6684699.A1 6684699	-
235 - INLET SCREEN HIT-6684700.A233 6684700	-
251 - CLUTCH SHAFT COMP. HIT-6695969.A3 6695969	£16.69	£20.03
252 - STOP RING C-12 OUTER HIT-6684664.A2 6684664	-
253 - ANTI-VIBE RUBBER HIT-6691839.A3 6691839	£5.92	£7.11
254 - HEX. HOLE BOLT 5X16 HIT-6695046.A0 6695046	£1.67	£2.00
255 - HEX. HOLE BOLT M5X25/S HIT-6684709.A4 6684709	£1.67	£2.00
256 - FAN CASE 1 HIT-6687029.A13 6687029	£26.97	£32.36
257 - PIPE HOLDER 1 HIT-6689651.A9 6689651	£8.88	£10.66
258 - WASHER M5 (BLACK) HIT-6684918.A25 6684918	£1.67	£2.00
259 - GEAR CASE WASHER HIT-6689159.A10 6689159	-
260 - METAL FITTING HIT-6689664.A31 6689664	£6.12	£7.35
281 - DRIVE SHAFT 633L FOR (SM) HIT-6689439.A5 6689439	-
282 - DRIVE SHAFT PIPE 600L FOR (SM) HIT-6689303.A3 6689303	-
283 - BUSH ASS'Y FOR (SM) HIT-6684831.A31 6684831	-
284 - HANGER D24 HIT-6689277.A13 6689277	-
285 - BRACKET A FOR (SM) HIT-6688103.A4 6688103	-
286 - BRACKET B FOR (SM) HIT-6688104.A2 6688104	-
287 - HEX. HOLE BUTTON BOLT M6X25 FOR (SM) HIT-6684714.A159 6684714	£1.67	£2.00
289 - NUT M5 (BLACK) FOR (SM) HIT-6685075.A2 6685075	-
290 - HEX.NUT 6 HIT-6684835.A13 6684835	£1.67	£2.00
291 - WASHER 6 FOR (SM) HIT-6695194.A5 6695194	-
292 - FRONT HANDLE FOR (SM) HIT-6688096.A1 6688096	£16.62	£19.94
293 - HEX. HOLE BOLT 5X55 FOR (SM) HIT-6695056.A3 6695056	-
294 - WASHER M5 (BLACK) FOR (SM) HIT-6684918.A90 6684918	£1.67	£2.00
295 - SPRING WASHER 5 FOR (SM) HIT-6684834.A44 6684834	£1.67	£2.00
296 - THROTTLE LEVER ASS'Y HIT-6693769.A7 6693769	-
297 - THROTTLE WIRE COMP. HIT-6693982.A3 6693982	£36.27	£43.52
298 - THROTTLE WIRE 4T HIT-6694025.A3 6694025	£14.47	£17.36
299 - STOP BUTTON COMP. HIT-6687452.A1 6687452	£28.71	£34.45
300 - PROTECTION TUBE 7X145L HIT-6687523.A5 6687523	-
301 - TRIGGER LOCK OUT HIT-6684721.A27 6684721	£5.17	£6.20
302 - RETURN SPRING HIT-6684722.A22 6684722	£1.67	£2.00
303 - BLIND PLUG HIT-6684724.A26 6684724	-
304 - SCREW M5X20 HIT-6684803.A27 6684803	-
305 - CONTAL NUT 5 HIT-6684727.A26 6684727	£1.67	£2.00
306 - SCREW M4X20 (BLACK) HIT-6684725.A14 6684725	-
307 - THROTTLE LEVER HIT-6684804.A3 6684804	£6.86	£8.23
308 - DRIVE SHAFT 978L FOR (S) HIT-6689440.A4 6689440	£50.06	£60.07
309 - DRIVE SHAFT PIPE 945L FOR (S) HIT-6689304.A1 6689304	-
310 - BUSH ASS'Y FOR (S) HIT-6697839.A3 6697839	-
311 - LOOP HANDLE BLACK HIT-6691046.A9 6691046	£16.30	£19.56
312 - HANDLE BRACKET A FOR (S) HIT-6691134.A2 6691134	£3.10	£3.72
313 - HANDLE GRIP FOR (S) HIT-6691098.A20 6691098	£10.90	£13.08
314 - BOLT 6X43/P (BLACK) FOR (S) HIT-6684838.A27 6684838	£1.67	£2.00
315 - TAPPING SCREW 5X20 FOR (S) HIT-6695255.A4 6695255	-
316 - BRAKE SHAFT WASHER FOR (S) HIT-6689681.A36 6689681	£1.67	£2.00
321 - GEAR CASE A 1 HIT-6688653.A7 6688653	£38.36	£46.03
322 - BALL BEARING 6901ZZ 2 HIT-6695582.A13 6695582	£15.31	£18.37
323 - STOP RING S-12 1 HIT-6695302.A0 6695302	£1.67	£2.00
324 - STOP RING C-24 1 HIT-6684732.A21 6684732	£1.67	£2.00
325 - BALL BEARING 608ZZC3 HIT-6698772.A20 6698772	£2.84	£3.41
326 - RETAINING RING C-TYPE D22 HIT-6695293.A7 6695293	£1.67	£2.00
327 - GREASE NIPPLE COMP. HIT-6688643.A37 6688643	£1.67	£2.00
328 - HEX. HOLE BOLT 5X10 HIT-6695042.A30 6695042	£1.67	£2.00
329 - HEX. HOLE BOLT M5X25/S HIT-6684709.A137 6684709	£1.67	£2.00
330 - HEX. HOLE BOLT 6X12 HIT-6695078.A4 6695078	£1.67	£2.00
331 - SPECIAL WASHER B HIT-6684822.A32 6684822	£1.67	£2.00
332 - GEAR CASE B HIT-6695981.A1 6695981	£40.62	£48.75
333 - BALL BEARING #6000DD 1 HIT-6695528.A2 6695528	-
334 - RETAINING RING C-TYPE D26 HIT-6695294.A30 6695294	-
335 - SPECIAL WASHER B HIT-6684822.A33 6684822	£1.67	£2.00
336 - RETAINING RING E-TYPE D6 HIT-6695310.A8 6695310	£1.67	£2.00
337 - GEAR CASE COVER (A) HIT-6689167.A11 6689167	-
338 - HEX HOLE BOLT 4X8 HIT-6695035.A11 6695035	-
339 - BALL BEARING 608ZZC3 HIT-6698772.A19 6698772	£2.84	£3.41
340 - RETAINING RING C-TYPE D22 HIT-6695293.A6 6695293	£1.67	£2.00
341 - HANDLE HIT-6688089.A4 6688089	£7.75	£9.30
342 - HEX HOLE BUTTON SCREW 6X15 HIT-6695079.A16 6695079	£1.67	£2.00
343 - GREASE STOP (D) HIT-6686669.A0 6686669	£1.67	£2.00
344 - GEAR SET PN HIT-6696411.A1 6696411	£97.03	£116.44
345 - HANDLE KNOB A COMP. HIT-6691200.A11 6691200	£12.10	£14.52
346 - PLUS BOLT 6X14 HIT-6695016.A13 6695016	-
347 - LOCK NUT 6 UPS-P HIT-6695175.A23 6695175	£1.67	£2.00
348 - SUPPORT PLATE HIT-6690744.A8 6690744	£17.82	£21.39
349 - GREASE STOP (B) HIT-6686659.A0 6686659	£1.67	£2.00
350 - ANGLE LIMITER FOR (SM) HIT-6688159.A3 6688159	-
351 - BOLT WASHER 6 HIT-6684639.A77 6684639	£1.67	£2.00
361 - CAM SHAFT COMP. HIT-6686790.A9 6686790	£62.78	£75.33
362 - CAM ROD HIT-6686809.A5 6686809	£11.92	£14.30
363 - CAM-ROD GUIDE PLATE HIT-6686611.A6 6686611	£2.98	£3.57
364 - CUTTER GUIDE 625.5MM HIT-6687125.A15 6687125	£37.68	£45.21
365 - CUTTER (A) HIT-6687079.A13 6687079	£46.75	£56.10
366 - FIXING BOLT A M6 HIT-6687158.A41 6687158	£1.67	£2.00
367 - WASHER 7 BLACK HIT-6687187.A30 6687187	£1.67	£2.00
368 - FLANGE NUT 6 HIT-6695170.A9 6695170	£1.67	£2.00
369 - HEX HOLE FLUSH SCREW 6X16 HIT-6695073.A5 6695073	£1.67	£2.00
370 - GREASE STOP (A) HIT-6686647.A10 6686647	£1.67	£2.00
371 - CAM ROD PLATE HIT-6686826.A6 6686826	£1.67	£2.00
372 - GEAR CASE COVER (B) HIT-6689173.A2 6689173	£27.59	£33.11
373 - BALL BEARING 608 ZZ C3 HIT-6695547.A18 6695547	£10.17	£12.20
374 - HEX. HOLE BOLT 4X10S HIT-6695484.A29 6695484	£1.67	£2.00
375 - HEX. SOCKET HD. BOLT (W/SP.WASHER) M4X12 HIT-6684595.A37 6684595	£1.67	£2.00
376 - CUTTER COVER HIT-6687301.A10 6687301	-
377 - CUTTER FIXING BOLT B HIT-6687162.A20 6687162	£1.67	£2.00
378 - HEX. HOLE FLUSH BOLT 6X25 HIT-6695075.A15 6695075	£1.67	£2.00
379 - GREASE STOP (C) HIT-6686666.A5 6686666	-
380 - SPACER HIT-6688633.A10 6688633	-
381A - PROTECTION PLATE HIT-6601208.A2 6601208	-
382 - LOCK NUT 6 UPS-P HIT-6695175.A24 6695175	£1.67	£2.00
383 - BOLT WASHER 6 HIT-6684639.A76 6684639	£1.67	£2.00
501 - COMBI. BOX SPANNER 10X19 1 HIT-6685997.A20 6685997	-
502 - HEX. BAR WRENCH 4MM HIT-6684813.A41 6684813	-
503 - SHOULDER BELT HIT-6692867.A9 6692867	£8.37	£10.04
601 - SYMBOL MARK CH55EPA(S) HIT-6694746.A0 6694746	-
602 - NAME PLATE CH55EPA(SM) HIT-6694745.A0 6694745	-

Attribute Name	Value
Brand	Hikoki

Reviews Write your own review!

There are currently no reviews of this product.

Fill in the form below to add your review for Hitachi / Hikoki CH55EPA Engine Pole Hedge Trimmer Spare Parts

Your Review
Title Required!
Rating Required!
Your Review Required!
Your Details
Your Name Required!
Your Location Required!
Email Address Required!Invalid email!

United Kingdom (Including N. Ireland)

On orders up to £40.00	Add £4.00 inc VAT (Royal Mail post)
On orders £40.00 to £130.00	Add £7.00 inc VAT (Courier)
On orders over £130.00	FREE (Courier)
