1 - COVER FIXING BOLT
HIT-6684655.A3
6684655
|
£7.78
|
£9.34
|
|
|
2 - O-RING (S-4)
HIT-981317.A11
981317
|
£1.67
|
£2.00
|
|
|
3 - AIR CLEANER COVER
HIT-6601540.A6
6601540
|
-
|
|
|
|
4 - AIR CLEANER ELEMENT
HIT-6601539.A2
6601539
|
-
|
|
|
|
5 - SWIVEL
HIT-6684697.A154
6684697
|
-
|
|
|
|
6 - STOP RING
HIT-6684696.A7
6684696
|
-
|
|
|
|
7 - O-RING
HIT-6684695.A187
6684695
|
£1.67
|
£2.00
|
|
|
8 - MAIN JET
HIT-000000.A2565
000000
|
-
|
|
|
|
9 - PUMP GASKET
HIT-6684692.A108
6684692
|
£17.28
|
£20.73
|
|
|
10 - PUMP BODY
HIT-000000.A2566
000000
|
-
|
|
|
|
11 - DIAPHRAGM COVER-METERING
HIT-6685222.A128
6685222
|
£5.70
|
£6.84
|
|
|
12 - SET SCREW
HIT-6691312.A71
6691312
|
-
|
|
|
|
13 - THROTTLE SET SCREW
HIT-6684698.A3
6684698
|
-
|
|
|
|
14 - THROTTLE VALVE
HIT-000000.A2567
000000
|
-
|
|
|
|
15 - PUMP DIAPHRAGM
HIT-6684693.A7
6684693
|
£5.70
|
£6.84
|
|
|
16 - INLET SCREEN
HIT-6684700.A20
6684700
|
-
|
|
|
|
17 - DIAPHRAGM PACKING-METERING
HIT-6685220.A51
6685220
|
£2.81
|
£3.37
|
|
|
18 - METERING DIAPHRAGM
HIT-6684690.A118
6684690
|
£24.05
|
£28.86
|
|
|
19 - SCREW M5X55
HIT-6694914.A16
6694914
|
-
|
|
|
|
20 - BOLT WASHER D5
HIT-6685407.A35
6685407
|
-
|
|
|
|
21 - WAVE WASHER 8
HIT-334242.A15
334242
|
-
|
|
|
|
22 - COLLAR M5
HIT-6601538.A5
6601538
|
-
|
|
|
|
23 - CHOKE VALVE
HIT-6601537.A3
6601537
|
-
|
|
|
|
24 - PRIMING PUMP COMP.
HIT-6685139.A94
6685139
|
£10.67
|
£12.80
|
|
|
25 - FUEL PIPE
HIT-6601607.A3
6601607
|
-
|
|
|
|
26 - CARBURETOR ASS'Y (WYL-367) INCLUD.5-18
HIT-6601535.A3
6601535
|
-
|
|
|
|
27 - AIR CLEANER BASE
HIT-6601536.A5
6601536
|
-
|
|
|
|
28 - LOCK NUT M6 (10 PCS.)
HIT-949567.A24
949567
|
£1.67
|
£2.00
|
|
|
29 - CARBURETOR PACKING
HIT-6698405.A68
6698405
|
£3.12
|
£3.74
|
|
|
30 - HEX. SOCKET HD. BOLT (W/WASHERS) M4X18
HIT-6698388.A16
6698388
|
£1.67
|
£2.00
|
|
|
31 - CORD
HIT-6696544.A36
6696544
|
-
|
|
|
|
32 - SEAL LOCK HEX. SOCKET HD. BOLT M6X27
HIT-6601358.A5
6601358
|
-
|
|
|
|
33 - SPRING WASHER D6
HIT-6600910.A11
6600910
|
-
|
|
|
|
34 - CARBURETOR INSULATOR
HIT-6601491.A4
6601491
|
-
|
|
|
|
35 - INTAKE PACKING
HIT-6601534.A5
6601534
|
-
|
|
|
|
36 - CYLINDER N24
HIT-6600902.A6
6600902
|
-
|
|
|
|
37 - PLUG CAP
HIT-6601421.A27
6601421
|
£1.67
|
£2.00
|
|
|
38 - PLUG CAP METAL
HIT-6699186.A27
6699186
|
£1.67
|
£2.00
|
|
|
39 - IGNITION PLUG (TORCH L7RTC)
HIT-6600542.A18
6600542
|
-
|
|
|
|
40 - HEX. SOCKET HD. BOLT (W/WASHERS) M5
HIT-6600372.A15
6600372
|
-
|
|
|
|
41 - EMISSION LABEL (EU)
HIT-000000.A2568
000000
|
-
|
|
|
|
42 - CYLINDER COVER
HIT-6601541.A3
6601541
|
-
|
|
|
|
43 - MUFFLER COVER
HIT-6601544.A5
6601544
|
-
|
|
|
|
44 - WASHER 5
HIT-6685408.A11
6685408
|
£3.49
|
£4.19
|
|
|
45 - HEX. SOCKET HD. BOLT (W/SP.WASHER) M5X18
HIT-6698386.A13
6698386
|
-
|
|
|
|
46 - GLASS WASHER
HIT-6698700.A79
6698700
|
£1.67
|
£2.00
|
|
|
47 - HEX. SOCKET HD. BOLT (W/SP.WASHER) M5X22
HIT-6601339.A12
6601339
|
-
|
|
|
|
48 - IGNITION COIL
HIT-6601612.A1
6601612
|
-
|
|
|
|
49 - CYLINDER PACKING
HIT-6601527.A7
6601527
|
-
|
|
|
|
50 - PISTON RING
HIT-6698404.A2
6698404
|
£7.03
|
£8.44
|
|
|
51 - PISTON N24
HIT-6601429.A4
6601429
|
-
|
|
|
|
52 - CIR CLIP
HIT-6684590.A122
6684590
|
£1.67
|
£2.00
|
|
|
53 - WOODRUFF KEY 3X13X4.5
HIT-6601343.A14
6601343
|
-
|
|
|
|
54 - SHIM
HIT-6600909.A12
6600909
|
-
|
|
|
|
55 - PISTON PIN
HIT-6601344.A13
6601344
|
-
|
|
|
|
56 - HEAT PROTECTION PANEL
HIT-6601531.A5
6601531
|
-
|
|
|
|
57 - MUFFLER ASS'Y INCLUD.58-61
HIT-6601529.A5
6601529
|
-
|
|
|
|
58 - EXHAUST PIPE PACKING
HIT-6601606.A5
6601606
|
-
|
|
|
|
59 - SPARK ARRESTER
HIT-6601605.A3
6601605
|
-
|
|
|
|
60 - EXHAUST PIPE
HIT-6601604.A5
6601604
|
-
|
|
|
|
61 - MACHINE SCREW (W/SP. WASHER) M4X12
HIT-6685068.A59
6685068
|
-
|
|
|
|
62 - SEAL LOCK HEX. SOCKET HD. BOLT M6X16
HIT-6600518.A4
6600518
|
-
|
|
|
|
63 - FLYWHEEL NUT M7
HIT-6696879.A6
6696879
|
-
|
|
|
|
64 - BOLT WASHER D7
HIT-6696880.A21
6696880
|
-
|
|
|
|
65 - STARTER PAWL
HIT-6685334.A1
6685334
|
£2.84
|
£3.41
|
|
|
66 - STARTER PAWL SPRING
HIT-6685335.A29
6685335
|
£2.84
|
£3.41
|
|
|
67 - MAGNETO ROTOR COMP.
HIT-6600053.A4
6600053
|
-
|
|
|
|
68 - RETAINING RING D4
HIT-6685336.A3
6685336
|
£3.49
|
£4.19
|
|
|
69 - CRANK CASE (F) ASS'Y INCLUD.70
HIT-6601602.A6
6601602
|
-
|
|
|
|
70 - OIL SEAL TB 12227
HIT-6684607.A104
6684607
|
£4.07
|
£4.88
|
|
|
71 - BALL BEARING 6001 C3
HIT-6684608.A96
6684608
|
£5.70
|
£6.84
|
|
|
72 - CRANK SHAFT
HIT-6601528.A1
6601528
|
-
|
|
|
|
73 - CRANK CASE (G) ASS'Y INCLUD.70
HIT-6601603.A2
6601603
|
-
|
|
|
|
74 - CRANK CASE PACKING
HIT-6600514.A26
6600514
|
-
|
|
|
|
75 - KNOCK PIN 4X12
HIT-6696947.A54
6696947
|
-
|
|
|
|
76 - CLUTCH (B)
HIT-6699173.A11
6699173
|
£11.61
|
£13.93
|
|
|
77 - CLUTCH DRUM
HIT-6601548.A4
6601548
|
-
|
|
|
|
78 - BALL BEARING 6002ZC3
HIT-6698740.A2
6698740
|
£6.94
|
£8.33
|
|
|
79 - RETAINING RING FOR D15 SHAFT (10 PCS.)
HIT-939544.A4
939544
|
£3.64
|
£4.37
|
|
|
80 - GREASE NIPPLE COMP.
HIT-6688643.A77
6688643
|
£1.67
|
£2.00
|
|
|
81 - MACHINE SCREW (W/WASHERS) M5X20 (BLACK)
HIT-995096.A19
995096
|
£1.67
|
£2.00
|
|
|
82 - FIXATION PLATE (B)
HIT-6699048.A2
6699048
|
-
|
|
|
|
83 - FIXATION PLATE (A)
HIT-6699047.A11
6699047
|
-
|
|
|
|
84 - TAIL PIPE COVER
HIT-6601564.A5
6601564
|
-
|
|
|
|
85 - TAIL PIPE
HIT-6601563.A1
6601563
|
-
|
|
|
|
86 - BRAND LABEL
HIT-000000.A2569
000000
|
-
|
|
|
|
87 - TANK MARK LABEL (50:1)
HIT-6698921.A57
6698921
|
-
|
|
|
|
88 - TAPPING SCREW D4.5X16
HIT-6698878.A30
6698878
|
£1.67
|
£2.00
|
|
|
89 - AIR DEFLECTOR
HIT-6601543.A4
6601543
|
-
|
|
|
|
90 - STARTER ASS'Y INCLUD.91-98
HIT-6601542.A4
6601542
|
-
|
|
|
|
91 - PLATE
HIT-6685189.A10
6685189
|
-
|
|
|
|
92 - STARTER HANDLE
HIT-6693227.A22
6693227
|
-
|
|
|
|
93 - STARTER ROPE
HIT-000000.A2570
000000
|
-
|
|
|
|
94 - SPIRAL SPRING
HIT-000000.A2571
000000
|
-
|
|
|
|
95 - REEL
HIT-000000.A2572
000000
|
-
|
|
|
|
96 - DAMPER SPRING
HIT-6685183.A15
6685183
|
£5.70
|
£6.84
|
|
|
97 - CAM PLATE
HIT-000000.A2573
000000
|
-
|
|
|
|
98 - SET SCREW
HIT-6684679.A162
6684679
|
£2.98
|
£3.57
|
|
|
99 - FUEL TANK CAP ASS'Y INCLUD.100
HIT-6698402.A96
6698402
|
-
|
|
|
|
100 - TANK CAP CHAIN
HIT-6698732.A8
6698732
|
-
|
|
|
|
101 - CUSHION RUBBER
HIT-6698615.A10
6698615
|
£3.56
|
£4.27
|
|
|
102 - TANK (FT)
HIT-6601533.A4
6601533
|
-
|
|
|
|
103 - FUEL GROMMET
HIT-6600358.A43
6600358
|
£1.67
|
£2.00
|
|
|
104 - FUEL PIPE
HIT-6698716.A19
6698716
|
£5.61
|
£6.73
|
|
|
105 - FUEL PIPE
HIT-6601399.A17
6601399
|
£3.02
|
£3.63
|
|
|
106 - CLIP
HIT-6696949.A51
6696949
|
£1.67
|
£2.00
|
|
|
107 - PUMP FILTER
HIT-6600351.A44
6600351
|
£4.45
|
£5.34
|
|
|
131 - NAME PLATE
HIT-000000.A2574
000000
|
-
|
|
|
|
132 - HANDLE
HIT-6699079.A12
6699079
|
£8.55
|
£10.26
|
|
|
133 - SEAL LOCK HEX. SOCKET HD. BOLT M5X40
HIT-6698885.A11
6698885
|
£2.84
|
£3.41
|
|
|
134 - SPRING WASHER M5
HIT-6698884.A4
6698884
|
-
|
|
|
|
135 - BRAKE AXIS WASHER
HIT-6698749.A10
6698749
|
-
|
|
|
|
136 - CAUTION LABEL
HIT-000000.A2575
000000
|
-
|
|
|
|
137 - REAR HANDLE (A)
HIT-6601545.A4
6601545
|
-
|
|
|
|
138 - SPRING (A)
HIT-6696348.A27
6696348
|
-
|
|
|
|
139 - LOCK BUTTON
HIT-6601546.A4
6601546
|
-
|
|
|
|
140 - THROTTLE LEVER
HIT-6699053.A18
6699053
|
-
|
|
|
|
141 - TRIGGER LOCKOUT
HIT-6696344.A27
6696344
|
£2.84
|
£3.41
|
|
|
142 - THROTTLE LEVER SPRING
HIT-6696345.A5
6696345
|
£2.84
|
£3.41
|
|
|
143 - STOP SWITCH
HIT-6601275.A44
6601275
|
£1.67
|
£2.00
|
|
|
144 - REAR HANDLE (B)
HIT-6601547.A4
6601547
|
-
|
|
|
|
145 - TAPPING SCREW (W/FLANGE) D4X16 (BLACK)
HIT-305812.A10
305812
|
£1.67
|
£2.00
|
|
|
146 - THROTTLE WIRE
HIT-6601613.A5
6601613
|
-
|
|
|
|
147 - FERRITE CORE
HIT-334379.A24
334379
|
-
|
|
|
|
148 - PROTECTION TUBE
HIT-6698738.A17
6698738
|
£1.67
|
£2.00
|
|
|
149 - BAND
HIT-6698943.A5
6698943
|
-
|
|
|
|
150 - SUPPORT (D)
HIT-6601617.A4
6601617
|
-
|
|
|
|
151 - STOP SWITCH CORD (B)
HIT-6699059.A17
6699059
|
-
|
|
|
|
152 - STOP SWITCH CORD
HIT-6696491.A4
6696491
|
-
|
|
|
|
153 - NYLON NUT M5
HIT-305491.A5
305491
|
-
|
|
|
|
154 - SMALL WASHER 5
HIT-6684864.A109
6684864
|
-
|
|
|
|
155 - U-NUT M5
HIT-6699108.A13
6699108
|
£2.94
|
£3.53
|
|
|
156 - SUPPORT PLATE
HIT-6601558.A1
6601558
|
-
|
|
|
|
157 - GUIDE PLATE (EA)
HIT-6601615.A0
6601615
|
-
|
|
|
|
158 - BLADE ASS'Y (500MM) INCLUD.155
HIT-6601553.A0
6601553
|
-
|
|
|
|
159 - BLADE GUIDE
HIT-6600009.A4
6600009
|
£13.28
|
£15.93
|
|
|
160 - HEX. SOCKET HD. BOLT (W/BUTTON) M5X25
HIT-6699110.A4
6699110
|
£2.75
|
£3.30
|
|
|
161 - WASHER (B)
HIT-6699112.A18
6699112
|
£1.67
|
£2.00
|
|
|
162 - BLADE LINER
HIT-6600359.A3
6600359
|
-
|
|
|
|
163 - HEDGE TRIMMER BLADE (A)
HIT-6600010.A3
6600010
|
£25.61
|
£30.73
|
|
|
164 - HEDGE TRIMMER BLADE (B)
HIT-6600011.A4
6600011
|
£25.76
|
£30.91
|
|
|
165 - WASHER M7
HIT-6699111.A5
6699111
|
£1.67
|
£2.00
|
|
|
166 - SHOULDER BUTTON BOLT M5X25
HIT-000000.A2576
000000
|
-
|
|
|
|
167 - BLADE CASE (A)
HIT-6698731.A5
6698731
|
-
|
|
|
|
168 - HANDLE BRACKET
HIT-6601565.A0
6601565
|
-
|
|
|
|
169 - CLIP
HIT-6696359.A15
6696359
|
£2.84
|
£3.41
|
|
|
170 - SEAL LOCK HEX. SOCKET BOLT (W/WASHERS)M5
HIT-6699044.A4
6699044
|
-
|
|
|
|
171 - GEAR CASE (A)
HIT-6601608.A2
6601608
|
-
|
|
|
|
172 - GUIDE PLATE (C)
HIT-6601549.A0
6601549
|
-
|
|
|
|
173 - GEAR 2 (EA)
HIT-6699038.A6
6699038
|
-
|
|
|
|
174 - FELT PACKING (A)
HIT-6601559.A2
6601559
|
-
|
|
|
|
175 - GEAR CASE PACKING
HIT-6601561.A4
6601561
|
-
|
|
|
|
176 - WASHER (EA)
HIT-6601618.A2
6601618
|
-
|
|
|
|
177 - GEAR CASE COVER
HIT-6601562.A3
6601562
|
-
|
|
|
|
178 - HEX. SOCKET HD. BOLT M4X12
HIT-6698385.A37
6698385
|
-
|
|
|
|
501 - BOX WRENCH 10/19MM
HIT-6698756.A9
6698756
|
-
|
|
|
