Hitachi / Hikoki CG47EY Engine Brush Cutter Spare Parts

An exploded diagram and spare parts listing for the Hitachi / Hikoki CG47EY Engine Brush Cutter

	Ex VAT	Inc VAT
1 - SPARK PLUG CAP ASS'Y HIT-6687468.A69 6687468	£3.64	£4.37
2 - SPARK PLUG RUBBER COVER TILL E329999 HIT-6688336.A10 6688336	£3.56	£4.27
3 - SPARK PLUG ASS'Y BPMR6A HIT-6699319.A8 6699319	-
4 - CYLINDER SET HIT-6685470.A6 6685470	£85.28	£102.33
5 - HEX.HOLE BOLT M5X18/S HIT-6684586.A99 6684586	-
6 - CYLINDER GASKET HIT-6685738.A6 6685738	£1.67	£2.00
7 - PISTON RING HIT-6686126.A2 6686126	£9.27	£11.12
8 - PISTON SET HIT-6685887.A6 6685887	£35.58	£42.69
9 - PISTON PIN 10X35 HIT-6686019.A1 6686019	£4.12	£4.94
10 - PISTON PIN CIRCLIP HIT-6686026.A1 6686026	£1.67	£2.00
11 - PISTON PIN COLLAR HIT-6685993.A1 6685993	£5.70	£6.84
12 - CRANK SHAFT COMP. HIT-6686190.A6 6686190	£123.58	£148.29
13 - NEEDLE BEARING 1 HIT-6695602.A11 6695602	-
14 - WOOD-RUFF KEY 3X13X5 HIT-6686457.A28 6686457	£1.67	£2.00
31 - SMALL NUT 10 HIT-6695139.A40 6695139	-
32 - CRANK CASE ASS'Y HIT-6686553.A6 6686553	£60.99	£73.19
33 - CRANK CASE GASKET HIT-6686713.A5 6686713	£1.67	£2.00
34 - OIL SEAL UD15257 HIT-6695637.A13 6695637	£3.66	£4.39
35 - BALL BEARING #6202 2 HIT-6695557.A9 6695557	-
36 - CRANK SHAFT WASHER 15.2X22 HIT-6686463.A6 6686463	-
*37 - CRANK SHAFT SHIM 0.20 HIT-6686472.A7 6686472	£1.67	£2.00
*37 - CRANK SHAFT SHIM 0.30 HIT-6686473.A24 6686473	£1.67	£2.00
38 - HEX HOLE BUTTON SCREW 6X45 HIT-6695084.A4 6695084	-
39 - S.WASHER 6 HIT-6684826.A0 6684826	£1.67	£2.00
40 - HEX. SOCKET HD. BOLT (W/BUTTON) M6 HIT-6684825.A25 6684825	£1.67	£2.00
41 - LOCK NUT M6 HIT-6684872.A6 6684872	-
42 - OUTER RECEIVER HIT-6694043.A2 6694043	-
43 - MAGNETO ROTOR COMP. HIT-6687371.A2 6687371	£59.76	£71.71
44 - SMALL WASHER 10 HIT-6695185.A12 6695185	-
45 - NUT 10 HIT-6695138.A0 6695138	-
46 - NO LONGER AVAILABLE HIT-6687662.A0 6687662	-
47 - SCREW 5X18/S HIT-6695339.A13 6695339	-
48 - SMALL WASHER 5 HIT-6684864.A42 6684864	-
49 - GROMMET HIT-6688053.A0 6688053	-
50 - LEAD WIRE ASS'Y HIT-6687967.A1 6687967	-
71 - FUEL TANK CUSHION RUBBER HIT-6692225.A3 6692225	£1.67	£2.00
72 - INLET MANUFOLD GASKET HIT-6689883.A6 6689883	£1.67	£2.00
73 - CARB. INSULATOR SET HIT-6689950.A6 6689950	-
74 - CARBURETOR GASKET HIT-6689826.A9 6689826	£1.67	£2.00
75 - CARBURETOR SET HDA306 TILL E519999 FOR EUROPE HIT-6690468.A1 6690468	£104.42	£125.30
75A - CARBURETOR SET HDA180A SINCE E610001 FOR EUROPE HIT-6697706.A1 6697706	£94.70	£113.64
76 - SCREW 5X24WS HIT-6695423.A12 6695423	-
77 - CHOKE LEVER HIT-6691004.A7 6691004	£2.98	£3.57
78 - FUEL PIPE 2.5X4X90 TILL E519999 HIT-6685267.A10 6685267	£1.67	£2.00
78A - FUEL PIPE 2.5X4X80 SINCE E610001 HIT-6692347.A12 6692347	£1.67	£2.00
79 - SMALL NUT 10 TILL E519999 HIT-6695139.A39 6695139	-
80 - INNER TOOTHED WASHER 10 TILL E519999 HIT-6695235.A6 6695235	-
81 - PRIMING PUMP COMP. TILL E519999 HIT-6690080.A0 6690080	£11.79	£14.15
81A - PRIMING PUMP COMP. SINCE E610001 HIT-6685139.A15 6685139	£10.67	£12.80
82 - FUEL PIPE ASS'Y 3X5X230 HIT-6688166.A7 6688166	£5.17	£6.20
83 - CLIP 1 HIT-6684619.A62 6684619	£1.67	£2.00
84 - PUMP FILTER BODY ASS'Y HIT-6692273.A1 6692273	£9.60	£11.52
85 - FUEL TANK 1 HIT-6691526.A0 6691526	£14.33	£17.20
86 - RETURN GROMMET HIT-6697846.A64 6697846	£2.08	£2.50
87 - TANK CAP D ASS'Y 1 HIT-6691763.A32 6691763	£13.46	£16.15
88 - TANK HOLDING BAND HIT-6691927.A2 6691927	£14.69	£17.63
89 - CUSHION RUBBER HIT-6692193.A5 6692193	£12.50	£15.00
90 - SCREW 5X16/PS HIT-6695386.A9 6695386	£1.67	£2.00
91 - SWIVEL CAP HIT-6691337.A66 6691337	£1.67	£2.00
92 - TANK CAP CHAIN HIT-6684625.A89 6684625	-
93 - CARBURETOR SET HDA306 TILL ED79999 FOR RUS HIT-6690468.A0 6690468	£104.42	£125.30
93A - CARBURETOR SET HDA305 SINCE E180001 TILL E519999 FOR RUS HIT-6690467.A3 6690467	£95.09	£114.11
93B - CARBURETOR ASS'Y PN SINCE E610001 FOR RUS HIT-6697732.A1 6697732	-
94 - CARBURETOR ASS'Y PN FOR NZL HIT-6697732.A2 6697732	-
111 - MUFFLER PROTECTOR HIT-6692777.A0 6692777	-
112 - SCREW 5X12/PS HIT-6695383.A3 6695383	£1.67	£2.00
113 - HEX.HOLE BOLT M5X12/S HIT-6684667.A83 6684667	£1.67	£2.00
114 - WASHER M5 (BLACK) HIT-6684918.A7 6684918	£1.67	£2.00
115 - HEX. HOLE BUTTON SCREW 6X65 HIT-6695088.A0 6695088	£3.72	£4.46
116 - BOLT WASHER 6 HIT-6684639.A201 6684639	£1.67	£2.00
117 - NO LONGER AVAILABLE HIT-6692463.A3 6692463	-
118 - MUFFLER SPECIAL GASKET HIT-6692883.A2 6692883	-
*119 - TAIL PIPE SET 1 HIT-6692648.A1 6692648	-
*119 - TAIL PIPE SET FOR NZL HIT-6692649.A2 6692649	-
*120 - SCREW 4X8/S FOR EUROPE HIT-6695325.A5 6695325	-
*120 - MACHINE SCREW (W/SP. WASHER) M4X8 FOR NZL HIT-6685109.A2 6685109	-
121 - MUFFLER GASKET HIT-6692741.A20 6692741	£3.89	£4.67
122 - HEAT SHIELD HIT-6687242.A4 6687242	£4.81	£5.77
123 - SCREW 5X18/PS HIT-6695389.A4 6695389	£1.67	£2.00
124 - TANK BRACKET HIT-6692205.A0 6692205	£10.50	£12.60
125 - FUEL TANK CUSHION RUBBER HIT-6692227.A4 6692227	£1.67	£2.00
126 - CLUTCH WASHER B HIT-6689645.A50 6689645	£1.67	£2.00
127 - CLUTCH ARM HIT-6688615.A4 6688615	£20.95	£25.14
128 - CLUTCH SPRING HIT-6689429.A0 6689429	£4.26	£5.11
129 - WAVE WASHER 10 HIT-6695203.A23 6695203	£1.67	£2.00
130 - CLUTCH STEP BOLT HIT-6689628.A1 6689628	£3.29	£3.95
131 - CLUTCH SET ASS'Y HIT-6699561.A2 6699561	£25.82	£30.99
151A - RECOIL STARTER BODY ASS'Y HIT-6697645.A6 6697645	£28.11	£33.73
152 - RECOIL STARTER BODY COMP. TILL E709999 HIT-6693025.A2 6693025	£14.11	£16.93
152A - RECOIL STARTER BODY COMP SINCE E800001 HIT-6697646.A17 6697646	-
153 - STARTER ROPE REEL TILL E709999 HIT-6693007.A8 6693007	£12.57	£15.08
153A - STARTER ROPE REEL SINCE E800001 HIT-6697647.A6 6697647	-
154 - RECOIL SPRING TILL E709999 HIT-6693114.A24 6693114	£9.02	£10.82
154A - RECOIL SPRING SINCE E800001 HIT-6697648.A17 6697648	-
155 - STARTER ROPE TILL E709999 HIT-6693165.A24 6693165	-
155A - STARTER ROPE SINCE E800001 HIT-6697649.A7 6697649	-
156 - STARTER HANDLE CAP TILL E709999 HIT-6693607.A2 6693607	-
157 - STARTER HANDLE TILL E709999 HIT-6693232.A24 6693232	-
157A - STARTER HANDLE SINCE E800001 HIT-6697650.A16 6697650	-
158 - SET SCREW HIT-6693634.A3 6693634	-
159 - STARTER PAWL TILL E709999 HIT-6693302.A4 6693302	£3.89	£4.67
159A - STARTER PAWL SINCE E800001 HIT-6697643.A7 6697643	-
*160 - D4E RETAINING RING TILL E709999 HIT-6685101.A55 6685101	-
*160 - D4E RETAINING RING SINCE E800001 HIT-6685101.A56 6685101	-
161 - SCREW 5X25PS HIT-6695395.A11 6695395	-
162 - STARTER PAWL SPRING TILL E709999 HIT-6693345.A11 6693345	£3.89	£4.67
162A - STARTER PAWL SPRING SINCE E800001 HIT-6697642.A16 6697642	-
163 - STARTER PULLEY TILL E709999 HIT-6693395.A25 6693395	£11.02	£13.22
163A - STARTER PULLEY ASS'Y SINCE E800001 HIT-6697644.A16 6697644	£12.94	£15.53
181 - CLEANER BODY SET TILL E519999 HIT-6699506.A5 6699506	-
181A - CLEANER BODY SINCE E610001 HIT-6697705.A5 6697705	-
182 - COLLAR 5.8 HIT-6692244.A65 6692244	£1.67	£2.00
183 - BLOW OVER CHECK BOARD COMP. HIT-6690848.A6 6690848	-
184 - CLEANER ELEMENT HIT-6690357.A4 6690357	£3.38	£4.06
185 - CLEANER COVER ASS'Y HIT-6690149.A4 6690149	£16.05	£19.26
186 - COVER FIXING BOLT HIT-6690383.A4 6690383	-
187 - SCREW 5X60/S HIT-6695354.A3 6695354	£1.67	£2.00
201 - SCREW FOR EUROPE HIT-6685210.A32 6685210	-
202 - PUMP BODY FOR EUROPE HIT-6691420.A9 6691420	-
203 - PUMP GASKET FOR EUROPE HIT-6691455.A2 6691455	-
204 - PUMP DIAPHRAGM FOR EUROPE HIT-6691446.A8 6691446	-
205 - INLET SCREEN FOR EUROPE HIT-6684700.A211 6684700	-
206 - IDLE ADJUST SPRING FOR EUROPE HIT-6690766.A10 6690766	-
207 - IDLE ADJUST SCREW FOR EUROPE HIT-6690736.A8 6690736	-
208 - NEEDLE VALVE FOR EUROPE HIT-6685215.A24 6685215	£6.79	£8.15
*209 - VALVE SPRING FOR EUROPE HIT-6690874.A3 6690874	-
*209 - VALVE SPRING FOR NZL HIT-6690871.A1 6690871	-
210 - CONTROL LEVER FOR EUROPE HIT-6690819.A11 6690819	-
211 - HINGE PIN FOR EUROPE HIT-6685219.A36 6685219	-
212 - HINGE PIN SET SCREW FOR EUROPE HIT-6685218.A37 6685218	-
213 - DIAPHRAGM GASKET TILL E519999 FOR EUROPE HIT-6690840.A6 6690840	-
213A - DIAPHRAGM GASKET SINCE E610001 FOR EUROPE HIT-6690838.A10 6690838	-
214 - METERING DIAPHRAGM COMP. TILL E519999 FOR EUROPE HIT-6690829.A2 6690829	-
214A - METERING DIAPHRAGM COMP. SINCE E610001 FOR EUROPE HIT-6690828.A10 6690828	-
215 - AIR PURGE COMP. TILL E519999 FOR EUROPE HIT-6690434.A0 6690434	£28.14	£33.77
216 - DIAPHRAGM COVER TILL E519999 FOR EUROPE HIT-6690860.A1 6690860	-
216A - DIAPHRAGM COVER SINCE E610001 FOR EUROPE HIT-6690858.A2 6690858	-
217 - SET SCREW TILL E519999 FOR EUROPE HIT-6691310.A6 6691310	-
217A - SET SCREW SINCE E610001 FOR EUROPE HIT-6685223.A37 6685223	-
218 - DIAPHRAGM GASKET SINCE E610001 FOR NZL HIT-6690838.A11 6690838	-
219 - METERING DIAPHRAGM COMP. SINCE E610001 FOR NZL HIT-6690828.A11 6690828	-
220 - DIAPHRAGM COVER SINCE E610001 FOR NZL HIT-6690858.A3 6690858	-
221 - SET SCREW SINCE E610001 FOR NZL HIT-6685223.A36 6685223	-
231 - SCREW TILL ED79999 FOR RUS HIT-6685210.A34 6685210	-
232 - PUMP BODY TILL ED79999 FOR RUS HIT-6691420.A7 6691420	-
233 - PUMP GASKET TILL ED79999 FOR RUS HIT-6691455.A1 6691455	-
234 - PUMP DIAPHRAGM TILL ED79999 FOR RUS HIT-6691446.A10 6691446	-
235 - INLET SCREEN TILL ED79999 FOR RUS HIT-6684700.A212 6684700	-
236 - IDLE ADJUST SPRING TILL ED79999 FOR RUS HIT-6690766.A12 6690766	-
237 - IDLE ADJUST SCREW TILL ED79999 FOR RUS HIT-6690736.A7 6690736	-
238 - NEEDLE VALVE TILL ED79999 FOR RUS HIT-6685215.A23 6685215	£6.79	£8.15
239 - VALVE SPRING TILL ED79999 FOR RUS HIT-6690874.A4 6690874	-
240 - CONTROL LEVER TILL ED79999 FOR RUS HIT-6690819.A10 6690819	-
241 - HINGE PIN TILL ED79999 FOR RUS HIT-6685219.A35 6685219	-
242 - HINGE PIN SET SCREW TILL ED79999 FOR RUS HIT-6685218.A38 6685218	-
243 - DIAPHRAGM GASKET TILL ED79999 FOR RUS HIT-6690840.A5 6690840	-
244 - METERING DIAPHRAGM COMP. TILL ED79999 FOR RUS HIT-6690829.A3 6690829	-
245 - AIR PURGE COMP. TILL ED79999 FOR RUS HIT-6690434.A1 6690434	£28.14	£33.77
246 - DIAPHRAGM COVER TILL ED79999 FOR RUS HIT-6690860.A2 6690860	-
247 - SET SCREW TILL ED79999 FOR RUS HIT-6691310.A5 6691310	-
251 - SCREW SINCE E180001 FOR RUS HIT-6685210.A33 6685210	-
252 - PUMP BODY SINCE E180001 FOR RUS HIT-6691420.A8 6691420	-
253 - PUMP GASKET SINCE E180001 FOR RUS HIT-6691455.A0 6691455	-
254 - PUMP DIAPHRAGM SINCE E180001 FOR RUS HIT-6691446.A9 6691446	-
255 - INLET SCREEN SINCE E180001 FOR RUS HIT-6684700.A213 6684700	-
256 - IDLE ADJUST SPRING SINCE E180001 FOR RUS HIT-6690766.A11 6690766	-
257 - IDLE ADJUST SCREW SINCE E180001 FOR RUS HIT-6690736.A6 6690736	-
258 - NEEDLE VALVE SINCE E180001 FOR RUS HIT-6685215.A25 6685215	£6.79	£8.15
259 - VALVE SPRING SINCE E180001 FOR RUS HIT-6690871.A2 6690871	-
260 - CONTROL LEVER SINCE E180001 FOR RUS HIT-6690819.A12 6690819	-
261 - HINGE PIN SINCE E180001 FOR RUS HIT-6685219.A37 6685219	-
262 - HINGE PIN SET SCREW SINCE E180001 FOR RUS HIT-6685218.A36 6685218	-
263 - DIAPHRAGM GASKET SINCE E180001 TILL E519999 FOR RUS HIT-6690840.A7 6690840	-
263A - DIAPHRAGM GASKET SINCE E610001 FOR RUS HIT-6690838.A9 6690838	-
264 - METERING DIAPHRAGM COMP. SINCE E180001 TILL E519999 FOR RUS HIT-6690829.A4 6690829	-
264A - METERING DIAPHRAGM COMP. SINCE E610001 FOR RUS HIT-6690828.A9 6690828	-
265 - AIR PURGE COMP. SINCE E180001 TILL E519999 FOR RUS HIT-6690434.A2 6690434	£28.14	£33.77
266 - DIAPHRAGM COVER SINCE E180001 TILL E519999 FOR RUS HIT-6690860.A0 6690860	-
266A - DIAPHRAGM COVER SINCE E610001 FOR RUS HIT-6690858.A4 6690858	-
267 - SET SCREW SINCE E180001 TILL E519999 FOR RUS HIT-6691310.A4 6691310	-
267A - SET SCREW SINCE E610001 FOR RUS HIT-6685223.A35 6685223	-
281 - CLUTCH SHAFT COMP. HIT-6688585.A1 6688585	£31.85	£38.22
282 - BALL BEARING #6202ZZ 1 HIT-6695558.A7 6695558	-
283 - STOP RING C-35 1 HIT-6695296.A15 6695296	-
284 - STOP RING C-15 1 HIT-6695285.A48 6695285	£1.67	£2.00
285 - HEX.HOLE BOLT 6X25 HIT-6695093.A0 6695093	-
286 - FAN CASE OR HIT-6686975.A1 6686975	-
287 - SCREW 6X25/S HIT-6695363.A2 6695363	-
288 - SMALL WASHER 6 SINCE TE540001 HIT-6695183.A22 6695183	-
301 - DRIVE SHAFT 1 HIT-6689476.A0 6689476	£25.99	£31.19
302 - DRIVE SHAFT PIPE HIT-6689403.A1 6689403	-
303 - BUSHING ASS'Y HIT-6689515.A1 6689515	-
304 - KNOB BOLT HIT-6691207.A4 6691207	£8.77	£10.52
305 - HANDLE BRACKET A HIT-6691143.A1 6691143	£9.68	£11.62
306 - HANDLE BRACKET B HIT-6691159.A1 6691159	-
307 - SUPPORT HOLDER HIT-6691237.A1 6691237	-
308 - HANDLE SUPPORT COMP. HIT-6691232.A1 6691232	£31.02	£37.23
309 - SPECIAL NUT M6X1.0 HIT-6689102.A4 6689102	£10.03	£12.04
310 - ANTI-VIBE RUBBER HIT-6689165.A5 6689165	£6.12	£7.35
311 - LOCK NUT 6 UPS-P HIT-6695175.A47 6695175	£1.67	£2.00
312 - HEX. HOLE BOLT 6X30 HIT-6695094.A5 6695094	-
313 - CORD CLAMP HIT-6688016.A5 6688016	-
314 - HANDLE GRIP HIT-6687627.A1 6687627	-
315 - CORD CLAMP HIT-6688025.A1 6688025	-
316 - HANDLE HIT-6691079.A3 6691079	-
331 - PROTECTION TUBU 990L HIT-6687549.A0 6687549	-
332 - THROTTLE LEVER 20 HIT-6693730.A1 6693730	-
333 - TRIGGER LOCK OUT HIT-6684721.A47 6684721	£5.17	£6.20
334 - RETURN SPRING HIT-6684722.A3 6684722	£1.67	£2.00
335 - THROTTLE LEVER HIT-6684723.A19 6684723	-
336 - SCREW M4X20 (BLACK) HIT-6684725.A47 6684725	-
337 - SCREW 5X30 (BLACK) HIT-6684726.A1 6684726	£1.67	£2.00
338 - CONTAL NUT 5 HIT-6684727.A46 6684727	£1.67	£2.00
339 - STOP SWITCH COMP. HIT-6687441.A1 6687441	-
340 - THROTTLE WIRE HIT-6694009.A1 6694009	£12.68	£15.22
341 - THROTTLE WIRE COMP. HIT-6693956.A1 6693956	-
361 - GEAR CASE ASS'Y 1 HIT-6688801.A2 6688801	£145.24	£174.29
362 - HEX. HOLE BOLT M5X25/S HIT-6684709.A16 6684709	£1.67	£2.00
363 - STOP RING C-28 1 HIT-6684741.A30 6684741	-
364 - STOP RING C-12 OUTER HIT-6684664.A8 6684664	-
365 - BALL BEARING #6001Z 1 HIT-6695532.A20 6695532	£15.01	£18.01
366 - BALL BEARING 6001 C3 HIT-6684608.A197 6684608	£5.70	£6.84
367 - GEARCASE 1 HIT-6688703.A7 6688703	-
368 - SPRING WASHER 5 HIT-6684834.A3 6684834	£1.67	£2.00
369 - HEX. SOCKET HD. BOLT M5X12 HIT-6684829.A27 6684829	-
370 - PLUS HEAD BOLT 8X10 HIT-6695437.A12 6695437	-
371 - BALL BEARING #6000 1 HIT-6695524.A43 6695524	-
372 - GEAR SHAFT 6X11X14 HIT-6688942.A5 6688942	-
373A - BALL BEARING #6203DD 1 HIT-6695564.A2 6695564	-
374 - STOP RING C-40 1 HIT-6695298.A1 6695298	-
375 - CUTTER HOLDER HIT-6689022.A6 6689022	-
376 - CUTTER HOLDER CAP.6X11X14 HIT-6689052.A5 6689052	£7.22	£8.66
377 - PROTECTION COVER A COMP. HIT-6688982.A5 6688982	£8.45	£10.14
378 - SCREW 5X16/WS HIT-6695418.A13 6695418	-
379 - CUTTER FIXING NUT 1 HIT-6689072.A10 6689072	£6.61	£7.93
380 - GEAR CASE WASHER HIT-6689157.A7 6689157	-
381 - HEX. HOLE BUTTON BOLT M6X25 HIT-6684714.A136 6684714	£1.67	£2.00
382 - COVER BRACKET 30 HIT-6690312.A1 6690312	-
383 - BLADE GUARD 30 CE TILL E979999 HIT-6690230.A3 6690230	-
383A - BLADE GUARD 30 CE SINCE EO70001 HIT-6690264.A2 6690264	£20.67	£24.80
384 - GUARD HOLDER HIT-6684748.A30 6684748	-
385 - COVER GUARD TILL E979999 HIT-6690372.A30 6690372	£2.81	£3.37
385A - BLADE GUARD SINCE EO70001 HIT-6690376.A26 6690376	£9.34	£11.21
386 - KNIFE TILL E979999 HIT-6693386.A10 6693386	£8.53	£10.24
386A - KNIFE SINCE EO70001 HIT-6684750.A59 6684750	£3.64	£4.37
387 - SCREW 5X12/S TILL E979999 HIT-6695334.A12 6695334	£1.67	£2.00
387A - TAPPING SCREW 4X14 SINCE EO70001 HIT-6684751.A40 6684751	£1.67	£2.00
388 - GEAR-PINION SET 1 HIT-6688866.A2 6688866	-
389 - NUT M5 TILL E979999 HIT-6684965.A31 6684965	£1.67	£2.00
*390 - TAPPING SCREW 5X20 SINCE EO70001 HIT-6684753.A49 6684753	£1.67	£2.00
*390 - TAPPING SCREW 5X20 TILL E819999 HIT-6684753.A50 6684753	£1.67	£2.00
501 - BOX WRENCH (HEX. SOCKET 17/19) HIT-6684764.A92 6684764	£7.64	£9.17
502 - HEX. WRENCH 5 HIT-6693529.A2 6693529	-
503 - HEX. BAR WRENCH 4MM HIT-6684813.A72 6684813	-
504 - BLADE B3/12/3.0 HIT-6695792.A8 6695792	£18.81	£22.57
505 - PROTECTION COVER B HIT-6688994.A3 6688994	£3.85	£4.62
506A - PROTECTIVE GLASSES HIT-875769.A19 875769	-
507 - CUTTER COVER HIT-6692016.A4 6692016	-
508 - SHOULDER HARNESS D5 HIT-6695797.A1 6695797	£38.32	£45.99
601 - NAME PLATE CG47EY(T) HIT-6694145.A0 6694145	-
602 - SYMBOL MARK CG47EY(T) HIT-6694615.A0 6694615	-

Attribute Name	Value
Brand	Hikoki

Reviews Write your own review!

There are currently no reviews of this product.

Fill in the form below to add your review for Hitachi / Hikoki CG47EY Engine Brush Cutter Spare Parts

Your Review
Title Required!
Rating Required!
Your Review Required!
Your Details
Your Name Required!
Your Location Required!
Email Address Required!Invalid email!

United Kingdom (Including N. Ireland)

On orders up to £40.00	Add £4.00 inc VAT (Royal Mail post)
On orders £40.00 to £130.00	Add £7.00 inc VAT (Courier)
On orders over £130.00	FREE (Courier)
