Hitachi / Hikoki CG47EF Engine Brush Cutter Spare Parts

An exploded diagram and spare parts listing for the Hitachi / Hikoki CG47EF Engine Brush Cutter

	Ex VAT	Inc VAT
1 - SPARK PLUG CAP ASS'Y HIT-6687468.A23 6687468	£3.64	£4.37
2 - SPARK PLUG RUBBER COVER TILL E329999 HIT-6688336.A5 6688336	£3.56	£4.27
3 - SPARK PLUG ASS'Y BPMR6A HIT-6699319.A26 6699319	-
4 - CYLINDER SET HIT-6685470.A3 6685470	£85.28	£102.33
5 - HEX.HOLE BOLT M5X18/S HIT-6684586.A9 6684586	-
6 - CYLINDER GASKET HIT-6685738.A1 6685738	£1.67	£2.00
7 - PISTON RING HIT-6686126.A7 6686126	£9.27	£11.12
8 - PISTON SET HIT-6685887.A3 6685887	£35.58	£42.69
9 - PISTON PIN 10X35 HIT-6686019.A10 6686019	£4.12	£4.94
10 - PISTON PIN CIRCLIP HIT-6686026.A17 6686026	£1.67	£2.00
11 - PISTON PIN COLLAR HIT-6685993.A17 6685993	£5.70	£6.84
12 - CRANK SHAFT COMP. HIT-6686190.A1 6686190	£123.58	£148.29
13 - NEEDLE BEARING 1 HIT-6695602.A16 6695602	-
14 - WOOD-RUFF KEY 3X13X5 HIT-6686457.A4 6686457	£1.67	£2.00
31 - SMALL NUT 10 HIT-6695139.A18 6695139	-
32 - CRANK CASE ASS'Y HIT-6686553.A1 6686553	£60.99	£73.19
33 - CRANK CASE GASKET HIT-6686713.A3 6686713	£1.67	£2.00
34 - OIL SEAL UD15257 HIT-6695637.A19 6695637	£3.66	£4.39
35 - BALL BEARING #6202 2 HIT-6695557.A31 6695557	-
36 - CRANK SHAFT WASHER 15.2X22 HIT-6686463.A4 6686463	-
*37 - CRANK SHAFT SHIM 0.20 HIT-6686472.A21 6686472	£1.67	£2.00
*37 - CRANK SHAFT SHIM 0.30 HIT-6686473.A10 6686473	£1.67	£2.00
38 - HEX HOLE BUTTON SCREW 6X45 HIT-6695084.A9 6695084	-
39 - S.WASHER 6 HIT-6684826.A30 6684826	£1.67	£2.00
40 - HEX. SOCKET HD. BOLT (W/BUTTON) M6 HIT-6684825.A3 6684825	£1.67	£2.00
41 - LOCK NUT M6 HIT-6684872.A53 6684872	-
42 - OUTER RECEIVER HIT-6694043.A7 6694043	-
43 - MAGNETO ROTOR COMP. HIT-6687371.A4 6687371	£59.76	£71.71
44 - SMALL WASHER 10 HIT-6695185.A0 6695185	-
45 - NUT 10 HIT-6695138.A13 6695138	-
46 - IGNITION COIL COMP. HIT-6687649.A3 6687649	£38.26	£45.91
47 - SCREW 5X18/S HIT-6695339.A25 6695339	-
48 - SMALL WASHER 5 HIT-6684864.A81 6684864	-
49 - PRIMARY CORD GROMMET HIT-6688049.A8 6688049	-
50 - CORD CLAMP COMP. HIT-6688004.A4 6688004	-
51 - FAN CASE 1 HIT-6686974.A3 6686974	£24.68	£29.61
52 - SCREW 6X20/S HIT-6695361.A0 6695361	-
53 - PRIMARY CORD GROMMET HIT-6688055.A2 6688055	-
55 - EARTH CORD B 180M HIT-6688452.A2 6688452	-
56 - CORD CLAMP COMP. HIT-6688008.A14 6688008	-
57 - STOP CORD COMP. HIT-6687864.A0 6687864	-
71 - FUEL TANK CUSHION RUBBER HIT-6692225.A4 6692225	£1.67	£2.00
72 - INLET MANUFOLD GASKET HIT-6689883.A3 6689883	£1.67	£2.00
73 - CARB. INSULATOR SET HIT-6689950.A3 6689950	-
74 - CARBURETOR GASKET HIT-6689826.A0 6689826	£1.67	£2.00
75 - CARBURETOR SET HDA306 TILL E519999 HIT-6690468.A5 6690468	£104.42	£125.30
75A - CARBURETOR SET HDA180A SINCE E610001 HIT-6697706.A6 6697706	£94.70	£113.64
76 - SCREW 5X24WS HIT-6695423.A1 6695423	-
77 - CHOKE LEVER HIT-6691004.A5 6691004	£2.98	£3.57
78 - FUEL PIPE 2.5X4X90 TILL E519999 HIT-6685267.A14 6685267	£1.67	£2.00
78A - FUEL PIPE 2.5X4X80 SINCE E610001 HIT-6692347.A28 6692347	£1.67	£2.00
79 - SMALL NUT 10 TILL E519999 HIT-6695139.A19 6695139	-
80 - INNER TOOTHED WASHER 10 TILL E519999 HIT-6695235.A0 6695235	-
81 - PRIMING PUMP COMP. TILL E519999 HIT-6690080.A4 6690080	£11.79	£14.15
81A - PRIMING PUMP COMP. SINCE E610001 HIT-6685139.A82 6685139	£10.67	£12.80
82 - FUEL PIPE ASS'Y 3X5X230 HIT-6688166.A15 6688166	£5.17	£6.20
83 - CLIP 1 HIT-6684619.A0 6684619	£1.67	£2.00
84 - PUMP FILTER BODY ASS'Y HIT-6692273.A18 6692273	£9.60	£11.52
85 - FUEL TANK 1 HIT-6691526.A7 6691526	£14.33	£17.20
86 - RETURN GROMMET HIT-6697846.A147 6697846	£2.08	£2.50
87 - TANK CAP D ASS'Y 1 HIT-6691763.A9 6691763	£13.46	£16.15
89 - CUSHION RUBBER HIT-6692193.A3 6692193	£12.50	£15.00
92 - TANK CAP CHAIN HIT-6684625.A12 6684625	-
93 - SWIVEL CAP HIT-6691337.A35 6691337	£1.67	£2.00
111 - MUFFLER PROTECTOR HIT-6692777.A7 6692777	-
112 - SCREW 5X12/PS HIT-6695383.A5 6695383	£1.67	£2.00
113 - HEX.HOLE BOLT M5X12/S HIT-6684667.A14 6684667	£1.67	£2.00
114 - WASHER M5 (BLACK) HIT-6684918.A77 6684918	£1.67	£2.00
115 - HEX. HOLE BUTTON SCREW 6X65 HIT-6695088.A7 6695088	£3.72	£4.46
116 - BOLT WASHER 6 HIT-6684639.A29 6684639	£1.67	£2.00
117 - MUFFLER SET 1 HIT-6692465.A5 6692465	£36.60	£43.92
118 - MUFFLER SPECIAL GASKET HIT-6692883.A20 6692883	-
119 - TAIL PIPE SET PN HIT-6692650.A1 6692650	-
120 - SCREW 4X8/S HIT-6695325.A12 6695325	-
121 - MUFFLER GASKET HIT-6692741.A4 6692741	£3.89	£4.67
122 - HEAT SHIELD HIT-6687242.A3 6687242	£4.81	£5.77
123 - FUEL TANK CUSHION RUBBER HIT-6692227.A3 6692227	£1.67	£2.00
126 - CLUTCH WASHER B HIT-6689645.A28 6689645	£1.67	£2.00
127 - CLUTCH ARM HIT-6688615.A3 6688615	£20.95	£25.14
128 - CLUTCH SPRING HIT-6689429.A7 6689429	£4.26	£5.11
129 - WAVE WASHER 10 HIT-6695203.A9 6695203	£1.67	£2.00
130 - CLUTCH STEP BOLT HIT-6689628.A17 6689628	£3.29	£3.95
131 - CLUTCH SET ASS'Y HIT-6699561.A7 6699561	£25.82	£30.99
132 - TAIL PIPE COMP. HIT-6692593.A4 6692593	-
133 - SCREW 4X12 HIT-6694865.A1 6694865	-
134 - NUT M4 HIT-6685069.A4 6685069	-
151A - RECOIL STARTER BODY ASS'Y HIT-6697645.A21 6697645	£28.11	£33.73
152 - RECOIL STARTER BODY COMP. TILL E700050 HIT-6693025.A13 6693025	£14.11	£16.93
152A - RECOIL STARTER BODY COMP SINCE E800001 HIT-6697646.A2 6697646	-
153 - STARTER ROPE REEL TILL E700050 HIT-6693007.A24 6693007	£12.57	£15.08
153A - STARTER ROPE REEL SINCE E800001 HIT-6697647.A21 6697647	-
154 - RECOIL SPRING TILL E700050 HIT-6693114.A5 6693114	£9.02	£10.82
154A - RECOIL SPRING SINCE E800001 HIT-6697648.A2 6697648	-
155 - STARTER ROPE TILL E700050 HIT-6693165.A3 6693165	-
155A - STARTER ROPE SINCE E800001 HIT-6697649.A21 6697649	-
156 - STARTER HANDLE CAP TILL E700050 HIT-6693607.A12 6693607	-
157 - STARTER HANDLE TILL E700050 HIT-6693232.A6 6693232	-
157A - STARTER HANDLE SINCE E800001 HIT-6697650.A2 6697650	-
158 - SET SCREW HIT-6693634.A19 6693634	-
159 - STARTER PAWL TILL E700050 HIT-6693302.A18 6693302	£3.89	£4.67
159A - STARTER PAWL SINCE E800001 HIT-6697643.A21 6697643	-
*160 - D4E RETAINING RING TILL E700050 HIT-6685101.A99 6685101	-
*160 - D4E RETAINING RING SINCE E800001 HIT-6685101.A100 6685101	-
161 - SCREW 5X25PS HIT-6695395.A3 6695395	-
162 - STARTER PAWL SPRING TILL E700050 HIT-6693345.A17 6693345	£3.89	£4.67
162A - STARTER PAWL SPRING SINCE E800001 HIT-6697642.A2 6697642	-
163 - STARTER PULLEY TILL E700050 HIT-6693395.A9 6693395	£11.02	£13.22
163A - STARTER PULLEY ASS'Y SINCE E800001 HIT-6697644.A2 6697644	£12.94	£15.53
181 - CLEANER BODY SET TILL E519999 HIT-6699506.A3 6699506	-
181A - CLEANER BODY SINCE E610001 HIT-6697705.A0 6697705	-
182 - COLLAR 5.8 HIT-6692244.A16 6692244	£1.67	£2.00
183 - BLOW OVER CHECK BOARD COMP. HIT-6690848.A3 6690848	-
184 - CLEANER ELEMENT HIT-6690357.A3 6690357	£3.38	£4.06
185 - CLEANER COVER ASS'Y HIT-6690149.A3 6690149	£16.05	£19.26
186 - COVER FIXING BOLT HIT-6690383.A3 6690383	-
187 - SCREW 5X60/S HIT-6695354.A17 6695354	£1.67	£2.00
201 - SCREW HIT-6685210.A53 6685210	-
202 - PUMP BODY HIT-6691420.A0 6691420	-
203 - PUMP GASKET HIT-6691455.A8 6691455	-
204 - PUMP DIAPHRAGM HIT-6691446.A1 6691446	-
205 - INLET SCREEN HIT-6684700.A55 6684700	-
206 - IDLE ADJUST SPRING HIT-6690766.A41 6690766	-
207 - IDLE ADJUST SCREW HIT-6690736.A10 6690736	-
208 - NEEDLE VALVE HIT-6685215.A22 6685215	£6.79	£8.15
209 - VALVE SPRING HIT-6690874.A6 6690874	-
210 - CONTROL LEVER HIT-6690819.A14 6690819	-
211 - HINGE PIN HIT-6685219.A34 6685219	-
212 - HINGE PIN SET SCREW HIT-6685218.A39 6685218	-
213 - DIAPHRAGM GASKET TILL E519999 HIT-6690840.A4 6690840	-
213A - DIAPHRAGM GASKET SINCE E610001 HIT-6690838.A12 6690838	-
214 - METERING DIAPHRAGM COMP. TILL E519999 HIT-6690829.A1 6690829	-
214A - METERING DIAPHRAGM COMP. SINCE E610001 HIT-6690828.A12 6690828	-
215 - AIR PURGE COMP. TILL E519999 HIT-6690434.A4 6690434	£28.14	£33.77
216 - DIAPHRAGM COVER TILL E519999 HIT-6690860.A3 6690860	-
216A - DIAPHRAGM COVER SINCE E610001 HIT-6690858.A1 6690858	-
217 - SET SCREW TILL E519999 HIT-6691310.A7 6691310	-
217A - SET SCREW SINCE E610001 HIT-6685223.A38 6685223	-
231 - SHOULDER FRAME COMP HIT-6688276.A1 6688276	-
232 - SHOULDER BELT ASS'Y HIT-6697909.A1 6697909	-
233 - SCREW 5X10/PS HIT-6695380.A2 6695380	-
234 - CUSHION RUBBER COMP. HIT-6689125.A0 6689125	-
235 - FLANGE NUT 6 HIT-6695170.A81 6695170	£1.67	£2.00
236 - BOLT WASHER M8 HIT-6684611.A100 6684611	-
237 - BALL BEARING #6202ZZ 1 HIT-6695558.A6 6695558	-
238 - BEARING HOLDER HIT-6697907.A2 6697907	-
239 - BOLT 5X10/S HIT-6695438.A1 6695438	-
240 - NUT M5 HIT-6684965.A27 6684965	£1.67	£2.00
241 - ENGINE BASE COMP HIT-6688132.A0 6688132	-
242 - SHOULDER PLATE HOLDER B. HIT-6688304.A1 6688304	£2.81	£3.37
243 - BOLT 6X25 HIT-6696295.A2 6696295	-
244 - FLANGE NUT 6 HIT-6695170.A80 6695170	£1.67	£2.00
245 - SCREW 5X16/S HIT-6695338.A1 6695338	-
246 - SCREW 5X18/PS HIT-6695389.A3 6695389	£1.67	£2.00
247 - NYLON LOCK NUT 8 HIT-6695165.A8 6695165	-
248 - ENGINE BASE B ASS'Y HIT-6697935.A2 6697935	-
261 - CLUTCH DRUM COMP HIT-6689232.A1 6689232	-
262 - BALL BEARING #6202ZZ 1 HIT-6695558.A5 6695558	-
263 - STOP RING C-15 1 HIT-6695285.A45 6695285	£1.67	£2.00
264 - CLUTCH CASE HIT-6689216.A2 6689216	-
265 - S.WASHER 6 HIT-6684826.A4 6684826	£1.67	£2.00
266 - HEX. SOCKET HD. BOLT (W/BUTTON) M6X20 HIT-6685064.A19 6685064	-
267 - LOCK PIN COMP. HIT-6689817.A2 6689817	-
268 - PROTECTION TUBE 10X700L HIT-6687586.A1 6687586	-
269 - PROTECTION TUBE 130L HIT-6687521.A0 6687521	£1.67	£2.00
270 - O-RING P-18 FKM HIT-6697780.A7 6697780	-
271 - CORD CLAMP HIT-6688016.A6 6688016	-
272 - FLEXIBLE SHAFT ASS'Y HIT-6689591.A0 6689591	£99.12	£118.95
273 - FLEXIBLE SHAFT COMP. HIT-6689589.A3 6689589	£18.81	£22.57
274 - FLEXIBLE LINNER COMP. 1 HIT-6689554.A0 6689554	-
281 - JOINT PIPE ASS'Y HIT-6688537.A2 6688537	-
282 - HEX. HOLE BOLT M5X25/S HIT-6684709.A13 6684709	£1.67	£2.00
283 - HEX. HOLE BOLT 5X22/S HIT-6695492.A34 6695492	-
284 - SPACER HIT-6689138.A3 6689138	-
285 - SPACER HIT-6684819.A16 6684819	-
286 - CLUTCH WASHER A HIT-6689638.A1 6689638	£1.67	£2.00
287 - HEX. HOLE BOLT 5X10 HIT-6695042.A48 6695042	£1.67	£2.00
288 - HANDLE HIT-6691036.A3 6691036	-
289 - BARRIER BLACK HIT-6691231.A8 6691231	-
290 - BOLT 6X43/P (BLACK) HIT-6684838.A4 6684838	£1.67	£2.00
291 - STOP RING C-10 1 HIT-6684821.A29 6684821	£1.67	£2.00
292 - HEX.NUT 6 HIT-6684835.A44 6684835	£1.67	£2.00
293 - DRIVE SHAFT COMP. HIT-6689346.A2 6689346	-
294 - BUSHING ASS'Y HIT-6689513.A1 6689513	-
295 - DRIVE SHAFT 1 HIT-6689459.A1 6689459	-
296 - CHOKE SHIM 0.8 HIT-6692596.A7 6692596	-
297 - CONNECTOR CASE HIT-6694031.A0 6694031	-
298 - THROTTLE WIRE COMP. HIT-6693885.A1 6693885	-
299 - TAPPING SCREW D4.5X20 HIT-6685191.A15 6685191	-
300 - JOINT COVER HIT-6688550.A1 6688550	-
311 - THROTTLE LEVER ASSY 26 HIT-6693759.A1 6693759	-
312 - THROTTLE WIRE HIT-6694019.A1 6694019	£14.66	£17.59
313 - STOP SWITCH HIT-6687455.A1 6687455	-
314 - TRIGGER LOCK OUT HIT-6684721.A46 6684721	£5.17	£6.20
315 - RETURN SPRING HIT-6693599.A1 6693599	-
316 - BLIND PLUG HIT-6684724.A2 6684724	-
317 - SCREW M5X20 HIT-6684803.A9 6684803	-
318 - CONTAL NUT 5 HIT-6684727.A47 6684727	£1.67	£2.00
319 - SCREW M4X20 (BLACK) HIT-6684725.A48 6684725	-
320 - PROTECTION TUBE 7X130L HIT-6687632.A1 6687632	-
321 - THROTTLE LEVER HIT-6684804.A20 6684804	£6.86	£8.23
331 - GEAR CASE SET PN HIT-6696497.A22 6696497	£60.35	£72.42
332 - HEX. HOLE BOLT M5X25/S HIT-6684709.A17 6684709	£1.67	£2.00
333 - RETAINING RING C-TYPE D26 HIT-6695294.A17 6695294	-
334 - STOP RING OUTER 10 HIT-6695315.A19 6695315	-
335 - BALL BEARING #6000Z 1 HIT-6695526.A18 6695526	-
336 - BALL BEARING #6000 1 HIT-6695524.A44 6695524	-
337 - GEAR CASE 26 DIA HIT-6688770.A15 6688770	-
338 - HEX.HOLE BOLT M5X12/S HIT-6684667.A84 6684667	£1.67	£2.00
339 - OILING BOLT HIT-6689109.A32 6689109	-
340 - BALL BEARING 609 HIT-6684734.A15 6684734	-
341 - GEAR SHAFT HIT-6688924.A24 6688924	-
342 - BALL BEARING 6201D 1 HIT-6695554.A4 6695554	-
343 - STOP RING C-32 1 HIT-6695295.A36 6695295	£1.67	£2.00
344 - CUTTER HOLDER HIT-6689032.A9 6689032	£15.16	£18.19
345 - CUTTER HOLDER CAP HIT-6689055.A24 6689055	£12.10	£14.52
346 - FIXING NUT M10X1.25 HIT-6689073.A0 6689073	£8.32	£9.99
347 - GEAR CASE WASHER HIT-6689159.A0 6689159	-
348 - HEX. HOLE BUTTON BOLT M6X25 HIT-6684714.A137 6684714	£1.67	£2.00
349 - COVER BRACKET 26 HIT-6690315.A19 6690315	-
350 - BLADE GUARD 26CE HIT-6690276.A23 6690276	£20.01	£24.01
351 - GUARD HOLDER HIT-6684748.A28 6684748	-
352 - BLADE GUARD HIT-6690376.A27 6690376	£9.34	£11.21
353 - KNIFE HIT-6684750.A61 6684750	£3.64	£4.37
354 - TAPPING SCREW 4X14 HIT-6684751.A38 6684751	£1.67	£2.00
355 - GEAR/PINION SET 1 HIT-6688875.A21 6688875	-
356 - TAPPING SCREW 5X20 HIT-6684753.A53 6684753	£1.67	£2.00
357 - KNIFE HIT-6684754.A39 6684754	£6.64	£7.97
501 - BOX WRENCH (HEX. SOCKET 17/19) HIT-6684764.A93 6684764	£7.64	£9.17
502 - HEX. BAR WRENCH 4MM HIT-6684813.A73 6684813	-
503 - CUTTER COVER TILL TE249999 HIT-6699555.A4 6699555	-
*503B - CUTTER COVER SINCE TE340001 HIT-6684768.A9 6684768	-
*503B - CUTTER COVER TILL TE049999 HIT-6684768.A10 6684768	-
504A - PROTECTIVE GLASSES HIT-875769.A21 875769	-
505 - BLADE B4/10/1.6 TILL TEO49999 HIT-6695790.A5 6695790	£17.08	£20.49
506 - PROTECTION COVER B TILL TEO49999 HIT-6688995.A12 6688995	£4.81	£5.77
521 - NYLON CORD CUTTER SINCE TEN40001 HIT-6601148.A14 6601148	£25.68	£30.81
522 - CASE SINCE TEN40001 HIT-6601149.A3 6601149	-
523 - NUT SINCE TEN40001 HIT-6601150.A14 6601150	-
524 - REEL SPRING SINCE TEN40001 HIT-6693380.A24 6693380	£6.47	£7.76
525 - LINE HOLDER SINCE TEN40001 HIT-6601151.A3 6601151	-
526 - COVER SINCE TEN40001 HIT-6601152.A14 6601152	-
527 - EYELET SINCE TEN40001 HIT-6684810.A13 6684810	£3.29	£3.95
601 - NAME PLATE CG47EF(L) HIT-6694146.A0 6694146	-
602 - SYMBOL MARK CG47EF(L) HIT-6694616.A0 6694616	£1.67	£2.00

Attribute Name	Value
Brand	Hikoki

Reviews Write your own review!

There are currently no reviews of this product.

Fill in the form below to add your review for Hitachi / Hikoki CG47EF Engine Brush Cutter Spare Parts

Your Review
Title Required!
Rating Required!
Your Review Required!
Your Details
Your Name Required!
Your Location Required!
Email Address Required!Invalid email!

United Kingdom (Including N. Ireland)

On orders up to £40.00	Add £4.00 inc VAT (Royal Mail post)
On orders £40.00 to £130.00	Add £7.00 inc VAT (Courier)
On orders over £130.00	FREE (Courier)

Shopping Basket (0) £0.00

Hitachi / Hikoki CG47EF Engine Brush Cutter Spare Parts

Your Review

Your Details

Carry On Shopping

Try these categories

Recently Viewed

Your Order

About Us

Other Links

Search

Customization

Shopping Basket (0) £0.00

Information

Hitachi / Hikoki CG47EF Engine Brush Cutter Spare Parts

Notify me

Your Review

Your Details

Carry On Shopping

Try these categories

Recently Viewed

Your Order

About Us

Other Links

Search
