Hitachi / Hikoki CG40EYA Engine Grass Trimmer Spare Parts

An exploded diagram and spare parts listing for the Hitachi / Hikoki CG40EYA Engine Grass Trimmer

	Ex VAT	Inc VAT
1 - SPARK PLUG RUBBER COVER HIT-6688336.A12 6688336	£3.56	£4.27
2 - SPARK PLUG CAP ASS'Y HIT-6687479.A0 6687479	-
3A - SPARK PLUG ASS'Y RCJ8Y HIT-6699328.A8 6699328	£5.70	£6.84
4 - CYLINDER SET HIT-6685476.A7 6685476	-
5 - HEX.HOLE BOLT M5X20/S HIT-6684668.A0 6684668	-
6 - CYLINDER GASKET HIT-6685741.A5 6685741	-
7 - PISTON RING HIT-6686123.A14 6686123	-
8 - PISTON SET HIT-6685889.A7 6685889	-
9 - PISTON PIN 10X30 HIT-6686007.A21 6686007	£3.52	£4.23
10 - PISTON PIN CIRCLIP HIT-6686032.A18 6686032	£1.67	£2.00
11 - CRANK SHAFT COMP. HIT-6686192.A5 6686192	-
13 - WOOD-RUFF KEY 3X13X5 HIT-6686457.A23 6686457	£1.67	£2.00
14 - IGNITION COIL COMP. HIT-6687655.A6 6687655	£32.83	£39.40
15 - RUBBER CAP HIT-6684602.A15 6684602	-
16 - HIGH TENSION CORD HIT-6687885.A0 6687885	£1.67	£2.00
17 - IGNITION COIL ASS'Y HIT-6687657.A7 6687657	£33.12	£39.74
18 - LEAD WIRE ASS'Y HIT-6687970.A7 6687970	-
19 - SCREW 4X18/WS HIT-6695406.A0 6695406	-
20 - WASHER T1.6 HIT-6684600.A52 6684600	-
21 - CORD CLAMP COMP. HIT-6688011.A8 6688011	-
41 - CRANK CASE ASS'Y HIT-6686559.A1 6686559	-
42 - CRANK CASE GASKET HIT-6686715.A5 6686715	-
43 - OIL SEAL UD15257 HIT-6695637.A7 6695637	£3.66	£4.39
44 - BALL BEARING #6202 2 HIT-6695557.A7 6695557	-
*45 - CRANK SHAFT SHIM 0.20 HIT-6686472.A16 6686472	£1.67	£2.00
*45 - CRANK SHAFT SHIM 0.30 HIT-6686473.A15 6686473	£1.67	£2.00
46 - HEX. SOCKET HD. BOLT M5X30 S HIT-6684786.A62 6684786	£1.67	£2.00
47 - MAGNETO ROTOR COMP. HIT-6687372.A13 6687372	-
48 - WASHER 10 HIT-6695198.A6 6695198	-
49 - NUT 10 HIT-6695138.A10 6695138	-
50 - SMALL NUT 10 HIT-6695139.A22 6695139	-
81 - INLET MANIFOLD GASKET HIT-6689885.A6 6689885	£2.81	£3.37
82 - CARB.INSULATOR SET 1 HIT-6689955.A6 6689955	£16.19	£19.43
83 - CARBURETOR GASKET HIT-6689833.A13 6689833	£1.67	£2.00
85 - COLLAR HIT-6690802.A3 6690802	£2.81	£3.37
86 - CLEANER BODY COMP. HIT-6690099.A0 6690099	£13.72	£16.47
87 - CHOKE VALVE HIT-6691258.A7 6691258	£3.62	£4.35
88 - BLOW OVER CHECK BOARD HIT-6690843.A32 6690843	£1.67	£2.00
89A - CLEANER ELEMENT 6T HIT-6690352.A10 6690352	£1.67	£2.00
90 - WAVE WASHER 8 HIT-6684658.A23 6684658	£1.67	£2.00
91 - CLEANER COVER ASS'Y HIT-6690397.A10 6690397	£6.61	£7.93
92 - SPECIAL SCREW HIT-6689737.A51 6689737	-
93 - SCREW M5X60 HIT-6684660.A11 6684660	-
94 - S.WASHER 5 HIT-6684662.A43 6684662	£1.67	£2.00
*95 - CARBURETOR SET FOR RUS HIT-6690477.A1 6690477	-
*95 - CARBURETOR SET 1 HIT-6690476.A2 6690476	-
97 - HEX. HOLE BOLT 5X25WS HIT-6695425.A2 6695425	-
98 - TANK FIXING COLLAR HIT-6692182.A5 6692182	-
99 - FUEL PIPE ASS'Y 3X5X230 HIT-6688166.A5 6688166	£5.17	£6.20
100A - CLIP D6 HIT-6685198.A31 6685198	-
101B - PUMP FILTER BODY COMP SINCE TE940001 HIT-66A3864.A24 66A3864	-
102 - TANK WHT HIT-6691539.A2 6691539	-
103 - COLLAR C HIT-6684623.A3 6684623	£1.67	£2.00
104 - TANK CAP ASS'Y HIT-6691714.A6 6691714	£8.44	£10.13
105 - AIR VENT RUBBER CAP HIT-6691369.A4 6691369	-
106 - AIR VENT VALVE ASS'Y HIT-6692172.A12 6692172	-
107 - AIR VENT PIPE HIT-6691394.A3 6691394	-
108 - AIR VENT ASS'Y HIT-6691385.A3 6691385	-
109 - HEX.HOLE BOLT 5X20/PS HIT-6684634.A61 6684634	£1.67	£2.00
110 - ENGINE BED HIT-6694785.A2 6694785	-
111 - FUEL PIPE 3X5X85 HIT-6684880.A28 6684880	-
112 - CLIP 5.5 HIT-6692305.A2 6692305	-
113 - FUEL PIPE GROMMET HIT-6688156.A9 6688156	-
114 - HEX. SOCKET HD. BOLT M5X30 S HIT-6684786.A63 6684786	£1.67	£2.00
115 - WASHER M5 (BLACK) HIT-6684918.A30 6684918	£1.67	£2.00
117 - TANK CAP CHAIN HIT-6684625.A74 6684625	-
118 - PUMP FILTER ASS'Y TILL TE849999 HIT-6601175.A12 6601175	-
131 - MUFFLER PROTECTOR HIT-6692783.A1 6692783	-
132 - HEX.HOLE BOLT M5X12/S HIT-6684667.A110 6684667	£1.67	£2.00
134 - HEX. HOLE BOLT M6X65 HIT-6695067.A33 6695067	£1.67	£2.00
135 - BOLT WASHER 6 HIT-6684639.A155 6684639	£1.67	£2.00
136 - MUFFLER SET 1 HIT-6692473.A1 6692473	-
137 - WASHER M5 (BLACK) HIT-6684918.A32 6684918	£1.67	£2.00
138 - TAIL PIPE HIT-6692652.A1 6692652	-
139 - MACHINE SCREW (W/SP. WASHER) M4X8 HIT-6685109.A17 6685109	-
140 - MUFFLER ARRESTOR HIT-6692696.A7 6692696	-
141 - MUFFLER GASKET HIT-6692741.A16 6692741	£3.89	£4.67
142 - HEAT SHIELD HIT-6687246.A5 6687246	-
144A - GROMMET HIT-6688050.A28 6688050	£1.67	£2.00
145 - HEX. HOLE BOLT M5X25/S HIT-6684709.A50 6684709	£1.67	£2.00
146 - WASHER M5 (BLACK) HIT-6684918.A31 6684918	£1.67	£2.00
147 - CLUTCH WASHER B HIT-6689645.A44 6689645	£1.67	£2.00
148 - CLUTCH ARM COMP. HIT-6688614.A3 6688614	£9.58	£11.50
149 - CLUTCH SPRING HIT-6689428.A9 6689428	£2.98	£3.57
150 - WAVE WASHER 10 HIT-6695203.A26 6695203	£1.67	£2.00
151 - CLUTCH STEP BOLT HIT-6689632.A9 6689632	£4.26	£5.11
152 - CLUTCH SET ASS'Y HIT-6699556.A10 6699556	-
171A - RECOIL STARTER BODY ASS'Y HIT-6697645.A5 6697645	£28.11	£33.73
172 - RECOIL STARTER BODY COMP. TILL E709999 HIT-6693025.A8 6693025	£14.11	£16.93
172A - RECOIL STARTER BODY COMP SINCE E800001 HIT-6697646.A18 6697646	-
173 - STARTER ROPE REEL TILL E709999 HIT-6693007.A5 6693007	£12.57	£15.08
173A - STARTER ROPE REEL SINCE E800001 HIT-6697647.A5 6697647	-
174 - RECOIL SPRING TILL E709999 HIT-6693114.A17 6693114	£9.02	£10.82
174A - RECOIL SPRING SINCE E800001 HIT-6697648.A18 6697648	-
175 - STARTER ROPE TILL E709999 HIT-6693165.A17 6693165	-
175A - STARTER ROPE SINCE E800001 HIT-6697649.A6 6697649	-
176 - STARTER HANDLE CAP TILL E709999 HIT-6693607.A7 6693607	-
177 - STARTER HANDLE TILL E709999 HIT-6693232.A18 6693232	-
177A - STARTER HANDLE SINCE E800001 HIT-6697650.A17 6697650	-
178 - SET SCREW HIT-6693634.A5 6693634	-
179 - STARTER PAWL TILL E709999 HIT-6693302.A9 6693302	£3.89	£4.67
179A - STARTER PAWL SINCE E800001 HIT-6697643.A6 6697643	-
*180 - D4E RETAINING RING TILL E709999 HIT-6685101.A31 6685101	-
*180 - D4E RETAINING RING SINCE E800001 HIT-6685101.A32 6685101	-
181 - HEX.HOLE BOLT 5X20/PS HIT-6684634.A63 6684634	£1.67	£2.00
182 - STARTER PAWL SPRING TILL E709999 HIT-6693345.A6 6693345	£3.89	£4.67
182A - STARTER PAWL SPRING SINCE E800001 HIT-6697642.A17 6697642	-
183 - STARTER PULLEY TILL E709999 HIT-6693395.A20 6693395	£11.02	£13.22
183A - STARTER PULLEY ASS'Y SINCE E800001 HIT-6697644.A17 6697644	£12.94	£15.53
191 - THROTTLE SET SCREW HIT-6684870.A36 6684870	-
192 - CABLE ADJUSTER STAY HIT-6684873.A41 6684873	-
193 - SWIVEL HIT-6684697.A74 6684697	-
194 - THRUST WASHER HIT-6684874.A37 6684874	-
195 - STOP RING HIT-6684696.A112 6684696	-
196 - CABLE ADJUSTER HIT-6684871.A37 6684871	-
197 - O-RING HIT-6684695.A97 6684695	£1.67	£2.00
198 - MAIN JET 1 HIT-6696131.A5 6696131	-
199 - LOCK NUT M6 HIT-6684872.A38 6684872	-
200 - PUMP GASKET HIT-6691457.A64 6691457	£8.48	£10.18
201 - PUMP DIAPHRAGM HIT-6684693.A101 6684693	£5.70	£6.84
202 - INLET SCREEN HIT-6684700.A126 6684700	-
203 - PUMP BODY COMP. HIT-6684879.A36 6684879	£35.37	£42.44
204 - DIAPHRAGM GASKET HIT-6684691.A47 6684691	£5.70	£6.84
205 - METERING DIAPHRAGM COMP. HIT-6690827.A43 6690827	£14.02	£16.83
206 - DIAPHRAGM COVER HIT-6684688.A50 6684688	£5.70	£6.84
207 - SET SCREW HIT-6684699.A52 6684699	-
208 - CLEANER PACKING HIT-6684875.A41 6684875	-
209 - PRIMING PUMP COMP. HIT-6684687.A49 6684687	£9.27	£11.12
*210 - PRIMING BODY HIT-6684689.A49 6684689	£5.87	£7.04
241 - CLUTCH SHAFT COMP. HIT-6688585.A0 6688585	£31.85	£38.22
242 - BALL BEARING #6202ZZ 1 HIT-6695558.A10 6695558	-
243 - STOP RING C-35 1 HIT-6695296.A8 6695296	-
244 - STOP RING C-15 1 HIT-6695285.A38 6695285	£1.67	£2.00
245 - PROTECTOR HIT-6688348.A1 6688348	-
246 - HEX.HOLE BOLT 5X20/PS HIT-6684634.A62 6684634	£1.67	£2.00
247 - HEX.HOLE BOLT 6X25 HIT-6695093.A2 6695093	-
248 - FAN CASE HIT-6686980.A1 6686980	-
249 - HEX.HOLE BOLT M5X20/S HIT-6684668.A1 6684668	-
250 - PRIMARY CORD GROMMET HIT-6688057.A16 6688057	-
251 - WASHER M5 (BLACK) SINCE ED30001 HIT-6685226.A7 6685226	-
271 - DRIVE SHAFT 1 HIT-6689476.A2 6689476	£25.99	£31.19
272 - DRIVE SHAFT PIPE HIT-6689403.A0 6689403	-
273 - BUSHING ASS'Y HIT-6689515.A0 6689515	-
274 - KNOB BOLT HIT-6691207.A3 6691207	£8.77	£10.52
275 - HANDLE BRACKET A HIT-6691143.A0 6691143	£9.68	£11.62
276 - HANDLE BRACKET B HIT-6691159.A2 6691159	-
277 - SUPPORT HOLDER HIT-6691237.A0 6691237	-
278 - HANDLE SUPPORT COMP. HIT-6691232.A0 6691232	£31.02	£37.23
279 - SPECIAL NUT M6X1.0 HIT-6689102.A3 6689102	£10.03	£12.04
280 - ANTI-VIBE RUBBER HIT-6689165.A3 6689165	£6.12	£7.35
281 - LOCK NUT 6 UPS-P HIT-6695175.A41 6695175	£1.67	£2.00
282 - HEX. HOLE BOLT 6X30 HIT-6695094.A3 6695094	-
283 - CORD CLAMP HIT-6688016.A8 6688016	-
284 - HANDLE GRIP HIT-6687627.A0 6687627	-
285 - CORD CLAMP HIT-6688025.A0 6688025	-
286 - HANDLE HIT-6691079.A5 6691079	-
287 - THROTTLE LEVER ASS'Y 22 HIT-6693762.A0 6693762	-
288 - PROTECTION TUBE 1 HIT-6687547.A1 6687547	-
289 - TRIGGER LOCK OUT HIT-6684721.A35 6684721	£5.17	£6.20
290 - RETURN SPRING HIT-6684722.A14 6684722	£1.67	£2.00
291 - THROTTLE LEVER HIT-6684723.A14 6684723	-
293 - SCREW M4X20 (BLACK) HIT-6684725.A37 6684725	-
294 - SCREW 5X30 (BLACK) HIT-6684726.A6 6684726	£1.67	£2.00
295 - CONTAL NUT 5 HIT-6684727.A35 6684727	£1.67	£2.00
296A - STOP SWITCH COMP. HIT-6687458.A2 6687458	-
297 - THROTTLE WIRE 1 HIT-6694021.A2 6694021	£20.95	£25.14
298A - THROTTLE WIRE COMP. HIT-6693975.A2 6693975	£18.81	£22.57
311 - GEAR CASE ASS'Y 1 HIT-6688801.A0 6688801	£145.24	£174.29
312 - HEX. HOLE BOLT M5X25/S HIT-6684709.A51 6684709	£1.67	£2.00
313 - STOP RING C-28 1 HIT-6684741.A21 6684741	-
314 - STOP RING C-12 OUTER HIT-6684664.A18 6684664	£1.67	£2.00
315 - BALL BEARING #6001Z 1 HIT-6695532.A10 6695532	£15.01	£18.01
316 - BALL BEARING 6001 C3 HIT-6684608.A119 6684608	£5.70	£6.84
317 - GEARCASE 1 HIT-6688703.A4 6688703	-
318 - SPRING WASHER 5 HIT-6684834.A13 6684834	£1.67	£2.00
319 - HEX. SOCKET HD. BOLT M5X12 HIT-6684829.A30 6684829	-
320 - PLUS HEAD BOLT 8X10 HIT-6695437.A9 6695437	-
321 - BALL BEARING #6000 1 HIT-6695524.A55 6695524	-
322 - GEAR SHAFT 6X11X14 HIT-6688942.A7 6688942	-
323A - BALL BEARING #6203DD 1 HIT-6695564.A0 6695564	-
324 - STOP RING C-40 1 HIT-6695298.A3 6695298	-
325 - CUTTER HOLDER HIT-6689022.A7 6689022	-
326 - CUTTER HOLDER CAP.6X11X14 HIT-6689052.A7 6689052	£7.22	£8.66
327 - PROTECTION COVER A COMP. HIT-6688982.A7 6688982	£8.45	£10.14
328 - SCREW 5X16/WS HIT-6695418.A8 6695418	-
329 - CUTTER FIXING NUT 1 HIT-6689072.A6 6689072	£6.61	£7.93
330 - GEAR CASE WASHER HIT-6689157.A4 6689157	-
331 - GEAR-PINION SET 1 HIT-6688866.A0 6688866	-
332 - HEX. HOLE BUTTON BOLT M6X25 HIT-6684714.A111 6684714	£1.67	£2.00
333 - COVER BRACKET 30 HIT-6690312.A3 6690312	-
334 - BLADE GUARD 30 CE TILL E979999 HIT-6690230.A0 6690230	-
334A - BLADE GUARD 30 CE SINCE EO70001 HIT-6690264.A0 6690264	£20.67	£24.80
335 - GUARD HOLDER HIT-6684748.A40 6684748	-
336 - COVER GUARD TILL E979999 HIT-6690372.A22 6690372	£2.81	£3.37
336A - BLADE GUARD SINCE EO70001 HIT-6690376.A21 6690376	£9.34	£11.21
337 - KNIFE TILL E979999 HIT-6693386.A7 6693386	£8.53	£10.24
337A - KNIFE SINCE EO70001 HIT-6684750.A87 6684750	£3.64	£4.37
338 - SCREW 5X12/S TILL E979999 HIT-6695334.A0 6695334	£1.67	£2.00
338A - TAPPING SCREW 4X14 SINCE EO70001 HIT-6684751.A2 6684751	£1.67	£2.00
339 - NUT M5 TILL E097999 HIT-6684965.A15 6684965	£1.67	£2.00
*340 - TAPPING SCREW 5X20 SINCE EO70001 HIT-6684753.A22 6684753	£1.67	£2.00
*340 - TAPPING SCREW 5X20 TILL E819999 HIT-6684753.A23 6684753	£1.67	£2.00
*341 - KNIFE SINCE EO70001 HIT-6684754.A60 6684754	£6.64	£7.97
*341 - KNIFE TILL E819999 HIT-6684754.A61 6684754	£6.64	£7.97
342 - GUARD SET MBG-08 FOR NOR HIT-6695794.A0 6695794	-
343 - SAFETY GUARD 1 HIT-6690227.A1 6690227	-
345 - SPECIAL BOLT M5X50 FOR NOR HIT-6689084.A2 6689084	-
346 - SPRING WASHER 5 FOR NOR HIT-6684834.A14 6684834	£1.67	£2.00
347 - NUT M5 (BLACK) FOR NOR HIT-6685075.A7 6685075	-
501 - HEX. BAR WRENCH 4MM HIT-6684813.A62 6684813	-
502 - HEX. WRENCH 5 HIT-6693529.A1 6693529	-
503 - CUTTER COVER HIT-6692016.A11 6692016	-
504 - BOX WRENCH (HEX. SOCKET 17/19) HIT-6684764.A79 6684764	£7.64	£9.17
505A - PROTECTIVE GLASSES HIT-875769.A51 875769	-
506 - BLADE B3/12/3.0 HIT-6695792.A5 6695792	£18.81	£22.57
507 - PROTECTION COVER B HIT-6688994.A0 6688994	£3.85	£4.62
508 - BLADE B24/8/1.6 FOR NOR HIT-6695793.A0 6695793	£19.74	£23.69
509 - CUTTER COVER TILL TE249999 FOR NOR HIT-6699555.A3 6699555	-
509B - CUTTER COVER SINCE TE340001 FOR NOR HIT-6684768.A35 6684768	-
510 - WINDING PROTECTOR COVER FOR NOR HIT-6688986.A0 6688986	-
511 - NYLON HEAD TH-97LM FOR NOR HIT-6695781.A3 6695781	-
512 - CUTTING BODY ASS'Y FOR NOR HIT-6693271.A1 6693271	-
513 - EYELET FOR NOR HIT-6693328.A5 6693328	-
514 - ADJUSTMENT BASE FOR NOR HIT-6693247.A3 6693247	-
515 - SPRING (SILVER) FOR NOR HIT-6693377.A3 6693377	-
516 - ADJUSTMENT WASHER FOR NOR HIT-6693362.A3 6693362	-
517 - CORD REEL BK FOR NOR HIT-6693292.A3 6693292	-
518 - STEEL BALL FOR NOR HIT-6692271.A4 6692271	£1.67	£2.00
519 - REEL SLIDER FOR NOR HIT-6693358.A2 6693358	-
520 - CUTTING BODY CAP FOR NOR HIT-6693338.A5 6693338	-
521 - MOUNTING NUT. L-M10X1.25 FOR NOR HIT-6689098.A1 6689098	-
523 - SHOULDER HARNESS D5 HIT-6695797.A0 6695797	£38.32	£45.99
601 - NAME PLATE CG40EYA(TP) HIT-6694352.A0 6694352	-
602 - SYMBOL MARK HITACHI HIT-6694626.A1 6694626	-
603 - SYMBOL MARK HIT-6694741.A6 6694741	-

Attribute Name	Value
Brand	Hikoki

Reviews Write your own review!

There are currently no reviews of this product.

Fill in the form below to add your review for Hitachi / Hikoki CG40EYA Engine Grass Trimmer Spare Parts

Your Review
Title Required!
Rating Required!
Your Review Required!
Your Details
Your Name Required!
Your Location Required!
Email Address Required!Invalid email!

United Kingdom (Including N. Ireland)

On orders up to £40.00	Add £4.00 inc VAT (Royal Mail post)
On orders £40.00 to £130.00	Add £7.00 inc VAT (Courier)
On orders over £130.00	FREE (Courier)
