Hitachi / Hikoki CG40EY Engine Brush Cutter Spare Parts

An exploded diagram and spare parts listing for the Hitachi / Hikoki CG40EY Engine Brush Cutter

	Ex VAT	Inc VAT
1 - SPARK PLUG CAP ASS'Y HIT-6687468.A24 6687468	£3.64	£4.37
2 - SPARK PLUG ASS'Y BPMR6A HIT-6699319.A27 6699319	-
3 - CYLINDER SET HIT-6685474.A5 6685474	£106.65	£127.98
4 - HEX.HOLE BOLT M5X20/S HIT-6684668.A58 6684668	-
5 - CYLINDER GASKET HIT-6685740.A7 6685740	£2.81	£3.37
6 - PISTON RING HIT-6686123.A4 6686123	-
7 - PISTON SET HIT-6685888.A6 6685888	£34.65	£41.58
8 - PISTON PIN 10X30 HIT-6686007.A8 6686007	£3.52	£4.23
9 - PISTON PIN CIRCLIP HIT-6686032.A1 6686032	£1.67	£2.00
10 - CRANK SHAFT COMP. HIT-6686191.A7 6686191	£121.17	£145.40
11 - WOOD-RUFF KEY 3X13X5 HIT-6686457.A2 6686457	£1.67	£2.00
12 - IGNITION COIL COMP. HIT-6687655.A11 6687655	£32.83	£39.40
13 - RUBBER CAP HIT-6684602.A48 6684602	-
14 - HIGH TENSION CORD HIT-6687885.A11 6687885	£1.67	£2.00
15 - LEAD WIRE ASS'Y HIT-6687970.A4 6687970	-
16 - IGNITION COIL ASS'Y HIT-6687657.A2 6687657	£33.12	£39.74
17 - HEX. HOLE BOLT M4X18/WS HIT-6684599.A73 6684599	-
18 - CORD CLAMP COMP. HIT-6688011.A27 6688011	-
31 - SMALL NUT 10 HIT-6695139.A16 6695139	-
32 - CRANK CASE ASS'Y HIT-6686556.A7 6686556	-
33 - NO LONGER AVAILABLE HIT-6686714.A5 6686714	-
34 - OIL SEAL UD15257 HIT-6695637.A20 6695637	£3.66	£4.39
35 - BALL BEARING #6202 2 HIT-6695557.A30 6695557	-
*36 - CRANK SHAFT SHIM 0.20 HIT-6686472.A23 6686472	£1.67	£2.00
*36 - CRANK SHAFT SHIM 0.30 HIT-6686473.A8 6686473	£1.67	£2.00
37 - HEX. SOCKET HD. BOLT M5X30 S HIT-6684786.A4 6684786	£1.67	£2.00
38 - MAGNETO ROTOR COMP. HIT-6687372.A3 6687372	-
39 - WASHER 10 HIT-6695198.A22 6695198	-
40 - NUT 10 HIT-6695138.A15 6695138	-
61 - INLET MANIFOLD GASKET HIT-6689885.A7 6689885	£2.81	£3.37
62 - CARB.INSULATOR SET 1 HIT-6689955.A8 6689955	£16.19	£19.43
63 - CARBURETOR GASKET HIT-6689833.A4 6689833	£1.67	£2.00
64 - COLLAR HIT-6690430.A0 6690430	-
65 - COLLAR HIT-6690802.A11 6690802	£2.81	£3.37
66 - CLEANER BODY COMP. HIT-6690099.A10 6690099	£13.72	£16.47
67 - CHOKE VALVE HIT-6691258.A2 6691258	£3.62	£4.35
68 - BLOW OVER CHECK BOARD HIT-6690843.A2 6690843	£1.67	£2.00
69 - CLEANER ELEMENT 6T HIT-6690352.A5 6690352	£1.67	£2.00
70 - WAVE WASHER 8 HIT-6684658.A39 6684658	£1.67	£2.00
71 - CLEANER COVER ASS'Y HIT-6690397.A4 6690397	£6.61	£7.93
72 - SPECIAL SCREW HIT-6689737.A10 6689737	-
73 - SCREW 5X57/S HIT-6695353.A13 6695353	£1.67	£2.00
*74 - CARBURETOR SET WYJ389 FOR EUROPE HIT-6690474.A2 6690474	£91.62	£109.95
*74 - CARBURETOR SET WYJ168 FOR RUS HIT-6690470.A1 6690470	£67.33	£80.80
75 - HEX. HOLE BOLT M5X25WS HIT-6695515.A58 6695515	£1.67	£2.00
76 - FUEL PIPE ASS'Y 3X5X230 HIT-6688166.A13 6688166	£5.17	£6.20
77A - CLIP D6 HIT-6685198.A39 6685198	-
78B - PUMP FILTER BODY COMP SINCE TE940001 HIT-66A3864.A57 66A3864	-
79 - TANK HIT-6691533.A0 6691533	£13.82	£16.59
80 - COLLAR C HIT-6684623.A23 6684623	£1.67	£2.00
81 - TANK CAP D ASS'Y 1 HIT-6691763.A8 6691763	£13.46	£16.15
82 - HEX.HOLE BOLT 5X20/PS HIT-6684634.A4 6684634	£1.67	£2.00
83 - FUEL PIPE 3X5X85 HIT-6684880.A43 6684880	-
84 - FUEL PIPE GROMMET HIT-6688156.A22 6688156	-
85 - TANK CAP CHAIN HIT-6684625.A11 6684625	-
86 - ENGINE BED HIT-6694785.A6 6694785	-
87 - WASHER M5 (BLACK) HIT-6684918.A71 6684918	£1.67	£2.00
88 - HEX. HOLE BOLT 5X22/S HIT-6695492.A20 6695492	-
90 - PUMP FILTER ASS'Y TILL TE849999 HIT-6601175.A1 6601175	-
101 - MUFFLER PROTECTOR HIT-6692780.A0 6692780	-
102 - WASHER M5 (BLACK) HIT-6684918.A72 6684918	£1.67	£2.00
103 - HEX.HOLE BOLT M5X12/S HIT-6684667.A16 6684667	£1.67	£2.00
104 - HEX. HOLE BOLT 5X15 WS HIT-6695512.A49 6695512	-
105 - HEX. HOLE BOLT M6X65 HIT-6695067.A3 6695067	£1.67	£2.00
106 - BOLT WASHER 6 HIT-6684639.A31 6684639	£1.67	£2.00
107 - MUFFLER SET P/N HIT-6692468.A0 6692468	-
108 - MUFFLER GASKET HIT-6692741.A3 6692741	£3.89	£4.67
109 - HEAT SHIELD HIT-6687243.A5 6687243	-
113 - CLUTCH WASHER B HIT-6689645.A23 6689645	£1.67	£2.00
114 - CLUTCH ARM COMP. HIT-6688614.A11 6688614	£9.58	£11.50
115 - CLUTCH SPRING HIT-6689428.A3 6689428	£2.98	£3.57
116 - WAVE WASHER 10 HIT-6695203.A7 6695203	£1.67	£2.00
117 - CLUTCH STEP BOLT HIT-6689632.A1 6689632	£4.26	£5.11
118 - CLUTCH SET ASS'Y HIT-6699556.A1 6699556	-
131A - RECOIL STARTER BODY ASS'Y HIT-6697645.A20 6697645	£28.11	£33.73
132 - RECOIL STARTER BODY COMP. TILL E709999 HIT-6693025.A15 6693025	£14.11	£16.93
132A - RECOIL STARTER BODY COMP SINCE E800001 HIT-6697646.A3 6697646	-
133 - STARTER ROPE REEL TILL E709999 HIT-6693007.A22 6693007	£12.57	£15.08
133A - STARTER ROPE REEL SINCE E800001 HIT-6697647.A20 6697647	-
134 - RECOIL SPRING TILL E709999 HIT-6693114.A3 6693114	£9.02	£10.82
134A - RECOIL SPRING SINCE E800001 HIT-6697648.A3 6697648	-
135 - STARTER ROPE TILL E709999 HIT-6693165.A2 6693165	-
135A - STARTER ROPE SINCE E800001 HIT-6697649.A20 6697649	-
136 - STARTER HANDLE CAP TILL E709999 HIT-6693607.A13 6693607	-
137 - STARTER HANDLE TILL E709999 HIT-6693232.A4 6693232	-
137A - STARTER HANDLE SINCE E800001 HIT-6697650.A3 6697650	-
138 - SET SCREW HIT-6693634.A18 6693634	-
139 - STARTER PAWL TILL E709999 HIT-6693302.A17 6693302	£3.89	£4.67
139A - STARTER PAWL SINCE E800001 HIT-6697643.A20 6697643	-
*140 - D4E RETAINING RING TILL E709999 HIT-6685101.A104 6685101	-
*140 - D4E RETAINING RING SINCE E800001 HIT-6685101.A105 6685101	-
141 - HEX.HOLE BOLT 5X20/PS HIT-6684634.A5 6684634	£1.67	£2.00
142 - STARTER PAWL SPRING TILL E709999 HIT-6693345.A18 6693345	£3.89	£4.67
142A - STARTER PAWL SPRING SINCE E800001 HIT-6697642.A3 6697642	-
143 - STARTER PULLEY TILL E709999 HIT-6693395.A8 6693395	£11.02	£13.22
143A - STARTER PULLEY ASS'Y SINCE E800001 HIT-6697644.A3 6697644	£12.94	£15.53
161 - PUMP BODY COMP. HIT-6684879.A22 6684879	£35.37	£42.44
162 - PRIMING PUMP COMP. HIT-6684687.A12 6684687	£9.27	£11.12
163 - DIAPHRAGM COVER HIT-6684688.A88 6684688	£5.70	£6.84
164 - PRIMING BODY HIT-6684689.A11 6684689	£5.87	£7.04
165 - METERING DIAPHRAGM COMP. HIT-6690827.A48 6690827	£14.02	£16.83
166 - DIAPHRAGM GASKET HIT-6684691.A15 6684691	£5.70	£6.84
167 - PUMP DIAPHRAGM HIT-6684693.A38 6684693	£5.70	£6.84
168 - PUMP GASKET HIT-6691457.A22 6691457	£8.48	£10.18
169 - MAIN JET #51 HIT-6696382.A6 6696382	-
170 - O-RING HIT-6684695.A155 6684695	£1.67	£2.00
171 - STOP RING HIT-6684696.A42 6684696	-
172 - SWIVEL HIT-6684697.A123 6684697	-
173 - THROTTLE VALVE COMP. SINCE E180001 FOR RUS HIT-6690944.A3 6690944	-
174 - THROTTLE SET SCREW HIT-6684870.A50 6684870	-
175 - CABLE ADJUSTER STAY HIT-6684873.A29 6684873	-
176 - LOCK NUT M6 HIT-6684872.A52 6684872	-
177 - CABLE ADJUSTER HIT-6684871.A26 6684871	-
178 - CLEANER PACKING HIT-6684875.A29 6684875	-
179 - SET SCREW HIT-6684699.A87 6684699	-
180 - THRUST WASHER HIT-6684874.A51 6684874	-
181 - INLET SCREEN HIT-6684700.A53 6684700	-
201 - CLUTCH SHAFT COMP. HIT-6688585.A3 6688585	£31.85	£38.22
202 - BALL BEARING #6202ZZ 1 HIT-6695558.A1 6695558	-
203 - STOP RING C-35 1 HIT-6695296.A27 6695296	-
204 - STOP RING C-15 1 HIT-6695285.A3 6695285	£1.67	£2.00
205 - SPARK PLUG COVER HIT-6688346.A2 6688346	£5.01	£6.01
206 - HEX.HOLE BOLT 5X20/PS HIT-6684634.A3 6684634	£1.67	£2.00
207 - HEX.HOLE BOLT 6X25 HIT-6695093.A3 6695093	-
208 - FAN CASE HIT-6686980.A2 6686980	-
209 - HEX.HOLE BOLT M5X20/S HIT-6684668.A61 6684668	-
210 - PRIMARY CORD GROMMET HIT-6688057.A22 6688057	-
211 - WASHER M5 (BLACK) SINCE ED30001 HIT-6685226.A22 6685226	-
231 - DRIVE SHAFT 1 HIT-6689476.A3 6689476	£25.99	£31.19
232 - DRIVE SHAFT PIPE HIT-6689403.A4 6689403	-
233 - BUSHING ASS'Y HIT-6689515.A6 6689515	-
234 - KNOB BOLT HIT-6691207.A2 6691207	£8.77	£10.52
235 - HANDLE BRACKET A HIT-6691143.A4 6691143	£9.68	£11.62
236 - HANDLE BRACKET B HIT-6691159.A3 6691159	-
237 - SUPPORT HOLDER HIT-6691237.A4 6691237	-
238 - HANDLE SUPPORT COMP. HIT-6691232.A4 6691232	£31.02	£37.23
239 - SPECIAL NUT M6X1.0 HIT-6689102.A1 6689102	£10.03	£12.04
240 - ANTI-VIBE RUBBER HIT-6689165.A1 6689165	£6.12	£7.35
241 - LOCK NUT 6 UPS-P HIT-6695175.A1 6695175	£1.67	£2.00
242 - HEX. HOLE BOLT 6X30 HIT-6695094.A2 6695094	-
243 - CORD CLAMP HIT-6688016.A3 6688016	-
244 - HANDLE GRIP HIT-6687627.A5 6687627	-
245 - CORD CLAMP HIT-6688025.A4 6688025	-
247 - HANDLE HIT-6691079.A2 6691079	-
301 - THROTTLE LEVER ASS'Y 22 HIT-6693762.A2 6693762	-
302 - PROTECTION TUBE 1 HIT-6687547.A2 6687547	-
303 - TRIGGER LOCK OUT HIT-6684721.A4 6684721	£5.17	£6.20
304 - RETURN SPRING HIT-6684722.A43 6684722	£1.67	£2.00
305 - THROTTLE LEVER HIT-6684723.A1 6684723	-
307 - SCREW M4X20 (BLACK) HIT-6684725.A8 6684725	-
308 - SCREW 5X30 (BLACK) HIT-6684726.A19 6684726	£1.67	£2.00
309 - CONTAL NUT 5 HIT-6684727.A3 6684727	£1.67	£2.00
310 - STOP SWITCH COMP. HIT-6687458.A0 6687458	-
311 - THROTTLE WIRE 1 HIT-6694021.A0 6694021	£20.95	£25.14
312 - THROTTLE WIRE COMP. HIT-6693975.A1 6693975	£18.81	£22.57
331 - GEAR CASE ASS'Y 1 HIT-6688801.A6 6688801	£145.24	£174.29
332 - HEX. HOLE BOLT M5X25/S HIT-6684709.A167 6684709	£1.67	£2.00
333 - STOP RING C-28 1 HIT-6684741.A1 6684741	-
334 - STOP RING C-12 OUTER HIT-6684664.A54 6684664	-
335 - BALL BEARING #6001Z 1 HIT-6695532.A5 6695532	£15.01	£18.01
336 - BALL BEARING 6001 C3 HIT-6684608.A71 6684608	£5.70	£6.84
337 - GEARCASE 1 HIT-6688703.A0 6688703	-
338 - HEX. SOCKET HD. BOLT M5X12 HIT-6684829.A2 6684829	-
339 - PLUS HEAD BOLT 8X10 HIT-6695437.A1 6695437	-
340 - BALL BEARING #6000 1 HIT-6695524.A21 6695524	-
341 - GEAR SHAFT 6X11X14 HIT-6688942.A2 6688942	-
342A - BALL BEARING #6203DD 1 HIT-6695564.A8 6695564	-
343 - STOP RING C-40 1 HIT-6695298.A6 6695298	-
344 - CUTTER HOLDER HIT-6689022.A0 6689022	-
345 - CUTTER HOLDER CAP.6X11X14 HIT-6689052.A2 6689052	£7.22	£8.66
346 - CUTTER FIXING NUT 1 HIT-6689072.A0 6689072	£6.61	£7.93
347 - GEAR CASE WASHER HIT-6689157.A2 6689157	-
349 - PROTECTION COVER A COMP. HIT-6688982.A0 6688982	£8.45	£10.14
350 - SCREW 5X16/WS HIT-6695418.A5 6695418	-
351 - GEAR-PINION SET 1 HIT-6688866.A4 6688866	-
352 - SPRING WASHER 5 HIT-6684834.A56 6684834	£1.67	£2.00
361 - HEX. HOLE BUTTON BOLT M6X25 HIT-6684714.A42 6684714	£1.67	£2.00
362 - COVER BRACKET 30 HIT-6690312.A6 6690312	-
363 - BLADE GUARD 30 CE TILL E979999 HIT-6690230.A4 6690230	-
363A - BLADE GUARD 30 CE SINCE EO70001 HIT-6690264.A4 6690264	£20.67	£24.80
364 - GUARD HOLDER HIT-6684748.A16 6684748	-
365 - COVER GUARD TILL E979999 HIT-6690372.A14 6690372	£2.81	£3.37
365A - BLADE GUARD SINCE EO70001 HIT-6690376.A10 6690376	£9.34	£11.21
366 - KNIFE TILL E979999 HIT-6693386.A23 6693386	£8.53	£10.24
366A - KNIFE SINCE EO70001 HIT-6684750.A29 6684750	£3.64	£4.37
367 - SCREW 5X12/S TILL E979999 HIT-6695334.A21 6695334	£1.67	£2.00
367A - TAPPING SCREW 4X14 SINCE EO70001 HIT-6684751.A72 6684751	£1.67	£2.00
368 - NUT M5 TILL E979999 HIT-6684965.A50 6684965	£1.67	£2.00
*369 - TAPPING SCREW 5X20 SINCE EO70001 HIT-6684753.A66 6684753	£1.67	£2.00
*369 - TAPPING SCREW 5X20 TILL E819999 HIT-6684753.A67 6684753	£1.67	£2.00
*370 - KNIFE SINCE EO70001 HIT-6684754.A25 6684754	£6.64	£7.97
*370 - KNIFE TILL E819999 HIT-6684754.A26 6684754	£6.64	£7.97
501 - BOX WRENCH (HEX. SOCKET 17/19) HIT-6684764.A8 6684764	£7.64	£9.17
502 - HEX. WRENCH 5 HIT-6693529.A6 6693529	-
503 - CUTTER COVER HIT-6692016.A2 6692016	-
504 - BLADE B3/12/3.0 HIT-6695792.A0 6695792	£18.81	£22.57
505 - SHOULDER HARNESS D5 HIT-6695797.A6 6695797	£38.32	£45.99
506A - PROTECTIVE GLASSES HIT-875769.A156 875769	-
507 - HEX. BAR WRENCH 4MM HIT-6684813.A5 6684813	-
511 - PROTECTION COVER B HIT-6688994.A8 6688994	£3.85	£4.62
601 - SYMBOL MARK CG40EY(T) HIT-6694620.A0 6694620	-
602 - NAME PLATE CG40EY(T) HIT-6694151.A0 6694151	-

Attribute Name	Value
Brand	Hikoki

Reviews Write your own review!

There are currently no reviews of this product.

Fill in the form below to add your review for Hitachi / Hikoki CG40EY Engine Brush Cutter Spare Parts

Your Review
Title Required!
Rating Required!
Your Review Required!
Your Details
Your Name Required!
Your Location Required!
Email Address Required!Invalid email!

United Kingdom (Including N. Ireland)

On orders up to £40.00	Add £4.00 inc VAT (Royal Mail post)
On orders £40.00 to £130.00	Add £7.00 inc VAT (Courier)
On orders over £130.00	FREE (Courier)
