Hitachi / Hikoki CG40EK Engine Brush Cutter Spare Parts

An exploded diagram and spare parts listing for the Hitachi / Hikoki CG40EK Engine Brush Cutter

	Ex VAT	Inc VAT
1 - SPARK PLUG RUBBER COVER HIT-6688336.A6 6688336	£3.56	£4.27
2 - SPARK PLUG CAP ASS'Y HIT-6687479.A5 6687479	-
3A - SPARK PLUG ASS'Y RCJ8Y HIT-6699328.A19 6699328	£5.70	£6.84
4 - CYLINDER SET HIT-6685476.A0 6685476	-
5 - HEX.HOLE BOLT M5X20/S HIT-6684668.A60 6684668	-
6 - CYLINDER GASKET HIT-6685741.A0 6685741	-
7 - PISTON RING HIT-6686123.A3 6686123	-
8 - PISTON SET HIT-6685889.A3 6685889	-
9 - PISTON PIN 10X30 HIT-6686007.A7 6686007	£3.52	£4.23
10 - PISTON PIN CIRCLIP HIT-6686032.A2 6686032	£1.67	£2.00
11 - CRANK SHAFT COMP. HIT-6686192.A0 6686192	-
13 - WOOD-RUFF KEY 3X13X5 HIT-6686457.A3 6686457	£1.67	£2.00
14 - IGNITION COIL COMP. HIT-6687655.A10 6687655	£32.83	£39.40
15 - RUBBER CAP HIT-6684602.A47 6684602	-
16 - HIGH TENSION CORD HIT-6687885.A10 6687885	£1.67	£2.00
17 - IGNITION COIL ASS'Y HIT-6687657.A3 6687657	£33.12	£39.74
18 - LEAD WIRE ASS'Y HIT-6687970.A3 6687970	-
19 - SCREW 4X18/WS HIT-6695406.A4 6695406	-
20 - WASHER T1.6 HIT-6684600.A1 6684600	-
21 - CORD CLAMP COMP. HIT-6688011.A28 6688011	-
41 - PROTECTOR HIT-6688348.A2 6688348	-
42 - HEX.HOLE BOLT 5X20/PS HIT-6684634.A8 6684634	£1.67	£2.00
45 - SMALL NUT 10 HIT-6695139.A17 6695139	-
48 - CRANK CASE ASS'Y HIT-6686559.A2 6686559	-
49 - CRANK CASE GASKET HIT-6686715.A0 6686715	-
50 - OIL SEAL UD15257 HIT-6695637.A21 6695637	£3.66	£4.39
51 - BALL BEARING #6202 2 HIT-6695557.A29 6695557	-
*52 - CRANK SHAFT SHIM 0.20 HIT-6686472.A22 6686472	£1.67	£2.00
*52 - CRANK SHAFT SHIM 0.30 HIT-6686473.A9 6686473	£1.67	£2.00
53 - HEX. SOCKET HD. BOLT M5X30 S HIT-6684786.A3 6684786	£1.67	£2.00
54 - MAGNETO ROTOR COMP. HIT-6687372.A4 6687372	-
55 - WASHER 10 HIT-6695198.A21 6695198	-
56 - NUT 10 HIT-6695138.A14 6695138	-
59 - FAN CASE HIT-6686982.A0 6686982	-
60 - HEX.HOLE BOLT M5X20/S HIT-6684668.A59 6684668	-
61 - PRIMARY CORD GROMMET HIT-6688057.A23 6688057	-
62 - WASHER M5 (BLACK) SINCE ED30001 HIT-6685226.A21 6685226	-
81 - INLET MANIFOLD GASKET HIT-6689885.A8 6689885	£2.81	£3.37
82 - CARB.INSULATOR SET 1 HIT-6689955.A7 6689955	£16.19	£19.43
83 - CARBURETOR GASKET HIT-6689833.A3 6689833	£1.67	£2.00
85 - COLLAR HIT-6690802.A10 6690802	£2.81	£3.37
86 - CLEANER BODY COMP. HIT-6690099.A11 6690099	£13.72	£16.47
87 - CHOKE VALVE HIT-6691258.A3 6691258	£3.62	£4.35
88 - BLOW OVER CHECK BOARD HIT-6690843.A1 6690843	£1.67	£2.00
89 - CLEANER ELEMENT 6T HIT-6690352.A6 6690352	£1.67	£2.00
90 - WAVE WASHER 8 HIT-6684658.A40 6684658	£1.67	£2.00
91 - CLEANER COVER ASS'Y HIT-6690397.A3 6690397	£6.61	£7.93
92 - SPECIAL SCREW HIT-6689737.A11 6689737	-
93 - SCREW M5X60 HIT-6684660.A18 6684660	-
94 - S.WASHER 5 HIT-6684662.A64 6684662	£1.67	£2.00
95 - CARBURETOR SET 1 HIT-6690476.A3 6690476	-
97 - HEX. HOLE BOLT 5X25WS HIT-6695425.A4 6695425	-
98 - TANK FIXING COLLAR HIT-6692182.A1 6692182	-
99 - FUEL PIPE ASS'Y 3X5X230 HIT-6688166.A14 6688166	£5.17	£6.20
100A - CLIP D6 HIT-6685198.A38 6685198	-
101B - PUMP FILTER BODY COMP SINCE TE940001 HIT-66A3864.A56 66A3864	-
102 - TANK WHT HIT-6691539.A3 6691539	-
103 - COLLAR C HIT-6684623.A24 6684623	£1.67	£2.00
104 - TANK CAP ASS'Y HIT-6691714.A8 6691714	£8.44	£10.13
105 - AIR VENT RUBBER CAP HIT-6691369.A1 6691369	-
106 - AIR VENT VALVE ASS'Y HIT-6692172.A0 6692172	-
107 - AIR VENT PIPE HIT-6691394.A1 6691394	-
108 - AIR VENT ASS'Y HIT-6691385.A1 6691385	-
109 - HEX.HOLE BOLT 5X20/PS HIT-6684634.A7 6684634	£1.67	£2.00
110 - ENGINE BED HIT-6694785.A7 6694785	-
111 - FUEL PIPE 3X5X85 HIT-6684880.A42 6684880	-
112 - CLIP 5.5 HIT-6692305.A4 6692305	-
113 - FUEL PIPE GROMMET HIT-6688156.A21 6688156	-
114 - HEX. SOCKET HD. BOLT M5X30 S HIT-6684786.A5 6684786	£1.67	£2.00
115 - WASHER M5 (BLACK) HIT-6684918.A68 6684918	£1.67	£2.00
117 - TANK CAP CHAIN HIT-6684625.A10 6684625	-
118 - PUMP FILTER ASS'Y TILL TE849999 HIT-6601175.A2 6601175	-
131 - MUFFLER PROTECTOR HIT-6692783.A2 6692783	-
132 - HEX.HOLE BOLT M5X12/S HIT-6684667.A17 6684667	£1.67	£2.00
134 - HEX. HOLE BOLT M6X65 HIT-6695067.A2 6695067	£1.67	£2.00
135 - BOLT WASHER 6 HIT-6684639.A30 6684639	£1.67	£2.00
136 - MUFFLER SET 1 HIT-6692473.A4 6692473	-
137 - WASHER M5 (BLACK) HIT-6684918.A70 6684918	£1.67	£2.00
138 - TAIL PIPE HIT-6692652.A2 6692652	-
139 - MACHINE SCREW (W/SP. WASHER) M4X8 HIT-6685109.A21 6685109	-
140 - MUFFLER ARRESTOR HIT-6692696.A2 6692696	-
141 - MUFFLER GASKET HIT-6692741.A2 6692741	£3.89	£4.67
142 - HEAT SHIELD HIT-6687246.A0 6687246	-
144A - GROMMET HIT-6688050.A7 6688050	£1.67	£2.00
145 - HEX. HOLE BOLT M5X25/S HIT-6684709.A163 6684709	£1.67	£2.00
146 - WASHER M5 (BLACK) HIT-6684918.A69 6684918	£1.67	£2.00
147 - CLUTCH WASHER B HIT-6689645.A24 6689645	£1.67	£2.00
148 - CLUTCH ARM COMP. HIT-6688614.A10 6688614	£9.58	£11.50
149 - CLUTCH SPRING HIT-6689428.A2 6689428	£2.98	£3.57
150 - WAVE WASHER 10 HIT-6695203.A8 6695203	£1.67	£2.00
151 - CLUTCH STEP BOLT HIT-6689632.A0 6689632	£4.26	£5.11
152 - CLUTCH SET ASS'Y HIT-6699556.A2 6699556	-
171A - RECOIL STARTER BODY ASS'Y HIT-6697645.A19 6697645	£28.11	£33.73
172 - RECOIL STARTER BODY COMP. TILL E709999 HIT-6693025.A14 6693025	£14.11	£16.93
172A - RECOIL STARTER BODY COMP SINCE E800001 HIT-6697646.A4 6697646	-
173 - STARTER ROPE REEL TILL E709999 HIT-6693007.A23 6693007	£12.57	£15.08
173A - STARTER ROPE REEL SINCE E800001 HIT-6697647.A19 6697647	-
174 - RECOIL SPRING TILL E709999 HIT-6693114.A4 6693114	£9.02	£10.82
174A - RECOIL SPRING SINCE E800001 HIT-6697648.A4 6697648	-
175 - STARTER ROPE TILL E709999 HIT-6693165.A1 6693165	-
175A - STARTER ROPE SINCE E800001 HIT-6697649.A19 6697649	-
176 - STARTER HANDLE CAP TILL E709999 HIT-6693607.A14 6693607	-
177 - STARTER HANDLE SINCE E800001 HIT-6693232.A5 6693232	-
177A - STARTER HANDLE TILL E709999 HIT-6697650.A4 6697650	-
178 - SET SCREW HIT-6693634.A17 6693634	-
179 - STARTER PAWL TILL E709999 HIT-6693302.A16 6693302	£3.89	£4.67
179A - STARTER PAWL SINCE E800001 HIT-6697643.A19 6697643	-
*180 - D4E RETAINING RING TILL E709999 HIT-6685101.A102 6685101	-
*180 - D4E RETAINING RING SINCE E800001 HIT-6685101.A103 6685101	-
181 - HEX.HOLE BOLT 5X20/PS HIT-6684634.A6 6684634	£1.67	£2.00
182 - STARTER PAWL SPRING TILL E709999 HIT-6693345.A19 6693345	£3.89	£4.67
182A - STARTER PAWL SPRING SINCE E800001 HIT-6697642.A4 6697642	-
183 - STARTER PULLEY TILL E709999 HIT-6693395.A7 6693395	£11.02	£13.22
183A - STARTER PULLEY ASS'Y SINCE E800001 HIT-6697644.A4 6697644	£12.94	£15.53
191 - THROTTLE SET SCREW HIT-6684870.A49 6684870	-
192 - CABLE ADJUSTER STAY HIT-6684873.A28 6684873	-
193 - SWIVEL HIT-6684697.A122 6684697	-
194 - THRUST WASHER HIT-6684874.A50 6684874	-
195 - STOP RING HIT-6684696.A43 6684696	-
196 - CABLE ADJUSTER HIT-6684871.A24 6684871	-
197 - O-RING HIT-6684695.A154 6684695	£1.67	£2.00
198 - MAIN JET 1 HIT-6696131.A2 6696131	-
199 - LOCK NUT M6 HIT-6684872.A55 6684872	-
200 - PUMP GASKET HIT-6691457.A21 6691457	£8.48	£10.18
201 - PUMP DIAPHRAGM HIT-6684693.A39 6684693	£5.70	£6.84
202 - INLET SCREEN HIT-6684700.A50 6684700	-
203 - PUMP BODY COMP. HIT-6684879.A21 6684879	£35.37	£42.44
204 - DIAPHRAGM GASKET HIT-6684691.A14 6684691	£5.70	£6.84
205 - METERING DIAPHRAGM COMP. HIT-6690827.A49 6690827	£14.02	£16.83
206 - DIAPHRAGM COVER HIT-6684688.A87 6684688	£5.70	£6.84
207 - SET SCREW HIT-6684699.A89 6684699	-
208 - CLEANER PACKING HIT-6684875.A30 6684875	-
209 - PRIMING PUMP COMP. HIT-6684687.A13 6684687	£9.27	£11.12
210 - PRIMING BODY HIT-6684689.A12 6684689	£5.87	£7.04
231 - CLUTCH SHAFT COMP. HIT-6688584.A1 6688584	-
232 - BALL BEARING #6202Z 2 HIT-6695559.A24 6695559	£12.76	£15.31
233 - STOP RING C-15 1 HIT-6695285.A1 6695285	£1.67	£2.00
234 - CLUTCH CASE HIT-6689194.A1 6689194	-
236 - CUSHION RUBBER HIT-6691829.A3 6691829	-
238A - HEX. HOLE BOLT 5X16 HIT-6695046.A30 6695046	£1.67	£2.00
239 - HEX. SOCKET HD. BOLT (W/BUTTON) M6X20 HIT-6685064.A42 6685064	-
240 - HEX HOLE BOLT 5X25 HIT-6695091.A0 6695091	-
242A - PIPE HOLDER HIT-6689655.A2 6689655	-
244 - WASHER M5 (BLACK) HIT-6684918.A67 6684918	£1.67	£2.00
245 - METAL FITTING HIT-6689664.A14 6689664	£6.12	£7.35
261 - DRIVE SHAFT HIT-6689471.A1 6689471	-
262 - MAIN PIPE COMP HIT-6699277.A1 6699277	-
263 - BUSHING ASS'Y HIT-6699278.A4 6699278	-
265 - TAPPING SCREW 5X20 HIT-6695255.A12 6695255	-
266 - BRAKE SHAFT WASHER HIT-6689681.A29 6689681	£1.67	£2.00
267 - HANDLE GRIP HIT-6691098.A26 6691098	£10.90	£13.08
268 - BOLT 6X43/P (BLACK) HIT-6684838.A29 6684838	£1.67	£2.00
269 - LOOP HANDLE BLACK HIT-6691049.A2 6691049	-
270 - BARRIER BLACK HIT-6691231.A2 6691231	-
271 - HEX.NUT 6 HIT-6684835.A4 6684835	£1.67	£2.00
272 - THROTTLE LEVER ASS'Y HIT-6693760.A0 6693760	-
273 - THROTTLE WIRE COMP. HIT-6693973.A0 6693973	-
274 - THROTTLE WIRE HIT-6694020.A1 6694020	-
275 - STOP SWITCH COMP. HIT-6687456.A1 6687456	-
276 - PROTECTION TUBE 200L HIT-6687529.A1 6687529	-
277 - TRIGGER LOCK OUT HIT-6684721.A2 6684721	£5.17	£6.20
278 - RETURN SPRING HIT-6684722.A45 6684722	£1.67	£2.00
279 - BLIND PLUG HIT-6684724.A33 6684724	-
280 - SCREW M5X20 HIT-6684803.A15 6684803	-
281 - CONTAL NUT 5 HIT-6684727.A2 6684727	£1.67	£2.00
282 - SCREW M4X20 (BLACK) HIT-6684725.A4 6684725	-
283 - THROTTLE LEVER HIT-6684804.A15 6684804	£6.86	£8.23
291 - NUT M5 HIT-6684965.A53 6684965	£1.67	£2.00
292 - LIFTING METAL HIT-6689264.A0 6689264	-
293 - HEX. HOLE BOLT M5X16/S HIT-6684903.A66 6684903	-
331 - GEAR CASE ASS'Y 1 HIT-6688813.A0 6688813	-
332 - HEX. HOLE BOLT M5X25/S HIT-6684709.A162 6684709	£1.67	£2.00
333 - STOP RING C-24 1 HIT-6684732.A51 6684732	£1.67	£2.00
334 - STOP RING C-9 1 HIT-6695281.A26 6695281	-
335 - BALL BEARING 609Z ST HIT-6684735.A16 6684735	£15.48	£18.57
336 - BALL BEARING 609 HIT-6684734.A19 6684734	-
337 - GEAR CASE 1 HIT-6688685.A2 6688685	-
338 - HEX. HOLE BOLT 5X10 HIT-6695042.A0 6695042	£1.67	£2.00
339 - PLUS HEAD BOLT 8X10 HIT-6695437.A2 6695437	-
340 - BALL BEARING 628 ST HIT-6695569.A1 6695569	-
341 - GEAR SHAFT HIT-6688947.A1 6688947	-
342 - BALL BEARING 6201D 1 HIT-6695554.A33 6695554	-
343 - STOP RING C-32 1 HIT-6695295.A1 6695295	£1.67	£2.00
344 - CUTTER HOLDER. 12X10X1 HIT-6689031.A0 6689031	-
345 - CUTTER HOLDER CAP. 12X10X1 HIT-6689050.A1 6689050	-
346 - PROTECTION COVER B TILL TEO49999 HIT-6688994.A9 6688994	£3.85	£4.62
347 - CUTTER FIXING NUT 1 HIT-6689072.A1 6689072	£6.61	£7.93
348 - GEAR CASE WASHER HIT-6689159.A27 6689159	-
349 - SPECIAL WASHER 1.0 HIT-6686453.A2 6686453	-
350 - HEX. HOLE BUTTON BOLT M6X25 HIT-6684714.A41 6684714	£1.67	£2.00
351 - COVER BRACKET 26 HIT-6690315.A9 6690315	-
352 - BLADE GUARD 26 CE TILL E979999 HIT-6690242.A7 6690242	£18.84	£22.61
352A - BLADE GUARD 26CE SINCE EO70001 HIT-6690276.A6 6690276	£20.01	£24.01
353 - GUARD HOLDER HIT-6684748.A18 6684748	-
354 - COVER GUARD TILL E979999 HIT-6690372.A16 6690372	£2.81	£3.37
354A - BLADE GUARD SINCE EO70001 HIT-6690376.A8 6690376	£9.34	£11.21
355 - KNIFE TILL E979999 HIT-6693386.A20 6693386	£8.53	£10.24
355A - KNIFE SINCE EO70001 HIT-6684750.A31 6684750	£3.64	£4.37
356 - SCREW 5X12/S TILL E979999 HIT-6695334.A23 6695334	£1.67	£2.00
356A - TAPPING SCREW 4X14 SINCE EO70001 HIT-6684751.A71 6684751	£1.67	£2.00
357 - GEAR-PINION SET 1 HIT-6688868.A0 6688868	£27.94	£33.53
358 - NUT M5 TILL E979999 HIT-6684965.A52 6684965	£1.67	£2.00
*359 - TAPPING SCREW 5X20 SINCE EO70001 HIT-6684753.A71 6684753	£1.67	£2.00
*359 - TAPPING SCREW 5X20 TILL E819999 HIT-6684753.A72 6684753	£1.67	£2.00
*360 - KNIFE SINCE EO70001 HIT-6684754.A20 6684754	£6.64	£7.97
*360 - KNIFE TILL E819999 HIT-6684754.A21 6684754	£6.64	£7.97
501 - BOX WRENCH (HEX. SOCKET 17/19) HIT-6684764.A7 6684764	£7.64	£9.17
502 - HEX. BAR WRENCH 4MM HIT-6684813.A7 6684813	-
503 - CUTTER COVER TILL TE249999 HIT-6699555.A11 6699555	-
*503B - CUTTER COVER SINCE TE340001 HIT-6684768.A58 6684768	-
*503B - CUTTER COVER TILL TE049999 HIT-6684768.A59 6684768	-
504A - PROTECTIVE GLASSES HIT-875769.A153 875769	-
505 - SHOULDER BELT ASS'Y HIT-6692874.A4 6692874	-
506 - BLADE B3/10/2.0 TILL TEO49999 HIT-6695791.A6 6695791	£20.11	£24.13
521 - NYLON CORD CUTTER SINCE TEN40001 HIT-6601148.A7 6601148	£25.68	£30.81
522 - CASE SINCE TEN40001 HIT-6601149.A10 6601149	-
523 - NUT SINCE TEN40001 HIT-6601150.A7 6601150	-
524 - REEL SPRING SINCE TEN40001 HIT-6693380.A11 6693380	£6.47	£7.76
525 - LINE HOLDER SINCE TEN40001 HIT-6601151.A10 6601151	-
526 - COVER SINCE TEN40001 HIT-6601152.A7 6601152	-
527 - EYELET SINCE TEN40001 HIT-6684810.A18 6684810	£3.29	£3.95
601 - NAME PLATE CG40EK(P) HIT-6694160.A0 6694160	-
602 - SYMBOL MARK HITACHI HIT-6694626.A0 6694626	-
603 - SYMBOL MARK HIT-6694741.A2 6694741	-

Attribute Name	Value
Brand	Hikoki

Reviews Write your own review!

There are currently no reviews of this product.

Fill in the form below to add your review for Hitachi / Hikoki CG40EK Engine Brush Cutter Spare Parts

Your Review
Title Required!
Rating Required!
Your Review Required!
Your Details
Your Name Required!
Your Location Required!
Email Address Required!Invalid email!

United Kingdom (Including N. Ireland)

On orders up to £40.00	Add £4.00 inc VAT (Royal Mail post)
On orders £40.00 to £130.00	Add £7.00 inc VAT (Courier)
On orders over £130.00	FREE (Courier)
