Hitachi / Hikoki CG40EF Engine Brush Cutter Spare Parts

An exploded diagram and spare parts listing for the Hitachi / Hikoki CG40EF Engine Brush Cutter

	Ex VAT	Inc VAT
1 - SPARK PLUG CAP ASS'Y HIT-6687468.A3 6687468	£3.64	£4.37
2 - SPARK PLUG ASS'Y BPMR6A HIT-6699319.A40 6699319	-
3 - CYLINDER SET HIT-6685474.A7 6685474	£106.65	£127.98
4 - HEX.HOLE BOLT M5X20/S HIT-6684668.A46 6684668	-
5 - CYLINDER GASKET HIT-6685740.A5 6685740	£2.81	£3.37
6 - PISTON RING HIT-6686123.A1 6686123	-
7 - PISTON SET HIT-6685888.A9 6685888	£34.65	£41.58
8 - PISTON PIN 10X30 HIT-6686007.A1 6686007	£3.52	£4.23
9 - PISTON PIN CIRCLIP HIT-6686032.A10 6686032	£1.67	£2.00
10 - CRANK SHAFT COMP. HIT-6686191.A5 6686191	£121.17	£145.40
11 - WOOD-RUFF KEY 3X13X5 HIT-6686457.A16 6686457	£1.67	£2.00
12 - IGNITION COIL COMP. HIT-6687655.A7 6687655	£32.83	£39.40
13 - RUBBER CAP HIT-6684602.A32 6684602	-
14 - HIGH TENSION CORD HIT-6687885.A8 6687885	£1.67	£2.00
15 - SPECIAL CORD B190M HIT-6687853.A0 6687853	-
16 - IGNITION COIL ASS'Y HIT-6687657.A6 6687657	£33.12	£39.74
17 - HEX. HOLE BOLT M4X18/WS HIT-6684599.A46 6684599	-
18 - CORD CLAMP COMP. HIT-6688011.A22 6688011	-
31 - SMALL NUT 10 HIT-6695139.A4 6695139	-
32 - CRANK CASE ASS'Y HIT-6686556.A6 6686556	-
33 - NO LONGER AVAILABLE HIT-6686714.A6 6686714	-
34 - OIL SEAL UD15257 HIT-6695637.A30 6695637	£3.66	£4.39
35 - BALL BEARING #6202 2 HIT-6695557.A19 6695557	-
*36 - CRANK SHAFT SHIM 0.20 HIT-6686472.A28 6686472	£1.67	£2.00
*36 - CRANK SHAFT SHIM 0.30 HIT-6686473.A3 6686473	£1.67	£2.00
37 - HEX. SOCKET HD. BOLT M5X30 S HIT-6684786.A44 6684786	£1.67	£2.00
38 - MAGNETO ROTOR COMP. HIT-6687372.A0 6687372	-
39 - WASHER 10 HIT-6695198.A15 6695198	-
40 - NUT 10 HIT-6695138.A22 6695138	-
41 - SPARK PLUG COVER HIT-6688346.A0 6688346	£5.01	£6.01
42 - HEX.HOLE BOLT 5X20/PS HIT-6684634.A34 6684634	£1.67	£2.00
43 - FAN CASE HIT-6686982.A2 6686982	-
44 - HEX.HOLE BOLT M5X20/S HIT-6684668.A45 6684668	-
45 - PRIMARY CORD GROMMET HIT-6688057.A36 6688057	-
46 - WASHER M5 (BLACK) SINCE ED30001 HIT-6685226.A17 6685226	-
61 - INLET MANIFOLD GASKET HIT-6689885.A12 6689885	£2.81	£3.37
62 - CARB.INSULATOR SET 1 HIT-6689955.A12 6689955	£16.19	£19.43
63 - CARBURETOR GASKET HIT-6689833.A1 6689833	£1.67	£2.00
65 - COLLAR HIT-6690802.A7 6690802	£2.81	£3.37
66 - CLEANER BODY COMP. HIT-6690099.A8 6690099	£13.72	£16.47
67 - CHOKE VALVE HIT-6691258.A6 6691258	£3.62	£4.35
68 - BLOW OVER CHECK BOARD HIT-6690843.A17 6690843	£1.67	£2.00
69 - CLEANER ELEMENT 6T HIT-6690352.A1 6690352	£1.67	£2.00
70 - WAVE WASHER 8 HIT-6684658.A31 6684658	£1.67	£2.00
71 - CLEANER COVER ASS'Y HIT-6690397.A0 6690397	£6.61	£7.93
72 - SPECIAL SCREW HIT-6689737.A2 6689737	-
73 - SCREW 5X57/S HIT-6695353.A1 6695353	£1.67	£2.00
74 - CARBURETOR SET WYJ389 HIT-6690474.A1 6690474	£91.62	£109.95
75 - HEX. HOLE BOLT M5X25WS HIT-6695515.A36 6695515	£1.67	£2.00
76 - FUEL PIPE ASS'Y 3X5X230 HIT-6688166.A20 6688166	£5.17	£6.20
77A - CLIP D6 HIT-6685198.A64 6685198	-
78B - PUMP FILTER BODY COMP SINCE TE940001 HIT-66A3864.A84 66A3864	-
79 - TANK HIT-6691533.A1 6691533	£13.82	£16.59
80 - COLLAR 5.8 HIT-6692244.A3 6692244	£1.67	£2.00
81 - TANK CAP D ASS'Y 1 HIT-6691763.A15 6691763	£13.46	£16.15
82 - HEX. HOLE BOLT 5X18PS HIT-6695505.A16 6695505	-
83 - FUEL PIPE 3X5X85 HIT-6684880.A50 6684880	-
84 - FUEL PIPE GROMMET HIT-6688156.A11 6688156	-
85 - TANK CAP CHAIN HIT-6684625.A35 6684625	-
90 - PUMP FILTER ASS'Y TILL TE849999 HIT-6601175.A5 6601175	-
101 - MUFFLER PROTECTOR HIT-6692780.A2 6692780	-
102 - WASHER M5 (BLACK) HIT-6684918.A106 6684918	£1.67	£2.00
103 - HEX.HOLE BOLT M5X12/S HIT-6684667.A39 6684667	£1.67	£2.00
104 - HEX. HOLE BOLT 5X15 WS HIT-6695512.A41 6695512	-
105 - HEX. HOLE BOLT M6X65 HIT-6695067.A15 6695067	£1.67	£2.00
106 - BOLT WASHER 6 HIT-6684639.A110 6684639	£1.67	£2.00
107 - MUFFLER SET HIT-6692469.A2 6692469	-
108 - MUFFLER GASKET HIT-6692741.A9 6692741	£3.89	£4.67
109 - HEAT SHIELD HIT-6687243.A7 6687243	-
110 - TAIL PIPE COMP. HIT-6692593.A3 6692593	-
111 - SCREW 4X12 HIT-6694865.A0 6694865	-
112 - NUT M4 HIT-6685069.A11 6685069	-
113 - CLUTCH WASHER B HIT-6689645.A5 6689645	£1.67	£2.00
114 - CLUTCH ARM COMP. HIT-6688614.A13 6688614	£9.58	£11.50
115 - CLUTCH SPRING HIT-6689428.A5 6689428	£2.98	£3.57
116 - WAVE WASHER 10 HIT-6695203.A11 6695203	£1.67	£2.00
117 - CLUTCH STEP BOLT HIT-6689632.A5 6689632	£4.26	£5.11
118 - CLUTCH SET ASS'Y HIT-6699556.A5 6699556	-
131A - RECOIL STARTER BODY ASS'Y HIT-6697645.A14 6697645	£28.11	£33.73
132 - RECOIL STARTER BODY COMP. TILL E709999 HIT-6693025.A25 6693025	£14.11	£16.93
132A - RECOIL STARTER BODY COMP SINCE E800001 HIT-6697646.A9 6697646	-
133 - STARTER ROPE REEL TILL E709999 HIT-6693007.A12 6693007	£12.57	£15.08
133A - STARTER ROPE REEL SINCE E800001 HIT-6697647.A14 6697647	-
134 - RECOIL SPRING TILL E709999 HIT-6693114.A10 6693114	£9.02	£10.82
134A - RECOIL SPRING SINCE E800001 HIT-6697648.A9 6697648	-
135 - STARTER ROPE TILL E709999 HIT-6693165.A13 6693165	-
135A - STARTER ROPE SINCE E800001 HIT-6697649.A14 6697649	-
136 - STARTER HANDLE CAP TILL E709999 HIT-6693607.A22 6693607	-
137 - STARTER HANDLE TILL E709999 HIT-6693232.A13 6693232	-
137A - STARTER HANDLE SINCE E800001 HIT-6697650.A9 6697650	-
138 - SET SCREW HIT-6693634.A27 6693634	-
139 - STARTER PAWL TILL E709999 HIT-6693302.A22 6693302	£3.89	£4.67
139A - STARTER PAWL SINCE E800001 HIT-6697643.A14 6697643	-
*140 - D4E RETAINING RING TILL E709999 HIT-6685101.A137 6685101	-
*140 - D4E RETAINING RING SINCE E800001 HIT-6685101.A138 6685101	-
141 - HEX.HOLE BOLT 5X20/PS HIT-6684634.A35 6684634	£1.67	£2.00
142 - STARTER PAWL SPRING TILL E709999 HIT-6693345.A31 6693345	£3.89	£4.67
142A - STARTER PAWL SPRING SINCE E800001 HIT-6697642.A9 6697642	-
143 - STARTER PULLEY TILL E709999 HIT-6693395.A0 6693395	£11.02	£13.22
143A - STARTER PULLEY ASS'Y SINCE E800001 HIT-6697644.A9 6697644	£12.94	£15.53
161 - PUMP BODY COMP. HIT-6684879.A11 6684879	£35.37	£42.44
162 - PRIMING PUMP COMP. HIT-6684687.A31 6684687	£9.27	£11.12
163 - DIAPHRAGM COVER HIT-6684688.A69 6684688	£5.70	£6.84
164 - PRIMING BODY HIT-6684689.A30 6684689	£5.87	£7.04
165 - METERING DIAPHRAGM COMP. HIT-6690827.A83 6690827	£14.02	£16.83
166 - DIAPHRAGM GASKET HIT-6684691.A24 6684691	£5.70	£6.84
167 - PUMP DIAPHRAGM HIT-6684693.A63 6684693	£5.70	£6.84
168 - PUMP GASKET HIT-6691457.A2 6691457	£8.48	£10.18
169 - MAIN JET #51 HIT-6696382.A7 6696382	-
170 - O-RING HIT-6684695.A131 6684695	£1.67	£2.00
171 - STOP RING HIT-6684696.A66 6684696	-
172 - SWIVEL HIT-6684697.A108 6684697	-
174 - THROTTLE SET SCREW HIT-6684870.A70 6684870	-
175 - CABLE ADJUSTER STAY HIT-6684873.A10 6684873	-
176 - LOCK NUT M6 HIT-6684872.A73 6684872	-
177 - CABLE ADJUSTER HIT-6684871.A7 6684871	-
178 - CLEANER PACKING HIT-6684875.A12 6684875	-
179 - SET SCREW HIT-6684699.A73 6684699	-
180 - THRUST WASHER HIT-6684874.A67 6684874	-
181 - INLET SCREEN HIT-6684700.A90 6684700	-
201 - SHOULDER FRAME COMP HIT-6688276.A3 6688276	-
202 - SHOULDER BELT ASS'Y HIT-6697909.A3 6697909	-
203 - SCREW 5X10/PS HIT-6695380.A3 6695380	-
205 - CUSHION RUBBER COMP. HIT-6689125.A3 6689125	-
206 - FLANGE NUT 6 HIT-6695170.A1 6695170	£1.67	£2.00
207 - BOLT WASHER M8 HIT-6684611.A47 6684611	-
208 - BALL BEARING #6202ZZ 1 HIT-6695558.A2 6695558	-
209 - BEARING HOLDER HIT-6697907.A0 6697907	-
210 - BOLT 5X10/S HIT-6695438.A3 6695438	-
211 - NUT M5 HIT-6684965.A40 6684965	£1.67	£2.00
212 - ENGINE BASE COMP. HIT-6688131.A2 6688131	-
213 - SHOULDER PLATE HOLDER B. HIT-6688304.A3 6688304	£2.81	£3.37
214 - BOLT 6X25 HIT-6696295.A3 6696295	-
215 - FLANGE NUT 6 HIT-6695170.A0 6695170	£1.67	£2.00
216 - HEX.HOLE BOLT M5X20/S HIT-6684668.A44 6684668	-
217 - NYLON LOCK NUT 8 HIT-6695165.A2 6695165	-
218 - ENGINE BASE B ASS'Y HIT-6697935.A0 6697935	-
231 - CLUTCH DRUM COMP HIT-6689232.A0 6689232	-
232 - BALL BEARING #6202ZZ 1 HIT-6695558.A3 6695558	-
233 - STOP RING C-15 1 HIT-6695285.A17 6695285	£1.67	£2.00
234 - CLUTCH CASE HIT-6689216.A0 6689216	-
235 - S.WASHER 6 HIT-6684826.A24 6684826	£1.67	£2.00
236 - HEX. SOCKET HD. BOLT (W/BUTTON) M6X20 HIT-6685064.A29 6685064	-
237 - LOCK PIN COMP. HIT-6689817.A3 6689817	-
238 - PROTECTION TUBE 10X700L HIT-6687586.A3 6687586	-
239 - PROTECTION TUBE 7X130L HIT-6687632.A0 6687632	-
240 - O-RING P-18 FKM HIT-6697780.A16 6697780	-
241 - CORD CLAMP HIT-6688016.A0 6688016	-
242 - FLEXIBLE SHAFT ASS'Y HIT-6689591.A3 6689591	£99.12	£118.95
243 - FLEXIBLE SHAFT COMP. HIT-6689589.A0 6689589	£18.81	£22.57
244 - FLEXIBLE LINNER COMP. 1 HIT-6689554.A3 6689554	-
261 - JOINT PIPE ASS'Y HIT-6688537.A0 6688537	-
262 - HEX. HOLE BOLT M5X25/S HIT-6684709.A124 6684709	£1.67	£2.00
263 - HEX. HOLE BOLT 5X22/S HIT-6695492.A4 6695492	-
264 - SPACER HIT-6689138.A0 6689138	-
265 - SPACER HIT-6684819.A6 6684819	-
266 - CLUTCH WASHER A HIT-6689638.A7 6689638	£1.67	£2.00
267 - HEX. HOLE BOLT 5X10 HIT-6695042.A17 6695042	£1.67	£2.00
268 - PROTECTION TUBE 1 HIT-6687599.A0 6687599	-
269 - HANDLE HIT-6691036.A1 6691036	-
270 - BARRIER BLACK HIT-6691231.A5 6691231	-
271 - BOLT 6X43/P (BLACK) HIT-6684838.A21 6684838	£1.67	£2.00
272 - STOP RING C-10 1 HIT-6684821.A7 6684821	£1.67	£2.00
273 - HEX.NUT 6 HIT-6684835.A23 6684835	£1.67	£2.00
274 - DRIVE SHAFT COMP. HIT-6689346.A0 6689346	-
275 - BUSHING ASS'Y HIT-6689513.A0 6689513	-
276 - DRIVE SHAFT 1 HIT-6689459.A0 6689459	-
277 - CHOKE SHIM 0.8 HIT-6692596.A0 6692596	-
278 - CONNECTOR CASE HIT-6694031.A4 6694031	-
279 - THROTTLE WIRE HIT-6693905.A1 6693905	-
280 - TAPPING SCREW D4.5X20 HIT-6685191.A26 6685191	-
281 - JOINT COVER HIT-6688550.A0 6688550	-
301 - THROTTLE LEVER ASSY 26 HIT-6693759.A3 6693759	-
302 - THROTTLE WIRE HIT-6694019.A0 6694019	£14.66	£17.59
303 - STOP SWITCH HIT-6687455.A0 6687455	-
304 - TRIGGER LOCK OUT HIT-6684721.A21 6684721	£5.17	£6.20
305 - RETURN SPRING HIT-6693599.A0 6693599	-
306 - BLIND PLUG HIT-6684724.A20 6684724	-
307 - SCREW M5X20 HIT-6684803.A29 6684803	-
308 - CONTAL NUT 5 HIT-6684727.A21 6684727	£1.67	£2.00
309 - SCREW M4X20 (BLACK) HIT-6684725.A23 6684725	-
310 - THROTTLE LEVER HIT-6684804.A1 6684804	£6.86	£8.23
331 - GEAR CASE SET PN HIT-6696497.A10 6696497	£60.35	£72.42
332 - HEX. HOLE BOLT M5X25/S HIT-6684709.A125 6684709	£1.67	£2.00
333 - RETAINING RING C-TYPE D26 HIT-6695294.A37 6695294	-
334 - STOP RING OUTER 10 HIT-6695315.A11 6695315	-
335 - BALL BEARING #6000Z 1 HIT-6695526.A3 6695526	-
336 - BALL BEARING #6000 1 HIT-6695524.A10 6695524	-
337 - GEAR CASE 26 DIA HIT-6688770.A5 6688770	-
338 - HEX.HOLE BOLT M5X12/S HIT-6684667.A40 6684667	£1.67	£2.00
339 - OILING BOLT HIT-6689109.A15 6689109	-
340 - BALL BEARING 609 HIT-6684734.A37 6684734	-
341 - GEAR SHAFT HIT-6688924.A13 6688924	-
342 - BALL BEARING 6201D 1 HIT-6695554.A19 6695554	-
343 - STOP RING C-32 1 HIT-6695295.A18 6695295	£1.67	£2.00
344 - CUTTER HOLDER HIT-6689032.A24 6689032	£15.16	£18.19
345 - CUTTER HOLDER CAP HIT-6689055.A7 6689055	£12.10	£14.52
346 - FIXING NUT M10X1.25 HIT-6689073.A23 6689073	£8.32	£9.99
347 - GEAR CASE WASHER HIT-6689159.A47 6689159	-
351 - GEAR/PINION SET 1 HIT-6688875.A7 6688875	-
361 - HEX. HOLE BUTTON BOLT M6X25 HIT-6684714.A26 6684714	£1.67	£2.00
362A - COVER BRACKET 26 HIT-6690315.A4 6690315	-
363 - BLADE GUARD 26 CE TILL E979999 HIT-6690242.A3 6690242	£18.84	£22.61
363A - BLADE GUARD 26CE SINCE EO70001 HIT-6690276.A5 6690276	£20.01	£24.01
364 - GUARD HOLDER HIT-6684748.A6 6684748	-
365 - COVER GUARD TILL E979999 HIT-6690372.A3 6690372	£2.81	£3.37
365A - BLADE GUARD SINCE EO70001 HIT-6690376.A5 6690376	£9.34	£11.21
366 - KNIFE TILL E979999 HIT-6693386.A30 6693386	£8.53	£10.24
366A - KNIFE SINCE EO70001 HIT-6684750.A5 6684750	£3.64	£4.37
367 - SCREW 5X12/S TILL E979999 HIT-6695334.A36 6695334	£1.67	£2.00
367A - TAPPING SCREW 4X14 SINCE EO70001 HIT-6684751.A99 6684751	£1.67	£2.00
368 - NUT M5 TILL E979999 HIT-6684965.A41 6684965	£1.67	£2.00
*369 - TAPPING SCREW 5X20 SINCE EO70001 HIT-6684753.A90 6684753	£1.67	£2.00
*369 - TAPPING SCREW 5X20 TILL E819999 HIT-6684753.A91 6684753	£1.67	£2.00
*370 - KNIFE SINCE EO70001 HIT-6684754.A7 6684754	£6.64	£7.97
*370 - KNIFE TILL E819999 HIT-6684754.A8 6684754	£6.64	£7.97
501 - BOX WRENCH (HEX. SOCKET 17/19) HIT-6684764.A29 6684764	£7.64	£9.17
502 - HEX. BAR WRENCH 4MM HIT-6684813.A30 6684813	-
503 - CUTTER COVER TILL TE249999 HIT-6699555.A8 6699555	-
*503B - CUTTER COVER SINCE TE340001 HIT-6684768.A37 6684768	-
*503B - CUTTER COVER TILL TE049999 HIT-6684768.A38 6684768	-
504 - BLADE B4/10/1.6 TILL TEO49999 HIT-6695790.A0 6695790	£17.08	£20.49
505 - PROTECTION COVER B TILL TEO49999 HIT-6688995.A8 6688995	£4.81	£5.77
506A - PROTECTIVE GLASSES HIT-875769.A120 875769	-
521 - NYLON CORD CUTTER SINCE TEN40001 HIT-6601148.A1 6601148	£25.68	£30.81
522 - CASE SINCE TEN40001 HIT-6601149.A16 6601149	-
523 - NUT SINCE TEN40001 HIT-6601150.A1 6601150	-
524 - REEL SPRING SINCE TEN40001 HIT-6693380.A3 6693380	£6.47	£7.76
525 - LINE HOLDER SINCE TEN40001 HIT-6601151.A16 6601151	-
526 - COVER SINCE TEN40001 HIT-6601152.A1 6601152	-
527 - EYELET SINCE TEN40001 HIT-6684810.A27 6684810	£3.29	£3.95
601 - NAME PLATE CG40EF(L) HIT-6694154.A0 6694154	-
602 - SYMBOL MARK CG40EF(L) HIT-6694623.A0 6694623	-

Attribute Name	Value
Brand	Hikoki

Reviews Write your own review!

There are currently no reviews of this product.

Fill in the form below to add your review for Hitachi / Hikoki CG40EF Engine Brush Cutter Spare Parts

Your Review
Title Required!
Rating Required!
Your Review Required!
Your Details
Your Name Required!
Your Location Required!
Email Address Required!Invalid email!

United Kingdom (Including N. Ireland)

On orders up to £40.00	Add £4.00 inc VAT (Royal Mail post)
On orders £40.00 to £130.00	Add £7.00 inc VAT (Courier)
On orders over £130.00	FREE (Courier)

Shopping Basket (0) £0.00

Hitachi / Hikoki CG40EF Engine Brush Cutter Spare Parts

Your Review

Your Details

Carry On Shopping

Try these categories

Recently Viewed

Your Order

About Us

Other Links

Search

Customization

Shopping Basket (0) £0.00

Information

Hitachi / Hikoki CG40EF Engine Brush Cutter Spare Parts

Notify me

Your Review

Your Details

Carry On Shopping

Try these categories

Recently Viewed

Your Order

About Us

Other Links

Search
