Hitachi / Hikoki CG22EJ2 Engine Grass Trimmer Spare Parts

An exploded diagram and spare parts listing for the Hitachi / Hikoki CG22EJ2 Engine Grass Trimmer

	Ex VAT	Inc VAT
1 - SPARK PLUG CAP ASS'Y TILL E909999 HIT-6687468.A2 6687468	£3.64	£4.37
2 - SPARK PLUG ASS'Y RCJ8Y HIT-6699328.A14 6699328	£5.70	£6.84
3 - CYLINDER SET HIT-6685489.A13 6685489	£62.25	£74.70
4 - HEX.HOLE BOLT M5X18/S HIT-6684586.A35 6684586	-
5 - CYLINDER GASKET HIT-6685709.A0 6685709	£1.67	£2.00
6 - PISTON RING HIT-6686118.A1 6686118	£6.94	£8.33
7 - PISTON ASS'Y HIT-6685869.A6 6685869	£28.00	£33.60
8 - CIR CLIP HIT-6684590.A72 6684590	£1.67	£2.00
9 - PISTON PIN HIT-6696944.A16 6696944	£5.61	£6.73
10 - CRANK SHAFT COMP. HIT-6686217.A8 6686217	£42.70	£51.24
11 - HIGH TENSION CORD 140L TILL E909999 HIT-6687888.A21 6687888	£3.89	£4.67
13 - HEX. HOLE BOLT 4X15/PS HIT-6684682.A26 6684682	£1.67	£2.00
14 - IGNITION COIL ASS'Y TILL E909999 HIT-6699772.A11 6699772	-
14A - IGNITION COIL ASS'Y SINCE EO00001 HIT-6697638.A5 6697638	-
15 - RUBBER CAP TILL E909999 HIT-6684602.A33 6684602	-
16 - LEAD WIRE ASS'Y HIT-6697836.A9 6697836	-
*31 - GEAR SHAFT SHIM 0.20 HIT-6684604.A27 6684604	-
*31 - GEAR SHAFT SHIM 0.30 HIT-6684605.A54 6684605	-
32 - CRANK CASE ASS'Y HIT-6686585.A5 6686585	£78.55	£94.26
33 - OIL SEAL TB 12227 HIT-6684607.A155 6684607	£4.07	£4.88
34 - BALL BEARING 6001 C3 HIT-6684608.A50 6684608	£5.70	£6.84
35 - CRANK CASE GASKET HIT-6686719.A13 6686719	£1.67	£2.00
36 - HEX.HOLE BOLT M5X18/S HIT-6684586.A36 6684586	-
37 - MAGNETO ASS'Y TILL E909999 HIT-6601171.A12 6601171	-
37A - MAGNETO ROTOR COMP. SINCE EO00001 HIT-6696928.A21 6696928	£50.30	£60.36
38 - BOLT WASHER M8 HIT-6684611.A46 6684611	-
39 - HEX. NUT M8 HIT-6684612.A81 6684612	-
51 - INLET MANIFOLD GASKET HIT-6689890.A5 6689890	£1.67	£2.00
52 - CARB INSULATOR SET HIT-6689914.A13 6689914	£8.34	£10.01
53 - CARBURETOR GASKET HIT-6684615.A13 6684615	£1.67	£2.00
54 - HEX.HOLE BOLT 5X22/WS HIT-6695514.A10 6695514	-
55 - SCREW 5X60/S HIT-6695354.A23 6695354	£1.67	£2.00
56 - WASHER 5 HIT-6684661.A61 6684661	£1.67	£2.00
57 - SHIELD TUBE HIT-6688174.A9 6688174	£3.85	£4.62
58 - CLIP D6 HIT-6685198.A8 6685198	-
59A - PUMP FILTER BODY COMP HIT-66A3864.A36 66A3864	-
60 - TANK 1 HIT-6691592.A6 6691592	£11.38	£13.66
61 - TANK CAP ASS'Y HIT-6685049.A31 6685049	£9.94	£11.93
62 - COLLAR 5.8 TILL E809999 HIT-6692244.A67 6692244	£1.67	£2.00
63 - CARBURETOR SET WYL182 HIT-6690512.A3 6690512	£69.17	£83.00
65 - HEX. HOLE BOLT 5X16/PS TILL E809999 HIT-6695504.A0 6695504	£1.67	£2.00
65A - BOLT (W/FLANGE) L17.8 SINCE E900001 HIT-6696574.A23 6696574	£1.67	£2.00
66 - SCREW 5X20WS TILL E809999 HIT-6695516.A10 6695516	-
66A - BOLT (W/FLANGE) L17.8 SINCE E900001 HIT-6696574.A22 6696574	£1.67	£2.00
67 - TANK CAP CHAIN HIT-6684625.A91 6684625	-
68 - FUEL PIPE 3X5X85 HIT-6684880.A14 6684880	£1.67	£2.00
69 - RETURN GROMMET HIT-6684627.A67 6684627	£1.67	£2.00
70 - SWIVEL CAP HIT-6691337.A63 6691337	£1.67	£2.00
91 - MUFFLER PROTECTOR BLACK HIT-6692809.A2 6692809	£8.45	£10.14
92 - SCREW 4X15PS HIT-6695373.A8 6695373	-
94 - TAPPING SCREW D4.5X12 HIT-6684637.A21 6684637	£1.67	£2.00
95 - HEX. SOCKET HD. BOLT M5X50 HIT-6685114.A22 6685114	£1.67	£2.00
96 - WASHER M5 (BLACK) HIT-6684918.A2 6684918	£1.67	£2.00
98 - MUFFLER SET HIT-6692487.A5 6692487	£29.28	£35.14
100 - MUFFLER GASKET HIT-6692745.A9 6692745	-
101 - HEAT SHIELD HIT-6687253.A9 6687253	£2.81	£3.37
103 - CLUTCH WASHER B HIT-6697619.A3 6697619	£1.67	£2.00
104 - CLUTCH SHOE COMP. 2 HIT-6688616.A9 6688616	£12.82	£15.38
104A - CLUTCH ARM COMP 54 SINCE E790001 HIT-6697161.A13 6697161	-
105 - CLUTCH SPRING TILL E699999 HIT-6689430.A14 6689430	£3.89	£4.67
105A - CLUTCH SPRING SINCE E790001 HIT-6697618.A9 6697618	-
106 - CLUTCH PLATE (A) HIT-6689528.A13 6689528	£1.67	£2.00
107 - STEP BOLT TILL E699999 HIT-6689627.A38 6689627	£1.67	£2.00
107A - STEP BOLT SINCE E790001 HIT-6684646.A4 6684646	£3.72	£4.46
108 - BENT WASHER 8 HIT-6684648.A7 6684648	£1.67	£2.00
109 - CLUTCH SET ASSY TILL E699999 HIT-6688484.A2 6688484	-
109A - CLUTCH ASS'Y SINCE E790001 HIT-6696932.A13 6696932	-
110 - HEX. HOLE BOLT M5X18/WS HIT-6684647.A27 6684647	£1.67	£2.00
112 - HEX.HOLE BOLT M5X30/WS HIT-6684973.A1 6684973	-
113 - CORD CLAMP COMP. HIT-6688011.A14 6688011	-
131 - RECOIL STARTER BODY ASS'Y TILL ED70100 HIT-6692988.A2 6692988	£53.19	£63.83
132 - STARTER HANDLE TILL ED70100 HIT-6693240.A18 6693240	£16.35	£19.62
133 - RECOIL STARTER BODY COMP. TILL ED70100 HIT-6693039.A3 6693039	-
134 - ROPE 2.6X830 TILL ED70100 HIT-6693175.A6 6693175	-
135 - RECOIL SPRING TILL ED70100 HIT-6693139.A2 6693139	-
136 - SPRING CASE ASS'Y TILL ED70100 HIT-6693102.A7 6693102	-
137 - STARTER ROPE REEL TILL ED70100 HIT-6693080.A4 6693080	-
138 - SPECIAL WASHER 5.2X15 TILL ED70100 HIT-6687947.A13 6687947	-
139 - TAPPING SCREW D5X14 TILL ED70100 HIT-6685275.A30 6685275	-
140 - HEX. HOLE BOLT 4X18WS TILL ED70100 HIT-6695508.A14 6695508	£1.67	£2.00
141 - STARTER PULLEY ASS'Y TILL ED70100 HIT-6693408.A7 6693408	£35.37	£42.44
142 - FLUNGE NUT 5 TILL ED70100 HIT-6695169.A0 6695169	£1.67	£2.00
171B - RECOIL STARTER BODY ASS'Y INCLUD.173-179 SINCE E180001 HIT-6601570.A55 6601570	£23.15	£27.78
173 - STARTER ROPE 3.5X860 SINCE E180001 HIT-6684674.A11 6684674	£5.70	£6.84
174 - RECOIL SPRING SINCE E180001 HIT-6684675.A130 6684675	£8.82	£10.58
175A - STARTER ROPE REEL SINCE TE540001 HIT-6699997.A80 6699997	-
176 - DAMPER SPRING SINCE E180001 HIT-6684677.A16 6684677	£5.70	£6.84
177A - CAM PLATE SINCE TE540001 HIT-6699996.A9 6699996	£4.28	£5.13
178 - SET SCREW SINCE E180001 HIT-6684679.A26 6684679	£2.98	£3.57
179 - STARTER HANDLE SINCE E180001 HIT-6684680.A95 6684680	£5.87	£7.04
180 - STARTER PULLEY ASS'Y SINCE E180001 HIT-6684681.A19 6684681	£18.16	£21.79
181 - HEX. HOLE BOLT 4X18WS TILL ED70100 HIT-6695508.A13 6695508	£1.67	£2.00
182 - STOP RING E-5 SINCE E180001 HIT-6684683.A3 6684683	-
183 - STARTER PAWL SPRING SINCE E180001 HIT-6684684.A92 6684684	£3.29	£3.95
184 - STARTER PAWL SINCE E180001 HIT-6684685.A25 6684685	£5.07	£6.08
*185 - CAMPLATE ASS'Y SINCE E180001 HIT-6699691.A8 6699691	£7.75	£9.30
*185 - CAMPLATE ASS'Y TILL TE449999 HIT-6699691.A9 6699691	£7.75	£9.30
231 - CLEANER ASSY HIT-6690048.A13 6690048	£11.61	£13.93
232 - CLEANER COVER SET HIT-6690391.A0 6690391	£7.48	£8.97
233 - AIR CLEANER ELEMENT HIT-6684654.A3 6684654	£1.67	£2.00
234 - SPECIAL SCREW HIT-6689737.A24 6689737	-
235 - CLEANER BODY COMP. HIT-6684656.A0 6684656	£7.64	£9.17
236 - CHOKE VALVE HIT-6684657.A14 6684657	£2.81	£3.37
237 - WAVE WASHER 8 HIT-6684658.A2 6684658	£1.67	£2.00
238 - COLLAR 8 HIT-6684659.A14 6684659	-
281 - PUMP BODY COMP. HIT-6684879.A58 6684879	£35.37	£42.44
282 - PRIMING PUMP COMP. HIT-6684687.A81 6684687	£9.27	£11.12
283 - DIAPHRAGM COVER HIT-6684688.A18 6684688	£5.70	£6.84
284 - PRIMING BODY HIT-6684689.A82 6684689	£5.87	£7.04
285 - METERING DIAPHRAGM COMP. HIT-6690830.A51 6690830	£14.58	£17.50
286 - DIAPHRAGM GASKET HIT-6684691.A79 6684691	£5.70	£6.84
287 - PUMP DIAPHRAGM HIT-6684693.A160 6684693	£5.70	£6.84
288 - PUMP GASKET HIT-6691457.A76 6691457	£8.48	£10.18
289 - MAIN JET #38 HIT-6691844.A8 6691844	-
290 - O-RING HIT-6684695.A42 6684695	£1.67	£2.00
291 - STOP RING HIT-6684696.A174 6684696	-
292 - SWIVEL HIT-6684697.A31 6684697	-
293 - THROTTLE SET SCREW HIT-6684698.A55 6684698	-
294 - SET SCREW HIT-6684699.A11 6684699	-
295 - INLET SCREEN HIT-6684700.A221 6684700	-
301 - CLUTCH SHAFT COMP. HIT-6695969.A0 6695969	£16.69	£20.03
302 - STOP RING C-12 OUTER HIT-6684664.A7 6684664	£1.67	£2.00
303 - ANTI-VIBE RUBBER HIT-6691839.A2 6691839	£5.92	£7.11
304 - HEX. HOLE BOLT 5X16 HIT-6695046.A3 6695046	£1.67	£2.00
305 - HEX. HOLE BOLT M5X25/S HIT-6684709.A21 6684709	£1.67	£2.00
306 - FAN CASE 1 HIT-6687029.A12 6687029	£26.97	£32.36
307 - PIPE HOLDER 1 HIT-6689651.A8 6689651	£8.88	£10.66
308 - WASHER M5 (BLACK) HIT-6684918.A3 6684918	£1.67	£2.00
309 - GEAR CASE WASHER HIT-6689159.A4 6689159	-
310 - METAL FITTING HIT-6689664.A22 6689664	£6.12	£7.35
321 - DRIVE SHAFT 1480L HIT-6696009.A9 6696009	£16.15	£19.38
322 - DRIVE SHAFT PIPE COMP.1450L HIT-6689410.A3 6689410	£27.59	£33.11
323 - BUSH ASS'Y HIT-6684831.A28 6684831	-
324 - HEX.NUT 6 HIT-6684835.A46 6684835	£1.67	£2.00
325 - HANDLE HIT-6684836.A1 6684836	£8.85	£10.62
326 - BARRIER(BLACK) HIT-6684837.A4 6684837	£5.17	£6.20
327 - BOLT 6X43/P (BLACK) HIT-6684838.A1 6684838	£1.67	£2.00
328 - HANGER COLLAR HIT-6689260.A3 6689260	-
329 - HANGER HIT-6689281.A3 6689281	-
330 - HANGER FIXING BRACKET HIT-6689294.A5 6689294	-
331 - MACHINE SCREW (W/WASHERS) M5X25 (BLACK) HIT-6696988.A0 6696988	-
332 - THROTTLE LEVER ASS'Y HIT-6693769.A1 6693769	-
333 - THROTTLE WIRE COMP. HIT-6693982.A5 6693982	£36.27	£43.52
334 - THROTTLE WIRE 4T HIT-6694025.A8 6694025	£14.47	£17.36
335 - STOP BUTTON COMP. HIT-6687452.A4 6687452	£28.71	£34.45
336 - PROTECTION TUBE 7X145L HIT-6687523.A0 6687523	-
337 - TRIGGER LOCK OUT HIT-6684721.A51 6684721	£5.17	£6.20
338 - RETURN SPRING HIT-6684722.A0 6684722	£1.67	£2.00
339 - BLIND PLUG HIT-6684724.A0 6684724	-
340 - SCREW M5X20 HIT-6684803.A13 6684803	-
341 - CONTAL NUT 5 HIT-6684727.A51 6684727	£1.67	£2.00
342 - SCREW M4X20 (BLACK) HIT-6684725.A49 6684725	-
343 - THROTTLE LEVER HIT-6684804.A17 6684804	£6.86	£8.23
351 - GEAR CASE ASS'Y 24 HIT-6688817.A3 6688817	£76.90	£92.28
352 - HEX. HOLE BOLT M5X25/S HIT-6684709.A22 6684709	£1.67	£2.00
353 - STOP RING C-24 1 HIT-6684732.A12 6684732	£1.67	£2.00
354 - STOP RING C-9 1 HIT-6695281.A2 6695281	-
355 - BALL BEARING 609Z ST HIT-6684735.A20 6684735	£15.48	£18.57
356 - GEAR CASE 24 HIT-6688815.A5 6688815	-
357 - SCREW 5X12/W.S HIT-6695414.A7 6695414	£1.67	£2.00
358 - OILING BOLT HIT-6689109.A31 6689109	-
359 - BALL BEARING 626 1 HIT-6695567.A6 6695567	-
360 - GEAR SHAFT HIT-6688948.A5 6688948	-
361 - BALL BEARING 6000D 1 HIT-6695527.A5 6695527	£12.50	£15.00
362 - RETAINING RING C-TYPE D26 HIT-6695294.A15 6695294	-
363 - CUTTER HOLDER HIT-6689033.A6 6689033	£11.61	£13.93
364 - CUTTER HOLDER CAP HIT-6689056.A0 6689056	£4.65	£5.58
365 - PROTECTION COVER HIT-6688996.A1 6688996	£5.87	£7.04
366 - FIXING NUT L/H HIT-6689075.A7 6689075	£1.67	£2.00
367 - GEAR CASE COVER HIT-6688917.A6 6688917	£1.67	£2.00
368 - SCREW 5X12/W.S HIT-6695414.A6 6695414	£1.67	£2.00
369 - GEAR/PINION SET HIT-6688883.A3 6688883	£24.88	£29.85
380 - HEX. HOLE BUTTON BOLT M6X25 HIT-6684714.A131 6684714	£1.67	£2.00
381 - COVER BRACKET 24 TILL E979999 HIT-6690317.A3 6690317	-
381A - COVER BRACKET SINCE EO70001 HIT-6690318.A3 6690318	£6.52	£7.82
382 - BLADE GUARD 26 CE TILL E979999 HIT-6690242.A19 6690242	£18.84	£22.61
382A - BLADE GUARD 24 CE SINCE EO70001 HIT-6684747.A1 6684747	-
383 - GUARD HOLDER HIT-6684748.A27 6684748	-
384 - COVER GUARD TILL E979999 HIT-6690372.A32 6690372	£2.81	£3.37
384A - COVER GUARD SINCE EO70001 HIT-6684749.A1 6684749	£8.52	£10.22
385 - KNIFE TILL E979999 HIT-6693386.A8 6693386	£8.53	£10.24
385A - KNIFE SINCE EO70001 HIT-6684750.A54 6684750	£3.64	£4.37
386 - SCREW 5X12/S TILL E979999 HIT-6695334.A13 6695334	£1.67	£2.00
386A - TAPPING SCREW 4X14 SINCE EO70001 HIT-6684751.A45 6684751	£1.67	£2.00
387 - NUT M5 TILL E979999 HIT-6684965.A26 6684965	£1.67	£2.00
388 - BRACKET SPACER TILL E979999 HIT-6690332.A3 6690332	-
*389 - TAPPING SCREW 5X20 SINCE EO70001 HIT-6684753.A40 6684753	£1.67	£2.00
*389 - TAPPING SCREW 5X20 TILL E819999 HIT-6684753.A41 6684753	£1.67	£2.00
*390 - KNIFE SINCE EO70001 HIT-6684754.A46 6684754	£6.64	£7.97
*390 - KNIFE TILL E819999 HIT-6684754.A47 6684754	£6.64	£7.97
501 - HEX. BAR WRENCH 4MM HIT-6684813.A70 6684813	-
502 - COMBI BOX SPANNER 13X19 HIT-6693588.A2 6693588	-
504A - PROTECTIVE GLASSES HIT-875769.A24 875769	-
505 - SHOULDER STRAP S HIT-6695795.A4 6695795	-
511 - NYLON HEAD Z-5 HIT-6695783.A7 6695783	£39.71	£47.65
512 - CUTTING BODY HIT-6693273.A6 6693273	-
513 - SPECIAL NUT HIT-6689103.A3 6689103	£11.71	£14.05
514 - REEL SPRING HIT-6693380.A25 6693380	£6.47	£7.76
515 - EYELET HIT-6684810.A15 6684810	£3.29	£3.95
516 - SPOOL HIT-6693294.A7 6693294	£11.02	£13.22
517 - NO LONGER AVAILABLE HIT-6693340.A6 6693340	-
518 - MANUAL NYLON HEAD Z5 HIT-6697932.A1 6697932	-
602 - SYMBOL MARK CG22EJ(SL) HIT-6699680.A0 6699680	-

Attribute Name	Value
Brand	Hikoki

There are currently no reviews of this product.

United Kingdom (Including N. Ireland)

On orders up to £40.00	Add £4.00 inc VAT (Royal Mail post)
On orders £40.00 to £130.00	Add £7.00 inc VAT (Courier)
On orders over £130.00	FREE (Courier)

Shopping Basket (0) £0.00

Hitachi / Hikoki CG22EJ2 Engine Grass Trimmer Spare Parts

Your Review

Your Details

Carry On Shopping

Try these categories

Recently Viewed

Your Order

About Us

Other Links

Search

Customization

Shopping Basket (0) £0.00

Information

Hitachi / Hikoki CG22EJ2 Engine Grass Trimmer Spare Parts

Notify me

Your Review

Your Details

Carry On Shopping

Try these categories

Recently Viewed

Your Order

About Us

Other Links

Search
