1 - LOWER GUARD
HIT-374360.A0
374360
|
-
|
|
|
|
2 - RETURN SPRING
HIT-374253.A1
374253
|
-
|
|
|
|
3 - RETAINING RING FOR D22 SHAFT (10 PCS.)
HIT-939548.A7
939548
|
£7.48
|
£8.97
|
|
|
4 - WASHER (A)
HIT-374254.A1
374254
|
-
|
|
|
|
5 - TCT SAW BLADE 125MM-D20 HOLE-NT28
HIT-374352.A0
374352
|
-
|
|
|
|
6 - WASHER (B)
HIT-374255.A1
374255
|
-
|
|
|
|
7 - HEX. FLANGE BOLT
HIT-338917.A3
338917
|
£1.67
|
£2.00
|
|
|
8 - SAW COVER (B)
HIT-374357.A0
374357
|
-
|
|
|
|
9 - SPECIAL BOLT
HIT-324894.A0
324894
|
-
|
|
|
|
10 - MACHINE SCREW (W/WASHER) M4X12 (BLACK)
HIT-333781.A2
333781
|
-
|
|
|
|
11 - SAW COVER (A)
HIT-374356.A0
374356
|
-
|
|
|
|
12 - BRAND LABEL
HIT-000000.A1846
000000
|
-
|
|
|
|
13 - WING NUT M6
HIT-307882.A0
307882
|
-
|
|
|
|
14 - DUST COVER
HIT-374347.A1
374347
|
-
|
|
|
|
15 - CAP
HIT-324891.A1
324891
|
-
|
|
|
|
16 - ROTOR
HIT-361100.A0
361100
|
-
|
|
|
|
17 - MACHINE SCREW (W/WASHERS) M4X14 (BLACK)
HIT-305691.A7
305691
|
£1.67
|
£2.00
|
|
|
18 - LOCK LEVER
HIT-374247.A1
374247
|
-
|
|
|
|
19 - SPRING
HIT-334225.A3
334225
|
-
|
|
|
|
20 - LED (A)
HIT-374241.A1
374241
|
-
|
|
|
|
21 - GEAR COVER (A)
HIT-375405.A0
375405
|
-
|
|
|
|
22 - WASHER (A)
HIT-329975.A2
329975
|
-
|
|
|
|
23 - RETAINING RING FOR D11 SHAFT
HIT-316487.A25
316487
|
£1.67
|
£2.00
|
|
|
24 - FIRST GEAR
HIT-338925.A2
338925
|
-
|
|
|
|
25 - O-RING (S-15)
HIT-319567.A0
319567
|
£2.91
|
£3.49
|
|
|
26 - FEATHER KEY 4X4X10
HIT-930511.A4
930511
|
£2.78
|
£3.34
|
|
|
27 - SECOND SHAFT ASS'Y INCLUD.23-26
HIT-374250.A1
374250
|
-
|
|
|
|
28 - BALL BEARING 606VV
HIT-606ZZM.A29
606ZZM
|
£14.07
|
£16.88
|
|
|
29 - BEARING HOLDER
HIT-374239.A1
374239
|
-
|
|
|
|
30 - BEARING HOLDER ASS'Y INCLUD.27-29
HIT-374252.A1
374252
|
-
|
|
|
|
31 - MACHINE SCREW (W/SP. WASHER) M4X12
HIT-951039.A6
951039
|
£1.67
|
£2.00
|
|
|
32 - BOLT (SQUARE) M6X20
HIT-375031.A2
375031
|
-
|
|
|
|
33 - SPINDLE GEAR SET
HIT-374251.A1
374251
|
-
|
|
|
|
34 - MACHINE SCREW M3X8 (10 PCS.)
HIT-949203.A10
949203
|
£1.67
|
£2.00
|
|
|
35 - BEARING COVER
HIT-338922.A4
338922
|
-
|
|
|
|
36 - BALL BEARING 6901VV
HIT-6901VV.A20
6901VV
|
£11.83
|
£14.20
|
|
|
37 - SPRING
HIT-374781.A0
374781
|
-
|
|
|
|
38 - KNOB
HIT-374780.A5
374780
|
-
|
|
|
|
39 - TRIGGER
HIT-338899.A3
338899
|
-
|
|
|
|
40 - SWITCH
HIT-371907.A3
371907
|
£15.22
|
£18.27
|
|
|
41 - MV LABEL (B)
HIT-373914.A0
373914
|
-
|
|
|
|
42 - STATOR FET PCB ASS'Y INCLUD.20
HIT-341046.A0
341046
|
-
|
|
|
|
43 - HANDLE SET (GREEN)
HIT-374302.A0
374302
|
-
|
|
|
|
44 - MACHINE SCREW (W/WASHERS) M4
HIT-375104.A1
375104
|
-
|
|
|
|
45 - HOUSING SET
HIT-374240.A1
374240
|
-
|
|
|
|
46 - CUSHION
HIT-336554.A0
336554
|
-
|
|
|
|
47 - RUBBER BUSHING
HIT-338928.A7
338928
|
-
|
|
|
|
48 - WASHER
HIT-375110.A1
375110
|
-
|
|
|
|
49 - TAPPING SCREW (W/FLANGE) D4X20 (BLACK)
HIT-301653.A234
301653
|
£1.67
|
£2.00
|
|
|
50 - BASE (C)
HIT-374358.A0
374358
|
-
|
|
|
|
51 - RETAINING RING (E-TYPE) FOR D8 SHAFT
HIT-942827.A5
942827
|
£1.67
|
£2.00
|
|
|
52 - LEVER
HIT-374246.A2
374246
|
-
|
|
|
|
53 - LOCK NUT
HIT-374248.A2
374248
|
-
|
|
|
|
54 - WAVE WASHER
HIT-375106.A5
375106
|
-
|
|
|
|
55 - SPACER
HIT-374359.A0
374359
|
-
|
|
|
|
56 - COVER
HIT-338914.A2
338914
|
-
|
|
|
|
57 - TAPPING SCREW (W/FLANGE) D4X16 (BLACK)
HIT-307811.A22
307811
|
£2.49
|
£2.99
|
|
|
58 - NAME PLATE
HIT-000000.A1847
000000
|
-
|
|
|
|
59 - ROLL PIN D6X40 (10 PCS.)
HIT-949686.A10
949686
|
£8.48
|
£10.18
|
|
|
60 - MV LABEL (A)
HIT-373913.A7
373913
|
-
|
|
|
|
61 - WASHER
HIT-320975.A14
320975
|
£1.67
|
£2.00
|
|
|
62 - BATTERY BSL 36A18 (EUROPE AUS NZL) INCLUD.502
HIT-371750.A18
371750
|
£173.17
|
£207.80
|
|
|
501 - CHARGER (MODEL UC 18YSL3)
HIT-000000.A1849
000000
|
-
|
|
|
|
502 - BATTERY COVER
HIT-329897.A116
329897
|
£1.67
|
£2.00
|
|
|
503 - HEX. BAR WRENCH 5MM
HIT-944459.A6
944459
|
£1.67
|
£2.00
|
|
|
504 - CASE ASS'Y (STACKABLE 4) INCLUD.505-507
HIT-337528.A21
337528
|
-
|
|
|
|
505 - LATCH
HIT-336472.A23
336472
|
£1.67
|
£2.00
|
|
|
506 - HANDLE
HIT-336473.A51
336473
|
£6.43
|
£7.72
|
|
|
507 - HINGE
HIT-336474.A23
336474
|
£1.67
|
£2.00
|
|
|
508 - INNER TRAY
HIT-375343.A0
375343
|
-
|
|
|
|
509 - INNER TRAY
HIT-375344.A0
375344
|
-
|
|
|
