Hitachi / Hikoki CB100FA Band Saw Spare Parts

An exploded diagram and spare parts listing for the Hitachi / Hikoki CB100FA Band Saw

	Ex VAT	Inc VAT
1 - BRAND LABEL HIT-975579.A0 975579	-
2 - BRAND LABEL HIT-988556.A0 988556	-
3 - CAUTION PLATE (H) HIT-988566.A0 988566	-
4 - SET GAUGE LABEL HIT-988565.A0 988565	-
5 - MACHINE SCREW M6X10 (10 PCS.) HIT-949254.A3 949254	-
6 - SPRING WASHER M6 (10 PCS.) HIT-949455.A48 949455	£1.67	£2.00
7 - BOLT M6X16 (10 PCS.) HIT-949613.A7 949613	£1.67	£2.00
8 - SPRING WASHER M6 (10 PCS.) HIT-949455.A49 949455	£1.67	£2.00
10 - SILICON FLEXIBLE TUBE HIT-974787.A0 974787	-
11 - CORD (C) HIT-975452.A0 975452	-
12 - CORD (B) HIT-975454.A0 975454	-
13 - CORD (C) HIT-975453.A0 975453	-
14 - MACHINE SCREW M4X10 (10 PCS.) HIT-949216.A36 949216	£1.67	£2.00
15 - SPRING WASHER M4 (10 PCS.) HIT-949453.A28 949453	£1.67	£2.00
16 - NYLON CLIP HIT-966049.A0 966049	-
17 - NUT M4 (10 PCS.) HIT-949554.A3 949554	£1.67	£2.00
18 - NAME PLATE HIT-000000.A4864 000000	-
19 - COVER (E) HIT-988498.A0 988498	-
20 - WIRING DIAGRAM HIT-988564.A0 988564	-
21 - SAFETY COVER (B) HIT-974785.A0 974785	-
22 - BOLT WASHER M5 (10 PCS.) HIT-949431.A11 949431	£1.67	£2.00
23 - WING BOLT M5X10 (10 PCS.) HIT-949397.A2 949397	£5.61	£6.73
24 - COVER HIT-988559.A0 988559	-
25 - BOLT M6X16 (10 PCS.) HIT-949613.A8 949613	£1.67	£2.00
26 - SPRING WASHER M6 (10 PCS.) HIT-949455.A50 949455	£1.67	£2.00
27 - SAFETY COVER HIT-974784.A0 974784	-
28 - BOLT M8X16 (10 PCS.) HIT-949622.A4 949622	-
29 - SPRING WASHER M8 (10 PCS.) HIT-949457.A55 949457	£1.67	£2.00
30 - SAW WHEEL HIT-974105.A1 974105	-
31 - BOLT M8X16 (10 PCS.) HIT-949622.A5 949622	-
32 - SPRING WASHER M8 (10 PCS.) HIT-949457.A56 949457	£1.67	£2.00
33 - COVER (D) HIT-988497.A0 988497	-
34 - WASHER (B) HIT-965715.A2 965715	-
35 - NUT (LEFT HAND) M20 HIT-948510.A1 948510	-
36 - BAND SAW BLADE (A) (STELLITE TIP) HIT-974100.A0 974100	-
36A - BAND SAW BLADE (C) (STELLITE TIP) FOR USA HIT-939973.A0 939973	-
37 - MACHINE SCREW M5X12 (10 PCS.) HIT-949237.A16 949237	£1.67	£2.00
38 - SPRING WASHER M5 (10 PCS.) HIT-949454.A97 949454	£1.67	£2.00
39 - BOLT WASHER M5 (10 PCS.) HIT-949431.A12 949431	£1.67	£2.00
40 - RUBBER PACKING (A) HIT-974769.A0 974769	-
41 - COVER PLATE (C) HIT-974768.A0 974768	-
42 - NUT M5 (10 PCS.) HIT-949555.A23 949555	£1.67	£2.00
43 - COVER (A) HIT-988496.A0 988496	-
44 - SAW WHEEL HIT-974105.A0 974105	-
45 - WASHER (B) HIT-965715.A1 965715	-
46 - NUT (LEFT HAND) M20 HIT-948510.A0 948510	-
47 - COVER PLATE (A) HIT-974767.A0 974767	-
48 - MACHINE SCREW M5X16 (10 PCS.) HIT-949239.A9 949239	£1.67	£2.00
49 - SPRING WASHER M5 (10 PCS.) HIT-949454.A98 949454	£1.67	£2.00
50 - MACHINE SCREW M6X16 (10 PCS.) HIT-949256.A10 949256	£1.67	£2.00
51 - SPRING WASHER M6 (10 PCS.) HIT-949455.A45 949455	£1.67	£2.00
52 - BEARING COVER (A) HIT-974103.A1 974103	-
53 - PIN (A) HIT-965725.A0 965725	-
54 - BALL BEARING (6310ZZCM) HIT-000000.A4867 000000	-
55 - CASING (B) ASS'Y INCLUD.50-52 HIT-974151.A0 974151	-
56 - CASING (B) HIT-000000.A4865 000000	-
57 - SAW SHAFT (B) HIT-000000.A4866 000000	-
58 - MARK PLATE (B) HIT-968331.A0 968331	-
59 - MARK PLATE (A) HIT-975571.A0 975571	-
60 - SCREW (D) HIT-967104.A1 967104	-
61 - LOCK NUT M8 (10 PCS.) HIT-949568.A12 949568	£1.67	£2.00
62 - DUSTER (B) HIT-974173.A0 974173	-
63 - DUSTER ARM HIT-974172.A0 974172	-
64 - HEX. SOCKET HD. BOLT M6X16 (10 PCS.) HIT-949755.A10 949755	£3.64	£4.37
65 - SPRING WASHER M6 (10 PCS.) HIT-949455.A47 949455	£1.67	£2.00
66 - BEARING COVER (C) HIT-974153.A0 974153	-
67 - MACHINE SCREW M6X16 (10 PCS.) HIT-949256.A11 949256	£1.67	£2.00
68 - SPRING WASHER M6 (10 PCS.) HIT-949455.A46 949455	£1.67	£2.00
69 - BALL BEARING 6307ZZCMPS2L HIT-6307ZZ.A0 6307ZZ	-
70 - WASHER (A) HIT-936305.A0 936305	-
71 - BOLT M10X20 (10 PCS.) HIT-949638.A0 949638	-
72 - SPRING WASHER M10 (10 PCS.) HIT-949458.A13 949458	£1.67	£2.00
73 - METAL SPRING (C) HIT-965342.A0 965342	-
74 - BOLT WASHER M12 (10 PCS.) HIT-949437.A7 949437	£1.67	£2.00
75 - WASHER (A) HIT-936305.A1 936305	-
76 - KNOB SHAFT HIT-974161.A0 974161	-
77 - BOLT M6X16 (10 PCS.) HIT-949613.A5 949613	£1.67	£2.00
78 - SPRING WASHER M6 (10 PCS.) HIT-949455.A41 949455	£1.67	£2.00
79 - BOLT WASHER M6 (10 PCS.) HIT-949432.A80 949432	£1.67	£2.00
80 - KNOB SHAFT STAY HIT-974202.A0 974202	-
81 - ROLL PIN D5X32 (10 PCS.) HIT-949746.A0 949746	-
82A - ROUND HANDLE 160MM HIT-988976.A0 988976	-
83 - BOLT M6X10 (10 PCS.) HIT-949610.A2 949610	£1.67	£2.00
84 - SPRING WASHER M6 (10 PCS.) HIT-949455.A42 949455	£1.67	£2.00
85 - CAUTION PLATE HIT-988562.A0 988562	-
86 - RUBBER PACKING (B) HIT-974770.A0 974770	-
87 - ROLL PIN D8X20 (10 PCS.) HIT-949878.A0 949878	-
88 - PULLEY (D) HIT-974106.A0 974106	-
89 - WASHER (B) HIT-965715.A0 965715	-
90 - SPRING WASHER M20 (10 PCS.) HIT-949745.A1 949745	-
91 - NUT M20 HIT-948530.A0 948530	-
92 - BELT COVER HIT-988528.A0 988528	-
93 - FEATHER KEY 10X8X35 HIT-965797.A0 965797	-
94 - MACHINE SCREW M6X16 (10 PCS.) HIT-949256.A8 949256	£1.67	£2.00
95 - SPRING WASHER M6 (10 PCS.) HIT-949455.A44 949455	£1.67	£2.00
96 - MACHINE SCREW M6X16 (10 PCS.) HIT-949256.A9 949256	£1.67	£2.00
97 - SPRING WASHER M6 (10 PCS.) HIT-949455.A43 949455	£1.67	£2.00
98 - BEARING COVER (A) HIT-974103.A0 974103	-
99 - BALL BEARING (6310ZZ) HIT-000000.A4868 000000	-
100 - CASING (A) ASS'Y INCLUD.96-99 HIT-974102.A0 974102	-
101 - CASING (A) HIT-000000.A4871 000000	-
102 - BOLT (W/SP. WASHER) M12X40 HIT-951688.A0 951688	-
103 - SAW SHAFT (A) HIT-000000.A4869 000000	-
104 - BALL BEARING (6308ZZ) HIT-000000.A4870 000000	-
105 - BEARING COVER (B) HIT-974104.A0 974104	-
106 - BOLT (W/WASHERS) M8X16 HIT-988495.A1 988495	-
107 - SWITCH BASE (A) HIT-988521.A0 988521	-
108 - HIGH TENSION BOLT M8X25 HIT-967594.A0 967594	-
109 - NUT M8 (10 PCS.) HIT-949558.A22 949558	£1.67	£2.00
110 - BOLT M6X16 (10 PCS.) HIT-949613.A6 949613	£1.67	£2.00
111 - SPRING WASHER M6 (10 PCS.) HIT-949455.A40 949455	£1.67	£2.00
112 - BOLT WASHER M6 (10 PCS.) HIT-949432.A79 949432	£1.67	£2.00
113 - BRAKE PLATE HIT-974252.A0 974252	-
114 - BRAKE SPRING HIT-965779.A0 965779	-
115 - MACHINE SCREW M6X16 (10 PCS.) HIT-949256.A7 949256	£1.67	£2.00
116 - SLIDE FRAME HIT-965716.A0 965716	-
117 - BOLT M12X35 (10 PCS.) HIT-949672.A0 949672	-
118 - SPRING WASHER M12 (10 PCS.) HIT-949463.A6 949463	£1.67	£2.00
119 - LINER HIT-974158.A0 974158	-
120 - BOLT M8X30 (10 PCS.) HIT-949628.A5 949628	-
121 - NUT M8 (10 PCS.) HIT-949558.A23 949558	£1.67	£2.00
122 - BOLT M8X40 (10 PCS.) HIT-949630.A0 949630	£3.64	£4.37
123 - NUT M8 (10 PCS.) HIT-949558.A24 949558	£1.67	£2.00
124 - BALANCE WEIGHT HIT-974166.A0 974166	-
125 - BOLT M8X50 (10 PCS.) HIT-949633.A0 949633	£5.43	£6.52
126 - NUT M8 (10 PCS.) HIT-949558.A25 949558	£1.67	£2.00
127 - CAUTION PLATE (I) HIT-988563.A0 988563	-
128 - MICRO SWITCH ARM HIT-974169.A0 974169	-
129 - MACHINE SCREW M5X10 (10 PCS.) HIT-949236.A27 949236	£1.67	£2.00
130 - SPRING WASHER M5 (10 PCS.) HIT-949454.A99 949454	£1.67	£2.00
131 - BOLT WASHER M5 (10 PCS.) HIT-949431.A13 949431	£1.67	£2.00
132 - SCALE ARM HIT-974167.A0 974167	-
133 - MACHINE SCREW M6X10 (10 PCS.) HIT-949254.A4 949254	-
134 - SPRING WASHER M6 (10 PCS.) HIT-949455.A39 949455	£1.67	£2.00
135 - PIN (B) HIT-974160.A0 974160	-
137 - FEATHER KEY 5X5X20 HIT-966413.A0 966413	-
138 - SHAFT (B) HIT-974165.A0 974165	-
139 - BEARING SHAFT ASS'Y INCLUD.140 HIT-974162.A0 974162	-
140 - BEARING PIECE HIT-000000.A4872 000000	-
141 - BOLT M6X25 (10 PCS.) HIT-949616.A2 949616	£1.67	£2.00
142 - LINK HIT-974159.A0 974159	-
143 - HEX. SOCKET SET SCREW M6X10 HIT-968247.A7 968247	-
144 - ROLL PIN D5X32 (10 PCS.) HIT-949746.A1 949746	-
145 - SHAFT HOLDER HIT-974163.A0 974163	-
146 - BOLT M6X20 (10 PCS.) HIT-949676.A0 949676	-
147 - SPRING WASHER M6 (10 PCS.) HIT-949455.A38 949455	£1.67	£2.00
148 - SLIDER ASS'Y INCLUD.149-154 HIT-974155.A0 974155	-
149 - SLIDER HIT-000000.A4873 000000	-
150 - ROLLER BEARING (NH24/16) HIT-000000.A4874 000000	-
151 - SHAFT HIT-974157.A0 974157	-
152 - RETAINING RING FOR D20 SHAFT (10 PCS.) HIT-939547.A10 939547	£4.61	£5.53
153 - BEARING HOLDER HIT-974156.A0 974156	-
154 - FEATHER KEY 5X5X40 HIT-965482.A0 965482	-
155 - HEX. SOCKET SET SCREW M6X10 HIT-968247.A6 968247	-
156 - ROLL PIN D3X20 (10 PCS.) HIT-949685.A8 949685	£1.67	£2.00
157 - BEARING SHAFT HIT-000000.A4875 000000	-
158 - RETAINING RING FOR D10 SHAFT (10 PCS.) HIT-939540.A21 939540	£1.67	£2.00
159 - BALL BEARING 6000VVCMPS2L HIT-6000VV.A87 6000VV	£7.62	£9.15
160 - WASHER M10 (10 PCS.) HIT-949445.A3 949445	-
161 - HEX. SOCKET SET SCREW M6X10 HIT-968247.A5 968247	-
162 - NUT M12 (10 PCS.) HIT-949561.A3 949561	-
163 - WASHER (A) HIT-965724.A0 965724	£1.67	£2.00
164 - HEX. SOCKET HD. BOLT M12X80 HIT-974780.A0 974780	-
165 - SCALE (B) HIT-975572.A0 975572	-
166 - SCALE PLATE HIT-974168.A0 974168	-
167 - MACHINE SCREW M6X10 (10 PCS.) HIT-949254.A1 949254	-
168 - SPRING WASHER M6 (10 PCS.) HIT-949455.A37 949455	£1.67	£2.00
169 - BOLT M8X75 HIT-944899.A0 944899	-
170 - DUSTER (A) HIT-974116.A0 974116	-
171 - LOCK NUT M8 (10 PCS.) HIT-949568.A10 949568	£1.67	£2.00
172B - ROUND HANDLE (B) ASS'Y INCLUD.173A HIT-988974.A0 988974	-
173 - FEED SCREW HIT-000000.A4876 000000	-
173A - FEED SCREW HIT-000000.A4878 000000	-
174 - BOLT M10X35 (10 PCS.) HIT-949695.A2 949695	-
175 - SPRING WASHER M10 (10 PCS.) HIT-949458.A12 949458	£1.67	£2.00
176 - SCREW HOLDER HIT-000000.A4881 000000	-
177 - THRUST BEARING (51103) HIT-939286.A3 939286	-
178 - SLEEVE HIT-000000.A4880 000000	-
179 - ROLL PIN D5X32 (10 PCS.) TILL 6.1995 HIT-949746.A2 949746	-
179A - ROLL PIN D6X36 (10 PCS.) SINCE 7.1995 HIT-949874.A0 949874	-
180A - ROUND HANDLE 200MM (I.D.12) TILL 6.1995 HIT-965867.A0 965867	-
180B - ROUND HANDLE 200MM (I.D.15) SINCE 7.1995 HIT-988982.A0 988982	-
181 - SQUARE SOCKET 12MM HIT-974119.A0 974119	-
182 - BOLT (W/SP. WASHER) M12X40 HIT-951688.A2 951688	-
183 - BOLT WASHER M12 (10 PCS.) HIT-949437.A6 949437	£1.67	£2.00
184 - HINGE (C) HIT-965747.A0 965747	-
185 - HINGE (A) HIT-965745.A0 965745	-
186 - BOLT (W/SP. WASHER) M12X40 HIT-951688.A1 951688	-
187 - BOLT M6X20 (10 PCS.) HIT-949676.A1 949676	-
188 - BOLT (W/SP. WASHER) M12X40 HIT-951688.A3 951688	-
189 - BOLT WASHER M12 (10 PCS.) HIT-949437.A4 949437	£1.67	£2.00
190 - HINGE (B) HIT-974118.A0 974118	-
191 - BOLT WASHER M12 (10 PCS.) HIT-949437.A5 949437	£1.67	£2.00
192 - SPRING WASHER M12 (10 PCS.) HIT-949463.A7 949463	£1.67	£2.00
193 - BOLT M12X180 HIT-974242.A1 974242	-
194 - HINGE SHAFT HIT-965748.A0 965748	-
195A - SET SRPING (B) HIT-963175.A1 963175	-
196 - WING BOLT M5X25 (10 PCS.) HIT-949400.A0 949400	-
197 - WING BOLT M8X25 (10 PCS.) HIT-949413.A5 949413	£12.46	£14.95
199 - STABILIZER HIT-974196.A1 974196	-
200 - NUT M5 (10 PCS.) HIT-949555.A24 949555	£1.67	£2.00
201 - MACHINE SCREW M5X30 (10 PCS.) HIT-949245.A3 949245	£1.67	£2.00
203 - HOOK HIT-974186.A0 974186	-
204 - MACHINE SCREW M3X10 (10 PCS.) HIT-949204.A4 949204	£1.67	£2.00
205 - SPRING WASHER M3 (10 PCS.) HIT-949451.A6 949451	£1.67	£2.00
206 - MACHINE SCREW M6X20 (10 PCS.) HIT-949258.A7 949258	£1.67	£2.00
207 - SPRING WASHER M6 (10 PCS.) HIT-949455.A36 949455	£1.67	£2.00
208 - BOLT WASHER M6 (10 PCS.) HIT-949432.A81 949432	£1.67	£2.00
209 - SAW DUST THROWER HIT-974781.A0 974781	-
210 - NUT M6 (10 PCS.) HIT-949556.A6 949556	£1.67	£2.00
211 - MACHINE SCREW M6X12 (10 PCS.) HIT-949255.A10 949255	£1.67	£2.00
212 - SPRING WASHER M6 (10 PCS.) HIT-949455.A34 949455	£1.67	£2.00
213 - BRAKE LINING HIT-974113.A0 974113	-
214 - FLAT HD. SCREW M5X10 (10 PCS.) HIT-949331.A0 949331	£1.67	£2.00
215 - LINING HOLDER HIT-988491.A0 988491	-
216 - BRAKE PEDAL HIT-974109.A0 974109	-
217 - BRAKE SHAFT HIT-974110.A0 974110	-
218 - ROLL PIN D5X25 (10 PCS.) HIT-949681.A9 949681	-
219 - FRAME HIT-000000.A4882 000000	-
220 - CAP NUT M8 HIT-974141.A0 974141	-
221 - CABLE TIE HIT-975144.A13 975144	-
222 - WASHER HIT-932314.A1 932314	-
223 - LOCK NUT M8 (10 PCS.) HIT-949568.A11 949568	£1.67	£2.00
224 - WASHER M8 (10 PCS.) HIT-949426.A4 949426	£1.67	£2.00
225 - HEX. SOCKET HD. BOLT M5X10 (10 PCS.) HIT-949819.A7 949819	£6.66	£7.99
226 - SPRING WASHER M5 (10 PCS.) HIT-949454.A100 949454	£1.67	£2.00
227 - ROLL PIN D5X25 (10 PCS.) HIT-949681.A8 949681	-
228 - HEX. SOCKET HD. BOLT M10X30 (10 PCS.) HIT-949846.A1 949846	£8.53	£10.24
229 - SPRING WASHER M10 (10 PCS.) HIT-949458.A11 949458	£1.67	£2.00
230 - GUIDE ASS'Y INCLUD.228 HIT-975580.A0 975580	-
231 - GUIDE (B) HIT-975582.A0 975582	-
232 - HEX. SOCKET HD. BOLT M8X25 (10 PCS.) HIT-949760.A6 949760	£6.62	£7.95
233 - GUIDE HOLDER (C) HIT-975584.A0 975584	-
234 - SET GAUGE HIT-974139.A0 974139	-
235 - SET GAUGE PLATE HIT-974137.A0 974137	-
236 - STEEL BALL HIT-974140.A0 974140	-
237 - BALL SPRING HIT-966459.A0 966459	-
238 - SET GAUGE SHAFT HIT-974138.A0 974138	-
239 - RETAINING RING (E-TYPE) FOR D6 SHAFT HIT-955479.A1 955479	£1.67	£2.00
240 - MACHINE SCREW M6X10 (10 PCS.) HIT-949254.A2 949254	-
241 - SPRING WASHER M6 (10 PCS.) HIT-949455.A33 949455	£1.67	£2.00
242A - SENSOR SINCE 1.1996 HIT-312682.A0 312682	-
243 - KNOB (A) M10X40 HIT-974142.A0 974142	-
244 - GUIDE MARK (A) HIT-988561.A0 988561	-
245 - KNOB HIT-974771.A0 974771	-
246 - ROLL PIN D5X25 (10 PCS.) HIT-949681.A7 949681	-
247 - BOLT WASHER M12 (10 PCS.) HIT-949437.A3 949437	£1.67	£2.00
248 - GUIDE HOLDER (A) HIT-974127.A0 974127	-
249 - GUIDE PLATE HIT-974147.A0 974147	-
250 - BOLT M8X20 (10 PCS.) HIT-949624.A6 949624	-
251 - SPRING WASHER M6 (10 PCS.) HIT-949455.A35 949455	£1.67	£2.00
252 - MACHINE SCREW M5X10 (10 PCS.) HIT-949236.A28 949236	£1.67	£2.00
253 - SPRING WASHER M4 (10 PCS.) HIT-949453.A27 949453	£1.67	£2.00
254 - DISC HIT-974131.A0 974131	-
255 - DISC HOLDER HIT-974130.A0 974130	-
256 - ROLL PIN D5X20 (10 PCS.) HIT-949753.A3 949753	-
257 - DISC COVER HIT-974132.A0 974132	-
258 - PINION SHAFT HIT-974128.A0 974128	-
259 - ROLL PIN D5X20 (10 PCS.) HIT-949753.A2 949753	-
260 - PINION HIT-974129.A0 974129	-
261 - NUT M12 (10 PCS.) HIT-949561.A2 949561	-
262 - BOLT M12X100 HIT-964621.A0 964621	-
263 - TABLE PIECE HIT-974244.A0 974244	-
264 - BOLT WASHER M8 (10 PCS.) HIT-949433.A14 949433	£1.67	£2.00
265 - SPRING WASHER M8 (10 PCS.) HIT-949457.A57 949457	£1.67	£2.00
266 - HIGH TENSION BOLT M8X25 HIT-967594.A1 967594	-
267 - GUIDE SPRING HIT-988494.A0 988494	-
268 - BOLT (W/WASHERS) M8X16 HIT-988495.A0 988495	-
269A - GUIDE SPRING ASS'Y INCLUD.267 HIT-988983.A0 988983	-
270A - GUIDE HOLDER HIT-988984.A0 988984	-
271 - KNOB (A) M10X40 HIT-974142.A1 974142	-
272 - STOPPER HIT-988532.A0 988532	-
273 - SPRING WASHER M8 (10 PCS.) HIT-949457.A58 949457	£1.67	£2.00
274 - BOLT M8X20 (10 PCS.) HIT-949624.A7 949624	-
275 - MACHINE SCREW M5X30 (10 PCS.) HIT-949245.A2 949245	£1.67	£2.00
277A - SET SRPING (B) HIT-963175.A0 963175	-
278 - NUT M5 (10 PCS.) HIT-949555.A25 949555	£1.67	£2.00
279 - STABILIZER HOLDER HIT-974197.A0 974197	-
280 - WING BOLT M8X25 (10 PCS.) HIT-949413.A6 949413	£12.46	£14.95
281 - MACHINE SCREW (W/WASHERS) M4X10 HIT-986662.A4 986662	£1.67	£2.00
282 - ARM PLATE HIT-974179.A0 974179	-
283 - BOLT M8X25 (10 PCS.) HIT-949626.A2 949626	-
284 - SPRING WASHER M8 (10 PCS.) HIT-949457.A61 949457	£1.67	£2.00
285 - ARM HIT-974174.A0 974174	-
286 - CORD COVER (C) HIT-988545.A0 988545	-
287 - STABILIZER SHAFT HIT-988539.A0 988539	-
288 - ROLLER BEARING (NK19/16) HIT-000000.A4883 000000	-
289 - BOLT M6X20 (10 PCS.) HIT-949676.A2 949676	-
290 - NUT M6 (10 PCS.) HIT-949556.A11 949556	£1.67	£2.00
291 - WORM HIT-932313.A1 932313	-
292 - GEAR HIT-932316.A1 932316	-
293 - LOCK SCREW HIT-974175.A0 974175	-
294 - MACHINE SCREW M6X20 (10 PCS.) HIT-949258.A6 949258	£1.67	£2.00
295 - SPRING WASHER M6 (10 PCS.) HIT-949455.A28 949455	£1.67	£2.00
296 - CLAMP BAR HIT-952407.A0 952407	-
297 - NUT M6 (10 PCS.) HIT-949556.A12 949556	£1.67	£2.00
298 - GEAR SHAFT HIT-932315.A0 932315	-
299A - ROUND HANDLE 200MM HIT-988975.A0 988975	-
300 - CAUTION LABEL (A) HIT-988571.A0 988571	-
301 - ROLL PIN D5X32 (10 PCS.) HIT-949746.A3 949746	-
302 - GEAR COVER HIT-965759.A0 965759	-
303 - FLAT HD. SCREW M5X16 (10 PCS.) HIT-949334.A3 949334	£1.67	£2.00
304 - RACK (A) HIT-965763.A0 965763	-
305 - BOLT M8X25 (10 PCS.) HIT-949626.A3 949626	-
306 - SPRING WASHER M8 (10 PCS.) HIT-949457.A62 949457	£1.67	£2.00
307 - HEX. SOCKET HD. BOLT M5X10 (10 PCS.) HIT-949819.A8 949819	£6.66	£7.99
308 - SPRING WASHER M5 (10 PCS.) HIT-949454.A102 949454	£1.67	£2.00
309 - INDICATOR COVER ASS'Y INCLUD.307 HIT-988525.A0 988525	-
310 - INDICATOR COVER (B) HIT-000000.A4884 000000	-
311 - BOLT M10X30 (10 PCS.) HIT-949698.A3 949698	-
312 - SPRING WASHER M10 (10 PCS.) HIT-949458.A8 949458	£1.67	£2.00
313 - BALL BEARING 6300VVCMPS2L HIT-6300VV.A1 6300VV	£8.87	£10.64
314A - BOLT WASHER M10 (10 PCS.) HIT-949434.A9 949434	£1.67	£2.00
315 - BEARING SHAFT HIT-974180.A0 974180	-
316 - POLYVINYL CHLORIDE PLATE (A) HIT-974178.A0 974178	-
317 - MACHINE SCREW M3X10 (10 PCS.) HIT-949204.A2 949204	£1.67	£2.00
318 - SPRING WASHER M3 (10 PCS.) HIT-949451.A8 949451	£1.67	£2.00
319 - BLADE SCALE HIT-975573.A0 975573	-
320 - INDICATOR COVER (A) HIT-000000.A4885 000000	-
321 - LOCK NUT M8 (10 PCS.) HIT-949568.A9 949568	£1.67	£2.00
322 - BOLT (W/WASHERS) M8X16 HIT-988495.A2 988495	-
323 - HANDLE SPRING HIT-988540.A0 988540	-
324 - SCREW HOLDER HIT-988541.A0 988541	-
325 - MACHINE SCREW M5X35 (10 PCS.) HIT-949247.A0 949247	£1.67	£2.00
326 - SPRING WASHER M5 (10 PCS.) HIT-949454.A101 949454	£1.67	£2.00
327 - ADJUSTING SCREW HIT-988542.A0 988542	-
328 - HEX. SOCKET SET SCREW M6X10 HIT-968247.A3 968247	-
330 - BALL BEARING 6201VV HIT-6201VV.A32 6201VV	£8.30	£9.96
332A - MACHINE SCREW (W/WASHERS) M6X10 HIT-997314.A7 997314	£1.67	£2.00
334 - 1NDICATOR HIT-000000.A4886 000000	-
335 - INDICATOR SHAFT (A) HIT-000000.A4887 000000	-
336A - INDICATOR SHAFT (B) ASS'Y INCLUD.330 HIT-988579.A0 988579	-
337 - STABILIZER HIT-974196.A0 974196	-
338 - WING BOLT M5X25 (10 PCS.) HIT-949400.A1 949400	-
339 - STABILIZER BASE HIT-974195.A0 974195	-
340 - BOLT (W/SP. WASHER) M12X40 HIT-951688.A4 951688	-
341 - BOLT M10X30 (10 PCS.) HIT-949698.A4 949698	-
342 - SPRING WASHER M10 (10 PCS.) HIT-949458.A9 949458	£1.67	£2.00
343 - ROLLER ANGLE HIT-974148.A0 974148	-
344 - NYLON CLIP HIT-974261.A0 974261	-
345 - MACHINE SCREW M4X10 (10 PCS.) HIT-949216.A38 949216	£1.67	£2.00
346 - SPRING WASHER M4 (10 PCS.) HIT-949453.A26 949453	£1.67	£2.00
347 - BOLT WASHER M4 (10 PCS.) HIT-949429.A52 949429	£1.67	£2.00
348 - RACK HOLDER (A) HIT-974123.A0 974123	-
349 - TABLE HIT-974120.A0 974120	-
350 - SCALE (C) HIT-974786.A0 974786	-
351 - TABLE INSERT HIT-974122.A0 974122	-
352 - FLAT HD. SCREW M5X16 (10 PCS.) HIT-949334.A4 949334	£1.67	£2.00
353 - CONVEYER ROLLER HIT-974149.A0 974149	-
354 - GUIDE STOPPER HIT-974755.A0 974755	-
355 - RACK (A) HIT-974125.A0 974125	-
356 - HEX. SOCKET HD. BOLT M6X20 (10 PCS.) HIT-949660.A10 949660	£3.97	£4.76
357 - SPRING WASHER M6 (10 PCS.) HIT-949455.A29 949455	£1.67	£2.00
358 - RACK (B) HIT-974126.A0 974126	-
359 - BOLT M8X20 (10 PCS.) HIT-949624.A2 949624	-
360 - SPRING WASHER M8 (10 PCS.) HIT-949457.A59 949457	£1.67	£2.00
361 - WASHER M8 (10 PCS.) HIT-949426.A3 949426	£1.67	£2.00
362 - RACK HOLDER (B) HIT-974124.A0 974124	-
363 - HEX. SOCKET HD. BOLT M8X20 (10 PCS.) HIT-949656.A0 949656	£6.62	£7.95
364 - SPRING WASHER M8 (10 PCS.) HIT-949457.A60 949457	£1.67	£2.00
365 - WASHER M8 (10 PCS.) HIT-949426.A2 949426	£1.67	£2.00
366 - CORD COVER (A) HIT-974198.A0 974198	-
367 - MACHINE SCREW M3X10 (10 PCS.) HIT-949204.A1 949204	£1.67	£2.00
368 - SPRING WASHER M3 (10 PCS.) HIT-949451.A9 949451	£1.67	£2.00
369 - CORD COVER (B) HIT-974199.A0 974199	-
370 - MICRO SWITCH (C) HIT-974778.A0 974778	-
371 - MACHINE SCREW M4X25 (10 PCS.) HIT-949223.A0 949223	£1.67	£2.00
372 - SPRING WASHER M4 (10 PCS.) HIT-949453.A25 949453	£1.67	£2.00
373 - CORD (A) HIT-974267.A0 974267	-
374 - VINYL TUBE (ID12XT0.5X500) HIT-000000.A4888 000000	-
375 - MACHINE SCREW (W/WASHERS) M4X10 HIT-986662.A2 986662	£1.67	£2.00
376 - NYLON CLIP HIT-967579.A4 967579	-
377 - CURL CORD HIT-974262.A0 974262	-
378 - VINYL TUBE (ID12XT0.5X1000) HIT-000000.A4889 000000	-
379 - MACHINE SCREW (W/WASHERS) M4X10 HIT-986662.A3 986662	£1.67	£2.00
380 - NYLON CLIP HIT-966049.A1 966049	-
381 - TERMINAL BOX ASS'Y HIT-967333.A0 967333	-
382 - INTERNAL WIRE (D) HIT-966607.A0 966607	-
383 - HEX. SOCKET SET SCREW M6X10 HIT-968247.A2 968247	-
384 - BOLT M10X25 (10 PCS.) HIT-949639.A0 949639	-
385 - SPRING WASHER M10 (10 PCS.) HIT-949458.A10 949458	£1.67	£2.00
386 - CONNECTOR 50092 (10 PCS.) HIT-959141.A43 959141	£7.12	£8.54
387 - MOTOR COVER HIT-974243.A0 974243	-
388 - CORD CLIP HIT-935123.A0 935123	-
389 - MACHINE SCREW M4X10 (10 PCS.) HIT-949216.A37 949216	£1.67	£2.00
390 - SPRING WASHER M4 (10 PCS.) HIT-949453.A24 949453	£1.67	£2.00
391 - NYLON CLIP HIT-973313.A1 973313	£1.67	£2.00
392 - INSULATING SEAT HIT-988544.A0 988544	-
393 - MICRO SWITCH (D) HIT-974269.A0 974269	-
394 - SPRING WASHER M3 (10 PCS.) HIT-949451.A10 949451	£1.67	£2.00
395 - MACHINE SCREW M3X16 (10 PCS.) HIT-949207.A1 949207	-
396 - CAP HIT-974788.A0 974788	-
397 - NYLON CLIP HIT-948614.A0 948614	£1.67	£2.00
399A - PULLEY (C) SINCE 3.1984 HIT-974206.A0 974206	-
401 - NUT M3 (10 PCS.) HIT-949553.A12 949553	£1.67	£2.00
402A - TAPE CORD HOLDER (A) SINCE 1.1996 HIT-312686.A0 312686	-
403 - MACHINE SCREW M3X30 (10 PCS.) HIT-949211.A0 949211	-
404 - SPRING WASHER M3 (10 PCS.) HIT-949451.A12 949451	£1.67	£2.00
405 - GROMMET HIT-964637.A0 964637	-
406 - MOTOR (THREE-PHASE) 230V HITACHI MOTOR 3.7KW EFOUP-K 4P HIT-988577.A0 988577	-
407 - LOCK NUT M12 (10 PCS.) HIT-949574.A7 949574	£3.64	£4.37
408 - NUT M12 (10 PCS.) HIT-949561.A1 949561	-
409 - MOTOR BASE HIT-974150.A0 974150	-
410 - NUT M10 (10 PCS.) HIT-949560.A2 949560	£2.98	£3.57
411 - BOLT M10 HIT-967786.A0 967786	-
412 - NUT M10 (10 PCS.) HIT-949560.A1 949560	£2.98	£3.57
413 - BOLT M12X180 HIT-974242.A0 974242	-
414 - CORD (A) HIT-974268.A0 974268	-
415 - LIMIT SWITCH HIT-988536.A0 988536	-
416 - SPRING WASHER M4 (10 PCS.) HIT-949453.A22 949453	£1.67	£2.00
417 - MACHINE SCREW M4X25 (10 PCS.) HIT-949223.A1 949223	£1.67	£2.00
418 - POLYVINYL CHLORIDE COVER HIT-974189.A0 974189	-
419 - NUT M3 (10 PCS.) HIT-949553.A11 949553	£1.67	£2.00
420 - MACHINE SCREW M3X10 (10 PCS.) HIT-949204.A0 949204	£1.67	£2.00
421 - SPRING WASHER M3 (10 PCS.) HIT-949451.A11 949451	£1.67	£2.00
422 - V-BELT (B) (B-64) FOR 3.7KW HIT-978901.A0 978901	-
423 - SCALE HIT-988537.A0 988537	-
424 - SPRING WASHER M4 (10 PCS.) HIT-949453.A23 949453	£1.67	£2.00
425 - STABILIZER HOLDER (A) HIT-988499.A0 988499	-
426 - STABILIZER HOLDER (B) HIT-988500.A0 988500	-
427 - UPPER SAW COVER (A) HIT-988504.A0 988504	-
428 - LOWER SAW COVER (A) HIT-988505.A0 988505	-
429 - MACHINE SCREW M6X10 (10 PCS.) HIT-949254.A0 949254	-
430 - SPRING WASHER M6 (10 PCS.) HIT-949455.A30 949455	£1.67	£2.00
451 - LED-PRINTED CIRCUIT BOARD HIT-988513.A0 988513	-
452 - CABLE TIE HIT-975144.A14 975144	-
453 - CONNECTOR SOCKET (B) HIT-988514.A0 988514	-
454 - MACHINE SCREW M4X10 (10 PCS.) HIT-949216.A39 949216	£1.67	£2.00
455 - SPRING WASHER M4 (10 PCS.) HIT-949453.A17 949453	£1.67	£2.00
456 - WASHER M4 (10 PCS.) HIT-949423.A62 949423	£1.67	£2.00
457 - CLAMP (DKN-10) HIT-974239.A0 974239	-
458 - CLAMP (DKN-13) HIT-974255.A1 974255	-
459 - CONNECTOR SOCKET (D) HIT-975450.A0 975450	-
460 - CONNECTOR SOCKET (C) HIT-975451.A0 975451	-
461 - CORD LOCK (NC-2) HIT-974266.A0 974266	-
462 - FUSE HOLDER HIT-972172.A0 972172	-
463 - FUSE HIT-976269.A0 976269	-
464 - COLLAR HIT-974232.A0 974232	-
465 - RELAY BASE HIT-988552.A0 988552	-
466 - NUT M3 (10 PCS.) HIT-949553.A13 949553	£1.67	£2.00
467 - CLAMP (DKN-16) HIT-974238.A0 974238	-
468 - MACHINE SCREW M3X6 (10 PCS.) HIT-949202.A9 949202	-
469 - SPRING WASHER M3 (10 PCS.) HIT-949451.A13 949451	£1.67	£2.00
470 - MACHINE SCREW (W/SP. WASHER) M3X20 HIT-975588.A0 975588	-
471 - MAIN SWITCH HIT-988567.A0 988567	-
472 - FILTER HIT-988551.A0 988551	-
473 - SPRING WASHER M4 (10 PCS.) HIT-949453.A16 949453	£1.67	£2.00
474 - MACHINE SCREW M4X10 (10 PCS.) HIT-949216.A40 949216	£1.67	£2.00
475 - TRANSFORMER ASS'Y HIT-988573.A0 988573	-
476 - MACHINE SCREW M4X10 (10 PCS.) HIT-949216.A41 949216	£1.67	£2.00
477 - SPRING WASHER M4 (10 PCS.) HIT-949453.A21 949453	£1.67	£2.00
478 - TIMER TERMINAL HIT-975445.A0 975445	-
479 - MACHINE SCREW M4X16 (10 PCS.) HIT-949219.A3 949219	-
480 - SPRING WASHER M4 (10 PCS.) HIT-949453.A18 949453	£1.67	£2.00
481 - WASHER M4 (10 PCS.) HIT-949423.A61 949423	£1.67	£2.00
482 - CORD LOCK (NC-1) HIT-974265.A0 974265	-
483 - RELAY HIT-988574.A0 988574	-
484 - MACHINE SCREW M4X20 (10 PCS.) HIT-949221.A5 949221	£1.67	£2.00
485 - SPRING WASHER M4 (10 PCS.) HIT-949453.A19 949453	£1.67	£2.00
486 - TERMINAL PLATE (A) HIT-966585.A1 966585	-
487 - MACHINE SCREW M4X16 (10 PCS.) HIT-949219.A4 949219	-
488 - SPRING WASHER M4 (10 PCS.) HIT-949453.A20 949453	£1.67	£2.00
489 - LABEL (A) HIT-988568.A0 988568	-
490 - ACRYLIC PLATE HIT-988503.A0 988503	-
491 - MACHINE SCREW M3X6 (10 PCS.) HIT-949202.A8 949202	-
492 - SPRING WASHER M3 (10 PCS.) HIT-949451.A14 949451	£1.67	£2.00
493 - LED-PACKING HIT-974188.A0 974188	-
494 - LABEL (D) HIT-988576.A0 988576	-
495 - LABEL (E) HIT-988570.A0 988570	-
496 - LABEL (C) HIT-988569.A0 988569	-
497 - LABEL (B) HIT-988575.A0 988575	-
498 - CONSOLE BOX HIT-988560.A0 988560	-
499 - CLEAR SWITCH HIT-974222.A0 974222	-
502 - MOMENTARY SWITCH (RED) HIT-988534.A0 988534	-
503 - MOMENTARY SWITCH (GREEN) HIT-988535.A0 988535	-
504 - CLAMP (DKN-13) HIT-974255.A0 974255	-
505 - TIMER HIT-988840.A0 988840	-
506 - TABLE PLATE HIT-974121.A0 974121	-
507 - LAMP (18V 1W) HIT-988978.A0 988978	-
601 - WRENCH 10/13MM HIT-972043.A1 972043	£7.22	£8.66
602 - WRENCH 17/19MM HIT-974254.A0 974254	£8.08	£9.69
603 - HEX. BAR WRENCH 6MM HIT-872422.A28 872422	£1.67	£2.00
604 - HEX. BAR WRENCH 8MM HIT-955857.A1 955857	£4.96	£5.95
605 - BOX WRENCH 13MM HIT-966821.A1 966821	-
701 - MITER GAUGE HIT-948583.A1 948583	-
702 - BAND SAW BLADE (A) (STELLITE TIP) HIT-974100.A1 974100	-

Attribute Name	Value
Brand	Hikoki

Reviews Write your own review!

There are currently no reviews of this product.

Fill in the form below to add your review for Hitachi / Hikoki CB100FA Band Saw Spare Parts

Your Review
Title Required!
Rating Required!
Your Review Required!
Your Details
Your Name Required!
Your Location Required!
Email Address Required!Invalid email!

United Kingdom (Including N. Ireland)

On orders up to £40.00	Add £4.00 inc VAT (Royal Mail post)
On orders £40.00 to £130.00	Add £7.00 inc VAT (Courier)
On orders over £130.00	FREE (Courier)
