4 - AIR-DEFLECTOR RING
BSD-1600502005.A163
1600502005
|
£2.61
|
£3.13
|
|
|
5 - ROTOR
BSD-3604080020.A126
3604080020
|
-
|
|
|
|
5/3 - FAN
BSD-1606610105.A164
1606610105
|
£15.65
|
£18.78
|
|
|
6 - GROOVE BALL BEARING 5x16x5
BSD-1900900232.A9
1900900232
|
£16.74
|
£20.09
|
|
|
7 - RUBBER RING 6MM.dia12xdia16.4x3MM
BSD-3600206002.A149
3600206002
|
-
|
|
|
|
8 - BALL BEARING 7x22x7
BSD-1900905018.A385
1900905018
|
£19.91
|
£23.89
|
|
|
13 - SOCKET-TERMINAL STRIP 1x1.5 MM/2
BSD-1901091012.A78
1901091012
|
£5.57
|
£6.68
|
|
|
14 - ON-OFF SWITCH
BSD-1607200040.A64
1607200040
|
-
|
|
|
|
15 - POWER SUPPLY CORD
BSD-3604462058.A25
3604462058
|
-
|
|
|
|
16 - GROMMET dia9.2-dia12x120 MM
BSD-3600703011.A387
3600703011
|
£2.94
|
£3.53
|
|
|
17 - FASTENING CLAMP
BSD-1601302014.A136
1601302014
|
£2.74
|
£3.29
|
|
|
18 - HANDLE
BSD-3605132045.A4
3605132045
|
-
|
|
|
|
21 - O-RING 12x2 MM
BSD-1900210009.A28
1900210009
|
-
|
|
|
|
23 - DRIVE SHAFT
BSD-2603124066.A7
2603124066
|
-
|
|
|
|
23/1 - DRIVER PIN
BSD-2603122033.A2
2603122033
|
-
|
|
|
|
24 - CYLINDRICAL GEAR Z=42
BSD-2606325003.A20
2606325003
|
-
|
|
|
|
25 - RETAINING RING
BSD-1600224025.A8
1600224025
|
£2.61
|
£3.13
|
|
|
26 - PLAIN WASHER
BSD-2600101513.A19
2600101513
|
£1.75
|
£2.10
|
|
|
27 - COMPRESSION SPRING
BSD-2604630000.A26
2604630000
|
-
|
|
|
|
28 - TWO-JAW DRILL JUCK M4-M12
BSD-2608573000.A8
2608573000
|
£134.16
|
£160.99
|
|
|
28/1 - CARRIER
BSD-1600328021.A2
1600328021
|
£71.84
|
£86.21
|
|
|
28/2 - COMPRESSION SPRING
BSD-1604617002.A8
1604617002
|
£2.94
|
£3.53
|
|
|
28/3 - SPRING RETAINER
BSD-1600506000.A1
1600506000
|
£8.49
|
£10.19
|
|
|
28/4 - CARRIER
BSD-1603219006.A8
1603219006
|
£121.96
|
£146.35
|
|
|
28/5 - STUD BOLT
BSD-1603502000.A25
1603502000
|
£22.60
|
£27.12
|
|
|
28/6 - CLAMPING JAWS M 12x1.5
BSD-1600390002.A7
1600390002
|
-
|
|
|
|
28/7 - CLAMPING JAWS M 12x1.5
BSD-1600390003.A26
1600390003
|
-
|
|
|
|
28/8 - STRAIGHT PIN
BSD-1613100012.A101
1613100012
|
£2.61
|
£3.13
|
|
|
29 - SPACER BUSHING
BSD-2600400023.A21
2600400023
|
-
|
|
|
|
30 - CYLINDRICAL GEAR Z=41
BSD-2606325004.A0
2606325004
|
-
|
|
|
|
31 - SHIM 0.5 MM
BSD-1600100631.A21
1600100631
|
£1.75
|
£2.10
|
|
|
32 - SHIM 0.50 MM
BSD-2600100613.A128
2600100613
|
£1.75
|
£2.10
|
|
|
33 - SPINDLE WITH GEAR Z=13/35
BSD-2606328900.A20
2606328900
|
-
|
|
|
|
34 - SPINDLE WITH GEAR Z=9/11
BSD-2606328901.A0
2606328901
|
-
|
|
|
|
36 - NAMEPLATE
BSD-3601106053.A924
3601106053
|
£5.57
|
£6.68
|
|
|
37 - GROOVED NAIL
BSD-3603133000.A656
3603133000
|
£2.61
|
£3.13
|
|
|
40 - CLAMPING SADDLE
BSD-3601321001.A213
3601321001
|
£3.72
|
£4.47
|
|
|
41 - SPRING WASHER dia4.2 MM
BSD-3600150006.A375
3600150006
|
£2.74
|
£3.29
|
|
|
42 - PAN HEAD SCREW DIN 85-AM4x10-MS
BSD-2910110120.A357
2910110120
|
£1.84
|
£2.21
|
|
|
43 - SOCKET HEAD CAP SCREW DIN 84-AM4x6-8.8
BSD-2910021116.A716
2910021116
|
£2.27
|
£2.72
|
|
|
44 - PAN HEAD SCREW DIN 85-AM4x8-4.8
BSD-2910091118.A30
2910091118
|
£1.84
|
£2.21
|
|
|
45 - TAPPING SCREW DIN 7971-ST3.9x16-F
BSD-2910211019.A472
2910211019
|
£1.84
|
£2.21
|
|
|
46 - SOCKET HEAD CAP SCREW DIN 84-AM4x18-5.8
BSD-2910011128.A12
2910011128
|
£1.84
|
£2.21
|
|
|
47 - HEX SOCKET HEAD CAP SCREW DIN 912-M 4x45-8.8
BSD-2910141140.A77
2910141140
|
£1.75
|
£2.10
|
|
|
48 - HEX SOCKET HEAD CAP SCREW
BSD-3603414001.A71
3603414001
|
-
|
|
|
|
49 - HEX SOCKET HEAD CAP SCREW DIN 912-M 4x12-8.8
BSD-2910141122.A234
2910141122
|
£2.27
|
£2.72
|
|
|
50 - SET SCREW
BSD-3603402000.A310
3603402000
|
£1.84
|
£2.21
|
|
|
51 - SOCKET HEAD CAP SCREW DIN 84-AM4x5-5.8
BSD-2910011115.A47
2910011115
|
£1.75
|
£2.10
|
|
|
52 - GRIPPING WEDGE dia 5x18 MM/3.6 MM
BSD-1603110000.A0
1603110000
|
-
|
|
|
|
52 - GRIPPING WEDGE dia 5x18 MM/3.0 MM
BSD-1603110003.A15
1603110003
|
-
|
|
|
|
52 - GRIPPING WEDGE dia 5x18 MM/3.3 MM
BSD-1603110004.A1
1603110004
|
-
|
|
|
|
56 - END SPLICE
BSD-3604477008.A354
3604477008
|
£1.75
|
£2.10
|
|
|
68 - BUSHING
BSD-2600322043.A26
2600322043
|
-
|
|
|
|
69 - BUSHING
BSD-2600300058.A28
2600300058
|
-
|
|
|
|
70 - BUSHING
BSD-3600328036.A26
3600328036
|
-
|
|
|
|
71 - RETAINING WASHER
BSD-3600190012.A132
3600190012
|
-
|
|
|
|
72 - COUNTERSUNK-HEAD SCREW DIN 963-M3x8-8.8
BSD-2910780050.A55
2910780050
|
-
|
|
|
|
73 - O-RING 8.0x1.0 MM
BSD-1600210045.A82
1600210045
|
£1.84
|
£2.21
|
|
|
74 - LOCATING RING
BSD-2600400026.A11
2600400026
|
-
|
|
|
|
75 - STRAIGHT PIN DIN 7-5h8x16-ST
BSD-2917500120.A3
2917500120
|
-
|
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A782
3601119236
|
£3.91
|
£4.69
|
|
|
700 - TAP CHUCK
BSD-3608502000.A9
3608502000
|
-
|
|
|
|
800 - MOTOR HOUSING
BSD-3605102022.A6
3605102022
|
-
|
|
|
|
809 - BEARING HOUSING
BSD-1605820179.A4
1605820179
|
-
|
|
|
|
810 - STATOR 200V/300HZ.135V/200HZ
BSD-1604229201.A42
1604229201
|
£431.32
|
£517.59
|
|
|
811 - GEAR HOUSING
BSD-2605806097.A12
2605806097
|
-
|
|
|
