2 - STATOR 265V/200HZ
BSD-3604229081.A0
3604229081
|
£481.43
|
£577.72
|
|
|
3/8 - GROOVE BALL BEARING 12x32x10
BSD-3600905119.A152
3600905119
|
£27.23
|
£32.68
|
|
|
4 - AIR-DEFLECTOR RING
BSD-3600209008.A54
3600209008
|
£8.67
|
£10.41
|
|
|
6 - GROOVE BALL BEARING
BSD-3600905095.A199
3600905095
|
£21.52
|
£25.83
|
|
|
7 - BEARING FLANGE
BSD-3605805009.A112
3605805009
|
£62.51
|
£75.01
|
|
|
14 - THREADED RING
BSD-3603344024.A246
3603344024
|
£17.22
|
£20.67
|
|
|
15 - O-RING 38.1x2.2 MM
BSD-1600210037.A106
1600210037
|
£2.74
|
£3.29
|
|
|
20 - THREAD-FORMING TAP. SCREW
BSD-2914451079.A10
2914451079
|
£2.61
|
£3.13
|
|
|
21 - THREAD-FORMING TAP. SCREW AM 6x80-ST
BSD-3603410007.A117
3603410007
|
£3.72
|
£4.47
|
|
|
23 - COMPRESSION SPRING
BSD-3604611019.A168
3604611019
|
£2.74
|
£3.29
|
|
|
27 - SEALING DISC
BSD-3600100049.A106
3600100049
|
£3.72
|
£4.47
|
|
|
28 - SEALING DISC
BSD-3600100048.A170
3600100048
|
£2.80
|
£3.36
|
|
|
60 - ELEC. CABLE W/CONNECTION
BSD-3604462017.A134
3604462017
|
£57.14
|
£68.57
|
|
|
61 - TAPPING SCREW BZ4.8x63 MM
BSD-1603435008.A72
1603435008
|
£1.32
|
£1.58
|
|
|
62 - TAPPING SCREW DIN 7971-BZ3.9x19
BSD-2910211020.A380
2910211020
|
£2.16
|
£2.59
|
|
|
63 - CABLE ROUTING
BSD-1602388027.A277
1602388027
|
£2.74
|
£3.29
|
|
|
64 - FASTENING CLAMP
BSD-3601303002.A20
3601303002
|
£2.74
|
£3.29
|
|
|
64 - FASTENING CLAMP
BSD-3601303004.A139
3601303004
|
£5.87
|
£7.04
|
|
|
65 - STORAGE LEDGE
BSD-1602388029.A339
1602388029
|
£1.84
|
£2.21
|
|
|
94 - SET SCREW DIN 915-M4x6-45H
BSD-2912081116.A375
2912081116
|
£2.61
|
£3.13
|
|
|
95 - NAMEPLATE
BSD-3601106053.A1227
3601106053
|
£5.57
|
£6.68
|
|
|
96 - MANUFACTURER'S NAMEPLATE
BSD-3601110047.A58
3601110047
|
£2.94
|
£3.53
|
|
|
97 - GROOVED NAIL DIN 1476-2x5 MM
BSD-3603133001.A348
3603133001
|
£2.61
|
£3.13
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A179
3601119236
|
£3.91
|
£4.69
|
|
|
103 - GRINDING SPINDLE
BSD-3606120009.A14
3606120009
|
£218.41
|
£262.09
|
|
|
105 - GROOVE BALL BEARING
BSD-3600905060.A61
3600905060
|
£22.60
|
£27.12
|
|
|
106 - GROOVE BALL BEARING
BSD-3600905058.A68
3600905058
|
£21.52
|
£25.83
|
|
|
108/1 - TOOTHED GEAR Z=30
BSD-3606300084.A3
3606300084
|
-
|
|
|
|
109 - TOOTHED GEAR Z=39
BSD-3606300083.A1
3606300083
|
-
|
|
|
|
110 - SPACER SLEEVE
BSD-3600700055.A4
3600700055
|
£31.64
|
£37.97
|
|
|
112 - O-RING 32.0x1.5 MM
BSD-3600210057.A63
3600210057
|
£2.61
|
£3.13
|
|
|
114 - THREADED RING
BSD-3603344024.A287
3603344024
|
£17.22
|
£20.67
|
|
|
115 - O-RING 33.0x2.5 MM
BSD-3600210050.A42
3600210050
|
£2.74
|
£3.29
|
|
|
117 - HEX SOCKET HEAD CAP SCREW DIN 912-M6x20-8.8
BSD-2910141201.A361
2910141201
|
£2.74
|
£3.29
|
|
|
118 - PLAIN WASHER
BSD-3600100043.A112
3600100043
|
£3.72
|
£4.47
|
|
|
119 - O-RING 79.0x1.78 MM
BSD-1600210033.A867
1600210033
|
£1.84
|
£2.21
|
|
|
123 - RETAINING RING 24x2 DIN9045-24
BSD-2916609112.A104
2916609112
|
£2.74
|
£3.29
|
|
|
650 - SINGLE-HEAD ENG. WRENCH SW32
BSD-2607950021.A31
2607950021
|
£27.23
|
£32.68
|
|
|
651 - PIN-TYPE FACE-WRENCH
BSD-2607950022.A38
2607950022
|
£31.64
|
£37.97
|
|
|
655 - PROTECTIVE COVER dia100 MM
BSD-3605510032.A28
3605510032
|
£188.33
|
£226.00
|
|
|
656 - CLAMPING-FLANGE
BSD-3605703089.A59
3605703089
|
£66.68
|
£80.01
|
|
|
656/10 - CLAMPING-FLANGE
BSD-3605703070.A21
3605703070
|
£93.88
|
£112.65
|
|
|
657 - CLAMPING RING
BSD-3605703074.A34
3605703074
|
£21.68
|
£26.01
|
|
|
657/10 - CLAMPING RING
BSD-3605703066.A12
3605703066
|
-
|
|
|
|
658 - RETAINING RING 24x2 DIN9045-24
BSD-2916609112.A105
2916609112
|
£2.74
|
£3.29
|
|
|
801 - MOTOR HOUSING GR.83
BSD-3605108158.A4
3605108158
|
-
|
|
|
|
803 - ROTOR
BSD-3604080024.A65
3604080024
|
£321.98
|
£386.38
|
|
|
810 - BEARING FLANGE
BSD-3607031292.A57
3607031292
|
£164.02
|
£196.83
|
|
|
810/020 - SPINDLE BEARING
BSD-3607031289.A1
3607031289
|
£481.43
|
£577.72
|
|
|
810/077 - SET OF EARTLING MATERIAL
BSD-3607031299.A142
3607031299
|
£8.67
|
£10.41
|
|
|
811 - FASTENING PARTS KIT
BSD-3607031288.A47
3607031288
|
£120.11
|
£144.13
|
|
|
823 - SPRING SET
BSD-3607031296.A135
3607031296
|
£17.22
|
£20.67
|
|
|
856 - SWITCH KIT
BSD-3607031295.A36
3607031295
|
-
|
|
|
|
858 - HANDLE
BSD-3607031297.A127
3607031297
|
£39.13
|
£46.96
|
|
|
859 - GROMMET
BSD-3607031550.A46
3607031550
|
£13.78
|
£16.54
|
|
