1 - MOTOR HOUSING
BSD-1605102035.A0
1605102035
|
-
|
|
|
|
2 - GROMMET
BSD-1600306000.A80
1600306000
|
£1.95
|
£2.34
|
|
|
3 - STATOR 265V/300HZ
BSD-1604229068.A6
1604229068
|
-
|
|
|
|
4 - SET SCREW
BSD-1603402003.A14
1603402003
|
-
|
|
|
|
5 - CYLINDRICAL GEAR Z=18
BSD-1606320007.A0
1606320007
|
-
|
|
|
|
6 - SHIM
BSD-1600101607.A3
1600101607
|
-
|
|
|
|
8 - SEAL RING
BSD-1600281002.A4
1600281002
|
-
|
|
|
|
9 - BEARING FLANGE
BSD-1605820026.A0
1605820026
|
-
|
|
|
|
10 - CENTERING SLEEVE
BSD-1600300022.A0
1600300022
|
-
|
|
|
|
11 - SPINDLE BEARING
BSD-1605806052.A0
1605806052
|
-
|
|
|
|
11/3 - SEALING DISK
BSD-1600108044.A2
1600108044
|
-
|
|
|
|
11/5 - SUPPORT DISC
BSD-1600103017.A3
1600103017
|
-
|
|
|
|
11/6 - O-RING 80x3 MM
BSD-1900210166.A4
1900210166
|
£5.30
|
£6.36
|
|
|
12 - GRINDING SPINDLE
BSD-1603052004.A3
1603052004
|
-
|
|
|
|
13 - GROOVE BALL BEARING 6204-Y DIN 625
BSD-1900900306.A30
1900900306
|
-
|
|
|
|
14 - TOOTHED LOCK WASHER V 5.3 DIN 6797
BSD-2916050006.A5
2916050006
|
-
|
|
|
|
15 - PLAIN WASHER
BSD-1600147003.A1
1600147003
|
-
|
|
|
|
16 - WOODRUFF KEY DIN 6888 3x5 ST60-2
BSD-1900023005.A14
1900023005
|
£1.32
|
£1.58
|
|
|
17 - WOODRUFF KEY DIN 6888-4x6.5-ST60-2K
BSD-1900023008.A1
1900023008
|
-
|
|
|
|
18 - CYLINDRICAL GEAR Z=32
BSD-1606320006.A0
1606320006
|
-
|
|
|
|
19 - PLAIN WASHER
BSD-1600147000.A3
1600147000
|
-
|
|
|
|
20 - COUNTERSUNK-HEAD SCREW DIN 63-AM5x15-8.8
BSD-2910501157.A3
2910501157
|
-
|
|
|
|
21 - SPACER RING
BSD-1600202009.A1
1600202009
|
-
|
|
|
|
22 - SPACER RING
BSD-1600201000.A3
1600201000
|
-
|
|
|
|
23 - THREADED RING
BSD-1603344005.A30
1603344005
|
£27.23
|
£32.68
|
|
|
24 - PROTECTIVE COVER dia 175 MM (5)
BSD-1605510017.A1
1605510017
|
-
|
|
|
|
27 - CLAMPING-FLANGE dia 85 MM
BSD-1605703008.A24
1605703008
|
-
|
|
|
|
28 - CONICAL SPRING WASHER
BSD-1600114007.A2
1600114007
|
-
|
|
|
|
29 - HEX NUT
BSD-1603300001.A4
1603300001
|
-
|
|
|
|
34 - HEX NUT DIN 934-M8-8-A
BSD-2915011009.A26
2915011009
|
£2.61
|
£3.13
|
|
|
35 - HANDLE
BSD-1605132024.A6
1605132024
|
-
|
|
|
|
36 - ON-OFF SWITCH
BSD-1607200017.A18
1607200017
|
£102.57
|
£123.08
|
|
|
37 - CONTROL LEVER
BSD-1602026015.A3
1602026015
|
-
|
|
|
|
38 - SEALING DISK dia18xdia10x4 MM
BSD-1600108024.A27
1600108024
|
£1.75
|
£2.10
|
|
|
39 - SEALING PLATE
BSD-1600009000.A10
1600009000
|
-
|
|
|
|
40 - SPRING LOCK WASHER DIN 128-A4-FST
BSD-2916690003.A471
2916690003
|
£1.75
|
£2.10
|
|
|
41 - SOCKET HEAD CAP SCREW DIN 84-AM4x12-8.8
BSD-2910021122.A743
2910021122
|
£2.16
|
£2.59
|
|
|
42 - HEX SOCKET HEAD CAP SCREW DIN 912-M6x40-8.8
BSD-2910141209.A9
2910141209
|
£2.61
|
£3.13
|
|
|
43 - SEALING PLATE
BSD-1600113003.A42
1600113003
|
£2.80
|
£3.36
|
|
|
44 - ELEC. CABLE W/CONNECTION
BSD-3604462043.A32
3604462043
|
£54.42
|
£65.30
|
|
|
45 - GROMMET dia11.5-dia15.0x150 MM
BSD-1600703009.A419
1600703009
|
£5.58
|
£6.70
|
|
|
46 - FASTENING CLAMP
BSD-1601302013.A336
1601302013
|
£1.75
|
£2.10
|
|
|
47 - PAN HEAD SCREW DIN 85-AM4x8-MS
BSD-2910110118.A189
2910110118
|
£1.75
|
£2.10
|
|
|
48 - PLAIN WASHER DIN 46 255-DPG 9
BSD-2916010409.A227
2916010409
|
-
|
|
|
|
49 - SPRING WASHER DIN 137-A4
BSD-1600150006.A7
1600150006
|
-
|
|
|
|
52 - NAMEPLATE
BSD-3601106053.A152
3601106053
|
£5.30
|
£6.36
|
|
|
53 - GROOVED NAIL DIN 1476-2x5 MM
BSD-3603133001.A690
3603133001
|
£2.61
|
£3.13
|
|
|
57 - SHIM 0.05 MM
BSD-1600102638.A129
1600102638
|
£3.34
|
£4.01
|
|
|
57 - SHIM 0.1 MM
BSD-1600102639.A105
1600102639
|
-
|
|
|
|
57 - SHIM 0.15 MM
BSD-1600102640.A129
1600102640
|
-
|
|
|
|
59 - SEAL RING
BSD-1600209005.A11
1600209005
|
-
|
|
|
|
60 - SPRING LOCK WASHER B 8 DIN 127
BSD-2916680009.A12
2916680009
|
-
|
|
|
|
61 - AIR-DEFLECTOR RING
BSD-1600151001.A1
1600151001
|
-
|
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A1769
3601119236
|
£3.72
|
£4.47
|
|
|
651 - SINGLE-HEAD ENG. WRENCH DIN 894 SW24
BSD-1907950513.A109
1907950513
|
£16.41
|
£19.69
|
|
|
652 - OFFSET SCREWDRIVER DIN 911;SW6
BSD-1907950007.A548
1907950007
|
£5.30
|
£6.36
|
|
|
752 - ON-OFF SWITCH
BSD-1607200006.A91
1607200006
|
£81.81
|
£98.17
|
|
|
752/1 - SOCKET HEAD CAP SCREW DIN 84-AM3x10-4.8
BSD-2910001052.A31
2910001052
|
£2.16
|
£2.59
|
|
|
752/2 - EXTENSION SPRING
BSD-1604650009.A56
1604650009
|
£1.75
|
£2.10
|
|
|
752/4 - PAN HEAD SCREW DIN 85-AM4x8-4.8
BSD-2910091118.A306
2910091118
|
£1.75
|
£2.10
|
|
|
752/7 - DETENT ROLLER
BSD-1603200007.A34
1603200007
|
-
|
|
|
|
753 - FIXING PLATE
BSD-3601023015.A168
3601023015
|
£21.68
|
£26.01
|
|
|
754 - SPRING LOCK WASHER DIN 128-A4-FST
BSD-2916690003.A472
2916690003
|
£1.75
|
£2.10
|
|
|
755 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A1735
2910021118
|
£1.75
|
£2.10
|
|
|
800 - ROTOR
BSD-1604081000.A0
1604081000
|
-
|
|
|
|
800/3 - FAN
BSD-1606610013.A2
1606610013
|
-
|
|
|
|
800/4 - COVER DISC
BSD-1600120004.A0
1600120004
|
-
|
|
|
|
800/5 - MAGNETO BALL BEARING E20T DIN 615
BSD-1900900117.A2
1900900117
|
-
|
|
|
|
800/6 - INTERMEDIATE RING
BSD-1600220009.A0
1600220009
|
-
|
|
|
|
800/7 - ANG. CONTACT BALL BEARING E15T DIN 615
BSD-1900900111.A10
1900900111
|
-
|
|
|
|
800/9 - SHIM 0.2 MM
BSD-1610101603.A41
1610101603
|
£1.75
|
£2.10
|
|
|
800/10 - SHIM
BSD-1100101600.A0
1100101600
|
-
|
|
|
|
800/13 - SHIM 0.10 MM
BSD-1200101606.A3
1200101606
|
-
|
|
|
|
802 - LIFTING EYE BOLT DIN 580-M 8
BSD-2912521237.A24
2912521237
|
£11.78
|
£14.13
|
|
|
803 - SPRING LOCK WASHER DIN 127-B12
BSD-2916680011.A34
2916680011
|
-
|
|
|
