2 - STATOR 200V/300HZ
BSD-1604229089.A9
1604229089
|
£410.78
|
£492.94
|
|
|
4 - CARRIER
BSD-1600320028.A13
1600320028
|
£37.27
|
£44.72
|
|
|
4/1 - STRAIGHT PIN 4 H 8x12 DIN 7
BSD-2917500095.A106
2917500095
|
£1.75
|
£2.10
|
|
|
5 - AIR-DEFLECTOR RING
BSD-1600209003.A5
1600209003
|
£8.13
|
£9.76
|
|
|
6 - CARRIER
BSD-1606442000.A10
1606442000
|
£5.58
|
£6.70
|
|
|
9 - GROMMET dia9.2-dia12x120 MM
BSD-3600703011.A331
3600703011
|
£2.80
|
£3.36
|
|
|
11 - SEALING PLATE
BSD-1600113003.A390
1600113003
|
£2.80
|
£3.36
|
|
|
12 - O-RING 45x3MM
BSD-1900210146.A154
1900210146
|
£4.26
|
£5.11
|
|
|
13 - SWITCH
BSD-1607200020.A14
1607200020
|
-
|
|
|
|
14 - FASTENING CLAMP
BSD-1601303003.A31
1601303003
|
£2.16
|
£2.59
|
|
|
17 - CONTROL LEVER
BSD-1602026030.A385
1602026030
|
£10.10
|
£12.12
|
|
|
17/8 - FELT WASHER
BSD-1600205008.A253
1600205008
|
£1.75
|
£2.10
|
|
|
18 - SPINDLE HOUSING
BSD-3605806109.A23
3605806109
|
£195.26
|
£234.31
|
|
|
18/1 - SEAL dia3x53 MM
BSD-1600703014.A22
1600703014
|
-
|
|
|
|
18/2 - SHRINKABLE TUBE
BSD-3600712004.A37
3600712004
|
-
|
|
|
|
20 - NAMEPLATE
BSD-3601106053.A854
3601106053
|
£5.30
|
£6.36
|
|
|
21 - SEAL RING
BSD-1600209006.A154
1600209006
|
£2.80
|
£3.36
|
|
|
22 - O-RING 20x2 MM
BSD-1900210118.A2
1900210118
|
£2.80
|
£3.36
|
|
|
23 - O-RING 25x2 MM
BSD-1900210124.A10
1900210124
|
£2.80
|
£3.36
|
|
|
24 - HEX SOCKET HEAD CAP SCREW DIN 912-M 5x25-8.8
BSD-2910141164.A140
2910141164
|
£2.16
|
£2.59
|
|
|
25 - THREAD-FORMING TAP. SCREW
BSD-3603435003.A45
3603435003
|
£2.80
|
£3.36
|
|
|
26 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A429
2910021118
|
£1.75
|
£2.10
|
|
|
28 - TAPPING SCREW DIN 7971-BZ2.9x13
BSD-2910211006.A272
2910211006
|
£1.75
|
£2.10
|
|
|
28/1 - SOCKET HEAD CAP SCREW DIN 84-AM3x8-8.8
BSD-2910021050.A82
2910021050
|
£1.75
|
£2.10
|
|
|
29 - SOCKET HEAD CAP SCREW
BSD-3603450008.A119
3603450008
|
£2.16
|
£2.59
|
|
|
30 - THREAD-FORMING TAP. SCREW
BSD-2914461403.A71
2914461403
|
£2.16
|
£2.59
|
|
|
33 - PLAIN WASHER DIN 433-3.2-ST 50
BSD-2916011005.A4
2916011005
|
£1.75
|
£2.10
|
|
|
34 - SPRING WASHER dia4.2 MM
BSD-3600150006.A194
3600150006
|
£2.61
|
£3.13
|
|
|
35 - CLAMPING SADDLE
BSD-3601321001.A272
3601321001
|
£3.72
|
£4.47
|
|
|
37 - SPRING WASHER dia4.2 MM
BSD-3600150006.A195
3600150006
|
£2.61
|
£3.13
|
|
|
40 - GROOVED NAIL DIN 1476-2x5 MM
BSD-3603133001.A123
3603133001
|
£2.61
|
£3.13
|
|
|
60 - SEALING CORD
BSD-1601014000.A322
1601014000
|
£2.80
|
£3.36
|
|
|
67 - SEALING PLATE
BSD-1602388006.A143
1602388006
|
£5.58
|
£6.70
|
|
|
68 - GROMMET
BSD-1600306001.A81
1600306001
|
£2.61
|
£3.13
|
|
|
69 - O-RING 22.0x1.5 MM
BSD-3600210016.A128
3600210016
|
£1.75
|
£2.10
|
|
|
70 - GROOVE BALL BEARING
BSD-3608871307.A7
3608871307
|
£31.64
|
£37.97
|
|
|
71 - SPACER RING
BSD-3600120015.A28
3600120015
|
£18.96
|
£22.75
|
|
|
72 - GRINDING SPINDLE
BSD-1603123011.A8
1603123011
|
£179.37
|
£215.24
|
|
|
73 - GROOVE BALL BEARING
BSD-3600905063.A67
3600905063
|
£23.86
|
£28.63
|
|
|
74 - THREADED RING
BSD-3603344059.A40
3603344059
|
£39.17
|
£47.00
|
|
|
75 - CARRIER
BSD-1600320028.A12
1600320028
|
£37.27
|
£44.72
|
|
|
75/1 - STRAIGHT PIN 4 H 8x12 DIN 7
BSD-2917500095.A105
2917500095
|
£1.75
|
£2.10
|
|
|
76 - SPACER RING
BSD-1600202016.A30
1600202016
|
£5.30
|
£6.36
|
|
|
77 - SPRING RETAINING RING DIN 471-12x1-FSTM
BSD-2916650903.A44
2916650903
|
£1.75
|
£2.10
|
|
|
78 - COLLET dia6 MM
BSD-1608570025.A55
1608570025
|
£37.27
|
£44.72
|
|
|
81 - ROTOR WITHOUT WINDING
BSD-3604080055.A6
3604080055
|
£218.41
|
£262.09
|
|
|
81/3 - FAN
BSD-3606610010.A15
3606610010
|
£4.26
|
£5.11
|
|
|
82 - CONICAL SPRING WASHER
BSD-1600501025.A5
1600501025
|
£33.74
|
£40.49
|
|
|
83 - BEARING FLANGE
BSD-3605820065.A7
3605820065
|
£68.42
|
£82.10
|
|
|
84 - SOCKET HEAD CAP SCREW DIN 84-AM4x18-5.8
BSD-2910011128.A24
2910011128
|
£1.75
|
£2.10
|
|
|
85 - GROOVE BALL BEARING 12x28x8
BSD-1900905121.A49
1900905121
|
£18.96
|
£22.75
|
|
|
86 - GROOVE BALL BEARING 7x22x7
BSD-1610900025.A193
1610900025
|
£16.41
|
£19.69
|
|
|
87 - END SPLICE
BSD-3604477008.A456
3604477008
|
£1.75
|
£2.10
|
|
|
90 - NEEDLE-ROLLER BEARING
BSD-1600910002.A41
1600910002
|
£23.86
|
£28.63
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A742
3601119236
|
£3.72
|
£4.47
|
|
|
102 - SET SCREW
BSD-1603402002.A283
1603402002
|
£1.75
|
£2.10
|
|
|
651 - SINGLE-HEAD ENG. WRENCH DIN 894 SW 12
BSD-1907950506.A92
1907950506
|
£13.12
|
£15.75
|
|
|
652 - SINGLE-HEAD ENG. WRENCH DIN 894 SW 15
BSD-1907950509.A53
1907950509
|
£13.12
|
£15.75
|
|
|
801 - MOTOR HOUSING
BSD-3605102040.A21
3605102040
|
£218.41
|
£262.09
|
|
|
808 - HANDLE
BSD-3605132048.A309
3605132048
|
£63.50
|
£76.20
|
|
|
810 - ELEC. CABLE W/CONNECTION
BSD-3607030236.A119
3607030236
|
£61.98
|
£74.38
|
|
|
813 - SWITCH KIT
BSD-1607000036.A9
1607000036
|
-
|
|
|
|
818 - SPINDLE BEARING
BSD-1605806202.A4
1605806202
|
£500.46
|
£600.55
|
|
|
867 - SEALING PLATE
BSD-1602388007.A19
1602388007
|
£12.04
|
£14.45
|
|
|
872 - GRINDING SPINDLE
BSD-3603123017.A23
3603123017
|
£251.67
|
£302.00
|
|
