2 - SEAL RING
BSD-1600209011.A22
1600209011
|
£2.94
|
£3.53
|
|
|
4 - AIR-DEFLECTOR RING
BSD-1600502005.A365
1600502005
|
£2.61
|
£3.13
|
|
|
5 - ROTOR
BSD-3604080020.A26
3604080020
|
-
|
|
|
|
5/3 - FAN
BSD-1606610105.A19
1606610105
|
£15.65
|
£18.78
|
|
|
6 - GROOVE BALL BEARING 625-2Z DIN 625
BSD-1900905015.A300
1900905015
|
£30.42
|
£36.51
|
|
|
7 - O-RING 12.0x2.25 MM
BSD-3600210039.A154
3600210039
|
£7.36
|
£8.83
|
|
|
7/1 - RUBBER RING 6MM.dia12xdia16.4x3MM
BSD-3600206002.A63
3600206002
|
-
|
|
|
|
8 - GROOVE BALL BEARING 9x24x7
BSD-1900905017.A59
1900905017
|
£23.86
|
£28.63
|
|
|
9 - BEARING HOUSING
BSD-3605820046.A4
3605820046
|
-
|
|
|
|
11 - HANDLE
BSD-3605132044.A12
3605132044
|
-
|
|
|
|
12 - ELEC. CABLE W/CONNECTION
BSD-3604462049.A25
3604462049
|
-
|
|
|
|
13 - GROMMET dia9.2-dia12x120 MM
BSD-3600703011.A1145
3600703011
|
£2.94
|
£3.53
|
|
|
14 - FASTENING CLAMP
BSD-1601302014.A786
1601302014
|
£2.74
|
£3.29
|
|
|
15 - CONNECTION HOUSING
BSD-3600099005.A20
3600099005
|
£16.41
|
£19.69
|
|
|
16 - REVERSING SWITCH
BSD-1607200043.A28
1607200043
|
-
|
|
|
|
17 - SWITCH
BSD-1607200038.A68
1607200038
|
£57.14
|
£68.57
|
|
|
18 - DISC SPRING
BSD-3600150013.A104
3600150013
|
£3.91
|
£4.69
|
|
|
19 - SEALING CAP
BSD-3605500071.A30
3605500071
|
£17.22
|
£20.67
|
|
|
20 - GEAR HOUSING
BSD-2605806227.A32
2605806227
|
-
|
|
|
|
21 - SPINDLE WITH GEAR Z=37
BSD-2606100052.A10
2606100052
|
-
|
|
|
|
22 - BALL DIN 5401-3 MM-III-ST
BSD-1903230004.A33
1903230004
|
£2.27
|
£2.72
|
|
|
23 - COUPLING HALF
BSD-2606445000.A62
2606445000
|
-
|
|
|
|
24 - COMPRESSION SPRING
BSD-1604616010.A42
1604616010
|
-
|
|
|
|
25 - COMPRESSION SPRING
BSD-1604619005.A72
1604619005
|
-
|
|
|
|
26 - SHIM
BSD-1600100607.A33
1600100607
|
-
|
|
|
|
27 - BUSHING
BSD-1600309004.A8
1600309004
|
-
|
|
|
|
28 - ROUND NUT
BSD-1603341000.A41
1603341000
|
-
|
|
|
|
29 - GUIDE SLEEVE
BSD-2600460001.A44
2600460001
|
-
|
|
|
|
30 - CARRIER 6 KT.. 6.3 MM
BSD-2606455002.A33
2606455002
|
-
|
|
|
|
31 - O-RING 8.0x1.5 MM
BSD-1900210103.A17
1900210103
|
£2.94
|
£3.53
|
|
|
32 - PRESSURE SPINDLE
BSD-1603120022.A73
1603120022
|
-
|
|
|
|
33 - COMPRESSION SPRING
BSD-1604626002.A36
1604626002
|
-
|
|
|
|
34 - TOOTHED SHAFT Z=11/34
BSD-2606100051.A13
2606100051
|
-
|
|
|
|
35 - SPINDLE WITH GEAR Z=18/35
BSD-2606100050.A1
2606100050
|
-
|
|
|
|
36 - SHIM 0.50 MM
BSD-2600100613.A259
2600100613
|
£1.75
|
£2.10
|
|
|
37 - SPRING LOCK WASHER
BSD-1600224011.A89
1600224011
|
-
|
|
|
|
38 - BALL DIN 5401-2.5MM-III-ST
BSD-1903230003.A504
1903230003
|
£2.74
|
£3.29
|
|
|
39 - NAMEPLATE
BSD-3601106053.A334
3601106053
|
£5.57
|
£6.68
|
|
|
40 - GROOVED NAIL
BSD-3603133000.A129
3603133000
|
£2.61
|
£3.13
|
|
|
41 - SPRING WASHER DIN 137-A5-ST
BSD-2916069006.A0
2916069006
|
-
|
|
|
|
42 - SPRING WASHER A 3 DIN 137-ST
BSD-2916060003.A239
2916060003
|
£1.32
|
£1.58
|
|
|
43 - PLAIN WASHER DIN 46 255-DPG 9
BSD-2916010409.A266
2916010409
|
-
|
|
|
|
44 - SPRING WASHER DIN 137-A4
BSD-1600150006.A82
1600150006
|
-
|
|
|
|
45 - PAN HEAD SCREW DIN 85 AM 4x6-MS
BSD-2910110116.A106
2910110116
|
£1.84
|
£2.21
|
|
|
46 - PAN HEAD SCREW DIN 85-AM3.5x15-4.8
BSD-2910091046.A143
2910091046
|
£1.84
|
£2.21
|
|
|
47 - SOCKET HEAD CAP SCREW DIN 84-AM4x6-8.8
BSD-2910021116.A33
2910021116
|
£2.27
|
£2.72
|
|
|
48 - HEX SOCKET HEAD CAP SCREW DIN 912-M 4x12-8.8
BSD-2910141122.A20
2910141122
|
£2.27
|
£2.72
|
|
|
49 - SOCKET HEAD CAP SCREW DIN 84-AM4x12-8.8
BSD-2910021122.A758
2910021122
|
£2.27
|
£2.72
|
|
|
50 - HEX SOCKET HEAD CAP SCREW DIN 912-M 4x22-8.8
BSD-2910141131.A22
2910141131
|
£2.16
|
£2.59
|
|
|
51 - HEX SOCKET HEAD CAP SCREW DIN 912-M 4x45-8.8
BSD-2910141140.A151
2910141140
|
£1.75
|
£2.10
|
|
|
52 - HEX SOCKET HEAD CAP SCREW
BSD-3603414001.A3
3603414001
|
-
|
|
|
|
53 - SOCKET HEAD CAP SCREW DIN 84-AM5x20-5.8
BSD-2910011162.A121
2910011162
|
£1.84
|
£2.21
|
|
|
54 - SET SCREW
BSD-3603402000.A238
3603402000
|
£1.84
|
£2.21
|
|
|
69 - BUSHING
BSD-2600300058.A95
2600300058
|
-
|
|
|
|
71 - RETAINING WASHER
BSD-3600190012.A10
3600190012
|
-
|
|
|
|
72 - COUNTERSUNK-HEAD SCREW DIN 963-M3x8-8.8
BSD-2910780050.A97
2910780050
|
-
|
|
|
|
73 - O-RING 8.0x1.0 MM
BSD-1600210045.A158
1600210045
|
£1.84
|
£2.21
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A1619
3601119236
|
£3.91
|
£4.69
|
|
|
651 - SINGLE-HEAD ENG. WRENCH DIN 894 SW 12
BSD-1907950506.A13
1907950506
|
£13.78
|
£16.54
|
|
|
652 - STRAIGHT PIN 4x60 MM
BSD-2603101035.A92
2603101035
|
£2.94
|
£3.53
|
|
|
800 - MOTOR HOUSING
BSD-3605102028.A31
3605102028
|
£156.22
|
£187.46
|
|
|
801 - CARRIER
BSD-3606455019.A9
3606455019
|
-
|
|
|
|
809 - BEARING HOUSING
BSD-1605820162.A47
1605820162
|
-
|
|
|
|
810 - STATOR 72V/300HZ
BSD-1604229203.A13
1604229203
|
-
|
|
|
