1 - MOTOR HOUSING
BSD-3605102044.A15
3605102044
|
£218.41
|
£262.09
|
|
|
3 - ROTOR WITHOUT WINDING
BSD-3604080023.A3
3604080023
|
-
|
|
|
|
3/3 - FAN
BSD-1606610105.A48
1606610105
|
£15.65
|
£18.78
|
|
|
4 - SWITCH
BSD-3607200004.A4
3607200004
|
£65.08
|
£78.10
|
|
|
5 - ELEC. CABLE W/CONNECTION
BSD-3604462050.A7
3604462050
|
£28.59
|
£34.31
|
|
|
6 - GROMMET dia9.2-dia12x120 MM
BSD-3600703011.A1273
3600703011
|
£2.94
|
£3.53
|
|
|
7 - FASTENING CLAMP
BSD-1601302014.A695
1601302014
|
£2.74
|
£3.29
|
|
|
8 - NAMEPLATE
BSD-3601106053.A18
3601106053
|
£5.57
|
£6.68
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-1601110483.A180
1601110483
|
£2.74
|
£3.29
|
|
|
13 - O-RING 12.0x2.25 MM
BSD-3600210039.A107
3600210039
|
£7.36
|
£8.83
|
|
|
14 - CYLINDRICAL GEAR Z=31
BSD-3606319014.A1
3606319014
|
-
|
|
|
|
15 - DISC SPRING
BSD-3600150013.A27
3600150013
|
£3.91
|
£4.69
|
|
|
16 - GROOVE BALL BEARING 625-2Z DIN 625
BSD-1900905015.A278
1900905015
|
£30.42
|
£36.51
|
|
|
17 - SEAL RING
BSD-1600209011.A131
1600209011
|
£2.94
|
£3.53
|
|
|
18 - AIR-DEFLECTOR RING
BSD-1600502005.A279
1600502005
|
£2.61
|
£3.13
|
|
|
19 - BEARING HOUSING
BSD-1605820196.A27
1605820196
|
£161.73
|
£194.08
|
|
|
19 - BEARING HOUSING
BSD-3605820066.A1
3605820066
|
-
|
|
|
|
21 - BALL BEARING 7x22x7
BSD-1900905018.A951
1900905018
|
£19.91
|
£23.89
|
|
|
22 - GEAR HOUSING
BSD-3605806106.A4
3605806106
|
-
|
|
|
|
23 - SPINDLE WITH GEAR Z=11
BSD-1606308017.A30
1606308017
|
-
|
|
|
|
24 - SHIM 0.50 MM
BSD-2600100613.A213
2600100613
|
£1.75
|
£2.10
|
|
|
25 - PRESSURE SPINDLE
BSD-1603203024.A41
1603203024
|
-
|
|
|
|
26 - CONTROL SHAFT
BSD-1603124099.A11
1603124099
|
-
|
|
|
|
27 - GUIDE BUSHING
BSD-1600521018.A23
1600521018
|
-
|
|
|
|
28 - COMPRESSION SPRING
BSD-1604616019.A5
1604616019
|
-
|
|
|
|
29 - BALL DIN 5401-3.5 MM-III-ST
BSD-1903230006.A429
1903230006
|
£2.27
|
£2.72
|
|
|
30 - RETAINING RING 10 DIN 9045
BSD-2916600006.A64
2916600006
|
£1.84
|
£2.21
|
|
|
31 - CYLINDRICAL GEAR Z=43
BSD-1606325021.A5
1606325021
|
-
|
|
|
|
32 - BALL DIN 5401-6 G28
BSD-1903230011.A17
1903230011
|
£2.74
|
£3.29
|
|
|
33 - COMPRESSION SPRING
BSD-1604612005.A15
1604612005
|
-
|
|
|
|
34 - BALL DIN 5401-8 MM III-ST
BSD-1903230014.A123
1903230014
|
£1.75
|
£2.10
|
|
|
35 - ROLLER
BSD-1603200019.A19
1603200019
|
-
|
|
|
|
36 - RETAINING SNAP RING
BSD-2600209018.A1
2600209018
|
-
|
|
|
|
37 - CARRIER
BSD-3606445022.A13
3606445022
|
-
|
|
|
|
38 - COUPLING HALF 6.3 MM
BSD-3606455029.A0
3606455029
|
£134.16
|
£160.99
|
|
|
39 - COMPRESSION SPRING
BSD-1604619015.A19
1604619015
|
£5.01
|
£6.01
|
|
|
40 - TAPER RING
BSD-1600250000.A7
1600250000
|
-
|
|
|
|
41 - THREADED BUSHING
BSD-3600364010.A14
3600364010
|
-
|
|
|
|
42 - BALL DIN 5401-3.5 MM-III-ST
BSD-1903230006.A428
1903230006
|
£2.27
|
£2.72
|
|
|
43 - HOLDING SPRING
BSD-3604682003.A57
3604682003
|
-
|
|
|
|
44 - SOCKET-TERMINAL STRIP 1x1.5 MM/2
BSD-1901091012.A294
1901091012
|
£5.57
|
£6.68
|
|
|
45 - SOCKET HEAD CAP SCREW DIN 84-AM4x6-8.8
BSD-2910021116.A166
2910021116
|
£2.27
|
£2.72
|
|
|
47 - HANDLE
BSD-3605132037.A3
3605132037
|
-
|
|
|
|
48 - CLAMPING SADDLE
BSD-3601321001.A784
3601321001
|
£3.72
|
£4.47
|
|
|
49 - SPRING WASHER dia4.2 MM
BSD-3600150006.A398
3600150006
|
£2.74
|
£3.29
|
|
|
50 - PAN HEAD SCREW DIN 85-AM4x10-MS
BSD-2910110120.A137
2910110120
|
£1.84
|
£2.21
|
|
|
51 - TORX OVAL-HEAD SCREW 4x20
BSD-2603490023.A1624
2603490023
|
£1.84
|
£2.21
|
|
|
52 - HEX SOCKET HEAD CAP SCREW DIN 912-M 4x45-8.8
BSD-2910141140.A99
2910141140
|
£1.75
|
£2.10
|
|
|
53 - SET SCREW
BSD-3603402000.A130
3603402000
|
£1.84
|
£2.21
|
|
|
54 - SOCKET HEAD CAP SCREW M3x10 MM
BSD-2603410023.A464
2603410023
|
-
|
|
|
|
55 - END SPLICE
BSD-3604477008.A113
3604477008
|
£1.75
|
£2.10
|
|
|
60 - O-RING 53.0x2.0 MM
BSD-3600210017.A101
3600210017
|
£3.72
|
£4.47
|
|
|
69 - BUSHING
BSD-2600300058.A140
2600300058
|
-
|
|
|
|
70 - CLAMP BUSHING
BSD-1600300081.A23
1600300081
|
-
|
|
|
|
71 - RETAINING WASHER
BSD-3600190012.A46
3600190012
|
-
|
|
|
|
72 - COUNTERSUNK-HEAD SCREW DIN 963-M3x8-8.8
BSD-2910780050.A130
2910780050
|
-
|
|
|
|
73 - O-RING 8.0x1.0 MM
BSD-1600210045.A198
1600210045
|
£1.84
|
£2.21
|
|
|
96 - MANUFACTURER'S NAMEPLATE
BSD-1601110483.A181
1601110483
|
£2.74
|
£3.29
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A1797
3601119236
|
£3.91
|
£4.69
|
|
|
651 - SLOTTED SCREWDRIVER
BSD-1607950037.A13
1607950037
|
£51.22
|
£61.47
|
|
|
700 - AUXILIARY HANDLE M14
BSD-1602025022.A793
1602025022
|
£13.41
|
£16.09
|
|
|
700 - AUXILIARY HANDLE M14. dia37x115 MM
BSD-1602025030.A186
1602025030
|
£19.91
|
£23.89
|
|
|
701 - SUPPORT CLAMP
BSD-3608040000.A37
3608040000
|
-
|
|
|
|
801 - GEAR HOUSING
BSD-3605806013.A22
3605806013
|
-
|
|
|
|
804 - SPINDLE WITH GEAR Z=31/11
BSD-3606328014.A4
3606328014
|
-
|
|
|
|
809 - BEARING HOUSING
BSD-3605820034.A0
3605820034
|
-
|
|
|
|
810 - STATOR 72V/200HZ.110V/300HZ
BSD-1604229202.A36
1604229202
|
£306.65
|
£367.98
|
|
