2 - STATOR 135V/200HZ.200V/300HZ
BSD-3604229109.A0
3604229109
|
£653.78
|
£784.53
|
|
|
3 - ROTOR
BSD-3604080070.A0
3604080070
|
£431.32
|
£517.59
|
|
|
3/8 - GROOVE BALL BEARING 12x32x10
BSD-3600905119.A198
3600905119
|
£27.23
|
£32.68
|
|
|
4 - AIR-DEFLECTOR RING
BSD-3600209006.A163
3600209006
|
£5.87
|
£7.04
|
|
|
6 - GROOVE BALL BEARING
BSD-3600905095.A8
3600905095
|
£21.52
|
£25.83
|
|
|
7 - BEARING FLANGE
BSD-3605805009.A5
3605805009
|
£62.51
|
£75.01
|
|
|
12 - FELT WASHER
BSD-3600205002.A36
3600205002
|
£2.61
|
£3.13
|
|
|
14 - THREADED RING
BSD-3603344024.A319
3603344024
|
£17.22
|
£20.67
|
|
|
15 - O-RING 38.1x2.2 MM
BSD-1600210037.A24
1600210037
|
£2.74
|
£3.29
|
|
|
20 - THREAD-FORMING TAP. SCREW
BSD-2914451079.A176
2914451079
|
£2.61
|
£3.13
|
|
|
21 - THREAD-FORMING TAP. SCREW
BSD-2914451080.A87
2914451080
|
£3.91
|
£4.69
|
|
|
27 - SEALING DISC
BSD-3600100049.A256
3600100049
|
£3.72
|
£4.47
|
|
|
28 - SEALING DISC
BSD-3600100048.A20
3600100048
|
£2.80
|
£3.36
|
|
|
59 - GROMMET dia12.8xdia13.5x100 MM
BSD-3600703003.A50
3600703003
|
£5.57
|
£6.68
|
|
|
60 - ELEC. CABLE W/CONNECTION
BSD-3604462017.A5
3604462017
|
£57.14
|
£68.57
|
|
|
61 - TAPPING SCREW C4.8x63 MM
BSD-1603435024.A43
1603435024
|
£1.75
|
£2.10
|
|
|
62 - TAPPING SCREW DIN 7971-BZ3.9x19
BSD-2910211020.A157
2910211020
|
£2.16
|
£2.59
|
|
|
63 - CABLE ROUTING
BSD-1602388027.A62
1602388027
|
£2.74
|
£3.29
|
|
|
64 - FASTENING CLAMP
BSD-3601303004.A208
3601303004
|
£5.87
|
£7.04
|
|
|
65 - STORAGE LEDGE
BSD-1602388029.A114
1602388029
|
£1.84
|
£2.21
|
|
|
66 - TAPPING SCREW DIN 7971-ST3.9x16-F
BSD-2910211019.A2001
2910211019
|
£1.84
|
£2.21
|
|
|
82 - STOPPER
BSD-1602002014.A2
1602002014
|
£2.94
|
£3.53
|
|
|
83 - THREAD-FORMING TAP. SCREW
BSD-1603435075.A8
1603435075
|
£2.16
|
£2.59
|
|
|
91 - SEAL RING
BSD-1600209004.A19
1600209004
|
£2.94
|
£3.53
|
|
|
94 - SET SCREW DIN 915-M4x6-45H
BSD-2912081116.A113
2912081116
|
£2.61
|
£3.13
|
|
|
95 - NAMEPLATE
BSD-3601106053.A433
3601106053
|
£5.57
|
£6.68
|
|
|
96 - MANUFACTURER'S NAMEPLATE
BSD-3601110047.A210
3601110047
|
£2.94
|
£3.53
|
|
|
97 - GROOVED NAIL DIN 1476-2x5 MM
BSD-3603133001.A408
3603133001
|
£2.61
|
£3.13
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A1045
3601119236
|
£3.91
|
£4.69
|
|
|
105 - NEEDLE BEARING
BSD-2600914018.A127
2600914018
|
£8.67
|
£10.41
|
|
|
107 - SEAL RING
BSD-1600290036.A118
1600290036
|
£2.27
|
£2.72
|
|
|
108/1 - PINION Z=17
BSD-3606309016.A0
3606309016
|
£98.57
|
£118.28
|
|
|
109/1 - CROWN GEAR Z=47
BSD-3606334058.A0
3606334058
|
£126.12
|
£151.34
|
|
|
113 - SHIM 0.1 MM
BSD-1600190022.A262
1600190022
|
£1.84
|
£2.21
|
|
|
113 - SHIM 0.15 MM
BSD-1600190020.A261
1600190020
|
£1.84
|
£2.21
|
|
|
113 - SHIM 0.3 MM
BSD-1600190021.A566
1600190021
|
£2.61
|
£3.13
|
|
|
119 - O-RING 79.0x1.78 MM
BSD-1600210033.A198
1600210033
|
£1.84
|
£2.21
|
|
|
120 - THREAD-FORMING TAP. SCREW
BSD-1603435076.A68
1603435076
|
£2.74
|
£3.29
|
|
|
651 - AUXILIARY HANDLE M14. dia37x115 MM
BSD-1602025030.A669
1602025030
|
£19.91
|
£23.89
|
|
|
652 - PIN-TYPE FACE-WRENCH
BSD-1607950061.A131
1607950061
|
£5.69
|
£6.83
|
|
|
653 - CLAMPING FLANGE dia22.3xdia42 MM
BSD-2605703014.A658
2605703014
|
£7.72
|
£9.27
|
|
|
653/20 - O-RING 20.35x1.78 MM
BSD-1600210039.A493
1600210039
|
£2.27
|
£2.72
|
|
|
655 - ROUND NUT M14
BSD-1603345043.A500
1603345043
|
£9.11
|
£10.93
|
|
|
657 - SINGLE-HEAD ENG. WRENCH SW17
BSD-2607950511.A631
2607950511
|
£4.48
|
£5.37
|
|
|
658 - PROTECTIVE COVER
BSD-1600A00XM0.A55
1600A00XM0
|
£22.76
|
£27.31
|
|
|
700/10 - AUXILIARY HANDLE
BSD-160202507H.A547
160202507H
|
£11.87
|
£14.24
|
|
|
700/20 - ADAPTER M8/M14
BSD-3603523013.A134
3603523013
|
£16.41
|
£19.69
|
|
|
801 - MOTOR HOUSING GR.810
BSD-3605108161.A36
3605108161
|
£205.02
|
£246.03
|
|
|
810 - GEAR HOUSING
BSD-3607020075.A121
3607020075
|
£188.33
|
£226.00
|
|
|
810/020 - BEARING FLANGE
BSD-3607031658.A1
3607031658
|
£59.53
|
£71.44
|
|
|
810/030 - GRINDING SPINDLE
BSD-3607031651.A8
3607031651
|
£57.14
|
£68.57
|
|
|
815 - SET OF EARTLING MATERIAL
BSD-3607031299.A270
3607031299
|
£8.67
|
£10.41
|
|
|
823 - SPRING SET
BSD-3607031296.A7
3607031296
|
£17.22
|
£20.67
|
|
|
856 - SWITCH KIT
BSD-3607031298.A5
3607031298
|
£85.90
|
£103.08
|
|
|
858 - HANDLE
BSD-3607031297.A240
3607031297
|
£39.13
|
£46.96
|
|
|
865/20 - ASSEMBLY OF SERVICE PARTS
BSD-3607030467.A18
3607030467
|
£22.76
|
£27.31
|
|
|
865/30 - FASTENING PARTS KIT
BSD-3607030290.A119
3607030290
|
£13.12
|
£15.75
|
|
