1 - MOTOR HOUSING
BSD-3609200078.A2
3609200078
|
-
|
|
|
|
3 - STATOR 72V/200HZ
BSD-3609200136.A0
3609200136
|
-
|
|
|
|
4 - SET SCREW DIN 417-M5x10-22H
BSD-2912050152.A3
2912050152
|
-
|
|
|
|
6 - ROTOR
BSD-3609200080.A2
3609200080
|
-
|
|
|
|
10 - SEAL RING
BSD-3609200081.A2
3609200081
|
-
|
|
|
|
11 - GEAR HOUSING
BSD-3609200082.A2
3609200082
|
-
|
|
|
|
12 - NEEDLE BEARING
BSD-3609200083.A2
3609200083
|
-
|
|
|
|
13 - SHIM
BSD-3609200084.A2
3609200084
|
-
|
|
|
|
14 - BEVEL-GEAR TRANSMISSION
BSD-3609200232.A3
3609200232
|
-
|
|
|
|
15 - DISC SPRING
BSD-3609200086.A2
3609200086
|
-
|
|
|
|
16 - GROOVE BALL BEARING
BSD-3609200087.A2
3609200087
|
-
|
|
|
|
17 - SPRING RETAINING RING
BSD-3609200088.A2
3609200088
|
-
|
|
|
|
18 - SPRING RETAINING RING DIN 472 35x1.5 MM
BSD-2916660014.A72
2916660014
|
£1.75
|
£2.10
|
|
|
19 - SHIM
BSD-3609200089.A2
3609200089
|
-
|
|
|
|
19 - SHIM
BSD-3609200090.A2
3609200090
|
-
|
|
|
|
20 - SPACER RING
BSD-3609200091.A2
3609200091
|
-
|
|
|
|
21 - GROOVE BALL BEARING
BSD-3609200092.A2
3609200092
|
-
|
|
|
|
22 - SPACER SLEEVE
BSD-3609200093.A2
3609200093
|
-
|
|
|
|
23 - CONNECTION PLATE
BSD-3609200094.A2
3609200094
|
-
|
|
|
|
24 - SOCKET HEAD CAP SCREW
BSD-3609200095.A2
3609200095
|
-
|
|
|
|
25 - DRIVE SHAFT
BSD-3609200096.A0
3609200096
|
-
|
|
|
|
27 - PARALLEL KEY
BSD-3609200098.A2
3609200098
|
-
|
|
|
|
28 - MANUFACTURER'S NAMEPLATE
BSD-3601110106.A2
3601110106
|
£5.87
|
£7.04
|
|
|
33 - SOCKET HEAD CAP SCREW
BSD-3609200099.A2
3609200099
|
-
|
|
|
|
34 - FLAT SEAL RING A 5x9 DIN 7603-CU
BSD-2916710601.A2
2916710601
|
-
|
|
|
|
35 - O-RING
BSD-3609200100.A2
3609200100
|
-
|
|
|
|
36 - SHIM
BSD-3609200101.A2
3609200101
|
-
|
|
|
|
36 - SHIM
BSD-3609200102.A2
3609200102
|
-
|
|
|
|
38 - PARALLEL KEY
BSD-3609200103.A2
3609200103
|
-
|
|
|
|
39 - CLAMPING-FLANGE
BSD-3609200104.A2
3609200104
|
-
|
|
|
|
40 - CLAMPING-FLANGE
BSD-3609200105.A2
3609200105
|
-
|
|
|
|
41 - STUD
BSD-3609200106.A2
3609200106
|
-
|
|
|
|
42 - LOCKING WASHER
BSD-3609200107.A2
3609200107
|
-
|
|
|
|
43 - HEX NUT DIN 934-M5-M-MS
BSD-2915010406.A2
2915010406
|
-
|
|
|
|
44 - PROTECTIVE COVER
BSD-3609200108.A2
3609200108
|
-
|
|
|
|
45 - REFERENCE PLATE
BSD-3609200109.A2
3609200109
|
-
|
|
|
|
46 - GROOVED NAIL
BSD-3609200222.A18
3609200222
|
-
|
|
|
|
47 - CLUTCH ELEMENT
BSD-3609200110.A2
3609200110
|
-
|
|
|
|
48 - PARALLEL KEY
BSD-3609200111.A2
3609200111
|
-
|
|
|
|
50 - INTERMEDIATE BEARING
BSD-3609200112.A2
3609200112
|
-
|
|
|
|
51 - GROOVE BALL BEARING 12x28x8
BSD-1900905121.A2
1900905121
|
£18.96
|
£22.75
|
|
|
52 - SEAL RING
BSD-3609200113.A2
3609200113
|
-
|
|
|
|
53 - THREADED RING
BSD-3609200114.A2
3609200114
|
-
|
|
|
|
54 - PARALLEL KEY DIN 6885-A3x3x12-ST50K
BSD-1902300022.A2
1902300022
|
-
|
|
|
|
56 - CLUTCH ELEMENT
BSD-3609200115.A2
3609200115
|
-
|
|
|
|
57 - GROOVE BALL BEARING 6000 Z DIN 625
BSD-1900905100.A80
1900905100
|
-
|
|
|
|
58 - PARALLEL KEY A 3x3x8 DIN 6885-ST
BSD-1902300020.A2
1902300020
|
-
|
|
|
|
59 - FAN
BSD-3609200116.A2
3609200116
|
-
|
|
|
|
61 - PLAIN WASHER A 6.4 DIN 9021-ST
BSD-2916010884.A2
2916010884
|
-
|
|
|
|
62 - HEX NUT M 6 DIN 985-8
BSD-2915060004.A4
2915060004
|
-
|
|
|
|
63 - SEAL
BSD-3609200117.A2
3609200117
|
-
|
|
|
|
64 - SPACER SLEEVE
BSD-3609200118.A2
3609200118
|
-
|
|
|
|
65 - OVAL-HEAD SCREW DIN 85-AM5x8-4.8
BSD-2910095150.A1
2910095150
|
-
|
|
|
|
66 - FAN HOUSING
BSD-3609200119.A2
3609200119
|
-
|
|
|
|
67 - HEX SOCKET HEAD CAP SCREW DIN 6912-M5x35-8.8
BSD-2910370168.A3
2910370168
|
-
|
|
|
|
68 - SPRING WASHER DIN 137-A5-FST
BSD-2916060006.A187
2916060006
|
£1.38
|
£1.66
|
|
|
69 - PAN HEAD SCREW DIN 85 AM 4x6-MS
BSD-2910110116.A215
2910110116
|
£1.84
|
£2.21
|
|
|
70 - HOUSING COVER
BSD-3609200120.A2
3609200120
|
-
|
|
|
|
71 - INSULATING PLATE
BSD-3609200121.A2
3609200121
|
-
|
|
|
|
74 - HEX SOCKET HEAD CAP SCREW DIN 6912-M5x20-8.8
BSD-2910370162.A3
2910370162
|
-
|
|
|
|
76 - NAMEPLATE
BSD-3601100004.A7
3601100004
|
-
|
|
|
|
78 - HEX SOCKET HEAD CAP SCREW DIN 6912-M5x16-8.8
BSD-2910370158.A7
2910370158
|
-
|
|
|
|
80 - PLAIN WASHER 15 DIN 433-ST
BSD-2916010021.A2
2916010021
|
-
|
|
|
|
81 - PIVOT PLATE
BSD-3609200122.A2
3609200122
|
-
|
|
|
|
83 - GROOVE BALL BEARING 15x35x11
BSD-1900905226.A24
1900905226
|
£27.23
|
£32.68
|
|
|
84 - SHIM
BSD-3609200123.A2
3609200123
|
-
|
|
|
|
84 - SHIM
BSD-3609200124.A2
3609200124
|
-
|
|
|
|
84 - SHIM
BSD-3609200125.A2
3609200125
|
-
|
|
|
|
85 - SPRING RETAINING RING DIN 472 35x1.5 MM
BSD-2916660014.A69
2916660014
|
£1.75
|
£2.10
|
|
|
86 - SEALING DISK
BSD-2916130023.A2
2916130023
|
-
|
|
|
|
90 - POWER SUPPLY CORD
BSD-3609200226.A0
3609200226
|
-
|
|
|
|
91 - PROTECTIVE SHEATH
BSD-3609200127.A2
3609200127
|
-
|
|
|
|
92 - HANDLE
BSD-3609200128.A2
3609200128
|
-
|
|
|
|
93 - ON-OFF SWITCH
BSD-3609200129.A2
3609200129
|
-
|
|
|
|
94 - CLAMPING PIECE
BSD-3609200006.A11
3609200006
|
-
|
|
|
|
95 - OVAL-HEAD SCREW DIN 85-AM3.5-16-4.8
BSD-2910090092.A1
2910090092
|
-
|
|
|
|
96 - SOCKET HEAD CAP SCREW DIN 84-AM5x35-4.8
BSD-2910005086.A3
2910005086
|
-
|
|
|
|
97 - FELT WASHER
BSD-3609200130.A2
3609200130
|
-
|
|
|
|
98 - CONTROL LEVER
BSD-3609200131.A2
3609200131
|
-
|
|
|
|
99 - OVAL-HEAD SCREW DIN 85-M3x16-4.8
BSD-2910095058.A3
2910095058
|
-
|
|
|
|
100 - CONNECTING CABLE
BSD-3609200132.A2
3609200132
|
-
|
|
|
|
101 - SEALING PLATE
BSD-3609200133.A2
3609200133
|
-
|
|
|
|
652 - OFFSET SCREWDRIVER DIN 911;SW6
BSD-1907950007.A365
1907950007
|
£5.57
|
£6.68
|
|
|
654 - SINGLE-HEAD ENG. WRENCH
BSD-2607950504.A65
2607950504
|
£2.64
|
£3.17
|
|
|
807 - OFFSET SCREWDRIVER DIN 911-4
BSD-2607950004.A456
2607950004
|
£1.84
|
£2.21
|
|
