Push the button for adjustment on the workpiece
Fine adjustment for optimum adaptation to different sizes of workpieces and a comfortable handle width
Self-locking on pipes and nuts: no slipping on the workpiece and low handforce required
Gripping surfaces with special hardened teeth, teeth hardness approx. 61 HRC: high wear resistance and stable gripping
Box-joint design for high stability due to double guide
Reliable catching of the hinge bolt: no unintentional shifting
Pinch guard prevents operators' fingers being pinched
Chrome vanadium electric steel, forged, multi stage oil-hardened

Article No.
87 01 300
EAN
4003773034087
Pliers
grey atramentized
Head
polished
Handles
with non-slip plastic coating
Weight
530 g
Dimensions
300 x 52 x 15 mm
Standard
DIN ISO 8976
REACH compliant
does not contain SVHC
RoHS compliant
not applicable
Adjustment positions
30
Kapazität für Rohre (Zoll)
Ø 2 3/4 Inch
Capacities for nuts
60 mm
Capacities for pipes (diameter)
Ø 70 mm
