9 - MANUFACTURER'S NAMEPLATE
BSD-2601119398.A5
2601119398
|
-
|
|
|
|
9 - REFERENCE PLATE
BSD-1601110125.A1
1601110125
|
-
|
|
|
|
20 - REFERENCE PLATE
BSD-2601119402.A15
2601119402
|
-
|
|
|
|
31 - PINION Z=10. dia2.3 MM
BSD-2606316175.A1
2606316175
|
-
|
|
|
|
31 - PINION Z=10. dia3.1 MM
BSD-2606316113.A5
2606316113
|
£2.80
|
£3.36
|
|
|
33 - ECCENTRIC COG WHEEL Z=85
BSD-2606334004.A5
2606334004
|
£3.99
|
£4.79
|
|
|
38 - CONTACT HOUSING
BSD-2608018002.A2
2608018002
|
-
|
|
|
|
40 - COVER STRIP
BSD-2602386000.A4
2602386000
|
-
|
|
|
|
46 - CONTACT SLEEVE
BSD-2600422003.A19
2600422003
|
-
|
|
|
|
52 - DAMPING PLATE 60x80x2 MM
BSD-2602388007.A16
2602388007
|
-
|
|
|
|
53 - WIPER
BSD-2602391002.A18
2602391002
|
-
|
|
|
|
54 - SOCKET HEAD CAP SCREW AM 2.6x8 MM
BSD-2603413030.A19
2603413030
|
-
|
|
|
|
54 - SOCKET HEAD CAP SCREW DIN 84-AM3x8-8.8
BSD-2910021050.A75
2910021050
|
£1.75
|
£2.10
|
|
|
55 - SCREW 4x16
BSD-2603490022.A2662
2603490022
|
£1.84
|
£2.21
|
|
|
56 - SPRING LOCK WASHER A3-FSt
BSD-2916690001.A146
2916690001
|
-
|
|
|
|
57 - STICKER
BSD-1601110317.A4
1601110317
|
-
|
|
|
|
58 - RECEPTACLE
BSD-1904478015.A15
1904478015
|
£1.32
|
£1.58
|
|
|
60 - PROTECTIVE CAP
BSD-2605510018.A9
2605510018
|
-
|
|
|
|
62 - STICKER
BSD-2601110999.A75
2601110999
|
£1.84
|
£2.21
|
|
|
63 - PROTECTIVE CAP
BSD-2605500141.A5
2605500141
|
-
|
|
|
|
64 - ADAPTER
BSD-2605719025.A1
2605719025
|
-
|
|
|
|
653 - POWER SUPPLY CORD 1.1m PVC
BSD-2604460107.A5
2604460107
|
-
|
|
|
|
799 - GUIDE BRACKET
BSD-2607001181.A18
2607001181
|
-
|
|
|
|
799/10/10 - MANUFACTURER'S NAMEPLATE
BSD-2601110601.A43
2601110601
|
-
|
|
|
|
799/650 - IMPELLER
BSD-1609200927.A2
1609200927
|
-
|
|
|
|
801 - UPPER HOUSING
BSD-2605104831.A8
2605104831
|
-
|
|
|
|
801 - UPPER HOUSING
BSD-2605104831.A9
2605104831
|
-
|
|
|
|
802 - DC MOTOR 18V
BSD-2607022960.A9
2607022960
|
-
|
|
|
|
802 - DC MOTOR 7.2V
BSD-1609200917.A9
1609200917
|
-
|
|
|
|
808 - NAMEPLATE
BSD-160111A3H4.A17
160111A3H4
|
-
|
|
|
|
825 - DC MOTOR 18V
BSD-2607022960.A8
2607022960
|
-
|
|
|
|
826 - HOUSING COVER
BSD-2605500906.A15
2605500906
|
-
|
|
|
|
826 - HOUSING COVER
BSD-1609200920.A2
1609200920
|
-
|
|
|
|
834 - SET OF KNIVES 100 MM
BSD-1609200908.A1
1609200908
|
-
|
|
|
|
841 - CHARGING TRANSFORMER 230V/4.8V
BSD-1609200915.A1
1609200915
|
-
|
|
|
|
845 - PARTS SET
BSD-2607010227.A15
2607010227
|
-
|
|
|
|
847 - CABLE
BSD-2604412900.A18
2604412900
|
-
|
|
|
|
850 - CONNECTING CABLE L=63 MM
BSD-2604412023.A1
2604412023
|
-
|
|
|
|
851 - BATTERY SET
BSD-1609200922.A5
1609200922
|
-
|
|
|
