2 - FIELD 220-230V
BSD-2604220429.A169
2604220429
|
£23.86
|
£28.63
|
|
|
3 - ARMATURE 230V
BSD-2604010870.A13
2604010870
|
-
|
|
|
|
3/60 - FAN
BSD-2606610068.A6
2606610068
|
-
|
|
|
|
4 - ON-OFF SWITCH
BSD-2607200291.A14
2607200291
|
-
|
|
|
|
5 - POWER SUPPLY CORD CH 0.4m 2 x 1.0mm H05 VV-F
BSD-1604460437.A24
1604460437
|
£7.36
|
£8.83
|
|
|
6 - GROMMET dia7 MM
BSD-2600703007.A40
2600703007
|
-
|
|
|
|
7 - CABLE CLIP
BSD-2601035001.A1335
2601035001
|
£1.75
|
£2.10
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-2601118195.A4
2601118195
|
-
|
|
|
|
12 - SUPPRESSION CAPACITOR
BSD-2607329133.A4
2607329133
|
-
|
|
|
|
13 - NEEDLE BEARING
BSD-2600917002.A43
2600917002
|
£3.72
|
£4.47
|
|
|
19 - SCREW 4x16
BSD-2603490022.A383
2603490022
|
£1.75
|
£2.10
|
|
|
20 - REFERENCE PLATE
BSD-2601118281.A2
2601118281
|
-
|
|
|
|
25 - GEAR HOUSING
BSD-2605806407.A19
2605806407
|
-
|
|
|
|
27 - AXLE
BSD-2603120038.A5
2603120038
|
-
|
|
|
|
29 - FREEWHEELING
BSD-2606490054.A8
2606490054
|
-
|
|
|
|
38/40 - THREAD-FORMING TAP. SCREW
BSD-2603413031.A57
2603413031
|
-
|
|
|
|
38/50 - THREAD-FORMING TAP. SCREW
BSD-2603413032.A9
2603413032
|
-
|
|
|
|
38/60 - CUPPED WASHER
BSD-2600200036.A13
2600200036
|
-
|
|
|
|
39 - COUNTERSUNK-HEAD SCREW TORX T25
BSD-2603421223.A13
2603421223
|
-
|
|
|
|
40 - CONTROL LEVER
BSD-2603239020.A18
2603239020
|
-
|
|
|
|
41 - SWITCH SLIDE
BSD-2603123020.A18
2603123020
|
-
|
|
|
|
42 - GEAR COVER
BSD-2605500121.A2
2605500121
|
-
|
|
|
|
43 - THREAD-FORMING TAP. SCREW M4x12 MM
BSD-2603410049.A109
2603410049
|
£1.75
|
£2.10
|
|
|
44 - SPRING RETAINING RING DIN 471 9x1MM
BSD-2916640006.A159
2916640006
|
£1.75
|
£2.10
|
|
|
46 - CRANK ROD
BSD-2603123021.A8
2603123021
|
-
|
|
|
|
47 - SHIM 0.2 MM
BSD-2600101614.A8
2600101614
|
-
|
|
|
|
47 - SHIM 0.3 MM
BSD-2600101654.A68
2600101654
|
£2.33
|
£2.80
|
|
|
49 - COMPRESSION SPRING
BSD-2604610029.A8
2604610029
|
-
|
|
|
|
50 - SHIFTER ROD
BSD-2608040060.A11
2608040060
|
-
|
|
|
|
51 - COMPRESSION SPRING
BSD-2604610027.A20
2604610027
|
-
|
|
|
|
52 - SWITCH SEGMENT
BSD-2608001011.A7
2608001011
|
-
|
|
|
|
53 - TORX OVAL-HEAD SCREW 4x20
BSD-2603490023.A1511
2603490023
|
£1.75
|
£2.10
|
|
|
54 - TORX OVAL-HEAD SCREW 4x25
BSD-2603490024.A183
2603490024
|
£1.75
|
£2.10
|
|
|
55 - BEARING SLEEVE
BSD-2600222002.A17
2600222002
|
-
|
|
|
|
56 - O-RING 5.0x1.5 MM
BSD-1900210000.A635
1900210000
|
£1.75
|
£2.10
|
|
|
57 - SPIRIT LEVEL
BSD-2607233010.A6
2607233010
|
-
|
|
|
|
58 - CONTACT SPRING
BSD-2601329057.A69
2601329057
|
-
|
|
|
|
59 - SPRING WASHER DIN 137-A5-FST
BSD-2916060006.A62
2916060006
|
£1.32
|
£1.58
|
|
|
60 - CONNECTING CABLE L=273 MM
BSD-2604448162.A74
2604448162
|
-
|
|
|
|
61 - CONNECTING CABLE L=88 MM
BSD-2604448034.A381
2604448034
|
£1.75
|
£2.10
|
|
|
62 - CONNECTING CABLE L=115 MM
BSD-2604448109.A16
2604448109
|
£1.75
|
£2.10
|
|
|
63 - OVAL-HEAD SCREW DIN 7985-M5x10-4.8
BSD-2910641152.A6
2910641152
|
-
|
|
|
|
66 - CLAMPING STRIP
BSD-2604490012.A84
2604490012
|
-
|
|
|
|
67 - STRAIGHT PIN
BSD-2609002714.A16
2609002714
|
£1.75
|
£2.10
|
|
|
68 - SUPPORT
BSD-2608005039.A4
2608005039
|
-
|
|
|
|
69 - SUPPORT
BSD-2608005040.A6
2608005040
|
-
|
|
|
|
70 - TAB WASHER
BSD-2601098019.A17
2601098019
|
-
|
|
|
|
701 - OIL SPRAY TIN
BSD-1609200399.A151
1609200399
|
£8.74
|
£10.49
|
|
|
702 - PROTECTIVE GLOVE
BSD-2607000134.A17
2607000134
|
-
|
|
|
|
753 - OIL RESERVOIR
BSD-2605411040.A15
2605411040
|
-
|
|
|
|
754 - STRAIN-RELIEF CLAMP
BSD-2601398012.A59
2601398012
|
-
|
|
|
|
765 - PROTECTIVE SHIELD
BSD-2607001151.A11
2607001151
|
-
|
|
|
|
801 - HOUSING SECTION
BSD-2605104836.A14
2605104836
|
-
|
|
|
|
814 - GROOVE BALL BEARING 9x24x7
BSD-2600905039.A208
2600905039
|
£12.04
|
£14.45
|
|
|
816 - BRUSH PLATE
BSD-2609992604.A19
2609992604
|
-
|
|
|
|
816/04 - CARBON-BRUSH SET
BSD-2604321917.A105
2604321917
|
-
|
|
|
|
816/06 - RATCHET CAP
BSD-2601322017.A124
2601322017
|
£1.75
|
£2.10
|
|
|
828 - SLIDING CLUTCH
BSD-2606490916.A20
2606490916
|
-
|
|
|
|
836 - ECCENTRIC
BSD-2602210901.A5
2602210901
|
-
|
|
|
|
838 - SET OF KNIVES 700 MM
BSD-2607001232.A3
2607001232
|
-
|
|
|
|
845 - SWITCHING ELEMENT
BSD-2601901003.A10
2601901003
|
-
|
|
|
|
864 - AUXILIARY HANDLE
BSD-2602025107.A17
2602025107
|
-
|
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A2061
160111A3H3
|
£2.61
|
£3.13
|
|
