2 - FIELD 230V
BSD-3604220069.A1
3604220069
|
-
|
|
|
|
5 - POWER SUPPLY CORD
BSD-1604460454.A3
1604460454
|
-
|
|
|
|
6 - GROMMET dia9.6-dia10.2x70 MM
BSD-1600703025.A45
1600703025
|
-
|
|
|
|
7 - CABLE CLIP
BSD-2601035001.A1476
2601035001
|
£1.75
|
£2.10
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-1601110483.A164
1601110483
|
£2.61
|
£3.13
|
|
|
12 - SUPPRESSION FILTER
BSD-1607328028.A479
1607328028
|
£5.30
|
£6.36
|
|
|
13 - BALL BEARING 7x19x6
BSD-2600905032.A1217
2600905032
|
£5.30
|
£6.36
|
|
|
14 - BALL BEARING 9x26x8
BSD-1900905025.A101
1900905025
|
£21.52
|
£25.83
|
|
|
16 - BRUSH HOLDER
BSD-3604336001.A12
3604336001
|
-
|
|
|
|
20 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A1273
2603410001
|
£1.75
|
£2.10
|
|
|
20 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A1274
2603410001
|
£1.75
|
£2.10
|
|
|
23 - SEALING CAP
BSD-3605500084.A52
3605500084
|
-
|
|
|
|
24 - PROTECTIVE SHIELD
BSD-3602311018.A42
3602311018
|
-
|
|
|
|
25 - GEAR COVER
BSD-3605500082.A4
3605500082
|
-
|
|
|
|
26 - PROTECTIVE COVER
BSD-3605500037.A38
3605500037
|
-
|
|
|
|
27 - COVER STRIP
BSD-3601012000.A28
3601012000
|
-
|
|
|
|
28 - INTERMEDIATE RING
BSD-1600502011.A164
1600502011
|
£2.61
|
£3.13
|
|
|
32 - CONICAL SPRING WASHER
BSD-3600190007.A37
3600190007
|
-
|
|
|
|
33 - INTERMEDIATE RING
BSD-1600206026.A50
1600206026
|
£1.75
|
£2.10
|
|
|
34 - ROTARY SHAFT LIP SEAL
BSD-1600290016.A61
1600290016
|
£2.61
|
£3.13
|
|
|
35 - INTERMEDIATE RING
BSD-1600300090.A136
1600300090
|
£3.72
|
£4.47
|
|
|
36 - CYLINDRICAL GEAR Z=41
BSD-3606317021.A29
3606317021
|
-
|
|
|
|
37 - NEEDLE BEARING dia8xdia12x8 MM
BSD-1600910018.A570
1600910018
|
£5.30
|
£6.36
|
|
|
38 - DRIVE SHAFT
BSD-3603124011.A36
3603124011
|
-
|
|
|
|
39 - HEADED BUSH
BSD-3600323000.A18
3600323000
|
-
|
|
|
|
41 - SPRING RETAINING RING DIN 471-12x1-FSt
BSD-2916650003.A308
2916650003
|
£1.75
|
£2.10
|
|
|
42 - ROTARY SHAFT LIP SEAL
BSD-1600283003.A77
1600283003
|
£4.26
|
£5.11
|
|
|
43 - OIL RESERVOIR
BSD-3607030320.A24
3607030320
|
-
|
|
|
|
47 - STUD BOLT
BSD-3603121004.A11
3603121004
|
-
|
|
|
|
48 - SWIVELLING LEVER
BSD-3601990001.A35
3601990001
|
-
|
|
|
|
55 - COILED SPRING
BSD-3604651002.A8
3604651002
|
£1.32
|
£1.58
|
|
|
56 - CONNECTING CABLE L=420 MM
BSD-3604431018.A16
3604431018
|
-
|
|
|
|
57 - CONNECTING CABLE L=180 MM
BSD-3604431012.A47
3604431012
|
-
|
|
|
|
58 - BLADE TERMINAL
BSD-1604477005.A158
1604477005
|
£2.61
|
£3.13
|
|
|
61 - HEX NUT DIN 934-M6-8-A
BSD-2915011007.A678
2915011007
|
-
|
|
|
|
62 - TAPPING SCREW DIN 7981-ST3.9x16-C-H
BSD-2910611019.A218
2910611019
|
£2.80
|
£3.36
|
|
|
63 - SOCKET HEAD CAP SCREW
BSD-3603410001.A32
3603410001
|
-
|
|
|
|
64 - HEX SOCKET HEAD CAP SCREW DIN 912-M6x25-8.8
BSD-2910141203.A83
2910141203
|
£1.75
|
£2.10
|
|
|
67 - TAPPING SCREW DIN 7971-B 3.9x19
BSD-2910211220.A131
2910211220
|
-
|
|
|
|
68 - THREAD-FORMING TAP. SCREW DIN 7500-CM 5x12-ST
BSD-2914411403.A35
2914411403
|
-
|
|
|
|
69 - COVER PLATE
BSD-3600000006.A53
3600000006
|
-
|
|
|
|
70 - SINTERED-METAL BUSHING J8G7x12r6x6DIN1850
BSD-1900301010.A22
1900301010
|
-
|
|
|
|
71 - HOSE
BSD-3600703001.A41
3600703001
|
-
|
|
|
|
72 - BALL DIN 5401-4 MM-III-ST
BSD-1903230007.A115
1903230007
|
£1.75
|
£2.10
|
|
|
74 - CONNECTING CABLE L=260 MM
BSD-3604431013.A13
3604431013
|
-
|
|
|
|
75 - COMPRESSION SPRING
BSD-3604630000.A8
3604630000
|
-
|
|
|
|
78 - OFFSET SCREWDRIVER DIN 911-SW5
BSD-1907950006.A14
1907950006
|
£4.26
|
£5.11
|
|
|
79 - REFERENCE PLATE
BSD-3601119081.A5
3601119081
|
-
|
|
|
|
80 - STICKER
BSD-3601119064.A1
3601119064
|
-
|
|
|
|
87 - PLAIN WASHER 0.5 MM
BSD-1600101023.A132
1600101023
|
£1.75
|
£2.10
|
|
|
88 - DETENT PIN
BSD-3603121003.A46
3603121003
|
-
|
|
|
|
90 - TAPPING SCREW DIN 7971-BZ2.9x13
BSD-2910211006.A452
2910211006
|
£1.75
|
£2.10
|
|
|
91 - OIL RESERVOIR
BSD-3607030320.A18
3607030320
|
-
|
|
|
|
92 - SINTERED-METAL BUSHING 14 MM
BSD-3600301007.A45
3600301007
|
£4.75
|
£5.70
|
|
|
650 - PROTECTIVE COVER
BSD-3605500038.A21
3605500038
|
-
|
|
|
|
745 - GUIDE RAIL 400 MM
BSD-3602317011.A1
3602317011
|
-
|
|
|
|
746 - SAW CHAIN 400 MM
BSD-3604730008.A7
3604730008
|
£30.28
|
£36.33
|
|
|
800 - CARBON-BRUSH SET
BSD-1607014129.A11
1607014129
|
-
|
|
|
|
801 - SPIRAL SPRING
BSD-2604652008.A56
2604652008
|
-
|
|
|
|
804 - ON-OFF SWITCH
BSD-1607000231.A38
1607000231
|
£18.96
|
£22.75
|
|
|
804 - ON-OFF SWITCH
BSD-1607200107.A15
1607200107
|
-
|
|
|
|
805 - MOTOR HOUSING
BSD-3605108137.A10
3605108137
|
-
|
|
|
|
812 - SUPPRESSION FILTER
BSD-1607328028.A476
1607328028
|
£5.30
|
£6.36
|
|
|
821 - HOUSING SECTION
BSD-3605190163.A35
3605190163
|
£51.22
|
£61.47
|
|
|
830 - ARMATURE 220V
BSD-3604010037.A20
3604010037
|
-
|
|
|
|
831 - AIR-DEFLECTOR RING
BSD-3600591002.A20
3600591002
|
-
|
|
|
|
840 - SPROCKET WHEEL
BSD-3607031199.A18
3607031199
|
-
|
|
|
|
844 - RESERVOIR CAP
BSD-3603317002.A27
3603317002
|
-
|
|
|
|
853 - BRAKING DEVICE
BSD-3607031182.A13
3607031182
|
-
|
|
|
|
873 - SPINDLE WITH GEAR Z=38
BSD-3606317031.A13
3606317031
|
-
|
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A2646
160111A3H3
|
£2.61
|
£3.13
|
|
