Festool CS 50 EBG / 201427 Spare Parts

Home Details Reviews Delivery

An exploded diagram and spare parts listing for the Festool CS 50 EBG / 201427

	Ex VAT	Inc VAT
1 - CHEESE HEAD SCREW M8 X 16 FSP-774346.A7 774346	£2.00	£2.40
2 - SPACER WEDGE PLATE FSP-463751.A1 463751	£2.82	£3.38
3 - SPACER WEDGE FSP-10023701.A3 10023701	£40.21	£48.25
4 - HOUSING FSP-470102.A0 470102	£11.63	£13.96
5 - SCREW FSP-401038.A1 401038	£2.00	£2.40
6 - CONTACT SPRING FSP-469925.A5 469925	£2.00	£2.40
7 - TAPPET FSP-463934.A5 463934	£2.00	£2.40
8 - PRESSURE SPRING FSP-463590.A6 463590	£2.00	£2.40
9 - CLAMPING NUT FSP-465326.A9 465326	£48.12	£57.74
10 - FLANGE FSP-463195.A4 463195	£7.68	£9.21
11 - SCREW FSP-400709.A7 400709	£2.00	£2.40
12 - CONTACT SPRING FSP-466698.A5 466698	£2.00	£2.40
13 - GEAR COVER FSP-202487.A6 202487	£31.36	£37.63
14 - BALL BEARING FSP-401518.A27 401518	£8.12	£9.74
15 - CHEESE HEAD SCREW FSP-400735.A6 400735	£2.00	£2.40
16 - SPACER WEDGE HOLDER FSP-492010.A3 492010	£19.45	£23.34
17 - HEXAGON NUT M8 FSP-200719.A77 200719	£2.00	£2.40
18 - SCREW FSP-400709.A8 400709	£2.00	£2.40
19 - PROTECTIVE PLATE FSP-10023706.A3 10023706	£3.12	£3.75
20 - BALL BEARING FSP-789595.A21 789595	£8.79	£10.55
21 - SNAP RING FSP-401246.A59 401246	£2.00	£2.40
22 - GEAR SHAFT FSP-465606.A4 465606	£53.77	£64.52
23 - GASKET FSP-463990.A5 463990	£2.00	£2.40
24 - GEAR HOUSING FSP-492321.A5 492321	£75.03	£90.04
25 - PRESSURE SPRING FSP-463590.A5 463590	£2.00	£2.40
26 - HEXAGON NUT M8 FSP-200719.A78 200719	£2.00	£2.40
27 - ADJUSTMENT BRACKET FSP-492307.A4 492307	£16.90	£20.28
28 - GLIDE PLATE FSP-463197.A5 463197	£2.00	£2.40
29 - SCREW FSP-400709.A5 400709	£2.00	£2.40
30 - LEVER FSP-470064.A9 470064	£2.00	£2.40
31 - CABLE CLAMP FSP-761618.A5 761618	£2.00	£2.40
32 - RAISED-HEAD SCREW 4.0 X 16 MM FSP-228713.A17 228713	£2.00	£2.40
33 - PROTECT SWITCH 230 V FSP-463936.A3 463936	£34.39	£41.27
34 - GASKET FSP-463933.A4 463933	£2.00	£2.40
35 - ELECTRONIC FSP-493626.A1 493626	£115.32	£138.39
36 - RAISED-HEAD SCREW 4.0 X 16 MM FSP-228713.A16 228713	£2.00	£2.40
37 - CABLE WITH PLUG FSP-10244897.A0 10244897	£25.08	£30.09
38 - BALL BEARING FSP-401576.A8 401576	£7.86	£9.43
39 - RAISED-HEAD SCREW 4.0 X 70 MM FSP-442415.A6 442415	£2.00	£2.40
40 - SNAP RING FSP-200619.A13 200619	£2.00	£2.40
41 - FAN FSP-463280.A9 463280	£4.41	£5.29
42 - AIR DUCT FSP-463512.A0 463512	£2.66	£3.19
43 - ARMATURE FSP-205200.A0 205200	£108.95	£130.74
44 - BALL BEARING FSP-400626.A23 400626	£5.98	£7.18
45 - FIELD ASSEMBLY 230V EQ / EBQ FSP-491713.A3 491713	£58.13	£69.76
46 - MOTOR HOUSING FSP-463199.A4 463199	£12.54	£15.05
47 - SPEED INDICATOR FSP-493567.A0 493567	£18.18	£21.81
48 - PTC RESISTOR FSP-491722.A2 491722	£20.22	£24.26
49 - BRUSH (PAIR) 230V FSP-491704.A18 491704	£17.85	£21.42
50 - RAISED-HEAD SCREW 3.5 X 8 MM FSP-219047.A30 219047	£2.00	£2.40
52 - SCREW FSP-401038.A2 401038	£2.00	£2.40
53 - HOUSING COVER FSP-463200.A5 463200	£8.62	£10.34
54 - RAISED-HEAD SCREW 4.0 X 16 MM FSP-228713.A14 228713	£2.00	£2.40
101 - FLAP FSP-10030844.A1 10030844	£37.00	£44.40
102 - RAISED-HEAD SCREW 4.0 X 16 MM FSP-228713.A15 228713	£2.00	£2.40
103 - SLIDE FSP-463350.A9 463350	£3.19	£3.83
104 - SCREW FSP-400709.A6 400709	£2.00	£2.40
105 - HOOD FSP-10023702.A0 10023702	£15.85	£19.02
106 - PROTECTION FSP-463300.A2 463300	£2.00	£2.40
107 - CRANK FSP-488159.A13 488159	£18.49	£22.19
108 - HEXAGON NUT M6 FSP-228541.A50 228541	£2.00	£2.40
109 - WASHER 6.4 MM FSP-200578.A102 200578	£2.00	£2.40
110 - WASHER FSP-447790.A9 447790	£2.00	£2.40
111 - RAISED-HEAD SCREW M4 X 14 FSP-445566.A24 445566	£2.00	£2.40
112 - SHEET METAL FSP-463299.A4 463299	£2.00	£2.40
113 - SUPPORTING BEARING FSP-465449.A13 465449	£8.81	£10.57
114 - SCREW FSP-400709.A2 400709	£2.00	£2.40
115 - SCREEN FSP-10023855.A2 10023855	£25.20	£30.24
116 - GEAR FSP-463179.A9 463179	£6.75	£8.10
117 - WASHER 8.4 MM FSP-200579.A13 200579	£2.00	£2.40
118 - SLEEVE FSP-463400.A5 463400	£9.86	£11.83
119 - HEXAGON SCREW M8 X 110 FSP-400734.A4 400734	£2.00	£2.40
120 - DEPTH ADJUSTER FSP-492253.A9 492253	£33.57	£40.28
121 - SCREW FSP-400709.A3 400709	£2.00	£2.40
122 - GUIDE RAIL FSP-463189.A0 463189	£2.00	£2.40
123 - RAISED-HEAD SCREW 4.0 X 70 MM FSP-442415.A5 442415	£2.00	£2.40
124 - KNOB LEVER FSP-463178.A0 463178	£11.18	£13.42
125 - ROTARY KNOB M8 FSP-483162.A45 483162	£5.30	£6.36
126 - RAISED-HEAD SCREW 4.0 X 16 MM FSP-228713.A13 228713	£2.00	£2.40
127 - COVER FSP-491925.A9 491925	£8.05	£9.66
128 - INDICATOR FSP-463181.A9 463181	£2.00	£2.40
129 - SUPPORT FSP-202485.A5 202485	£84.30	£101.16
130 - BEARING SLEEVE FSP-492251.A0 492251	£66.90	£80.28
131 - GUIDE TUBE FSP-202486.A4 202486	£39.50	£47.40
132 - NUTENSTEIN FSP-463176.A9 463176	£2.00	£2.40
133 - CLAMPING PLATE FSP-463251.A0 463251	£2.00	£2.40
134 - END STOP FSP-463281.A0 463281	£4.06	£4.87
135 - SCREW FSP-400709.A1 400709	£2.00	£2.40
136 - PUSHER FSP-492248.A5 492248	£23.65	£28.38
137 - CLOSURE FSP-463725.A9 463725	£3.07	£3.68
138 - SNAP RING FSP-400788.A9 400788	£2.00	£2.40
139 - CLIP FSP-458614.A18 458614	£2.00	£2.40
140 - RAISED-HEAD SCREW 4.0 X 12 MM FSP-400691.A21 400691	£2.00	£2.40
141 - SWIVELING SEGMENT FSP-492322.A4 492322	£91.53	£109.84
201 - WASHER FSP-222490.A34 222490	£2.00	£2.40
202 - SHOCK ABSORBER FSP-491760.A4 491760	£35.90	£43.08
203 - LEG FSP-10030845.A2 10030845	£92.23	£110.68
204 - SWITCH MODUL FSP-492274.A0 492274	£49.05	£58.86
205 - PRESSURE SPRING FSP-463590.A7 463590	£2.00	£2.40
206 - SWITCH MECHANISM FSP-492117.A3 492117	£6.46	£7.75
207 - GRIP FSP-492250.A9 492250	£17.12	£20.55
208 - BUTTON FSP-463673.A0 463673	£2.00	£2.40
209 - PIPE FSP-10023867.A1 10023867	£46.72	£56.07
210 - TRAILING CABLE FSP-10176889.A1 10176889	£41.70	£50.04
211 - CONNECTING MEMBER FSP-463918.A5 463918	£15.44	£18.53
212 - CLAMPING FSP-204745.A2 204745	£7.62	£9.14
213 - SNAP RING FSP-200352.A10 200352	£2.00	£2.40
214 - FLANGE FSP-463260.A9 463260	£4.62	£5.54
215 - SCREW FSP-400709.A0 400709	£2.00	£2.40
216 - SHEET METAL FSP-464030.A4 464030	£2.00	£2.40
217 - DRAW SPRING FSP-464031.A5 464031	£3.16	£3.79
218 - WHEEL FSP-766488.A7 766488	£22.52	£27.02
219 - BOLT FSP-10024062.A6 10024062	£2.00	£2.40
220 - SNAP RING FSP-615477.A9 615477	£2.00	£2.40
221 - HOLDER FSP-10024831.A6 10024831	£2.00	£2.40
222 - NUT M8 FSP-618497.A8 618497	£2.00	£2.40
223 - RUBBER FOOT FSP-465163.A32 465163	£3.12	£3.75
224 - WASHER 8.4 MM FSP-200579.A12 200579	£2.00	£2.40
225 - HEXAGON SCREW FSP-10029228.A2 10029228	£2.00	£2.40
226 - SCREW FSP-10023530.A0 10023530	£2.00	£2.40
227 - LEG FSP-10020001.A6 10020001	£11.05	£13.26
228 - LEG FSP-10020002.A0 10020002	£11.05	£13.26
229 - UPPER SECTION OF PISTOL FSP-447534.A14 447534	£2.00	£2.40
230 - HEXAGON NUT M8 FSP-200735.A37 200735	£2.00	£2.40
231 - LOWER SECTION OF PISTOL FSP-492148.A19 492148	£4.72	£5.66
232 - HEXAGON SCREW FSP-464713.A0 464713	£2.00	£2.40
233 - FOLDAWAY LEG FSP-10198251.A0 10198251	£75.93	£91.12
234 - ADJUSTMENT FSP-448178.A9 448178	£2.00	£2.40
235 - FOOT FSP-465883.A37 465883	£13.48	£16.18
301 - SIDE WALL FSP-463205.A9 463205	£87.80	£105.36
302 - TABLE TOP INSERT FSP-10045447.A0 10045447	£46.09	£55.31
303 - TURN LOCK FASTENER FSP-492257.A4 492257	£20.34	£24.41
304 - SPRING FSP-492259.A4 492259	£15.91	£19.09
305 - AXLE FSP-705620.A9 705620	£44.10	£52.92
306 - PLATE FSP-10007882.A5 10007882	£59.78	£71.73
307 - SPRING FSP-492258.A5 492258	£15.78	£18.93
308 - RAISED-HEAD SCREW 4.0 X 12 MM FSP-400691.A22 400691	£2.00	£2.40
309 - BEARING SHEET FSP-448236.A20 448236	£2.00	£2.40
310 - RAISED-HEAD SCREW 4.0 X 12 MM FSP-219071.A90 219071	£2.00	£2.40
311 - CLAMP SHOE FSP-467630.A2 467630	£2.00	£2.40
312 - RAISED-HEAD SCREW FSP-401137.A7 401137	£2.00	£2.40
313 - STICKER FSP-463724.A0 463724	£3.50	£4.20
314 - PORTAL FSP-10029970.A2 10029970	£76.14	£91.37
315 - CLAMPING FSP-492262.A9 492262	£16.63	£19.96
316 - RUBBER PEDAL FSP-204747.A1 204747	£32.59	£39.11
318 - RAM PROTECTION FSP-10024406.A2 10024406	£18.97	£22.76
319 - DRAW SPRING FSP-465456.A4 465456	£11.52	£13.83
320 - GUIDE FSP-10018211.A2 10018211	£2.00	£2.40
321 - SCALE FSP-492256.A5 492256	£29.84	£35.81
322 - SPRING FSP-10030842.A1 10030842	£9.04	£10.85
323 - SWITCH FSP-10030843.A2 10030843	£47.80	£57.36
324 - SLEEVE FSP-464027.A4 464027	£2.00	£2.40
325 - SHOCK ABSORBER FSP-465528.A5 465528	£2.00	£2.40
326 - SLEEVE FSP-464028.A5 464028	£2.00	£2.40
327 - SPRING WASHER FSP-832605.A5 832605	£2.00	£2.40
701 - PLATE FSP-465145.A2 465145	£2.00	£2.40
702 - BAG FSP-10032097.A6 10032097	£28.70	£34.44
703 - ROUND-HEAD SCREW M6 X 40 FSP-228534.A13 228534	£2.00	£2.40
704 - SPACER BUSH FSP-448066.A35 448066	£9.59	£11.51
705 - SCREW M6 X 12 FSP-449888.A7 449888	£2.00	£2.40
706 - GRIP FSP-487893.A12 487893	£7.24	£8.69
707 - CLAMP SUPPORT FSP-10031568.A6 10031568	£14.60	£17.52
708 - SLEEVE 6 X 36 MM FSP-400289.A7 400289	£2.00	£2.40
709 - PRESSURE SPRING FSP-448064.A31 448064	£2.00	£2.40
710 - TERMINAL FSP-204748.A5 204748	£39.55	£47.46
711 - WASHER 6.4 MM FSP-228546.A113 228546	£2.00	£2.40
712 - ROTARY KNOB M6 FSP-483350.A17 483350	£6.30	£7.56
713 - SUPPORT FSP-489181.A40 489181	£30.82	£36.99
714 - ROTARY KNOB FSP-440713.A68 440713	£2.64	£3.17
715 - STUD SCREW FSP-464525.A26 464525	£2.00	£2.40
716 - WASHER 6.4 MM FSP-228546.A114 228546	£2.00	£2.40
717 - ROTARY KNOB FSP-487755.A19 487755	£9.03	£10.84
718 - WASHER FSP-448471.A14 448471	£3.62	£4.34
719 - FLAT HEAD SCREW M4 X 8 FSP-219043.A22 219043	£2.00	£2.40
720 - FLAT HEAD SCREW FSP-448065.A6 448065	£3.81	£4.57
721 - SCALE FSP-488156.A14 488156	£25.04	£30.05
722 - SWIVELING SEGMENT FSP-448014.A6 448014	£34.26	£41.11
723 - SLEEVE 5 X 12 MM FSP-228692.A48 228692	£2.00	£2.40
724 - CLAMPING PLATE FSP-10023711.A22 10023711	£4.44	£5.33
725 - GUIDING PROFILE FSP-10023709.A5 10023709	-
726 - STOP PROFILE FSP-10023710.A2 10023710	£36.30	£43.56
727 - Y-PIECE FSP-450575.A0 450575	£25.45	£30.54
728 - HOSE 27 X 2 M FSP-459250.A0 459250	£38.39	£46.07
729 - HOSE 36 X 1.5 M FSP-459251.A24 459251	£38.39	£46.07
730 - CONNECTING SLEEVE FSP-577162.A73 577162	£16.25	£19.50
731 - REDUCING SLEEVE. ANTISTATIC FSP-452358.A10 452358	£26.08	£31.30
732 - WORKPIECE HOLDER FSP-10023700.A0 10023700	£8.48	£10.18
733 - SAFETY DEVICE FSP-10023759.A2 10023759	£43.63	£52.36
734 - CLAMP FSP-450158.A24 450158	£2.00	£2.40
735 - SLIDING GUIDE FSP-450031.A1 450031	£4.00	£4.80
736 - RAISED-HEAD SCREW 4.0 X 20 MM FSP-228567.A138 228567	£2.00	£2.40

Attribute Name	Value
Brand	Festool

Reviews Write your own review!

There are currently no reviews of this product.

Fill in the form below to add your review for Festool CS 50 EBG / 201427 Spare Parts

Your Review
Title Required!
Rating Required!
Your Review Required!
Your Details
Your Name Required!
Your Location Required!
Email Address Required!Invalid email!

United Kingdom (Including N. Ireland)

On orders up to £40.00	Add £4.00 inc VAT (Royal Mail post)
On orders £40.00 to £130.00	Add £7.00 inc VAT (Courier)
On orders over £130.00	FREE (Courier)

Shopping Basket (0) £0.00

Festool CS 50 EBG / 201427 Spare Parts

Your Review

Your Details

Carry On Shopping

Try these categories

Recently Viewed

Your Order

About Us

Other Links

Search

Customization

Shopping Basket (0) £0.00

Information

Festool CS 50 EBG / 201427 Spare Parts

Notify me

Your Review

Your Details

Carry On Shopping

Try these categories

Recently Viewed

Your Order

About Us

Other Links

Search
