1 - ARMATURE 230V
BDE-574370-08.A16
574370-08
|
-
|
|
|
|
2 - NO LONGER AVAILABLE
BDE-000000-00.A49541
000000-00
|
-
|
|
|
|
3 - SWITCH LOCK-ON QS
BDE-949825-04.A1
949825-04
|
£40.21
|
£48.25
|
|
|
4 - BRUSH 230V
BDE-403485-03.A4
403485-03
|
£11.18
|
£13.41
|
|
|
5 - CABLE
BDE-330080-53.A5
330080-53
|
£9.17
|
£11.00
|
|
|
6 - FLANGE
BDE-931771.A62
931771
|
£11.18
|
£13.41
|
|
|
7 - SCREW
BDE-933058-00.A38
933058-00
|
£1.66
|
£1.99
|
|
|
8 - WASHER
BDE-932369.A14
932369
|
-
|
|
|
|
9 - FLANGE
BDE-930927.A54
930927
|
-
|
|
|
|
10 - NUT
BDE-860083-03.A355
860083-03
|
£1.66
|
£1.99
|
|
|
11 - WASHER
BDE-930925.A79
930925
|
-
|
|
|
|
12 - NO LONGER AVAILABLE
BDE-000000-00.A49542
000000-00
|
-
|
|
|
|
13 - SCREW
BDE-949892-07.A59
949892-07
|
£1.66
|
£1.99
|
|
|
14 - NO LONGER AVAILABLE
BDE-000000-00.A49543
000000-00
|
-
|
|
|
|
15 - SCREW
BDE-949887-01.A60
949887-01
|
£1.66
|
£1.99
|
|
|
16 - GEARCASE COVER
BDE-947962-00.A31
947962-00
|
-
|
|
|
|
17 - SPINDLE
BDE-578243-00.A17
578243-00
|
£19.40
|
£23.28
|
|
|
18 - NO LONGER AVAILABLE
BDE-000000-00.A49544
000000-00
|
-
|
|
|
|
19 - FLANGE
BDE-930924.A48
930924
|
-
|
|
|
|
20 - SEAL
BDE-930923.A51
930923
|
-
|
|
|
|
21 - SPACER
BDE-930922.A56
930922
|
£1.66
|
£1.99
|
|
|
22 - GEAR & PINION SA
BDE-932522.A29
932522
|
-
|
|
|
|
23 - NO LONGER AVAILABLE
BDE-000000-00.A49545
000000-00
|
-
|
|
|
|
24 - NO LONGER AVAILABLE
BDE-000000-00.A49546
000000-00
|
-
|
|
|
|
25 - CLIP SA
BDE-937098-49.A50
937098-49
|
-
|
|
|
|
26 - SEAL SA
BDE-930909.A67
930909
|
-
|
|
|
|
27 - BEARING
BDE-330003-14.A77
330003-14
|
£8.08
|
£9.70
|
|
|
28 - SEAL SA
BDE-931067-00.A25
931067-00
|
£1.66
|
£1.99
|
|
|
29 - SPACER
BDE-931062.A134
931062
|
£1.66
|
£1.99
|
|
|
30 - O RING
BDE-930028-00.A190
930028-00
|
£1.66
|
£1.99
|
|
|
31 - FLANGE
BDE-931066-00.A132
931066-00
|
£1.82
|
£2.19
|
|
|
32 - SPACER
BDE-N174055.A126
N174055
|
£1.66
|
£1.99
|
|
|
33 - BEARING
BDE-577745-00.A160
577745-00
|
£8.08
|
£9.70
|
|
|
34 - SLEEVE
BDE-938332-00.A31
938332-00
|
£1.66
|
£1.99
|
|
|
35 - HANDLE SIDE SA
BDE-933499.A49
933499
|
-
|
|
|
|
36 - SCREW
BDE-931072.A69
931072
|
-
|
|
|
|
37 - NO LONGER AVAILABLE
BDE-000000-00.A49547
000000-00
|
-
|
|
|
|
38 - NO LONGER AVAILABLE
BDE-000000-00.A49548
000000-00
|
-
|
|
|
|
39 - NO LONGER AVAILABLE
BDE-000000-00.A49549
000000-00
|
-
|
|
|
|
40 - NO LONGER AVAILABLE
BDE-000000-00.A49550
000000-00
|
-
|
|
|
|
41 - HANDLE & COVER
BDE-N097875.A43
N097875
|
-
|
|
|
|
42 - NO LONGER AVAILABLE
BDE-000000-00.A49551
000000-00
|
-
|
|
|
|
43 - SHOCK ABSORBER
BDE-930934-00.A58
930934-00
|
£1.66
|
£1.99
|
|
|
44 - CORD PROTECTOR
BDE-947964-01.A62
947964-01
|
£3.92
|
£4.70
|
|
|
45 - SCREW
BDE-931297-00.A257
931297-00
|
£1.66
|
£1.99
|
|
|
46 - SCREW
BDE-931469-02.A132
931469-02
|
£1.66
|
£1.99
|
|
|
47 - SCREW
BDE-930284-01.A6
930284-01
|
£1.66
|
£1.99
|
|
|
48 - CORD CLAMP
BDE-931477-00.A49
931477-00
|
£1.66
|
£1.99
|
|
|
49 - WRENCH PIN
BDE-938733.A24
938733
|
£7.40
|
£8.88
|
|
|
50 - WRENCH
BDE-807043.A86
807043
|
£1.66
|
£1.99
|
|
|
51 - NO LONGER AVAILABLE
BDE-000000-00.A49552
000000-00
|
-
|
|
|
|
800 - GREASE 100 GMS
BDE-575762-02.A53
575762-02
|
£8.08
|
£9.70
|
|
