1 - NO LONGER AVAILABLE GB 240v
BDE-000000-00.A16486
000000-00
|
-
|
|
|
|
1 - NO LONGER AVAILABLE GB 115v
BDE-000000-00.A16487
000000-00
|
-
|
|
|
|
2 - NO LONGER AVAILABLE GB 115v
BDE-000000-00.A16488
000000-00
|
-
|
|
|
|
2 - NO LONGER AVAILABLE GB 240v
BDE-000000-00.A16489
000000-00
|
-
|
|
|
|
3 - NO LONGER AVAILABLE GB 240v
BDE-000000-00.A16490
000000-00
|
-
|
|
|
|
3 - NO LONGER AVAILABLE GB 115v
BDE-000000-00.A16491
000000-00
|
-
|
|
|
|
4 - BRUSH CUT OFF 230V GB 240v
BDE-940160-03.A47
940160-03
|
£14.57
|
£17.48
|
|
|
4 - BRUSH CUT OFF 115V GB 115v
BDE-940160-02.A21
940160-02
|
-
|
|
|
|
5 - NO LONGER AVAILABLE GB 115v
BDE-000000-00.A16492
000000-00
|
-
|
|
|
|
5 - NO LONGER AVAILABLE GB 240v
BDE-000000-00.A16493
000000-00
|
-
|
|
|
|
6 - FLANGE
BDE-931771.A30
931771
|
£10.85
|
£13.02
|
|
|
7 - SCREW
BDE-933058-00.A72
933058-00
|
£1.66
|
£1.99
|
|
|
8 - WASHER
BDE-932369.A41
932369
|
-
|
|
|
|
9 - FLANGE
BDE-930927.A22
930927
|
-
|
|
|
|
10 - NUT
BDE-860083-03.A282
860083-03
|
£1.66
|
£1.99
|
|
|
11 - WASHER
BDE-930925.A115
930925
|
-
|
|
|
|
12 - NO LONGER AVAILABLE
BDE-000000-00.A16494
000000-00
|
-
|
|
|
|
13 - SCREW
BDE-949892-07.A5
949892-07
|
£1.66
|
£1.99
|
|
|
14 - NO LONGER AVAILABLE
BDE-000000-00.A16495
000000-00
|
-
|
|
|
|
15 - SCREW
BDE-949887-01.A90
949887-01
|
£1.66
|
£1.99
|
|
|
16 - GEARCASE COVER
BDE-947962-00.A6
947962-00
|
-
|
|
|
|
17 - SPINDLE
BDE-578243-00.A43
578243-00
|
£19.40
|
£23.28
|
|
|
18 - NO LONGER AVAILABLE
BDE-000000-00.A16496
000000-00
|
-
|
|
|
|
19 - FLANGE
BDE-930924.A14
930924
|
-
|
|
|
|
20 - SEAL
BDE-930923.A83
930923
|
-
|
|
|
|
21 - SPACER
BDE-930922.A24
930922
|
£1.66
|
£1.99
|
|
|
22 - GEAR & PINION SA
BDE-932522.A12
932522
|
-
|
|
|
|
23 - NO LONGER AVAILABLE
BDE-000000-00.A16497
000000-00
|
-
|
|
|
|
24 - NO LONGER AVAILABLE
BDE-000000-00.A16498
000000-00
|
-
|
|
|
|
25 - CLIP SA
BDE-937098-49.A22
937098-49
|
-
|
|
|
|
26 - SEAL SA
BDE-930909.A98
930909
|
-
|
|
|
|
27 - BEARING
BDE-330003-14.A126
330003-14
|
£7.85
|
£9.42
|
|
|
28 - SEAL SA
BDE-931067-00.A60
931067-00
|
£1.66
|
£1.99
|
|
|
29 - SPACER
BDE-931062.A101
931062
|
£1.66
|
£1.99
|
|
|
30 - O RING
BDE-930028-00.A234
930028-00
|
£1.66
|
£1.99
|
|
|
31 - FLANGE
BDE-931066-00.A96
931066-00
|
£1.82
|
£2.19
|
|
|
32 - SPACER
BDE-N174055.A64
N174055
|
£1.66
|
£1.99
|
|
|
33 - BEARING
BDE-577745-00.A265
577745-00
|
£7.85
|
£9.42
|
|
|
34 - SLEEVE
BDE-938332-00.A49
938332-00
|
£1.66
|
£1.99
|
|
|
35 - HANDLE SIDE SA
BDE-933499.A79
933499
|
-
|
|
|
|
36 - SCREW
BDE-931072.A48
931072
|
-
|
|
|
|
37 - BAFFLE
BDE-931073-00.A35
931073-00
|
£1.66
|
£1.99
|
|
|
38 - NO LONGER AVAILABLE GB 240v
BDE-000000-00.A16499
000000-00
|
-
|
|
|
|
38 - NO LONGER AVAILABLE GB 115v
BDE-000000-00.A16500
000000-00
|
-
|
|
|
|
39 - SPRING
BDE-931076-00.A59
931076-00
|
£1.66
|
£1.99
|
|
|
40 - NO LONGER AVAILABLE
BDE-000000-00.A16501
000000-00
|
-
|
|
|
|
41 - HANDLE & COVER
BDE-N097875.A50
N097875
|
-
|
|
|
|
42 - NO LONGER AVAILABLE
BDE-000000-00.A16502
000000-00
|
-
|
|
|
|
43 - SHOCK ABSORBER
BDE-930934-00.A91
930934-00
|
£1.66
|
£1.99
|
|
|
44 - CORD PROTECTOR GB 115v
BDE-947964-00.A44
947964-00
|
£10.85
|
£13.02
|
|
|
44 - CORD PROTECTOR GB 240v
BDE-947964-01.A2
947964-01
|
£3.80
|
£4.56
|
|
|
45 - SCREW
BDE-931297-00.A159
931297-00
|
£1.66
|
£1.99
|
|
|
46 - SCREW
BDE-931469-02.A173
931469-02
|
£1.66
|
£1.99
|
|
|
47 - SCREW
BDE-930284-01.A113
930284-01
|
£1.66
|
£1.99
|
|
|
48 - CORD CLAMP
BDE-931477-00.A10
931477-00
|
£1.66
|
£1.99
|
|
|
49 - WRENCH PIN
BDE-938733.A48
938733
|
£7.18
|
£8.62
|
|
|
50 - WRENCH
BDE-807043.A111
807043
|
£1.66
|
£1.99
|
|
|
51 - BRUSH CUT OFF 115V GB 115v
BDE-940160-02.A25
940160-02
|
-
|
|
|
|
51 - BRUSH CUT OFF 230V GB 240v
BDE-940160-03.A44
940160-03
|
£14.57
|
£17.48
|
|
