Elu HH40L Type 1 Planer Spare Parts

Home Details Reviews Delivery

An exploded drawing and spare parts listing for the Elu HH40L Type 1 Planer

	Ex VAT	Inc VAT
1 - NO LONGER AVAILABLE GB 230V BDE-000000-00.A115618 000000-00	-
1 - NO LONGER AVAILABLE GB 115V BDE-000000-00.A115619 000000-00	-
2 - NO LONGER AVAILABLE GB 230V BDE-000000-00.A115620 000000-00	-
2 - NO LONGER AVAILABLE GB 115V BDE-000000-00.A115621 000000-00	-
3 - SWITCH SA BDE-327383-03.A15 327383-03	£8.08	£9.70
4 - BRUSH PAIR 230V GB 230V BDE-575963-00.A10 575963-00	£20.50	£24.60
4 - BRUSH PAIR 115V GB 115V BDE-575963-04.A2 575963-04	£19.48	£23.37
5 - CORDSET (M/PLUG) GB 115V LX BDE-330061-04.A66 330061-04	£12.53	£15.04
5 - CORD GB 230V GB BDE-330060-78.A7 330060-78	-
6 - BLADEDRUM SA BDE-574232-01.A0 574232-01	£62.77	£75.32
7 - CORD PROTECTOR BDE-320785.A1221 320785	£1.66	£1.99
8 - CORD CLAMP BDE-329301-00.A39 329301-00	£1.66	£1.99
9 - SCREW BDE-330065-06.A315 330065-06	£1.66	£1.99
10 - NO LONGER AVAILABLE BDE-000000-00.A115624 000000-00	-
11 - NO LONGER AVAILABLE GB 115V BDE-000000-00.A115625 000000-00	-
11 - CAPACITOR GB 230V BDE-321384.A66 321384	£1.66	£1.99
12 - NO LONGER AVAILABLE BDE-000000-00.A115626 000000-00	-
13 - CAP BDE-326592-00.A15 326592-00	£4.83	£5.80
14 - NUT BDE-328772-00.A0 328772-00	£1.66	£1.99
15 - BASE BDE-326590-01.A8 326590-01	£1.66	£1.99
16 - NO LONGER AVAILABLE BDE-000000-00.A115627 000000-00	-
17 - RATCHET BDE-326381-00.A2 326381-00	£1.66	£1.99
18 - WASHER SPRING BDE-327341-00.A11 327341-00	£1.66	£1.99
20 - NO LONGER AVAILABLE BDE-000000-00.A115628 000000-00	-
21 - POST BDE-326636-00.A16 326636-00	£1.66	£1.99
22 - SCREW BDE-330065-08.A385 330065-08	£1.66	£1.99
25 - SPRING BDE-323722-00.A20 323722-00	£1.66	£1.99
26 - BUSH BDE-326823-01.A6 326823-01	£1.66	£1.99
27 - SCREW BDE-324006-00.A90 324006-00	£1.66	£1.99
28 - EJECTOR BDE-327387-00.A1 327387-00	-
29 - SCREW BDE-324006-11.A6 324006-11	£1.66	£1.99
30 - NO LONGER AVAILABLE BDE-000000-00.A115629 000000-00	-
32 - SPRING BDE-572255-00.A12 572255-00	£1.66	£1.99
34 - CAP BDE-323481-00.A13 323481-00	£1.66	£1.99
35 - BEARING BDE-605040-63.A71 605040-63	£3.39	£4.07
37 - NO LONGER AVAILABLE BDE-000000-00.A115632 000000-00	-
38 - WASHER BDE-330016-01.A45 330016-01	£1.66	£1.99
39 - NO LONGER AVAILABLE BDE-000000-00.A115630 000000-00	-
40 - NO LONGER AVAILABLE BDE-000000-00.A115631 000000-00	-
41 - BEARING BDE-330003-11.A36 330003-11	£11.18	£13.41
42 - BEARING BDE-N542566.A13 N542566	£12.53	£15.04
43 - PULLEY BDE-324105-00.A5 324105-00	£2.87	£3.44
44 - PINION BDE-327065-00.A11 327065-00	£3.39	£4.07
45 - BELT TOOTHED BDE-325106-00.A4 325106-00	£16.52	£19.82
46 - NUT BDE-761225-02.A23 761225-02	£1.66	£1.99
47 - NO LONGER AVAILABLE BDE-000000-00.A115633 000000-00	-
48 - NO LONGER AVAILABLE BDE-000000-00.A115634 000000-00	-
54 - BEARING NEEDLE BDE-330004-31.A9 330004-31	£3.92	£4.70
55 - NO LONGER AVAILABLE BDE-000000-00.A115635 000000-00	-
57 - GUIDE BDE-327393-00.A11 327393-00	£3.39	£4.07
58 - SCREW WING BDE-326573-01.A83 326573-01	£1.88	£2.26
59 - GUIDE FENCE BDE-327391-00.A3 327391-00	£9.69	£11.63
60 - NUT WING BDE-328834-00.A12 328834-00	£1.66	£1.99
61 - BOLT BDE-911111.A4 911111	£1.66	£1.99
62 - BRACKET BDE-328175-00.A9 328175-00	£3.39	£4.07
64 - GUARD BDE-326637-00.A7 326637-00	£1.88	£2.26
68 - SCREW BDE-330065-10.A58 330065-10	£1.66	£1.99
70 - CLAMP SA BDE-N542564.A10 N542564	£16.52	£19.82
72 - NO LONGER AVAILABLE BDE-000000-00.A115636 000000-00	-
82 - SPANNER BDE-868148-00.A21 868148-00	£3.92	£4.70
91 - CABLE TIE BDE-941486-00.A6 941486-00	-
97 - CLIP BDE-329145-00.A6 329145-00	£1.66	£1.99
101 - ADAPTOR HH40K - HH40KL BDE-327390-00.A8 327390-00	-
102 - NO LONGER AVAILABLE HH40K - HH40KL BDE-000000-00.A115637 000000-00	-
103 - NO LONGER AVAILABLE HH40K - HH40KL BDE-000000-00.A115638 000000-00	-
104 - NO LONGER AVAILABLE HH40K - HH40KL BDE-000000-00.A115639 000000-00	-
105 - WASHER HH40K - HH40KL BDE-249233-00.A20 249233-00	£1.66	£1.99
106 - SCREW HH40K - HH40KL BDE-249416-06.A113 249416-06	£1.66	£1.99
107 - NO LONGER AVAILABLE BDE-000000-00.A115646 000000-00	-
108 - NO LONGER AVAILABLE 115V BDE-000000-00.A115647 000000-00	-
108 - BRUSH PAIR 230V 230V BDE-575963-00.A11 575963-00	£20.50	£24.60
109 - BRUSH HOLDER PAIR BDE-329780-49.A1 329780-49	£10.57	£12.68

Attribute Name	Value
Brand	Elu
