1 - NO LONGER AVAILABLE
BDE-000000-00.A16271
000000-00
|
-
|
|
|
|
2 - NO LONGER AVAILABLE
BDE-000000-00.A16272
000000-00
|
-
|
|
|
|
4 - BRUSH CUT OFF
BDE-940160-01.A18
940160-01
|
£12.17
|
£14.60
|
|
|
6 - FLANGE
BDE-931771.A25
931771
|
£10.85
|
£13.02
|
|
|
7 - FLANGE
BDE-930927.A33
930927
|
-
|
|
|
|
8 - SCREW
BDE-933058-00.A63
933058-00
|
£1.66
|
£1.99
|
|
|
9 - WASHER
BDE-932369.A28
932369
|
-
|
|
|
|
10 - NUT
BDE-860083-03.A302
860083-03
|
£1.66
|
£1.99
|
|
|
11 - WASHER
BDE-930925.A104
930925
|
-
|
|
|
|
12 - NO LONGER AVAILABLE
BDE-000000-00.A16273
000000-00
|
-
|
|
|
|
13 - SCREW
BDE-949892-07.A17
949892-07
|
£1.66
|
£1.99
|
|
|
14 - GUARD 7"
BDE-932525-02.A28
932525-02
|
-
|
|
|
|
15 - SCREW
BDE-949887-01.A96
949887-01
|
£1.66
|
£1.99
|
|
|
16 - GEARCASE COVER
BDE-947962-00.A17
947962-00
|
-
|
|
|
|
17 - SPINDLE
BDE-578243-00.A28
578243-00
|
£19.40
|
£23.28
|
|
|
18 - NO LONGER AVAILABLE
BDE-000000-00.A16274
000000-00
|
-
|
|
|
|
19 - FLANGE
BDE-930924.A26
930924
|
-
|
|
|
|
20 - SEAL
BDE-930923.A73
930923
|
-
|
|
|
|
21 - SPACER
BDE-930922.A28
930922
|
£1.66
|
£1.99
|
|
|
22 - NO LONGER AVAILABLE
BDE-000000-00.A16275
000000-00
|
-
|
|
|
|
23 - NO LONGER AVAILABLE
BDE-000000-00.A16276
000000-00
|
-
|
|
|
|
24 - NO LONGER AVAILABLE
BDE-000000-00.A16277
000000-00
|
-
|
|
|
|
25 - SCREW
BDE-930284-01.A118
930284-01
|
£1.66
|
£1.99
|
|
|
26 - NO LONGER AVAILABLE
BDE-000000-00.A16278
000000-00
|
-
|
|
|
|
27 - WRENCH PIN
BDE-938733.A62
938733
|
£7.18
|
£8.62
|
|
|
28 - CLIP SA
BDE-937098-49.A18
937098-49
|
-
|
|
|
|
29 - SEAL SA
BDE-930909.A94
930909
|
-
|
|
|
|
30 - BEARING
BDE-330003-14.A117
330003-14
|
£7.85
|
£9.42
|
|
|
31 - SEAL SA
BDE-931067-00.A48
931067-00
|
£1.66
|
£1.99
|
|
|
32 - SPACER
BDE-931062.A89
931062
|
£1.66
|
£1.99
|
|
|
33 - O RING
BDE-930028-00.A231
930028-00
|
£1.66
|
£1.99
|
|
|
34 - FLANGE
BDE-931066-00.A108
931066-00
|
£1.82
|
£2.19
|
|
|
35 - SCREW
BDE-N412453.A10
N412453
|
£1.66
|
£1.99
|
|
|
36 - SPACER
BDE-N174055.A70
N174055
|
£1.66
|
£1.99
|
|
|
37 - BEARING
BDE-577745-00.A176
577745-00
|
£7.85
|
£9.42
|
|
|
38 - SLEEVE
BDE-938332-00.A54
938332-00
|
£1.66
|
£1.99
|
|
|
39 - BAFFLE
BDE-931073-00.A27
931073-00
|
£1.66
|
£1.99
|
|
|
40 - BRUSH PLATE SA
BDE-D935745.A0
D935745
|
-
|
|
|
|
41 - SPRING
BDE-931076-00.A68
931076-00
|
£1.66
|
£1.99
|
|
|
42 - NO LONGER AVAILABLE
BDE-000000-00.A16279
000000-00
|
-
|
|
|
|
43 - SHOCK ABSORBER
BDE-930934-00.A86
930934-00
|
£1.66
|
£1.99
|
|
|
44 - SCREW
BDE-931297-00.A139
931297-00
|
£1.66
|
£1.99
|
|
|
45 - NO LONGER AVAILABLE
BDE-000000-00.A16280
000000-00
|
-
|
|
|
|
46 - NO LONGER AVAILABLE
BDE-000000-00.A16281
000000-00
|
-
|
|
|
|
47 - CORD CLAMP
BDE-931477-00.A17
931477-00
|
£1.66
|
£1.99
|
|
|
49 - SCREW
BDE-931469-02.A165
931469-02
|
£1.66
|
£1.99
|
|
|
50 - COVER
BDE-933364-02.A22
933364-02
|
£1.66
|
£1.99
|
|
|
51 - BRUSH CUT OFF
BDE-940160-01.A19
940160-01
|
£12.17
|
£14.60
|
|
|
52 - WRENCH
BDE-807043.A106
807043
|
£1.66
|
£1.99
|
|
|
54 - NO LONGER AVAILABLE
BDE-000000-00.A16282
000000-00
|
-
|
|
|
