1 - ARMATURE GB 115V
BDE-868404-01.A6
868404-01
|
-
|
|
|
|
1 - ARMATURE GB 240V
BDE-868404-00.A4
868404-00
|
£238.94
|
£286.73
|
|
|
2 - NO LONGER AVAILABLE GB 115V
BDE-000000-00.A15312
000000-00
|
-
|
|
|
|
2 - FIELD 240V GB 240V
BDE-868503-04.A0
868503-04
|
£226.53
|
£271.84
|
|
|
3 - NO LONGER AVAILABLE GB 115V
BDE-000000-00.A15308
000000-00
|
-
|
|
|
|
3 - NO LONGER AVAILABLE GB 240V
BDE-000000-00.A15309
000000-00
|
-
|
|
|
|
4 - BRUSH GB 115V
BDE-932497-00.A14
932497-00
|
£4.69
|
£5.63
|
|
|
4 - BRUSH GB 240V
BDE-932497-00.A15
932497-00
|
£4.69
|
£5.63
|
|
|
5 - CABLE & PLUG GB 240V
BDE-949770-15.A4
949770-15
|
£33.13
|
£39.76
|
|
|
5 - CABLE & PLUG GB 115V
BDE-949770-29.A3
949770-29
|
-
|
|
|
|
6 - NO LONGER AVAILABLE
BDE-000000-00.A15310
000000-00
|
-
|
|
|
|
7 - NO LONGER AVAILABLE
BDE-000000-00.A15311
000000-00
|
-
|
|
|
|
8 - HANDLE SA
BDE-935833-02.A2
935833-02
|
£44.00
|
£52.80
|
|
|
9 - SCREW
BDE-949896-14.A2
949896-14
|
£1.66
|
£1.99
|
|
|
10 - SCREW
BDE-949896-13.A7
949896-13
|
£1.66
|
£1.99
|
|
|
11 - LEVER
BDE-932315-00.A5
932315-00
|
£3.22
|
£3.86
|
|
|
12 - SPRING
BDE-932313-00.A5
932313-00
|
£5.72
|
£6.87
|
|
|
13 - COVER
BDE-932317-00.A3
932317-00
|
£3.70
|
£4.44
|
|
|
14 - PIN
BDE-932314-00.A3
932314-00
|
£1.66
|
£1.99
|
|
|
15 - SPRING
BDE-931013-00.A7
931013-00
|
£1.66
|
£1.99
|
|
|
16 - SCREW
BDE-860093-11.A16
860093-11
|
£1.66
|
£1.99
|
|
|
18 - WASHER
BDE-932293-00.A1
932293-00
|
£1.66
|
£1.99
|
|
|
19 - NO LONGER AVAILABLE
BDE-000000-00.A15313
000000-00
|
-
|
|
|
|
20 - NO LONGER AVAILABLE
BDE-000000-00.A15314
000000-00
|
-
|
|
|
|
21 - NO LONGER AVAILABLE
BDE-000000-00.A15315
000000-00
|
-
|
|
|
|
22 - NO LONGER AVAILABLE
BDE-000000-00.A15316
000000-00
|
-
|
|
|
|
23 - WASHER
BDE-932287-00.A6
932287-00
|
£1.66
|
£1.99
|
|
|
24 - SPINDLE & GEAR SA
BDE-869219-00.A5
869219-00
|
£135.36
|
£162.43
|
|
|
25 - WASHER
BDE-932286-00.A3
932286-00
|
£2.71
|
£3.25
|
|
|
26 - SPINDLE & GEAR SA
BDE-869219-02.A4
869219-02
|
£101.69
|
£122.03
|
|
|
27 - WASHER
BDE-932285-00.A8
932285-00
|
£3.30
|
£3.96
|
|
|
28 - PLATE
BDE-932288-00.A3
932288-00
|
£1.66
|
£1.99
|
|
|
29 - SEAL
BDE-930039.A15
930039
|
£1.66
|
£1.99
|
|
|
30 - WASHER
BDE-932289-00.A8
932289-00
|
£1.66
|
£1.99
|
|
|
31 - LEVER SA
BDE-932265-00.A3
932265-00
|
£29.32
|
£35.18
|
|
|
32 - SPRING
BDE-932290-00.A5
932290-00
|
£1.78
|
£2.13
|
|
|
33 - SPRING
BDE-932291-00.A6
932291-00
|
£4.58
|
£5.49
|
|
|
34 - NO LONGER AVAILABLE
BDE-000000-00.A15317
000000-00
|
-
|
|
|
|
35 - WASHER
BDE-931429-00.A2
931429-00
|
£3.30
|
£3.96
|
|
|
36 - NO LONGER AVAILABLE
BDE-000000-00.A15318
000000-00
|
-
|
|
|
|
37 - NO LONGER AVAILABLE
BDE-000000-00.A15319
000000-00
|
-
|
|
|
|
38 - CAP
BDE-932308-01.A5
932308-01
|
-
|
|
|
|
39 - GASKET
BDE-932312-00.A4
932312-00
|
£1.66
|
£1.99
|
|
|
40 - PIN
BDE-932301-00.A1
932301-00
|
-
|
|
|
|
41 - NO LONGER AVAILABLE
BDE-000000-00.A15320
000000-00
|
-
|
|
|
|
42 - WASHER
BDE-932302-00.A40
932302-00
|
£1.66
|
£1.99
|
|
|
43 - NO LONGER AVAILABLE
BDE-000000-00.A15321
000000-00
|
-
|
|
|
|
45 - NO LONGER AVAILABLE
BDE-000000-00.A15322
000000-00
|
-
|
|
|
|
46 - NO LONGER AVAILABLE
BDE-000000-00.A15323
000000-00
|
-
|
|
|
|
47 - NO LONGER AVAILABLE
BDE-000000-00.A15324
000000-00
|
-
|
|
|
|
48 - NO LONGER AVAILABLE
BDE-000000-00.A15325
000000-00
|
-
|
|
|
|
49 - SEAL
BDE-932311-00.A5
932311-00
|
£2.21
|
£2.65
|
|
|
50 - RING
BDE-931052-00.A7
931052-00
|
£1.66
|
£1.99
|
|
|
51 - RING
BDE-930940-00.A2
930940-00
|
£3.22
|
£3.86
|
|
|
52 - BEARING
BDE-868768-05.A2
868768-05
|
£7.64
|
£9.17
|
|
|
53 - CIRCLIP
BDE-949729-02.A12
949729-02
|
£1.66
|
£1.99
|
|
|
54 - WASHER
BDE-932309-00.A7
932309-00
|
£1.66
|
£1.99
|
|
|
55 - SPACER
BDE-930073-00.A4
930073-00
|
£1.66
|
£1.99
|
|
|
56 - BEARING
BDE-577745-00.A232
577745-00
|
£7.85
|
£9.42
|
|
|
57 - SLEEVE
BDE-934409-00.A12
934409-00
|
-
|
|
|
|
58 - BAFFLE
BDE-930072-00.A11
930072-00
|
£2.21
|
£2.65
|
|
|
59 - SCREW
BDE-930246-00.A5
930246-00
|
£1.66
|
£1.99
|
|
|
60 - WASHER
BDE-761035-00.A4
761035-00
|
£1.66
|
£1.99
|
|
|
61 - WASHER
BDE-949876-08.A22
949876-08
|
£1.66
|
£1.99
|
|
|
62 - FIELDCASE
BDE-932261-01.A6
932261-01
|
-
|
|
|
|
63 - END CAP SA
BDE-932272-02.A1
932272-02
|
£15.63
|
£18.76
|
|
|
64 - SCREW.TEMP
BDE-930251-01.A3
930251-01
|
£1.66
|
£1.99
|
|
|
65 - NO LONGER AVAILABLE
BDE-000000-00.A15326
000000-00
|
-
|
|
|
|
66 - SCREW
BDE-930242-00.A4
930242-00
|
£1.66
|
£1.99
|
|
|
67 - BASEPLATE SA
BDE-930269-00.A6
930269-00
|
£3.22
|
£3.86
|
|
|
68 - SPRING
BDE-930099-00.A17
930099-00
|
-
|
|
|
|
69 - BLOCK
BDE-932307-00.A8
932307-00
|
£1.66
|
£1.99
|
|
|
70 - PLATE
BDE-932320-00.A3
932320-00
|
£7.64
|
£9.17
|
|
|
71 - SCREW
BDE-932319-00.A5
932319-00
|
£1.66
|
£1.99
|
|
|
72 - CAPACITOR GB 115V
BDE-932476-00.A1
932476-00
|
£3.22
|
£3.86
|
|
|
72 - CAPACITOR GB 240V
BDE-932476-00.A2
932476-00
|
£3.22
|
£3.86
|
|
|
73 - PIN
BDE-932406-00.A2
932406-00
|
£1.66
|
£1.99
|
|
|
74 - RING
BDE-932268-00.A6
932268-00
|
£3.22
|
£3.86
|
|
|
75 - ROLLER
BDE-932405-00.A6
932405-00
|
£1.66
|
£1.99
|
|
|
76 - SCREW
BDE-930079-01.A2
930079-01
|
£1.66
|
£1.99
|
|
|
77 - SWITCH REVERSE
BDE-932403-00.A3
932403-00
|
£23.75
|
£28.50
|
|
|
78 - SLIDER
BDE-932402-00.A3
932402-00
|
-
|
|
|
|
79 - NO LONGER AVAILABLE
BDE-000000-00.A15327
000000-00
|
-
|
|
|
|
85 - SCREW GB 240V
BDE-930076-00.A70
930076-00
|
£1.66
|
£1.99
|
|
|
85 - SCREW GB 115V
BDE-930076-00.A71
930076-00
|
£1.66
|
£1.99
|
|
|
86 - CORD CLAMP GB 115V
BDE-930103-00.A181
930103-00
|
£1.66
|
£1.99
|
|
|
86 - CORD CLAMP GB 240V
BDE-930103-00.A182
930103-00
|
£1.66
|
£1.99
|
|
|
87 - CORD PROTECTOR GB 240V
BDE-930981-00.A33
930981-00
|
£1.66
|
£1.99
|
|
|
87 - CORD PROTECTOR GB 115V
BDE-930981-00.A34
930981-00
|
£1.66
|
£1.99
|
|
