1 - MOTOR HOUSING
BSD-3600760020.A2
3600760020
|
£61.70
|
£74.04
|
|
|
2 - STATOR 180W
BSD-3604090011.A35
3604090011
|
£81.81
|
£98.17
|
|
|
3 - ROTOR
BSD-3604220009.A15
3604220009
|
£75.79
|
£90.95
|
|
|
5 - BEARING FLANGE
BSD-3605700015.A66
3605700015
|
£47.95
|
£57.54
|
|
|
6 - GROOVE BALL BEARING DIN 625-7x19x6
BSD-3600905148.A104
3600905148
|
£8.92
|
£10.70
|
|
|
7 - BEARING FLANGE
BSD-3605700016.A17
3605700016
|
£59.53
|
£71.44
|
|
|
8 - GROOVE BALL BEARING 7x17x5
BSD-1900905028.A258
1900905028
|
£33.74
|
£40.49
|
|
|
26 - PINION
BSD-3606300013.A24
3606300013
|
£14.08
|
£16.89
|
|
|
27 - STOP DISC
BSD-3600101047.A132
3600101047
|
£2.16
|
£2.59
|
|
|
28 - RING GEAR Z=42
BSD-3606334005.A36
3606334005
|
£59.53
|
£71.44
|
|
|
29 - PLANETARY-GEAR CARRIER
BSD-3606337057.A50
3606337057
|
£50.80
|
£60.96
|
|
|
31 - CYLINDRICAL GEAR Z=14
BSD-3606316093.A101
3606316093
|
£2.74
|
£3.29
|
|
|
32 - NEEDLE-ROLLER ASSEMBLY INA K3x5x7
BSD-3600913000.A93
3600913000
|
£4.26
|
£5.11
|
|
|
33 - NEEDLE ROLLER
BSD-3603201000.A352
3603201000
|
£1.84
|
£2.21
|
|
|
36 - GROOVE BALL BEARING 12x21x5
BSD-3600905002.A72
3600905002
|
£16.41
|
£19.69
|
|
|
38 - PLANETARY-GEAR CARRIER
BSD-3606337018.A6
3606337018
|
£85.90
|
£103.08
|
|
|
39 - CYLINDRICAL GEAR
BSD-3606316114.A114
3606316114
|
£13.78
|
£16.54
|
|
|
41 - BALL BEARING 7x19x6
BSD-2600905032.A2286
2600905032
|
£5.57
|
£6.68
|
|
|
44 - THREADED BUSHING
BSD-3600390003.A1
3600390003
|
£12.64
|
£15.17
|
|
|
46 - THREADED RING
BSD-3603344004.A35
3603344004
|
£15.65
|
£18.78
|
|
|
52 - PLAIN WASHER DIN 125-A3.2-ST
BSD-2916011006.A109
2916011006
|
£1.84
|
£2.21
|
|
|
53 - O-RING 2.4x1.9 MM
BSD-2600210007.A31
2600210007
|
£2.27
|
£2.72
|
|
|
54 - COMPRESSION SPRING
BSD-3604611017.A97
3604611017
|
£2.74
|
£3.29
|
|
|
55 - VALVE CONE
BSD-3603132000.A39
3603132000
|
£2.94
|
£3.53
|
|
|
56 - VALVE HOUSING
BSD-3605190152.A2
3605190152
|
£156.22
|
£187.46
|
|
|
57 - HOUSING COVER
BSD-3605500003.A18
3605500003
|
£2.61
|
£3.13
|
|
|
59 - SILENCER
BSD-3600002002.A34
3600002002
|
£3.72
|
£4.47
|
|
|
60 - STRAINER
BSD-3600002001.A123
3600002001
|
£2.61
|
£3.13
|
|
|
62 - SUSPENSION LOOP
BSD-2604720004.A11
2604720004
|
£4.26
|
£5.11
|
|
|
63 - NEEDLE ROLLER
BSD-3603201023.A7
3603201023
|
£1.84
|
£2.21
|
|
|
66 - STRAIGHT PIN
BSD-3603201009.A80
3603201009
|
£5.58
|
£6.70
|
|
|
68 - BALL DIN 5401-dia7MM-III-ST
BSD-1903230013.A303
1903230013
|
£2.27
|
£2.72
|
|
|
69 - COMPRESSION SPRING
BSD-3604611006.A117
3604611006
|
£2.27
|
£2.72
|
|
|
70 - CENTRIFUGAL GOVERNOR
BSD-3607021007.A30
3607021007
|
£33.74
|
£40.49
|
|
|
74 - RETAINING SNAP RING
BSD-3600211001.A22
3600211001
|
£6.52
|
£7.83
|
|
|
76 - THREADED RING
BSD-3603344003.A27
3603344003
|
£2.61
|
£3.13
|
|
|
77 - CONTROL LEVER
BSD-3601902001.A47
3601902001
|
£6.52
|
£7.83
|
|
|
78 - GROOVED PIN DIN 1475-2x18-ST
BSD-2917700040.A87
2917700040
|
£2.80
|
£3.36
|
|
|
86 - COUNTERSUNK-HEAD SCREW DIN 963-M4x10-4.8
BSD-2910761120.A5
2910761120
|
£1.84
|
£2.21
|
|
|
87 - SEALING PLATE
BSD-3600054001.A19
3600054001
|
£1.75
|
£2.10
|
|
|
88 - SILENCER
BSD-3601010002.A1
3601010002
|
£2.80
|
£3.36
|
|
|
89 - SILENCER
BSD-3601010010.A43
3601010010
|
£2.16
|
£2.59
|
|
|
95 - NAMEPLATE
BSD-160111A3HF.A514
160111A3HF
|
£3.91
|
£4.69
|
|
|
96 - MANUFACTURER'S NAMEPLATE
BSD-3601119055.A170
3601119055
|
£3.72
|
£4.47
|
|
|
97 - GROOVED NAIL
BSD-3603133000.A460
3603133000
|
£2.61
|
£3.13
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A351
3601119236
|
£3.91
|
£4.69
|
|
|
705 - COMBI ANGLE DRIVE
BSD-1608580011.A8
1608580011
|
-
|
|
|
|
706 - CLAMPING SLEEVE
BSD-3600220005.A8
3600220005
|
-
|
|
|
|
750/07 - CHUCK WRENCH SG2
BSD-2607950007.A326
2607950007
|
£6.85
|
£8.22
|
|
|
752 - HOSE FITTING
BSD-3607010011.A53
3607010011
|
-
|
|
|
|
802 - ASSEMBLY OF SERVICE PARTS
BSD-3607031044.A19
3607031044
|
-
|
|
|
|
804 - PARTS SET
BSD-3607030256.A67
3607030256
|
£31.95
|
£38.34
|
|
|
870 - ASSEMBLY OF SERVICE PARTS
BSD-3607031038.A8
3607031038
|
£42.84
|
£51.41
|
|
|
873 - O-RING
BSD-3607010003.A1
3607010003
|
£17.22
|
£20.67
|
|
|
882 - O-RING
BSD-3607010006.A27
3607010006
|
£33.22
|
£39.87
|
|
