1 - GEAR HOUSING
BSD-2605806920.A11
2605806920
|
-
|
|
|
|
9 - NEEDLE-ROLLER BEARING dia6 MM
BSD-2600914010.A625
2600914010
|
£2.80
|
£3.36
|
|
|
10 - SPINDLE WITH GEAR Z= 16/41
BSD-2606100041.A3
2606100041
|
-
|
|
|
|
12 - SHIM 0.3 MM
BSD-2600100607.A609
2600100607
|
£1.75
|
£2.10
|
|
|
14 - NEEDLE ROLLER DIN 5402-A3x11.8-G2
BSD-1903201042.A399
1903201042
|
£2.16
|
£2.59
|
|
|
15 - INTERMEDIATE FLANGE
BSD-2605700900.A4
2605700900
|
-
|
|
|
|
16 - FELT DISC
BSD-2600108000.A236
2600108000
|
-
|
|
|
|
17 - CUPPED WASHER
BSD-2600500030.A20
2600500030
|
-
|
|
|
|
18 - SEAL BUSHING
BSD-2600300049.A29
2600300049
|
-
|
|
|
|
19 - BALL BEARING 8x22x7
BSD-1900905029.A303
1900905029
|
£21.52
|
£25.83
|
|
|
20 - ARMATURE WITH FAN 240-250V
BSD-2604010368.A0
2604010368
|
-
|
|
|
|
21 - GROOVE BALL BEARING 6x19x6
BSD-1900905019.A104
1900905019
|
£14.91
|
£17.89
|
|
|
22 - SHIM
BSD-2600150003.A246
2600150003
|
£2.16
|
£2.59
|
|
|
23 - FAN
BSD-2606610018.A13
2606610018
|
-
|
|
|
|
24 - SHIM 0.2 MM
BSD-2600101655.A30
2600101655
|
-
|
|
|
|
24 - SHIM 0.3 MM
BSD-2600101656.A151
2600101656
|
-
|
|
|
|
24 - SHIM 0.5 MM
BSD-2600101657.A30
2600101657
|
-
|
|
|
|
26 - MOTOR HOUSING
BSD-2605104911.A3
2605104911
|
-
|
|
|
|
27 - POLE SHOE 240V
BSD-2604222255.A0
2604222255
|
-
|
|
|
|
28 - COVER DISC
BSD-2601328015.A4
2601328015
|
-
|
|
|
|
29 - COMPRESSION SPRING
BSD-2604611026.A288
2604611026
|
-
|
|
|
|
31 - SOCKET HEAD CAP SCREW DIN 84-AM4x25-8.8
BSD-2910021132.A19
2910021132
|
£1.75
|
£2.10
|
|
|
32 - SPRING LOCK WASHER DIN 128-A4-FST
BSD-2916690003.A223
2916690003
|
£1.75
|
£2.10
|
|
|
37 - SPIRAL SPRING
BSD-2604652003.A35
2604652003
|
-
|
|
|
|
38 - TAPPING SCREW DIN 7971-BZ2.9x6.5
BSD-2910211004.A408
2910211004
|
-
|
|
|
|
40 - SOCKET HEAD CAP SCREW
BSD-2603410010.A62
2603410010
|
-
|
|
|
|
42 - ON-OFF SWITCH
BSD-2607200043.A185
2607200043
|
-
|
|
|
|
43 - SUPPRESSION FILTER
BSD-2607329051.A221
2607329051
|
-
|
|
|
|
44 - POWER SUPPLY CORD GB 110V 2.65m 2 x 1.0mm H05 VV-F
BSD-2604460205.A62
2604460205
|
£27.23
|
£32.68
|
|
|
45 - GROMMET dia8.3-dia9.4x95 MM
BSD-2600703011.A313
2600703011
|
£2.80
|
£3.36
|
|
|
45 - GROMMET dia6.5-dia6.9x95 MM
BSD-2600703012.A1116
2600703012
|
£2.80
|
£3.36
|
|
|
45 - GROMMET dia7.6-dia8.2x95 MM
BSD-2600703013.A258
2600703013
|
£2.61
|
£3.13
|
|
|
46 - CABLE CLIP
BSD-2601035001.A56
2601035001
|
£1.75
|
£2.10
|
|
|
47 - SOCKET HEAD CAP SCREW M3x10 MM
BSD-2603410023.A356
2603410023
|
-
|
|
|
|
48 - TAPPING SCREW DIN 7971-ST3.9x16-F
BSD-2910211019.A1863
2910211019
|
£1.75
|
£2.10
|
|
|
49 - TAPPING SCREW DIN 7971-BZ3.9x19
BSD-2910211020.A204
2910211020
|
£2.16
|
£2.59
|
|
|
50 - HOUSING COVER
BSD-2605132005.A83
2605132005
|
-
|
|
|
|
51 - TAPPING SCREW DIN 7971-ST3.9x22-F
BSD-2910211021.A728
2910211021
|
£1.75
|
£2.10
|
|
|
52 - GROOVED NAIL 2x4 DIN 1476-ST
BSD-2917724032.A36
2917724032
|
-
|
|
|
|
54 - MANUFACTURER'S NAMEPLATE
BSD-2601007003.A16
2601007003
|
-
|
|
|
|
55 - ON-OFF SWITCH
BSD-2607200049.A9
2607200049
|
-
|
|
|
|
56 - CONNECTING CABLE
BSD-2604411505.A80
2604411505
|
-
|
|
|
|
57 - CABLE
BSD-2604411530.A45
2604411530
|
-
|
|
|
|
57 - SUPPRESSOR BOX
BSD-2604465026.A14
2604465026
|
-
|
|
|
|
58 - CABLE
BSD-2604411523.A3
2604411523
|
-
|
|
|
|
58 - SUPPRESSOR BOX
BSD-2604465027.A51
2604465027
|
-
|
|
|
|
64 - SPRING RETAINING RING
BSD-2600119000.A30
2600119000
|
£1.75
|
£2.10
|
|
|
653 - KEY CHUCK dia1-10 MM. 3/8
BSD-1608571020.A186
1608571020
|
-
|
|
|
|
654 - CHUCK WRENCH SG2
BSD-2607950007.A1416
2607950007
|
£6.52
|
£7.83
|
|
|
836 - CARBON-BRUSH SET
BSD-2604320902.A213
2604320902
|
-
|
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A681
160111A3H3
|
£2.61
|
£3.13
|
|
